ADB9ZWRTR082MARINE RADAR

Furuno USA Inc
MARINE RADAR - FCC ID ADB9ZWRTR082 - Furuno USA Inc
Click to zoom

Application Details

Equipment Class
MRD - Marine Radar
Date of Grant
Jul 14, 2005
Application Purpose
Original Equipment
Date of Application
Apr 19, 2004
Equipment Note
MARINE RADAR
Frequency Range
2900.00000000 - 3100.00000000
Company
Furuno USA Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

MARINE RADAR/ARPA FAR-28x7 Series FAR-21x7(-BB) Series Your Local Agent/DealerYour Local Agent/Dealer 9-52 Ashihara-cho,9-52 Ashihara-cho, Nishinomiya, JapanNishinomiya, Japan Telephone :Telephone :0798-65-21110798-65-2111 faxfax0798-65-42000798-65-4200 :: FIRST EDITION :FIRST EDITION :JAN.JAN.20042004 Printed in JapanPrinted in Japan All rights reserved.All rights reserved. A2A2::JAN.JAN.22,200422,2004 PUB.No.PUB.No.OME-35190OME-35190 *00014745200**00014745200* *00014745200**00014745200* ((DAMIDAMI)) FAR-2107/2807 SER.FAR-2107/2807 SER. * 0 0 0 1 4 7 4 5 2 0 0 ** 0 0 0 1 4 7 4 5 2 0 0 * *OME35190A20**OME35190A20* *OME35190A20**OME35190A20* * O M E 3 5 1 9 0 A 2 0 ** O M E 3 5 1 9 0 A 2 0 * i SAFETY INSTRUCTIONS WARNINGWARNING Radio Frequency Radiation Hazard The radar antenna emits electromagnetic radio frequency (RF) energy which can be harmful, particularly to your eyes. Never look directly into the antenna aperture from a close distance while the radar is in operation or expose yourself to the transmitting antenna at a close distance. Distances at which RF radiation levels of 100 and 10 W/m 2 exist are given in the table below. Note: If the antenna unit is installed at a close distance in front of the wheel house, your administration may require halt of transmission within a certain sector of antenna revolution. This is possible. Ask your FURUNO representative or dealer to provide this feature. FAR-2827/2127RTR-079MG5436XN12AF0.80 m11.20 m FAR-2827/2127RTR-079MG5436XN20AF0.40 m8.60 m FAR-2827/2127RTR-079MG5436XN24AF0.20 m5.80 m FAR-2817/2117RTR-078MG4010 2 XN12AF0.30 m4.20 m FAR-2817/2117RTR-078 MG4010 2 XN20AF0.10 m3.00 m FAR-2817/2117RTR-078MG4010 2 XN24AF -- 2.40 m FAR-2137SRTR-080MG5223FSN30AF FAR-2137SRTR-080MG5223FSN36AF FAR-2827WRTR-081MG5436XN20AF FAR-2827WRTR-081MG5436XN24AF FAR-2837SRTR-080MG5223FSN30AF FAR-2837SRTR-080MG5223FSN36AF FAR-2837SWRTR-082MG5223FSN30AF FAR-2837SWRTR-082MG5223FSN36AF Distance to 100 W/m 2 point Distance to 10 W/m 2 point Model 3 TR unitMagnetronAntenna 1 1 XN12AF: 4 ftXN20AF: 6.5 ftXN24AF: 8 ft SN30AF: 10 ftSN36AF: 12 ft 2 Or MAF1425B 3 FAR-2117/2127/2137S available in blackbox configuration. SAFETY INSTRUCTIONS ii WARNING ELECTRICAL SHOCK HAZARD Do not open the equipment. Only qualified personnel should work inside the equipment. Turn off the radar power switch before servicing the antenna unit. Post a warn- ing sign near the switch indicating it should not be turned on while the antenna unit is being serviced. Prevent the potential risk of being struck by the rotating antenna and exposure to RF radiation hazard. Wear a safety belt and hard hat when working on the antenna unit. Serious injury or death can result if someone falls from the radar antenna mast. Do not disassemble or modify the equipment. Fire, electrical