ADB9ZWFS1575GMDSS SSB

SSB RADIOTELEPHONE FS-1575 FS-2575 FS-5075 OPERATOR'S MANUAL www.furuno.com MODEL The paper used in this manual is elemental chlorine free. ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN Telephone :+81-(0)798-65-2111 Fax :+81-(0)798-65-4200 A:JUL2011 . Printed in Japan All rights reserved. Z4:NOV.30, 2011 Pub. No.OME-56770-Z4 (YOTA)FS-2575/5075/1575 i IMPORTANT NOTICES General • This manual has been authored with simplified grammar, to meet the needs of international us- ers. • The operator of this equipment must read and follow the descriptions in this manual. Wrong op- eration or maintenance can cancel the warranty or cause injury. • Do not copy any part of this manual without written permission from FURUNO. • If this manual is lost or worn, contact your dealer about replacement. • The contents of this manual and equipment specifications can change without notice. • The example screens (or illustrations) shown in this manual can be different from the screens you see on your display. The screens you see depend on your system configuration and equip- ment settings. • Save this manual for future reference. • Any modification of the equipment (including software) by persons not authorized by FURUNO will cancel the warranty. • All brand and product names are trademarks, registered trademarks or service marks of their respective holders. How to discard this product Discard this product according to local regulations for the disposal of industrial waste. For disposal in the USA, see the homepage of the Electronics Industries Alliance (http://www.eiae.org/) for the correct method of disposal. How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery, see the chapter on Maintenance. Follow the instructions below if a battery is used. Tape the + and - terminals of battery before disposal to prevent fire, heat generation caused by short circuit. In the European Union The crossed-out trash can symbol indicates that all types of batteries must not be discarded in standard trash, or at a trash site. Take the used batteries to a battery collection site according to your national legislation and the Batteries Directive 2006/66/EU. In the USA The Mobius loop symbol (three chasing arrows) indicates that Ni-Cd and lead-acid rechargeable batteries must be recycled. Take the used batteries to a battery collection site according to local laws. In the other countries There are no international standards for the battery recycle symbol. The number of symbols can increase when the other countries make their own recycle symbols in the future. Cd Ni-CdPb ii SAFETY INSTRUCTIONS Indicates a condition that can cause death or serious injury if not avoided. Indicates a condition that can cause minor or moderate injury if not avoided. Indicates a condition that will result in death or serious injury if not avoided. The user and installer must read the appropriate safety instructions before attempting to install or operate the equipment. DANGER WARNING CAUTION Warning, CautionProhibitive ActionMandatory Action DANGER WARNING WARNING Never touch the SSB antenna, antenna coupler or lead-in insulator when the SSB radiotelephone is transmitting. High voltage which will cause death or serious injury is present at the locations shown in the illustration below when the SSB radiotelephone is transmitting. Antenna Coupler Antenna Wire (High Voltage) Indoor Antenna Wire Lead-in Insulator (High Voltage) Do not open the equipment. Only qualified personnel should work inside the equipment. Immediately turn off the power at the switchboard if water leaks into the equipment or something is dropped into the equipment. Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service. Do not disassemble or modify the equipment. Fire, electrical shock or serious injury can result. Immediately turn off the power at the switchboard if the equipment is emitting smoke or fire. Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service. Do not place liquid-filled containers on the top of the equipment. Fire or electrical shock can result if a liquid spills into the equipment. Do not operate the equipment with wet hands. Electrical shock can result. Turn off the power immediately if you feel the equipment is behaving abnormally. Turn off the power at the switchboard if the equipment becomes abnormally warm or is emitting odd noises. Contact a FURUNO dealer or agent for advice. Make sure no rain or water splash leaks into the equipment. Fire or electrical shock can result if water leaks in the equipment. Use the proper fuse. Use of the wrong fuse can cause fire or electrical shock. SAFETY INSTRUCTIONS iii The TFT LCD is constructed using the latest LCD techniques, and displays 99.99% of its pixels. The remaining 0.01% of the pixels may drop out or blink, however this is not an indication of malfunction. About the TFT LCD Warning labels are attached to the equipment. Do not remove any label. If a label is missing or damaged, contact a FURUNO agent or dealer about replacement. Name: Warning Label 1 Type: 86-003-1011-3 Code No.: 100-236-233-10 WARNING CAUTION Do not operate the [DISTRESS] key except in case of a life-endangering situation on your vessel. Operating the [DISTRESS] key transmits the distress alert. Accidental transmission may prevent search and rescue operations for actual emergency. If the distress alert is accidentally transmitted, contact the nearest station to cancel the alert. If the distress alert is accidentally transmitted, contact the nearest coast station and inform them of the accidental transmission, providing the following data: a) Ship's name b) Ship's call sign and DSC number c) Position at time of transmission d) Time of transmission WARNING LABELS Do not apply strong pressure to the LCD, which is made of glass. Injury can result if the LCD breaks. Nam…

Text truncated - open the document above for the full version.

