ADB9ZWRTR081AMarine Radar

MARINE RADAR/ARPA FAR-28x7 Series FAR-21x7(-BB) Series OPERATOR'S MANUAL www.furuno.co.jp MODEL Complies with IMO MSC.192(79) i IMPORTANT NOTICES General • The operator of this equipment must read and follow the descriptions in this manual. Wrong operation or maintenance can cancel the warranty or cause injury. • Do not copy any part of this manual without written permission from FURUNO. • If this manual is lost or worn, contact your dealer about replacement. • The contents of this manual and equipment specifications can change without notice. • The example screens (or illustrations) shown in this manual can be different from the screens you see on your display. The screens you see depend on your system configuration and equipment settings. • Save this manual for future reference. • Any modification of the equipment (including software) by persons not authorized by FURUNO will cancel the warranty. • All brand and product names are trademarks, registered trademarks or service marks of their respective holders. How to discard this product Discard this product according to local regulations for the disposal of industrial waste. For disposal in the USA, see the homepage of the Electronics Industries Alliance (http://www.eiae.org/) for the correct method of disposal. How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery, see the chapter on Maintenance. Follow the instructions below if a battery is used. Tape the + and - terminals of battery before disposal to prevent fire, heat generation caused by short circuit. In the European Union The crossed-out trash can symbol indicates that all types of batteries must not be discarded in standard trash, or at a trash site. Take the used batteries to a battery collection site according to your national legislation and the Batteries Directive 2006/66/EU. In the USA The Mobius loop symbol (three chasing arrows) indicates that Ni-Cd and lead-acid rechargeable batteries must be recycled. Take the used batteries to a battery collection site according to local laws. In the other countries There are no international standards for the battery recycle symbol. The number of symbols can increase when the other countries make their own recycling symbols in the future. Cd Ni-CdPb SAFETY INSTRUCTIONS ii Mandatory Action Prohibitive Action WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation which, if not avoided, can result in minor or moderate injury. Warning, Caution SAFETY INSTRUCTIONS The operator and installer must read the applicable safety instructions before attempting to install or operate the equipment. WARNING Radio Frequency Radiation Hazard The radar antenna emits electromagnetic radio frequency (RF) energy which can be harmful, particularly to your eyes. Never look directly into the antenna aperture from a close distance while the radar ius in operation or eexpose yourself to the transmitting antenna at a close distance. Distances at which RF radiation level of 100, 50 and 10 W/m are given in the table below. Note: If the antenna unit is installed at a close distance in front of the wheel house, your administration may require halt of transmission within a certain sector of antenna revolution. This is possible. Ask your FURUNO representive or dealer to provide this feature. 2 DANGER Indicates a potentially hazardous situation which, if not avoided, will result in death or se rious injury. *1 XN12AF: 120cm, XN20AF: 198cm, XN24AF: 243cm, SN30AF: 309cm, SN36AF: 377cm 100W/m 2 Radar model FAR-2127/2827 FAR-2117/2817 XN12AF XN20AF XN24AF XN12AF XN20AF XN24AF SN30AF 0.3m 0.1m 0.1m 0.9m 0.5m 0.2m FAR-2137S/2837S XN20AF FAR-2837SW FAR-2827W Transceiver Magnetron RTR-079A MG5436 RTR-078A RTR-080 RTR-081A RTR-082 MAF-1565N MG5223F MG5436 MG5223F SN36AF Antenna *1 0.1m 0.4m 10W/m 2 3.7m 2.2m 1.5m 9.0m 4.6m 3.3m 2.4m 5.6m 1.9m 50W/m 2 1.2m 0.7m 0.4m 2.6m 1.7m 1.0m 1.0m 0.2m SN36AF 0.1m 2.0m 0.7m XN24AF0.2m3.4m 0.5m - SAFETY INSTRUCTIONS iii WARNING ELECTRICAL SHOCK HAZARD Do not open the equipment. Only qualified personnel should work inside the equipment. Turn off the radar power switch before servicing the antenna unit. Post a warn- ing sign near the switch indicating it should not be turned on while the antenna unit is being serviced. Prevent the potential risk of being struck by the rotating antenna and exposure to RF radiation hazard. Wear a safety belt and hard hat when working on the antenna unit. Serious injury or death can result if someone falls from the radar antenna mast. Do not disassemble or modify the equipment. Fire, electrical shock or serious injury can result. Immediately turn off the power at the ship's mains switchboard if water leaks into the equipment or the equip- ment is emitting smoke or fire. Continued use can cause fatal damage to the equipment. WARNING Use the proper fuse. Use of a wrong fuse can result in damage to the equipment or cause fire. Keep heater away from equipment. Heat can alter equipment shape and melt the power cord, which can cause fire or electrical shock. Do not place liquid-filled containers near the equipment. Fire or electrical shock can result if a liquid spills into the equipment. Do not operate the equipment with wet hands. Electrical shock can result. Before servicing the radar, turn off the appropriate external breaker. Power is not removed from the radar simply by turning off its power switch. SAFETY INSTRUCTIONS iv WARNING No one navigational aid should be relied upon for the safety of vessel and crew. The navigator has the responsibility to check all aids available to confirm position. Electronic aids are not a substitute for basic navigational principles and common sense. • This TT automatically tracks automatically or manually acquired radar targets and calculates their courses and speeds, indicating them by vectors. Since the data genera…

Text truncated - open the document above for the full version.