shock or serious injury can result. Immediately turn off the power at the ship's mains switchboard if water leaks into the equipment or the equip- ment is emitting smoke or fire. Continued use can cause fatal damage to the equipment. WARNING Use the proper fuse. Use of a wrong fuse can result in damage to the equipment or cause fire. Keep heater away from equipment. Heat can alter equipment shape and melt the power cord, which can cause fire or electrical shock. Do not place liquid-filled containers near the equipment. Fire or electrical shock can result if a liquid spills into the equipment. Do not operate the equipment with wet hands. Electrical shock can result. Before servicing the radar, turn off the appropriate external breaker. Power is not removed from the radar simply by turning off its power switch. SAFETY INSTRUCTIONS iii WARNINGWARNING No one navigational aid should be relied upon for the safety of vessel and crew. The navigator has the responsibility to check all aids available to confirm position. Electronic aids are not a substitute for basic navigational principles and common sense. • This ARPA automatically tracks automatically or manually acquired radar targets and calculates their courses and speeds, indicating them by vectors. Since the data generated by the auto plotter are based on what radar targets are selected, the radar must always be optimally tuned for use with the auto plotter, to ensure required targets will not be lost or unwanted targets such as sea returns and noise will not be acquired and tracked. • A target does not always mean a land- mass, reef, ships or other surface vessels but can imply returns from sea surface and clutter. As the level of clutter changes with environment, the operator should properly adjust the A/C SEA, A/C RAIN and GAIN controls to be sure target echoes are not eliminated from the radar screen. CAUTIONCAUTION The plotting accuracy and response of this ARPA meets IMO standards. Tracking accuracy is affected by the following: • Tracking accuracy is affected by course change. One to two minutes is required to restore vectors to full accuracy after an abrupt course change. (The actual amount depends on gyrocompass specifications.) • The amount of tracking delay is inversely proportional to the relative speed of the target. Delay is on the order of 15—30 seconds for high relative speed; 30—60 seconds for low relative speed. The data generated by ARPA, AIS and video plotter are intended for reference only. Refer to official nautical charts for detailed and up-to-date information. SAFETY INSTRUCTIONS i v WARNING To avoid electrical shock, do not remove cover. No user-serviceable parts inside. WARNING LABEL Warning labels are attached to the equipment. Do not remove any label. If a label is missing or damaged, contact a FURUNO agent or dealer about replacement. WARNING Radiation hazard. Only qualified personnel should work inside scanner. Confirm that TX has stopped before opening scanner. DISPLAY UNIT, PROCESSOR UNIT Name:Warning Label (1) Type:86-003-1011-0 Code No.: 100-236-230 ANTENNA UNIT Name:Radiation Warning Label Type:03-142-3201-0 Code No.: 100-266-890 v TABLE OF CONTENTS…