4. DSC DISTRESS OPERATIONS 4-9 • Relay the distress alert in the following cases: • You have not received a distress acknowledge call from a coast station within five minutes after receiving a distress call. • You have not received a distress relay from other ship. • You cannot receive distress communications from other ship over radiotele- phone. • The ship relaying the distress alert should establish communications with the sta- tion controlling the distress as directed and render such assistance as required and appropriate. • If it is clear the ship or persons in distress are not near your ship and/or other ves- sels are better placed to assist, superfluous communications which could interfere with search and rescue activities should be avoided. Details should be recorded in the log. • When the received distress frequency is different from the current communication frequency, do the following: 1. Rotate the ENTER knob to select [CHANGE] then push the knob. 2. Rotate the ENTER knob to select the frequency same as the received distress one then push the knob. Action for ship receiving distress alert on HF band No Ye s Ye s Ye s No No DSC distress alert received. Press the CANCEL key to silence alarm. Listen to associated RTF* or NBDP channel(s) for 5 minutes. Is the alert acknowledged or relayed by CS and/ or RCC? HF DSC, RTF AND NBDP CHANNELS (kHz) * = Radiotelephone DSCRTF*NBDP 4207.5 6312.0 8414.5 12577.0 16804.5 4125 6215 8291 12290 16420 4177.5 6268 8376.5 12520 16695 Is distress communication in progress on associated RTF* channels? Transmit distress relay on HF to CS and inform RCC. Is your ship able to assist? Contact RCC via most efficient medium to offer assistance. CS = Coast Station RCC = Rescue Coordination Center Enter details in log. 4. DSC DISTRESS OPERATIONS 4-10 Send the distress relay to coast station (on HF band) When you receive a distress alert from a ship in distress, the audio alarm sounds and the LED flashes in red. The icon for DISTRESS receiving () appears in the tab area and the pop-up message appears on the screen. 1. Press the CANCEL key to silence the audio alarm and stop the flashing of the LED. 2. Rotate the ENTER knob to select [RELAY] in the user options area then push the knob. If three minutes have not passed after receiving the distress alert from the ship in distress, the following message appears on the screen. If you are sure to acknowl- edge the distress call, rotate the ENTER knob to select [Yes] then push the knob to erase the pop-up message and show the above screen. 3. With [RELAY INDIVIDUAL] selected, push the ENTER knob. 4. With [TO] selected, push the ENTER knob. 5. Rotate the ENTER knob to select [DIRECT INPUT] or [ADDRESS BOOK DATA] then push the knob. [ADDRESS BOOK DATA]: Select a MMSI from the [ADDRESS BOOK] (see section 6.15) then push the ENTER knob. [DIRECT INPUT]: Enter the MMSI of the coast station, where to send the distress relay, with the numeric keys then push the ENTER knob. 6. With [DSC FREQ] selected, push the ENTER knob. 7. Rotate the ENTER knob to select a frequency then push the knob. You should first select [8414.5 kHz]. 8. With [GO TO CALL] selected, push the ENTER knob. The screen changes to the one for transmitting. After transmitting, the WAIT FOR ACK screen appears. 4. DSC DISTRESS OPERATIONS 4-11 When you receive the distress relay individual acknowledgement from the coast sta- tion, the audio alarm sounds and a pop-up message appears. Press the CANCEL key to silence the alarm and erase the pop-up message. Communicate with the coast sta- tion by telephone, over the frequency specified. If you do not receive the distress ac- knowledgement from a coast station, select [RELAY] then push the ENTER knob to transmit the distress relay again, over a different frequency. 4.3How to Send Distress Relay on Behalf of a Ship in Distress 4.3.1How to send distress relay to coast station You can send the distress relay to a coast station on behalf of a ship in distress in the following cases: • You are near the ship in distress and the ship in distress cannot transmit the distress alert. • When the master or person responsible for your ship considers that further assis- tance is necessary. Note: Do not use the DISTRESS key to relay distress. 1. Press the DISTRESS MSG key and the OTHER DSC MSG key simultaneously to open the composing screen for the distress relay individual. 2. With [TO] selected, push the ENTER knob. 3. Rotate the ENTER knob to select [DIRECT INPUT] or [ADDRESS BOOK DATA] then push the knob. [ADDRESS BOOK DATA]: Select a MMSI from the [ADDRESS BOOK] (see section 6.15) then push the ENTER knob. [DIRECT INPUT]: Enter the MMSI of the coast station, where to send the distress relay, with the numeric keys then push the ENTER knob. 4. With [DISTRESS ID] selected, push the ENTER knob. 5. Rotate the ENTER knob to select [DIRECT INPUT] or [NO INFO] then push the knob. For [DIRECT INPUT], go to step 6. For [NO INFO], go to step 7. 6. Enter the ID (MMSI) of the ship in distress with the numeric keys then push the ENTER knob. 7. With [NATURE] selected, push the ENTER knob. 4. DSC DISTRESS OPERATIONS 4-12 8. Rotate the ENTER knob to select nature of distress then push the knob. 9. With [LAT] and [LON/UTC] selected, push the ENTER knob. 10. Rotate the ENTER knob to select [GNSS], [MANUAL] or [NO INFO] then push the knob. For [MANUAL], go to step 11. For others, go to step 12. 11. Use the numeric keys to enter latitude and longitude of the ship in distress. (If nec- essary, switch coordinates: 1 key to switch to North (East for longitude); 2 key to switch to South (West for longitude).) Push the ENTER knob. Also, enter the UTC time then push the ENTER knob. 12. With [COMM] selected, push the ENTER knob. 13. Rotate the ENTER knob to select [TELEPHONE] or [NBDP-FEC] then push the knob. 14. With [DSC FREQ] selected, push the ENTER knob. 15. Rotate the ENTER knob to select the frequency then push the knob. 16. With [GO TO CALL] se…

