ADB9ZWRTR115Transceiver for Radar

www.furuno.com All brand and product names are trademarks, registered trademarks or service marks of their respective holders. Installation Manual RADAR SENSOR MODEL DRS4D-NXT SAFETY INFORMATION.................................................................................................. i SYSTEM CONFIGURATION .......................................................................................... iii EQUIPMENT LISTS........................................................................................................ iv 1. INSTALLATION.......................................................................................................... 1 1.1 General Information about DRS4D-NXT............................................................................... 1 1.2 Installation Considerations.................................................................................................... 1 1.3 Installation of the Radar Sensor............................................................................................4 2. WIRING.......................................................................................................................8 2.1 Connections .......................................................................................................................... 8 2.2 Check Points After Installation ..............................................................................................8 2.3 Initial Setup ........................................................................................................................... 9 3. MAINTENANCE, TROUBLE- SHOOTING............................................................... 13 3.1 Maintenance ....................................................................................................................... 13 3.2 Replacement of Fuse..........................................................................................................13 3.3 Troubleshooting .................................................................................................................. 14 4. PROCEDURE FOR RETROFIT................................................................................ 15 4.1 Required Tools and a Part for Retrofit ................................................................................ 15 4.2 Retrofit Procedures ............................................................................................................. 15 SPECIFICATIONS ..................................................................................................... SP-1 PACKING LISTS ......................................................................................................... A-1 OUTLINE DRAWING ................................................................................................... D-1 INTERCONNECTION DIAGRAM ................................................................................ S-1 i SAFETY INFORMATION Read these safety instructions before installing or operating the equipment. WARNING Indicates a potentially hazardous situation which, if not avoided, can result in minor or moderate injury. Warning, Caution Prohibitive Action CAUTION Mandatory Action Indicates a potentially hazardous situation which, if not avoided, can result in serious injury or death. Wear a safety belt and hard hat when working on the antenna unit. Serious injury or death can result if someone falls from the radar mast. ELECTRICAL SHOCK HAZARD Do not open the equipment. The installation does not require you to open the radar sensor. Be sure the power source is compatible with the voltage rating of the equipment. Connection of an incorrect power source can cause fire or damage the equipment. Turn off the power at the power source before beginning the installation. Fire, electrical shock or serious injury can result if the power is left on or is applied while the equipment is being installed. WARNING Do not disassemble or modify the equipment. Fire, electrical shock or serious injury can result. Use the proper fuse. Use of a wrong fuse can damage the equipment or cause fire. Do not depend one navigation device for the navigation of the vessel. For the safety of vessel and crew, the navigator must check all aids available to confirm position. The radar antenna emits electromagnetic radio frequency (RF) energy which can be harmful, particularly to your eyes. Never look directly into the antenna aperture from a close distance while the radar is in operation or expose yourself to the transmitting antenna at a close distance. Distances at which RF radiation levels of 100, 50 and 10 W/m 2 exist are given in the table below. 100W/m 2 10W/m 2 Model DRS4D-NXTN/A0.7 m 50W/m 2 N/A SAFETY INFORMATION ii NOTICE It is recommended that you connect the sensor to a disconnecting device (circuit breaker, etc.) to control the power. Observe the following compass safe distances to prevent interference to a magnetic compass. Standard compass Steering compass 0.55 m0.30 m iii SYSTEM CONFIGURATION Power supply 12/24 VDC RADAR SENSOR DRS4D-NXT Multi Function Display * 1 TZTL12F/TZTL15F * 2 TZT9/TZT14/TZTBB LAN Pre-attached power/LAN cable 1 m : Local supply * 1 Software upgrade to V4 or after is required. * 2 Software upgrade to V5 or after is required. Selectable power/LAN cable CP03-36400/ CP03-36410/ CP03-36420/ CP03-36430 (10/15/20/30 m, 15 m is set as standard.) DO NOT cut the cable near its connector (encircled location). iv EQUIPMENT LISTS Standard supply Optional supply Optional supply for Retrofit from DRS2D, DRS4D and DRS6A NameTypeCode No.QtyRemarks Radar SensorRSB-135000-027-2001 Installation MaterialsCP03-35701001-295-9201 CP03-36400000-027-211Select one Power/Network cable 10 m CP03-36410000-027-212Power/Network cable 15 m CP03-36420000-027-213Power/Network cable 20 m CP03-36430000-027-214Power/Network cable 30 m Spare PartsSP03-17901001-351-4701Fuses NameTypeCode No.QtyRemarks Radome MountOP03-208001-078-3401 NameTy…

Text truncated - open the document above for the full version.