Text truncated - open the document above for the full version.

External Photos

Furuno Labotech International Report no.: FLI 12-04-028 - Page E.1 of 37- Attachment E Photographs of EUT FAR-2837SW 1 Transceiver unit RTR-082 1.1 Front View (Showing Name Plate and Warning Label on Top cover) Note: Photographs for the units Processor RPU-013 and Control RCU-014 have been already reported. (See Technical Information FLI 12-03-027 for the Radar FAR-2127 (Transceiver type: RTR-079)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.2 of 37- 1.2 Inside View (with Top cover removed, showing Magnetron (upper left), IF AMP Board (upper right, with shield-cover) and TB Board 03P9349 (center right)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.3 of 37- 1.3 Inside View (with IF Board and TB Board removed) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.4 of 37- 1.4 Inside View (with shield-cover and Magnetron removed, showing MD Board 03P9244 (center) PWR Board 03P9348 (lower left) and RFC Board 03P9346 (lower right)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.5 of 37- 1.5 MD Board 03P9244 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.6 of 37- 1.6 MD Board 03P9244 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.7 of 37- 1.7 TB Board 03P9349 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.8 of 37- 1.8 TB Board 03P9349 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.9 of 37- 1.9 IF AMP Board 03P9335 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.10 of 37- 1.10 IF AMP Board 03P9335 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.11 of 37- 1.11 RFC Board 03P9346 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.12 of 37- 1.12 RFC Board 03P9346 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.13 of 37- 1.13 PWR Board 03P9348 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.14 of 37- 1.14 PWR Board 03P9348 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.15 of 37- 1.15 Name Plate and Warning Label Furuno Labotech International Report no.: FLI 12-04-028 - Page E.16 of 37 - 2 Antenna (Scanner) unit RSB-104 2.1 Outside View (showing Radiator SN-36AF and Antenna Scanner) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.17 of 37 - 2.2 Outside View Furuno Labotech International Report no.: FLI 12-04-028 - Page E.18 of 37 - 2.3 Inside Right View (with Antenna right side cover removed, showing MSS Board MSS-7497 (lower)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.19 of 37 - 2.4 Inside Right View (with MSS Board cover removed, showing Antenna Motor (lower)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.20 of 37 - 2.5 Inside Left View (with Antenna left side cover removed, showing Antenna Motor (upper), TB Board 03P9349 (center), and Performance Monitor PM-51(lower left)). Furuno Labotech International Report no.: FLI 12-04-028 - Page E.21 of 37 - 2.6 Inside Left View (with TB Board removed) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.22 of 37 - 2.7 TB Board 03P9349 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.23 of 37 - 2.8 TB Board 03P9349 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.24 of 37 - 2.9 BP GEN Board 03P9347 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.25 of 37 - 2.10 BP GEN Board 03P9347 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.26 of 37 - 2.11 MSS Board MSS-7497 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.27 of 37 - 2.12 MSS Board MSS-7497 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.28 of 37 - 2.13 Name Plate Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.29 of 37 - 3 Monitor unit MU-231CR 3.1 Front View Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.30 of 37 - 3.2 Rear View (Showing Name Plate and Warning Labels) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.31 of 37 - 3.3 Rear View (Showing Connector Panel) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.32 of 37 - 3.4 Inside View (with Rear Cover removed, showing Power supply (upper), Filter Board 03P9360 (lower left) and DVI I/F Board (lower right)) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.33 of 37 - 3.5 Inside View (with Rear Cover removed, Showing Back of LCD Panel) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.34 of 37 - 3.6 Inside View (showing Filter module and Power supply (RKW12-13RE)) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.35 of 37 - 3.7 DVI I/F Board BSM501 Front side Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.36 of 37 - 3.8 DVI I/F Board BSM501 Rear side Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.37 of 37 - 3.9 Name Plate and Warning Label