Text truncated - open the document above for the full version.

6. MENU OPERATION 6-12 1) Rotate the ENTER knob to select [+0.00 kHz] then push the knob. 2) Rotate the ENTER knob to adjust the receiving frequency (setting value: -0.20 to +0.20). 6.13External Alarm Setting The [EXTERNAL ALARM] menu enables/disables output of the contact signal for ur- gency, safety and routine frequencies to an external alarm system. 1. Rotate the ENTER knob to select [SYSTEM] on the [MENU] screen then push the knob. 2. Rotate the ENTER knob to select [EXTERNAL ALARM] then push the knob. 3. Rotate the ENTER knob to select [URGENCY], [SAFETY] or [ROUTINE], then push the knob. 4. Rotate the ENTER knob to select [ON] or [OFF] then push the knob. 6.14NETWORK Setting View your network settings on the [NETWORK SETTING (VIEW)] screen. 1. Rotate the ENTER knob to select [SYSTEM] on the [MENU] screen then push the knob. 2. Rotate the ENTER knob to select [NETWORK] then push the knob. 6. MENU OPERATION 6-13 6.15Address Book You can register a maximum of 50 MMSI or the address name (max. 20 letters) in the memory. 6.15.1List for address data 1. Rotate the ENTER knob to select [DSC] on the [MENU] screen then push the knob. 2. Rotate the ENTER knob to select [ADDRESSBOOK] then push the knob. 6.15.2How to register addresses 1. Open the [ADDRESS BOOK] screen. 2. Press the 5 key to open the [ADDRESS DATA ENTRY] screen. Key/knobFunction ENTER• Move the cursor by rotating the ENTER knob. • Open the [ADDRESS DATA EDIT] screen by pushing the ENTER knob (see paragraph 6.15.3).. CANCELReturn to the [MENU] screen. 1Go to the previous page. 3Go to the next page. 4Delete address (see paragraph 6.15.4). 5Open the [ADDRESS DATA ENTRY] screen (see paragraph 6.15.2). 6Switch the address type. Each press changes the type continuously (SHIP → COAST → GROUP → SHIP → ...). When 50 addresses are registered, this is not available. 6. MENU OPERATION 6-14 3. With [NAME] selected, push the ENTER knob. 4. Enter the address name (max. 20 letters) with the numeric keys then push the EN- TER knob. 5. With [MMSI] selected, push the ENTER knob. 6. Enter the MMSI with the numeric keys then push the ENTER knob. 7. With [REGISTER] selected, push the ENTER knob. 6.15.3How to edit addresses 1. Open the [ADDRESS BOOK] screen. 2. Rotate the ENTER knob to select the address to edit then push the knob. 3. Rotate the ENTER knob to select [NAME] or [MMSI] as appropriate then push the knob. 4. Enter the address name or MMSI with the numeric keys then push the ENTER knob. 5. Rotate the ENTER knob to select [REGISTER] then push the knob. Note: If the MMSI is already registered to another address, the error alarm sounds and a warning pop-up message appears when selecting [REGISTER]. 