15 April 2014 TUV SUD BABT TCB/FCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, I, Shane Ryan of Furuno USA Inc , hereby authorize Akira Yamamoto and Ichiya Ogino of Furuno Electric Co., Ltd to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 15 April 2016. Sincerely, Shane Ryan FURUNO USA Company Officer: Shane Ryan Telephone Number: (360) 834-9300 X-5060 Email: [email protected]

Labotech International Report no.: LIC 01-15-045 Date of issue: 30 September 2015 - Page 1 of 3 - Photographs of the Marine Radar DRS4D-NXT 1 Outside View 1.1 Front View Labotech International Report no.: LIC 01-15-045 Date of issue: 30 September 2015 - Page 2 of 3 - 1.2 Rear View (showing Warning Labels) ID Label Labotech International Report no.: LIC 01-15-045 Date of issue: 30 September 2015 - Page 3 of 3 - 1.3 ID Label (Name Plate)

Labotech International Document number: LIC 01-15-052 Date of issue: 30 September 2015 Form: Q053/01 - Page 1 of 2 - Identification of Equipment for the Furuno Radar Sensor DRS4D-NXT with Transceiver RTR-115 included (FCC Rule, 2.925) 1 ID Label The following nameplate is permanently fixed on the corresponding equipment unit. FCC ID: ADB9ZWRTR115 Material of Nameplate: Polyester film, 0.1 mm thick Labotech International Document number: LIC 01-15-052 Date of issue: 30 September 2015 Form: Q053/01 - Page 2 of 2 - 2 ID Label Location ID Label is affixed on the Scanner case. ID Label

Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 1 of 10 - Photographs of the Marine Radar DRS4D-NXT 2 Inside View 2.1 Top View (with Top cover (Radome) opened, showing Scanner module RSB-135 and Transceiver module RTR-115 including Radar antenna) Scanner module RSB-135 Radar antenna Transceiver module RTR-115 (inside RSB-135) Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 2 of 10 - 2.2 Top View Rotary Joint Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 3 of 10 - 2.3 Top View (with Radar antenna removed) Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 4 of 10 - 2.4 Top View (with Transceiver module removed) IF-SPU Board Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 5 of 10 - 2.5 Transceiver module (with the shield cover opened, showing PWR Board 03P9613 and TRX module) TRX module Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 6 of 10 - 2.6 Transceiver module PWR Board 03P9613 RU-9969 (Spurious Filter) Circulator Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 7 of 10 - 2.7 Transceiver module (with the shield cover opened, showing SPU Board 03P9603 (upper left) and PWR Board 03P9613 (lower left)) SPU Board 03P9603 PWR Board 03P9613 Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 8 of 10 - 2.8 Transceiver module (with PWR Board 03P9613 removed) Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 9 of 10 - 2.9 Transceiver module (with SPU Board 03P9603 removed) Labotech International Report no.: LIC 01-15-046 Date of issue: 30 September 2015 - Page 10 of 10 - 2.10 TRX module

Labotech International Report no.: LIC 01-15-047 Date of issue: 30 September 2015 - Page 1 of 6 - Photographs of the Marine Radar DRS4D-NXT 3 PCBs 3.1 SPU Board 03P9603 3.1.1 SPU Board 03P9603 front side Labotech International Report no.: LIC 01-15-047 Date of issue: 30 September 2015 - Page 2 of 6 - 3.1.2 SPU Board 03P9603 rear side Labotech International Report no.: LIC 01-15-047 Date of issue: 30 September 2015 - Page 3 of 6 - 3.2 PWR Board 03P9613 3.2.1 PWR Board 03P9613 front side Labotech International Report no.: LIC 01-15-047 Date of issue: 30 September 2015 - Page 4 of 6 - 3.2.2 PWR Board 03P9613 rear side Labotech International Report no.: LIC 01-15-047 Date of issue: 30 September 2015 - Page 5 of 6 - 3.3 TRX Board 03P9602 3.3.1 TRX Board 03P9602 front side Labotech International Report no.: LIC 01-15-047 Date of issue: 30 September 2015 - Page 6 of 6 - 3.3.2 TRX Board 03P9602 rear side