Internal Photos

Furuno Labotech International Report no.: FLI 12-04-028 - Page E.1 of 37- Attachment E Photographs of EUT FAR-2837SW 1 Transceiver unit RTR-082 1.1 Front View (Showing Name Plate and Warning Label on Top cover) Note: Photographs for the units Processor RPU-013 and Control RCU-014 have been already reported. (See Technical Information FLI 12-03-027 for the Radar FAR-2127 (Transceiver type: RTR-079)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.2 of 37- 1.2 Inside View (with Top cover removed, showing Magnetron (upper left), IF AMP Board (upper right, with shield-cover) and TB Board 03P9349 (center right)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.3 of 37- 1.3 Inside View (with IF Board and TB Board removed) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.4 of 37- 1.4 Inside View (with shield-cover and Magnetron removed, showing MD Board 03P9244 (center) PWR Board 03P9348 (lower left) and RFC Board 03P9346 (lower right)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.5 of 37- 1.5 MD Board 03P9244 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.6 of 37- 1.6 MD Board 03P9244 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.7 of 37- 1.7 TB Board 03P9349 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.8 of 37- 1.8 TB Board 03P9349 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.9 of 37- 1.9 IF AMP Board 03P9335 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.10 of 37- 1.10 IF AMP Board 03P9335 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.11 of 37- 1.11 RFC Board 03P9346 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.12 of 37- 1.12 RFC Board 03P9346 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.13 of 37- 1.13 PWR Board 03P9348 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.14 of 37- 1.14 PWR Board 03P9348 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.15 of 37- 1.15 Name Plate and Warning Label Furuno Labotech International Report no.: FLI 12-04-028 - Page E.16 of 37 - 2 Antenna (Scanner) unit RSB-104 2.1 Outside View (showing Radiator SN-36AF and Antenna Scanner) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.17 of 37 - 2.2 Outside View Furuno Labotech International Report no.: FLI 12-04-028 - Page E.18 of 37 - 2.3 Inside Right View (with Antenna right side cover removed, showing MSS Board MSS-7497 (lower)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.19 of 37 - 2.4 Inside Right View (with MSS Board cover removed, showing Antenna Motor (lower)) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.20 of 37 - 2.5 Inside Left View (with Antenna left side cover removed, showing Antenna Motor (upper), TB Board 03P9349 (center), and Performance Monitor PM-51(lower left)). Furuno Labotech International Report no.: FLI 12-04-028 - Page E.21 of 37 - 2.6 Inside Left View (with TB Board removed) Furuno Labotech International Report no.: FLI 12-04-028 - Page E.22 of 37 - 2.7 TB Board 03P9349 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.23 of 37 - 2.8 TB Board 03P9349 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.24 of 37 - 2.9 BP GEN Board 03P9347 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.25 of 37 - 2.10 BP GEN Board 03P9347 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.26 of 37 - 2.11 MSS Board MSS-7497 Front side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.27 of 37 - 2.12 MSS Board MSS-7497 Rear side Furuno Labotech International Report no.: FLI 12-04-028 - Page E.28 of 37 - 2.13 Name Plate Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.29 of 37 - 3 Monitor unit MU-231CR 3.1 Front View Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.30 of 37 - 3.2 Rear View (Showing Name Plate and Warning Labels) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.31 of 37 - 3.3 Rear View (Showing Connector Panel) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.32 of 37 - 3.4 Inside View (with Rear Cover removed, showing Power supply (upper), Filter Board 03P9360 (lower left) and DVI I/F Board (lower right)) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.33 of 37 - 3.5 Inside View (with Rear Cover removed, Showing Back of LCD Panel) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.34 of 37 - 3.6 Inside View (showing Filter module and Power supply (RKW12-13RE)) Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.35 of 37 - 3.7 DVI I/F Board BSM501 Front side Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.36 of 37 - 3.8 DVI I/F Board BSM501 Rear side Furuno Labotech International Co., Ltd. Document number: FLI 012-04-028 - Page E.37 of 37 - 3.9 Name Plate and Warning Label