6. Rotate the ENTER knob to select [Yes] then push the knob. Push the ENTER knob. LIST : 24: 20 : 6 MMSI number overlaps. : Close window 6. MENU OPERATION 6-15 6.15.4How to delete addresses Open the [ADDRESS BOOK] screen then follow the applicable procedure below. Individual address 1. Rotate the ENTER knob to select the address to delete then press the 4 key. 2. With [DELETE SELECTION] selected, push the ENTER knob. 3. Rotate the ENTER knob to select [Yes] then push the knob. Address by type 1. Press the 6 key several times to select desired type. 2. Press the 4 key. 3. Rotate the ENTER knob to select [DELETE LIST] then push the knob. 4. Rotate the ENTER knob to select [Yes] then push the knob. All addresses 1. Press the 4 key. 2. Rotate the ENTER knob to select [DELETE ALL LISTS] then push the knob. 3. Rotate the ENTER knob to select [Yes] then push the knob. 6.15.5How to create a DSC message with registered address 1. Open the [ADDRESS BOOK] screen. 2. Rotate the ENTER knob to select the address to use. 3. Press the OTHER DSC MSG key to open the [COMPOSE MESSAGE] screen. Press the OTHER DSC MSG key. N06 HNKYU LIST : 24: 20 : 6 6. MENU OPERATION 6-16 6.16TX Message Preparation For the individual, PSTN, group and test messages, you can create messages and store them in the memory for future use. You can edit, send or delete these messages. A maximum of 100 messages can be stored into the memory. 6.16.1List for message files 1. Rotate the ENTER knob to select [DSC] on the [MENU] screen then push the knob. 2. Rotate the ENTER knob to select [MSG FILE] then push the knob. Detailed information screen for message files Rotate the ENTER knob to se- lect the message file desired on the [MESSAGE FILE] list then push the knob. The de- tailed information screen for the selected message file ap- pears as shown right. Several functions can be done from this screen. • 1 key: Go to the detailed in- formation screen for the previous message file. Key/knobFunction ENTER• Move the cursor by rotating the ENTER knob. • Open the detailed information screen for the selected message file by pushing the ENTER knob (see the following "Detailed information screen for message files"). CANCELReturn to the [MENU] screen. 1Go to the previous page. 3Go to the next page. 4Delete messages (see paragraph 6.16.8). 5Open the [MESSAGE FILE ENTRY] screen. 6Switch the message type. Each press changes the type continuously (INDIVIDUAL → GROUP → PSTN → TEST → INDIVIDUAL → ...). When 100 messages are registered, this is not available. 10 70 29 6. MENU OPERATION 6-17 • 3 key: Go to the detailed information screen for the next message file. • 4 key: Delete the selected message file. The following message appears on the screen. Rotate the ENTER knob to select [Yes] then push the knob. 6.16.2Individual calls 1. Open the [MESSAGE FILE] list. 2. Press the 5 key to open the [MESSAGE FILE ENTRY] screen. 3. With [MSG TYPE] selected, push the ENTER knob. 4. Rotate the ENTER knob to select [INDIVIDUAL MSG] then push the knob. 5. With [TO] selected, push the ENTER knob. 6. Rotate the ENTER knob to select [DIRECT INPUT] or [ADDRESS BOOK DATA] then push the knob. [ADDRESS BOOK DATA]: Select a MMSI from the [ADDRESS BOOK] (see section 6.15) then push the ENTER knob. [DIRECT INPUT]: Enter the MMSI of c…

Text truncated - open the document above for the full version.