This report shall not be reproduced except in full, without the written approval of Labotech International Co., Ltd. Safety Test Report for human exposure (IEC 60945 and EN/IEC 62311) For Trade name: Furuno Model: Radar Sensor Type: DRS4D-NXT Report No.: LIC 12-15-074 Date of Issue: 30 September 2015 Labotech International Co., Ltd. 1-16, Fukazu-cho, Nishinomiya-shi, Hyogo, 663-8203 Japan Tel: +81 (0) 798 63 1094 Fax: +81 (0) 798 63 1098 URL: http://www.furuno-labotech.co.jp Labotech International Report number: LIC12-15-074 Form: FQ057-4/01 - Page 2 of 9 - Report Summary LIC project number: LIC 04-15-0240 Test report number of initial issue: LIC 12-15-074 Date of initial issue 30 September 2015 Test report number of revised/replaced issue: --- Date of revised/replaced issue --- Test report revision/ replacement history: --- Test standard(s)/ Test specifications: EN 62311: 2008, and IEC 62311: 2007 ICNIRP Guideline Gen.Pub.1998 IEC 62233: 2005 IEC 60945, 12.2 RF Radiation. Customer: Furuno Electric Co., Ltd. 9-52 Ashihara-Cho, Nishinomiya-City, 662-8580 Japan Manufacturer: Furuno Electric Co., Ltd. 9-52 Ashihara-Cho, Nishinomiya-City, 662-8580 Japan Trade name: FURUNO Model: Radar Sensor Type: DRS4D-NXT Product function and intended use: For Marine Safety Navigation Number of samples tested: One Serial number: 1000-4900-0012 Power rating: 12 - 24 VDC, 2.1 - 1.0 A Product status: Pre-production model Modifications made to samples during testing: None. Date of receipt of samples: 2 July 2015 Test period: 18 July 2015 Place of test: Labotech International Co., Ltd. - LABOTECH EMC Center 1-16, Fukazu-cho, Nishinomiya-shi, Hyogo, 663-8203 Japan Test results/ Compliance: Passed. The test results of this report relate only to the samples tested. Tested by: Yasuharu Nakamura and Tadayuki Ekawa, Written by: Akiko Inoue Verified by: Yoshihiro Ishii Approved by: Date: 30 September 2015 Name: Yoshihiro Ishii Title: Senior Manager, Technical Department, Labotech International Co., Ltd. Signature: Labotech International Report number: LIC12-15-074 Form: FQ057-4/01 - Page 3 of 9 - Testing Laboratory Status Labotech International Co., Ltd. (hereafter called “LIC“) has been holding the following status after having been assessed according to the provisions of ISO/IEC 17025 and/or the relevant rules: (1) JAB Accredited Testing Laboratory: - accredited by Japan Accreditation Board (JAB), - Laboratory accreditation number: RTL03220 - Date of initial accreditation: 14 January 2011 - Scope of accreditation: Electrical testing - EMC testing (*) (2) Telefication Listed Testing Laboratory: - listed by Telefication B. V., (The Netherlands) - Laboratory assignment number: L116 - Date of initial listing: 26 July 1999 (*) - for testing the following product categories/ test standards: EN 60945, IEC 61162-1/-2, IEC/EN 61162-450 and IEC 62288 (3) BSH Recognized Testing Laboratory: - recognized by Bundesamt für Seeschifffahrt und Hydrographie (BSH), (Germany) - Recognition certificate number: BSH/4613/06202/1864/11 - Date of initial recognition: 4 April 2003 (*) - for testing the following product categories/ test standards: - IEC/EN 60945, IEC 62388, IEC 61162-1/-2, and IEC 62288 (4) TÜV Appointed EMC Test Laboratory: - appointed by TÜV Rheinland Japan Ltd., - Laboratory assignment number: UA 50046428 - Date of initial appointment: 21 December 1998 (*) - for carrying out the tests of: EN 55011, CISPR 11, EN 55022, CISPR 22, EN 55024, CISPR 24, EN 55025, CISPR 25, EN/IEC 61000-3-2/-3, EN/IEC 61000-4-2/-3/-4/-5/-6/-8/-11, EN/IEC 61000-6-1/-2/-3/-4, EN/IEC 60945, EN/IEC 61326-1, EN/IEC 61326-2-6, EN/IEC 60601-1-2, JIS T 0601-1-2, JIS C 1806-1, and ISO 11452-1/-2/-4. (5) RMRS Recognized Testing Laboratory: - recognized by Russian Maritime Register of Shipping (RMRS), (Russia) - Laboratory recognition number: 11.02594.011 - Date of initial recognition: 27 January 2009 (*) - for carrying out testing in the field of: Elecrtrical measurements and tests, EMC tests, Mechanical measurements and tests, Equipment protection degree tests, and Climatic tests for Ship’s radio and navigational equipment and IEC 60945: 2002 (6) RRR Recognized Test Laboratory: - recognized by Russian River Register (RRR), (Russia) - Recognition certificate number: 154262 - Date of initial recognition: 31 May 2013 - for carrying out of tests of ships radio and navigation equipment (7) DNV Recognized Environmental Test Laboratory: - recognized by Det Norske Veritas AS (DNV), (Norway) - Recogntion certificate number: 262.1-015854-J-12 - Date of initial recognition: 12 July 2013 - Scope of recognition: Testing according to the standards IEC 60945, IEC 61162-1/-2/-450, IEC 62288, IEC 62388 and IEC 62252 Annex E - Application: Provisions of Environmental, interface and safety testing. (8) CCS Recognized Test Agency : - recognized by China Classification Society - Recognition certificate number : DB13A00001 - Date of initial recognition : 29 January 2014 - Scope of recognition : Performance/Environmental/EMC/Special purpose/Safety precautions tests for Electrical & Electronic Product including Maritime Navigation and Radio-communication Equipment & Systems Note: (*) – The current certificates may be found in the LIC web site (http://www.furuno-labotech.co.jp). Labotech International Report number: LIC12-15-074 Form: FQ057-4/01 - Page 4 of 9 - TABLE OF CONTENTS Report Summary ............................................................................................................................... 2 Testing Laboratory Status ................................................................................................................. 3 1 Principal Information ...................................................................................................................... 5 1.1 Equipment under test (EUT) .................................................................................................... 5 1.2 Observation and comments ................…