Test Report

This report shall not be reproduced except in full, without the written approval of Furuno Labotech International Co., Ltd. TECHNICAL INFORMATION TEST REPORT ON THE PERFORMANCE OF MARINE RADAR Trade Name : FURUNO Transceiver Type : RTR-082 Report no.: FLI 12-04-028 Date of issue: April 15, 2004 Furuno Labotech International Co., Ltd. 9-52 Ashihara-cho, Nishinomiya City, Hyogo 662-8580, Japan Tel: +81-798-63-1094 Fax: +81-798-63-1098 Furuno Labotech International Report no.: FLI 12-04-028 Form: Q053/01 - Page 1 of 47 - All tests were performed in Furuno Labotech International Co., Ltd. All data herein contained is true and correct to our best knowledge. All tests were performed and reported by: Name: Katsumi Imamura Function : Assistant Chief Signature: Verified by: Name: Sadatomo Kuwahara Function: Chief Engineer Signature: This report has been approved by: Date: April 15, 2004 Name: Mitsuyoshi Komori Function: Manager, Technical Section Signature: Furuno Labotech International Report no.: FLI 12-04-028 Form: Q053/01 - Page 2 of 47 - * * * * * * C O N T E N T S * * * * * * 1 General Information.............................................................................................................................. 3 2 Identification of Equipment (FCC Rule, 2.925)................................................................................... 9 3 Test data.............................................................................................................................................. 10 3.1 RF Power Output (FCC Rule, 2.1046).................................................................................................. 10 3.2 Modulation Characteristics (FCC Rule, 2.1047) ................................................................................... 13 3.3 Occupied Bandwidth (FCC Rule, 2.1049) ............................................................................................ 24 3.4 Spurious Emissions at Antenna Terminal (FCC Rule, 2.1051) ............................................................ 26 3.5 Field Strength of Spurious Radiation (FCC Rule, 2.1053) ................................................................. 30 3.6 Frequency Stability (FCC Rule, 2.1055) ............................................................................................... 32 3.7 Suppression of Interference Aboard Ships (FCC Rule, 80.217) .......................................................... 35 4 Photographs to Reveal Equipment Construction and Layout (FCC Rule, 2.1033).................... 39 5 Description of Circuitry and Devices (FCC Rules, 2.1033).......................................................... 40 5.1 Function of Each Semiconductor or Active Device ............................................................................... 40 5.2 Description of the circuitry and devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation, and for limiting power ............................... 43 6 Operator’s Manual Incl. Circuit Diagrams (FCC Rule, 2.1033)....................................................... 47 Attachment A [ Test data for 3.4 Spurious Emissions at Antenna Terminal ] ......... A.1 - A.14 Attachment B [ Test data for 3.5 Field Strength of Spurious Radiation ] ......... B.1 - B.7 Attachment C [ Test data for 3.7 Suppression of Interference Aboard Ships ] ......... C.1 - C.21 Attachment D [ List of Test/ Measuring Equipment ] ......... D.1 - D.3 Attachment E [ Photographs of the EUT ] ......... E.1 - E.28 Furuno Labotech International Report no.: FLI 12-04-028 Form: Q053/01 - Page 3 of 47 - 1 General Information 1.1 General (a) Manufacturer: Furuno Electric Co., Ltd. Ashihara-cho 9-52, Nishinomiya-city, 662-8580 Japan (b) Model: FAR-2837SW Type Serial Number Antenna unit RSB-104 R144-0002 Radiator: SN-36AF Transceiver Unit RTR-082 R148-0001 Processor unit RPU-013 4318-0003 Control unit RCU-014 0003 Monitor unit MU-231CR 0004 (c) Primary Function: Search, Navigation and anticollison (d) Discrimination Range Discrimination:26 meters on a range scale of 1.5 nm Bearing Discrimination: on a range scale of 1.5 nm, Radiator type: SN-30AF SN-36AF Discrimination (°):2.48 2.03 (e) Minimum Range: 22 meters on a range scale of 0.25 nm (f) Frequency Range: Fixed frequency, S-band Type of Emission: P0N (g) Power Supply: 100 - 115/220 - 230 VAC (for Processor unit), 100 - 230 VAC (for Monitor unit), 200 / 220 VAC (for Antenna Motor drive via Transceiver unit) 1.2 Transceiver Unit Type: RTR-082 (1) Transmitter (a) Assignable Frequency for Shipborne Radar: Between 2900 and 3100 MHz (FCC Rule: 80.375 (d)-(1)) (b) Type of RF Generator Magnetron Type: MG5223F Peak Output Power: 30 kW nominal (c) Magnetron Ratings Center frequency of Magnetron:3050 MHz Tolerances Furuno Labotech International Report no.: FLI 12-04-028 Form: Q053/01 - Page 4 of 47 - MG5223F Manufacturing: 30 MHz Pulling: 13 MHz Tolerance for 20°C temperature variation: -1.4 MHz (d) Guard Band: Guard Band is specified to be equal to 1.5/T MHz, where "T" is the pulselength in microseconds. See para (e). (FCC Rule: 80.209(b)) (e) Pulse Characteristics: Range Scale (Short 1) (Short 2) (Middle 1) (Middle 2) (Middle 3) (Long 1) (Long 2) (nm) 0.125 0.25 0.5 0.5 0.75 0.75 0.75 1.5 1.5 1.5 3 3 3 3 6 6 6 6 12 12 12 24 24 24 48 96 Pulselength (μs) 0.07 0.15 0.30 0.50 0.70 1.20 1.20 P.R.R.(Hz) 3000 3000 1500 1000 1000 600 500 Duty cycle 2.10X10 -4 4.50X10 -4 4.50X10 -4 5.00X10 -4 7.00X10 -4 7.20X10 -4 6.00X10 -4 Guard Band (MHz) 21.43 10.00 5.00 3.00 2.14 1.25 1.25 Note 1: Tests were carried out for the underlined Range Scales. (2) Modulator (a) FET Type: 2SK1466 Trigger Voltage: Approx. +16 VDC positive (3) Receiver (a) Passband (MHz) RF Stage: 100 MHz IF Stage: Pulselength Short 1 Short 2 Middle 1 Middle 2 Middle 3 Long 1 Long 2 (MHz) 40 40 10 10 10 3 3 Furuno Labotech International Report no.: FLI 12-04-028 Form: Q053/01 - Page 5 of 47 - (b) Ga…

Text truncated - open the document above for the full version.