10. NBDP TRANSMISSION, RECEPTION 10-2 For IB-585: • To enter the frequency, press the 9 key to select [Set Frequency]. Go to step 3. • To enter the ITU or user channel, press the 0 key to select [Set Channel]. Go to step 4. 3. Input a pair of TX and RX frequencies. Go to step 5. 4. Input the user channel. To select the user channel from the list, press the → key to display [User Channel List]. Press the ↑ or ↓ key to select the desired user channel. 5. Press the Enter key. Note: You can not set frequency or user channel in the following cases; • When opening the menu from the control panel (FS-2575C). • When communicating by radiotelephone. • When the DSC scan screen is displayed. • When sending DSC calls. 6. Press the function key F3 then the 8 key to select [Manual Calling]. 7. Press the ← or → key to select a communication mode. 8. Press the ↓ key then input party's ID number. 9. Press the Enter key to connect the communication line. "Channel Busy Check" appears. If the line is free, "Connect", "Send" and "Lock" appear in highlight as be- low.                                 ! "#  $% ! &  !  #'(   #)*+  ,-$%(   $%  &  !.&/() , + 0 (#1 2.  3 4#5  &  46  27 , 8  ,/$. /0,0, , 16! 10. NBDP TRANSMISSION, RECEPTION 10-3 For the ARQ mode, go to step 10. For the FEC mode, type your message then go to step 13. 10. Press the function key F7. The party's answerback code appears on the screen. Note: Step 10 and 11 are needed for ship-to-ship calling only. 11. Press the function key F8. Your ship's answerback code is sent to the party. 12. Press the Enter key and type your message. 13. If you want to receive other party's response, press the function key F9. 14. Press the function key F10 to disconnect the line. 10.2ARQ Mode Operation In ARQ operation, one station (information sending station) sends data to another block by block, then listens for the acknowledge signal between blocks from the infor- mation receiving station which requests either the next block or retransmission of the last block if there is an error. The request can be repeated up to 32 times until the com- plete block is received free of error. How to establish connection 1. Press the function key F3 to open the [Operate] menu. 2. Press the 1 key to select [Call Station]. 3. Select a station. (Station must be registered for use in the ARQ mode). 4. Press the Enter key. The message "Calling Station" appears. If the message shown below appears, check both the power of the radiotelephone and the con- nections between the radiotelephone and the NBDP terminal unit. Message: "Station calling suspended. Check interconnections between the termi- nal and main units. Press any key to escape." When an acknowledge signal is detected, "Connect" appears in reverse video on the [Comm Status] line. Note: If the signal conditions are poor, connection can take a while. If the line could not be connected in one minute, the calling stops. The message "Station calling suspended" appears. Try step 3 again, one minute later. Should the signal conditions worsen during message transmission, "Error" appears in reverse video on the [Comm Status] line and the line is disconnected. 5. Transmit message by one of the following methods:          !"  #$%&'' ($%&'')*"   + ,-.     Connect Send Lock   )  +  / 0  1''2" ,!-    ' ,!-    '" 1',3'13 1%1'4'  00     5  ,67 ,6$ ,613 ,6 !        ,67 8 +  7%$#  +  ,!-   90  :0  90  90 1 0 3+ 4  7. + ; %   $   #.! ! (< 1'6) 10. NBDP TRANSMISSION, RECEPTION 10-4 How to send a file stored on a floppy disk or an SD card 1. Press the function key F7 to request the answerback code of the other station. Verify that the code from the station called is correct. 2. Press the function key F8 to transmit your own identity (answerback code). 3. Press the function key F3 then the 3 key to open the [Send File] window. 4. Press the ↑ or ↓ key to select the file to send and press the Enter key. 5. Press the Enter key again. Sending volume (percentage of message transmitted, counts upward as the mes- sage is being transmitted), ARQ error count and ARQ transmission time appear on the screen. "Lock" appears in reverse video when the mark and space signals in the received signal are normal. [ARQ Error] shows the number of errors found during transmission. [ARQ Time] is the time in seconds the communication con- nected. 6. After the message is transmitted, press the function key F10 to disconnect the line. How to type a message from the keyboard 1. After exchanging answerback code by the function keys F7 and F8, type your message directly from the keyboard. 2. To change the direction of traffic, press the function key F9, or + and ? in order. The other station becomes the information sending station, your station becomes the information receiving station. Receive a message from the sending station. 3. After you have completed communications, press the function key F7 to request the answerback code of the other station. 4. Press the function key F8 to transmit your own answerback code. 5. Press the function key F10 to disconnect the line. Note: When you are requested to change the direction of traffic while transmitting a message, or communication is interrupted because of an error, some of the final char- acters on the screen may not …

Text truncated - open the document above for the full version.