Text truncated - open the document above for the full version.

This report shall not be reproduced except in full, without the written approval of Labotech International Co., Ltd. Test Report (FCC Rules 47 CFR, 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, and 80.209, 80.211, 80.213, 80.215) For Trade name: Furuno Model: Transceiver for Marine Radar Type: RTR-115 Report no.: LIC 12-15-102 Date of issue: 30 September 2015 Labotech International Co., Ltd. 1-16, Fukazu-cho, Nishinomiya-shi, Hyogo, 663-8203 Japan Tel: +81-798-63-1094 Fax: +81-798-63-1098 Labotech International Report no.: LIC 12-15-102 Form: FQ053/06 - Page 2 of 57 - Report Summary LIC project number: LIC 04-15-0239 Test report number of initial issue: LIC 12-15-102 Date of initial issue 30 September 2015 Test report number of revised/replaced issue: --- Date of revised/replaced issue --- Test report revision/ replacement history: --- Test standard(s)/ Test specifications: FCC Rules 47 CFR, Sections: 2.1046 - RF Power Output 2.1047 - Modulation Characteristics, 2.1049 - Occupied Bandwidth, 2.1051 - Spurious Emissions at Antenna Terminals, 2.1053 - Field Strength of Spurious Radiation, 2.1055 - Frequency Stability, (Date of issue: 23 June 2015) 80.209 - Transmitter frequency tolerances 80.211 - Emission limitations. 80.213 - Modulation requirements. 80.215 - Transmitter power Customer: Furuno Electric Co., Ltd. 9-52 Ashihara-Cho, Nishinomiya-City, 662-8580 Japan Manufacturer: Furuno Electric Co., Ltd. 9-52 Ashihara-Cho, Nishinomiya-City, 662-8580 Japan Trade name: FURUNO Model: Transceiver for Marine Radar Type: RTR-115 Product function and intended use: For marine safety navigation Number of samples tested: One Serial number: 1000-4900-0011 Power rating: 12-24 VDC Product status: Pre-production model Modifications made to samples during testing: None. Date of receipt of samples: 3 July 2015 Test period: From 7 July 2015 to 2 September 2015 Place of test: Labotech International Co., Ltd. - Nishinomiya-Hama Lab. 2-20, Nishinomiya-Hama, Nishinomiya-shi, Hyogo, 662-0934 Japan Anechoic Chamber used for the test has been registered by FCC. (File number: 90607) Test firm Designation Number: JP2007, Test firm Registration #: 838049 Test results/ Compliance: Passed. The test results of this report relate only to the samples tested. Tested by: Akira Inoue Written by: Akiko Inoue Verified by: Yoshihiro Ishii Approved by: Date: 30 September 2015 Name: Yoshihiro Ishii Title: Senior Manager, Technical Department Labotech International Co., Ltd. Signature: Labotech International Report no.: LIC 12-15-102 Form: FQ053/06 - Page 3 of 57 - Testing Laboratory Status Labotech International Co., Ltd. (hereafter called “LIC”) has been holding the following status after having been assessed according to the provisions of ISO/IEC 17025 and/or the relevant rules: (1) JAB Accredited Testing Laboratory: - accredited by Japan Accreditation Board (JAB), - Laboratory accreditation number: RTL03220 - Date of initial accreditation: 14 January 