Test Report

Furuno Labotech International Report no.: FLI 12-04-028 - Page C .1 of 21 - Attachment C [ TEST DATA for Clause 3.7 SUPPRESSION OF INTERFERENCE ABOARD SHIPS ] 1 Harmful Interference to Receiver (Band: 14 kHz - 490 kHz) a) Radar Power: OFF b) Radar TX: O N Furuno Labotech International Report no.: FLI 12-04-028 - Page C .2 of 21 - (Band: 490 kHz - 5 MHz) a) Radar Power: OFF b) Radar TX: O N Furuno Labotech International Report no.: FLI 12-04-028 - Page C .3 of 21 - (Band: 5 MHz - 10 MHz) a) Radar Power: OFF b) Radar TX: O N Furuno Labotech International Report no.: FLI 12-04-028 - Page C .4 of 21 - (Band: 10 MHz - 30 MHz) a) Radar Power: OFF b) Radar TX: O N Furuno Labotech International Report no.: FLI 12-04-028 - Page C .5 of 21 - (Band: 30 MHz - 100 MHz) a) Radar Power: OFF b) Radar TX: O N Furuno Labotech International Report no.: FLI 12-04-028 - Page C .6 of 21 - (Band: 100 MHz - 300 MHz) a) Radar Power: OFF b) Radar TX: O N Furuno Labotech International Report no.: FLI 12-04-028 - Page C .7 of 21 - (Band: 300 MHz - 1 GHz) a) Radar Power: OFF b) Radar TX: O N Furuno Labotech International Report no.: FLI 12-04-028 - Page C .8 of 21 - 2 Electromagnetic Field (Band: 14 kHz - 490 kHz, Limit at 1 nm = 0.1 μV/m = -20 dBμV/m) a) Radar Power: OFF b) Radar TX: O N Ref. Level: -26 dBμV/m Furuno Labotech International Report no.: FLI 12-04-028 - Page C .9 of 21 - (Band: 490 kHz - 5 MHz, Limit at 1 nm = 0.1 μV/m = -20 dBμV/m) a) Radar Power: OFF b) Radar TX: O N -20 dBμV/m limit line Ref. level (dBμV/m) = 100 - 126 = -26 (at 0.5 MHz) = 100 - 96 = 4 (at 3 MHz) = 100 - 88 = 1 2 (at 5 MHz) Furuno Labotech International Report no.: FLI 12-04-028 - Page C .10 of 21 - (Band: 5 MHz - 10 MHz, Limit at 1 nm = 0.1 μV/m = -20 dBμV/m) a) Radar Power: OFF b) Radar TX: O N Ref. level (dBμV/m) = 100 - 88 = 12 (at 5 MHz) = 100 - 83 = 17 (at 7 MHz) = 100 - 78 = 22 (at 10 MHz) -20 dBμV/m limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .11 of 21 - (Band: 10 MHz - 30 MHz, Limit at 1 nm = 0.1 μV/m = -20 dBμV/m) a) Radar Power: OFF b) Radar TX: O N Ref. level (dBμV/m) = 100 - 78 = 22 (at 10 MHz) = 100 - 70 = 30 (at 20 MHz) = 100 - 67 = 33 (at 30 MHz) -20 dBμV/m limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .12 of 21 - (Band: 30 MHz - 100 MHz, Limit at 1 nm = 0.1 μV/m = -10.5 dBμV/m) a) Radar Power: OFF b) Radar TX: O N -10.5 dBμV/m limit line Ref. level (dBμV/m) = 100 - 61 = 3 9 Furuno Labotech International Report no.: FLI 12-04-028 - Page C .13 of 21 - (Band: 100 MHz - 300 MHz, Limit at 1 nm = 0.1 μV/m = 0 dBμV/m) a) Radar Power: OFF b) Radar TX: O N 0 dBμV/m limit line Ref. level (dBμV/m) = 100 - 60 = 4 0 Note: All components above the limit are from external noise or signals, not from Radar. Furuno Labotech International Report no.: FLI 12-04-028 - Page C .14 of 21 - (Band: 300 MHz - 1 GHz, Limit at 1 nm = 3 μV/m = 9.5 dBμV/m) a) Radar Power: OFF b) Radar TX: O N Ref. level (dBμV/m) = 100 - 59.5 = 40.5 9.5 dBμV/m limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .15 of 21 - 3 