Federal Communications Commission Office of Engineering and Technology 445 12th Street, SW Washington, DC 20554 To whom it may concern, We hereby respectfully request that under the provision of FCC rules section0.457(d) and0.459, the following documents submitted in support of this application for ADB9ZWFS1575 certification be provided with confidential status. Schematics Parts list/Tune up info Operational description These documents contain trade secrets that are treated as confidential by us. Substantial competitive harm to our company business could result should they be made available to the public. Best regards , Shane Ryan Type Acceptance Commercial Service FURUNO USA Inc. (360) 834-9300 X5060 (360) 834- 833 -5195 [email protected]

Federal Communications Commission Office of Engineering and Technology 445 12th Street, SW Washington, DC 20554 To whom it may concern, We hereby respectfully request that under the provision of FCC rules section0.457(d) and0.459, the following documents submitted in support of this application for ADB9ZWFS1575 certification be provided with confidential status. Schematics Parts list/Tune up info Operational description These documents contain trade secrets that are treated as confidential by us. Substantial competitive harm to our company business could result should they be made available to the public. Best regards , Shane Ryan Type Acceptance Commercial Service FURUNO USA Inc. (360) 834-9300 X5060 (360) 834- 833 -5195 [email protected]

 Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 February 2012 (2) - Page 1 of 5 - 2 Photographs of Antenna Coupler AT-1575AES for Furuno SSB Radiotelephone FS-1575 2.1 Outside View 2.1.1 Outside Front View (showing ID (Name Plate) and Warning Labels)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 February 2012 (2) - Page 2 of 5 - 2.1.2 Outside Bottom View 2.1.3 ID Label (Name Plate)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 February 2012 (2) - Page 3 of 5 - 2.2 Inside View (with Front cover removed, showing COUP Board 05P0883)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 February 2012 (2) - Page 4 of 5 - 2.3 PCB 2.3.1 COUP Board 05P0883 Front side  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 February 2012 (2) - Page 5 of 5 - 2.3.2 COUP Board 05P0883 Rear side

 Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 Februay 2012 (3) - Page 1 of 5 - 3 Photographs of Antenna Coupler AT-1575SUS for Furuno SSB Radiotelephone FS-1575 3.1 Outside View 3.1.1 Outside Front View (showing ID (Name Plate) and Warning Labels)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 Februay 2012 (3) - Page 2 of 5 - 3.1.2 Outside Bottom View 3.1.3 ID Label (Name Plate)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 Februay 2012 (3) - Page 3 of 5 - 3.2 Inside View (with Front cover removed, showing COUP Board 05P0883)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 Februay 2012 (3) - Page 4 of 5 - 3.3 PCB 3.3.1 COUP Board 05P0883 Front side  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue: 29 Februay 2012 (3) - Page 5 of 5 - 3.3.2 COUP Board 05P0883 Rear side

 Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 1 of 5 - 5 Photographs of Keyboard of Terminal Unit IB-585 for Furuno SSB Radiotelephone FS-1575 5.1 Outside View 5.1.1 Outside Top View  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 2 of 5 - 5.1.2 Outside Bottom View (showing ID Label (Name Plate))  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 3 of 5 - 5.1.3 ID Label (Name Plate)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 4 of 5 - 5.2 Inside View 5.2.1 Inside View (with Top Cover opened)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 5 of 5 - 5.2.2 Inside View (showing Printed circuit sheet)

 Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 1 of 16 - 4 Photographs of Terminal Unit IB-585 for Furuno SSB Radiotelephone FS-1575 4.1 Outside View 4.1.1 Front View  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 2 of 16 - 4.1.2 Rear View (showing Name Plate (ID Label))  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 3 of 16 - 4.1.3 ID Label (Name Plate)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 4 of 16 - 4.2 Inside View 4.2.1 Inside View (with Rear cover removed, showing TERMCPU 16P0283, SD-USB 16P0289, TERMPWR 16P0287, and PWR-C 16P0214 Boards) TERMCPU Board SD-USB Board TERMPWR Board PWR-C Board  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 5 of 16 - 4.2.2 Inside View  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 6 of 16 - 4.2.3 Inside View (with PCBs removed)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 7 of 16 - 4.2.4 Inside View (showing Back of chassis plate, and LCD module)  Furuno Labotech International Co., Ltd. Document number: FLI 01-12-008 Date of issue:29 February 2012 (4) - Page 8 of 16 - 4.2.5 Inside View (showing Back of Front Panel, and SW Board 16P0212)…