2011 (*) - Scope of accreditation: Electrical testing - EMC testing (2) Telefication Listed Testing Laboratory: - listed by Telefication B. V., (The Netherlands) - Laboratory assignment number: L116 - Date of initial listing: 26 July 1999 (*) - for testing the following product categories/ test standards: EN 60945, IEC 61162-1/-2, IEC/EN 61162-450 and IEC 62288 (3) BSH Recognized Testing Laboratory: - recognized by Bundesamt für Seeschifffahrt und Hydrographie (BSH), (Germany) - Recognition certificate number: BSH/4613/06202/1864/11 - Date of initial recognition: 4 April 2003 (*) - for testing the following product categories/test standards: - IEC/EN 60945, IEC 62388, IEC 61162-1/-2, and IEC 62288 (4) TÜV Appointed EMC Test Laboratory: - appointed by TÜV Rheinland Japan Ltd., - Laboratory assignment number: UA 50046428 - Date of initial appointment: 21 December 1998 (*) - for carrying out the tests of: EN 55011, CISPR 11, EN 55022, CISPR 22, EN 55024, CISPR 24, EN 55025, CISPR 25, EN/IEC 61000-3-2/-3, EN/IEC 61000-4-2/-3/-4/-5/-6/-8/-11, EN/IEC 61000-6-1/-2/-3/-4, EN/IEC 60945, EN/IEC 61326-1, EN/IEC 61326-2-6, EN/IEC 60601-1-2, JIS T 0601-1-2, JIS C 1806-1, and ISO 11452-1/-2/-4. (5) RMRS Recognized Testing Laboratory: - recognized by Russian Maritime Register of Shipping (RMRS), (Russia) - Laboratory recognition number: 11.02594.011 - Date of initial recognition: 27 January 2009 (*) - for carrying out testing in the field of: Electrical measurements and tests, EMC tests, Mechanical measurements and tests, Equipment protection degree tests, and Climatic tests for Ship’s radio and navigational equipment and IEC 60945: 2002 (6) RRR Recognized Test Laboratory: - recognized by Russian River Register (RRR), (Russia) - Recognition certificate number: 154262 - Date of initial recognition: 31 May 2013 (*) - for carrying out of tests of ships radio and navigation equipment (7) DNV Recognized Environmental Test Laboratory: - recognized by Det Norske Veritas AS (DNV), (Norway) - Recognition certificate number: 262.1-015854-J-12 - Date of initial recognition: 12 July 2013 (*) - Scope of recognition: Testing according to the standards IEC 60945, IEC 61162-1/-2/-450, IEC 62288, IEC 62388 and IEC 62252 Annex E - Application: Provisions of Environmental, interface and safety testing. (8) CCS Recognized Test Agency : - recognized by China Classification Society - Recognition certificate number : DB13A00001 - Date of initial recognition : 29 January 2014 (*) - Scope of recognition : Performance/Environmental/EMC/Special purpose/Safety precautions tests for Electrical & Electronic Product including Maritime Navigation and Radio-communication Equipment & Systems Note: (*) – The current certificates may be found in the LIC web site (http://www.furuno-labotech.co.jp). Labotech International Report no.: LIC 12-15-102 Form: FQ053/06 - Page 4 of 57 - TABLE OF CONTENTS Testing Laboratory Status ..............................................................................................................…