Power Input to an Artificial Antenna (Band: 14 kHz - 490 kHz, Limit at 2 m = -81 dBm) a) Radar Power: OFF b) Radar TX: O N Note: All components above the limit are from external noise or signals, not from Radar. -81 dBm limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .16 of 21 - (Band: 490 kHz - 5 MHz, Limit at 2 m = -81 dBm) a) Radar Power: OFF b) Radar TX: O N Note: All components above the limit are from external noise or signals, not from Radar. -81 dBm limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .17 of 21 - (Band: 5 MHz - 10 MHz, Limit at 2 m = -81 dBm) a) Radar Power: OFF b) Radar TX: O N Note: All components above the limit are from external noise or signals, not from Radar. -81 dBm limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .18 of 21 - (Band: 10 MHz - 30 MHz, Limit at 2 m = -81 dBm) a) Radar Power: OFF b) Radar TX: O N Note: All components above the limit are from external noise or signals, not from Radar. -81 dBm limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .19 of 21 - (Band: 30 MHz - 100 MHz, Limit at 2 m = -71 dBm) a) Radar Power: OFF b) Radar TX: O N Note: All components above the limit are from external noise or signals, not from Radar. -71 dBm limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .20 of 21 - (Band: 100 MHz - 300 MHz, Limit at 2 m = -61 dBm) a) Radar Power: OFF b) Radar TX: O N Note: All components above the limit are from external noise or signals, not from Radar. -61 dBm limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page C .21 of 21 - (Band: 300 MHz - 1 GHz, Limit at 2 m = -51 dBm) a) Radar Power: OFF b) Radar TX: O N -51 dBm limit line Furuno Labotech International Report no.: FLI 12-04-028 - Page D.1 of 3 - ATTACHMENT D [ List of Test/Measuring Equipment ] (for S-band radar) For Clause 3.1 RF Power Output Model Type Serial no. Mfr. Spectrum Analyzer 71210C 2927A02847 HP Oscilloscope TDS680B B030202 Tektronix Directional Coupler ----- R1788 Shimada High Voltage Probe HV-P30 2870 Iwatsu Current Transformer 2100 ---- Pearson Electronics Power Meter 436A 2410A19137 HP Power Sensor 8481A 2349A39603 HP Frequency Counter TR5824A 41940036 Advantest Frequency Meter 536A 1441A-01864 HP Crystal Detector 423B 1822A24214 HP Dummy Load 4D106 R35872 Shimada Rotary Attenuator (10 dB Step) 8495B 3308A22026 HP Rotary Attenuator (1 dB Step) 8494B US00430229 HP For Clause 3.2 Modulation Characteristics Model Type Serial no. Mfr. Oscilloscope TDS680B B030202 Tektronix Crystal Detector 423B 1822A24214 HP Directional Coupler ----- R1788 Shimada Dummy Load 4D106 R35872 Shimada Spectrum Analyzer 71210C 2927A02847 HP High Voltage Probe HV-P30 2870 Iwatsu Furuno Labotech International Report no.: FLI 12-04-028 - Page D.2 of 3 - For Clause 3.4 Spurious Emissions at Antenna Terminal Mode…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Bill Haynes(Deep Sea Product Manager)
[email protected]888-834-9330Fax: 360-833-5195

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
180,902.90 GHz - 3.10 GHz30000 W63M7PON915.0000000000 %