Federal Communications Commission Office of Engineering and Technology 445 12th Street, SW Washington, DC 20554 To whom it may concern, We hereby respectfully request that under the provision of KDB Publication 726920, the following documents submitted in support of this application for ADB9ZWRTR081A certification be provided with confidential status. Schematics Parts list/Tune up info Operational description These documents contain trade secrets that are treated as confidential by us. Substantial competitive harm to our company business could result should they be made available to the public. Best regards , Shane Ryan Type Acceptance Commercial Service FURUNO USA Inc. (360) 834-9300 X5060 (360) 834- 833 -5195 [email protected]

Furuno Labotech International Report no.: FLI 01-10-029 Date of issue: 22 September 2010 - Page 1 of 3 - Photographs of the Transceiver Unit RTR-081A for Furuno Radar FAR-2827W 1 External View 1.1 Front and Top View (Showing Name Plate and Warning Label on Top cover) Furuno Labotech International Report no.: FLI 01-10-029 Date of issue: 22 September 2010 - Page 2 of 3 - 1.2 Right side View Furuno Labotech International Report no.: FLI 01-10-029 Date of issue: 22 September 2010 - Page 3 of 3 - 1.3 Name Plate (ID Label)

 Furuno Labotech International Document number: FLI 01-10-056 Date of issue: 13 January 2011 Form: Q053/01 - Page 1 of 2 - Identification of Equipment for the Furuno Radar Transceiver RTR-081A (FCC Rule, 2.925) 1 ID Label The following nameplate is permanently fixed on the corresponding equipment unit. FCC ID: ADB9ZWRTR081A Material of Nameplate: Aluminum, 0.5 mm thick  Furuno Labotech International Document number: FLI 01-10-056 Date of issue: 13 January 2011 Form: Q053/01 - Page 2 of 2 - 2 ID Label Location ID Label is affixed on the Transceiver Unit.

Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 1 of 11 - Photographs of the Transceiver Unit RTR-081A for Furuno Radar FAR-2827W 1 Internal View 1.1 Top cover removed (showing TB Board 03P9349 (lower) and Transceiver module (upper)) Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 2 of 11 - 1.2 TB Board 03P9349 and Shield cover removed (Showing PWR Board 03P9348 on Transceiver Module) Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 3 of 11 - 1.3 Transceiver Module removed Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 4 of 11 - 1.4 Transceiver Module (Showing PWR Board 03P9348 (left) and RFC Board 03P9346 (right)) Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 5 of 11 - 1.5Transceiver Module (Right side, PWR Board removed) Circulator Limiter Filter Isolator Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 6 of 11 - 1.6 Transceiver Module (Front side) Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 7 of 11 - 1.7 Transceiver Module (Front cover opened, showing IF_AMP Board 03P9335) Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 8 of 11 - 1.8 Transceiver Module (IF_AMP Board 03P9335 removed, showing MIC RU-9601) Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 9 of 11 - 1.9 Transceiver Module (Bottom side) Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 10 of 11 - 1.10 Transceiver Module (Bottom cover opened, showing Pulse Transformer (lower left) and Magnetron (lower right)) MD Board Magnetron Pulse Transformer Furuno Labotech International Report no.: FLI 01-10-030 Date of issue: 22 September 2010 - Page 11 of 11 - 1.11 Transceiver Module (showing MD Board 03P9244)

This report shall not be reproduced except in full, without the written approval of Furuno Labotech International Co., Ltd. Test Report (FCC Rules 2.1046/2.1047/2.1049/2.1051/2.1053/2.1055/80.217) For Trade name: Furuno Model: Transceiver for Marine Radar Type: RTR-081A Report no.: FLI 12-10-082 Date of issue: 13 January 2011 Furuno Labotech International Co., Ltd. 9-52 Ashihara-cho, Nishinomiya City, Hyogo 662-8580, Japan Tel: +81-798-63-1094 Fax: +81-798-63-1098 Furuno Labotech International Report no.: FLI 12-10-082 Form: FQ053/05 - Page 2 of 40 - Report Summary FLI project number: FLI 04-10-0351 Test report number of initial issue: FLI 12-10-082 Date of initial issue 13 January 2011 Test report number of revised/replaced issue: --- Date of revised/replaced issue --- Test report revision/ replacement history: Test report no. Rev. no.Date PageItem Description of change/reason --- --- --- --- --- --- Test standard(s)/ Test specifications: FCC 47 CFR, Sections: 2.1046 - RF Power Output, 2.1047 - Modulation Characteristics, 2.1049 - Occupied Bandwidth, 2.1051 - Spurious Emissions at Antenna Terminal, 2.1055 - Frequency Stability, 2.1053 - Field Strength of Spurious Radiation, 80.217 - Suppression of Interference Aboard Ships. (Date of issue: 1 October 2008) Customer: Furuno Electric Co., Ltd. 9-52 Ashihara-Cho, Nishinomiya-City, 662-8580 Japan Manufacturer: Furuno Electric Co., Ltd. 9-52 Ashihara-Cho, Nishinomiya-City, 662-8580 Japan Trade name: FURUNO Model: Transceiver for Marine Radar Type: RTR-081A Product function and intended use: For Marine Safety navigation Number of samples tested: One Serial number: R147-0340 Power rating: 100 - 115/ 200 - 230 VAC, 50/60 Hz, 3.2/1.6A (for Processer Unit RPU-013) (The EUT was powered through the Processor unit, not directly from AC mains. Product status: Pre-production model Modifications made to samples during testing: None. Date of receipt of samples: 5 July 2010 Test period: 5 July 2010 to 6 December 2010 Place of test: Furuno Labotech International Co., Ltd. - Nishinomiya Lab. 9-52 Ashihara-Cho, Nishinomiya City, Hyogo Prefecture, 662-8580 Japan - Nishinomiya-Hama Lab. 2-20 Nishinomiya-Hama, Nishinomiya City, Hyogo Prefecture, 662-0934 Japan Anechoic Chamber used for the test has been registered by FCC. (File number: 90607) Test results/ Compliance: Passed. The test results of this report relate only to the samples tested. Tested by: Katsumi Imamura Written by: Akiko Inoue Verified by: Yoshihiro Ishii Approved by: Date: 13 January 2011 Name: Yoshihiro Ishii Title: Manager, Technical Section, Furuno Labotech International Co., Ltd. Signature: Furuno Labotech International Report no.: FLI 12-10-082 Form: FQ053/05 - Page 3 of 40 - Testing Laboratory Status Furuno Labotech International Co., Ltd. (hereafter called FLI) has been holding the following status after having been assessed according to the provisions of ISO/IEC 17025 and/or the relevant rules: (1) Telefication Listed Testing Laboratory: - listed by Telefication B. V., Edisonstraat 12a, 6902 PK Zevenaar, The Netherlands - Laboratory assignment number: L116 - Date of initial certification: 26 July 1999 (*) - for testing the following product categories/ test standards: - EN 60945, Maritime navigation and radiocommunication equipment and systems - General requirements. - IEC 61162-1/-2, Maritime navigation and radiocommunication equipment and systems - Digital interfaces - Part 1: Single talker and multiple listeners / Part 2: Single talker and multiple listeners, high speed transmission. (2) BSH Recognized Testing Laboratory: - recognized by Bundesamt für Seeschifffahrt und Hydrographie, Bernhad-Nocht-Str. 78, 20359 Hamburg, Federal Republic of Germany - Recognition certificate number: BSH4613/06201/0835/08 - Date of initial certification: 4 April 2003 (*) - for testing in the fields of: “Marine navigational and radiocommunication equipment and systems” - EMC and environmental tests according to: IEC 60945: 2002, DIN EN 60945: 2003 - Radar - Shipborne navigational displays IEC 60936-1: 1999, DIN EN 60936-1: 2000 IEC 62288: 2008 IEC 60936-2: 1998, DIN EN 60936-2: 1999 (3) TÜV Appointed EMC Test Laboratory: - appointed by TÜV Rheinland Japan Ltd., 19-5 Shin Yokohama 3-chome, Kohoku-ku, Yokohama 222-0033 Japan - Laboratory assignment number: UA 50046428 - Date of initial certification: 21 December 1998 (*) - for carrying out the tests of: - EN 55022, CISPR 22, EN 61000-3-2/-3, EN/IEC 61000-4-2/-3/-4/-5/-6/-8/-11, EN/IEC 61000-6-1/-2, EN/IEC 61000-6-3/-4, EN/IEC 60945, EN/IEC 61326-1, EN/IEC 61326-2-6, EN/IEC 60601-1-2, JIS T 0601-1-2, JIS C 1806-1, EN 55011, CISPR 11. (4) RMRS Recognized Testing Laboratory: - recognized by Russian Maritime Register of Shipping, 8, Dvortsovaya Nab., St. Petersburg, 191186 Russia - Laboratory recognition number : 09.00110.011 - Date of initial certification : 27 January 2009 (*) - for carrying out testing in the field of : 21001301 Elecrtrical measurements and tests, 21001302 EMC tests, 21001500 Mechanical measurements and tests, 21002000 Equipment protection degree tests, and 21002100 Climatic tests for Ship’s radio and navigational equipment and IEC 60945 : 2002 Note: (*) – The current certificates may be found in the FLI web site (http://www.furuno-labotech.co.jp). Furuno Labotech International Report no.: FLI 12-10-082 Form: FQ053/05 - Page 4 of 40 - TABLE OF CONTENTS Report Summary ............................................................................................................................. 2 Testing Laboratory Status ............................................................................................................. 3 1 Principal Information ................................................................................................................... 5 1.1 Equipment under test (EUT) ................................................................................................... 5 1.2 Observation and comments ..............…

Text truncated - open the document above for the full version.
