AFJ242700HF/VHF/UHF All Mode Transceiver

HF/VHF/UHF ALL MODE TRANSCEIVER i7000 INSTRUCTION MANUAL i-1 IMPORTANT READ THIS INSTRUCTION MANUAL CAREFULLY before attempting to operate the transceiver. SAVE THIS INSTRUCTION MANUAL.This manual contains important safety and operating in- structions for the IC-7000. EXPLICIT DEFINITIONS WORDDEFINITION R WARNING Personal injury, fire hazard or electric shock may occur. CAUTIONEquipment damage may occur. NOTE If disregarded, inconvenience only. No risk or personal injury, fire or electric shock. We understand that you have a choice of many differ- ent radios in the market place. We want to take a cou- ple of moments of your time to thank you for making the IC-7000 your radio of choice, and hope you agree with Icom’s philosophy of “technology first.” Many hours of research and development went into the de- sign of your IC-7000. DFEATURES ❍IF DSP features ❍All mode capability covering 160–0.7 m (depending on version) ❍Compact with detachable front panel ❍±0.5 ppm of high frequency stability ❍Boudot RTTY demodulator ❍Simple band scope function ❍Selectable SSB transmission passband width (Each for Higher and lower pass fre- quency) ❍Standard voice synthesizer/voice recorder The transceiver comes with the following acces- sories. Qty. qHand microphone (HM-151) ........................... 1 wDC power cable (OPC-1457) .......................... 1 eSpare fuse (ATC 5 A) ...................................... 1 rSpare fuse (ATC 30 A) .................................... 2 tACC cable ........................................................1 y3.5 (d) mm plug ................................................1 u6.5 (d) mm Electronic keyer plug......................1 iMicrophone hanger...........................................1 q e t w yu r i FOREWORDSUPPLIED ACCESSORIES Icom, Icom Inc. and the logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries. Spurious may be received near the following frequencies. These are made in the internal circuit and does not indicate a transceiver malfunction: 52.76497 MHz, 443.03535 MHz THIS P THIS P AGE AGE OPEN i-2 SPCH /LOCK TUNER /CALL XFC V/M F-1 F-2 FIL MODE GENE MW 123 456 789 . 0 CE F-INP ENT 1.83.57 101418 212428 50144430 Mic element q e w o !7!8!9@0@2@3@4@1 t r yu!2 !5 !6 !1!0i !3 !4 z c v b n m , . ⁄0 ⁄2 ⁄3 ⁄1 x Front panel HM-151 The front panel and HM-151’s panel descriptions are descrived between pages 1 to 4, and on page 9, respec- tively (see the Chapter 1 (Panel de- scription) for more details). ILLUSTRATIONS i-3 ■Front panel qAF GAIN CONTROL [AF] (inner control; p. 33) wRF GAIN CONTROL/SQUELCH CONTROL [RF/SQL](outer control; p. 35) ePOWER KEY [PWR] (p. 25) rFRONT PANEL LATCH (p. 16) tPASSBAND TUNING/M-ch/RIT CONTROLS [PBT/M-ch/RIT](pgs. 75, 79, 88, 102, 106) yTWIN PBT (M-ch/RIT) INDICATOR (pgs. 75, 79, 88, 102, 106) uMENU/GROUP KEYS [MENU/GRP] (p. 153) iTUNER/CALL KEY [TUNER/CALL] (pgs. 102, 116) oMULTI-FUNCTION KEYS [F1]/[F2]/[F3]/[F4] (pgs. 5–8, 153) !0MANUAL NOTCH KEY [MNF/ADJ](p. 83) !1AUTO NOTCH/VOICE RECORDER KEY [ANF/ • REC](pgs. 82, 95) !2SPCH/LOCK KEY [SPCH/LOCK] (pgs. 34, 37) !3MICROPHONE CONNECTOR (p. 10) !4UP/DOWN (BAND) KEYS [Y(BAND)]/[ Z (BAND)] !5MAIN DIAL TENSION LATCH !6HEADPHONE JACK [PHONES] (p. 18) !7MAIN DIAL [DIAL] !8RECEIVE/TRANSMIT INDICATORS [RX]/[TX] !9TUNING STEP KEY [TS] (pgs. 30–32) @0NOISE BLANKER KEY [NB/ADJ](p. 80) @1NOISE REDUCTION KEY [NR/LEV](p. 81) @2FUNCTION DISPLAY(p. 13) @3PRE AMP/ATTENUATOR KEY [P.AMP/ATT] (p. 74) @4MODE KEY [MODE] (p. 34) ■Microphone (HM-151) zSPCH/LOCK KEY [SPCH/LOCK] (p. 34, 37) xPTT SWITCH[PTT](p. 37) cUP/DOWN SWITCHES [ Y ]/[ Z ] vTRANSMIT INDICATOR bKEYPAD(pgs. 28, 29) nFILTER SELECTION [FIL](p. 77) mMODE KEY [MODE] (p. 34) ,POWER INDICATOR .PROGRAMMABLE FUNCTION KEYS [F-1]/[F-2] ⁄0MEMORY WRITE [MW](pgs. 103, 104) ⁄1VFO/MEMORY SELECTION [V/M] (pgs. 27, 102, 109) ⁄2TRANSMIT FREQUENCY CHECK [XFC] (pgs. 65, 91) ⁄3TUNER/CALL KEY [TUNER/CALL] (pgs. 102, 116) ii RWARNING RF EXPOSURE!This device emits Radio Frequency (RF) energy. Extreme caution should be observed when operating this device. If you have any questions regarding RF exposure and safety standards please refer to the Federal Communications Commission Office of Engineering and Technology’s report on Evalu- ating Compliance with FCC Guidelines for Human Radio Frequency Electromagnetic Fields (OET Bulletin 65). RWARNING HIGH VOLTAGE! NEVERattach an antenna or internal antenna connector during transmis- sion. This may result in an electrical shock or burn. RNEVERapply AC to the [DC13.8V] socket on the transceiver rear panel. This could cause a fire or damage the transceiver. RNEVERapply more than 16 V DC, such as a 24 V battery, to the [DC13.8V] jack on the transceiver rear panel. This could cause a fire or damage the transceiver. RNEVERlet metal, wire or other objects touch any in- ternal part or connectors on the rear panel of the trans- ceiver. This may result in an electric shock. RNEVERconnect or use the HM-151 (microphone) with other transceiver. This could cause damage to the transceiver. The HM-151 is designed for use with the IC- 7000ONLY NEVERexpose the transceiver to rain, snow or any liq- uids. AVOIDusing or placing the transceiver in areas with tem- peratures below –10°C (+14°F) or above +60°C (+140°F). Be aware that temperatures on a vehicle’s dashboard can exceed +80°C (+176°F), resulting in permanent damage to the transceiver if left there for extended periods. AVOIDplacing the transceiver in excessively dusty envi- ronments or in direct sunlight. AVOIDplacing the transceiver against walls or putting anything on top of the transceiver. This will obstruct heat dissipation. Place unit in a secure place to avoid inadvertent use by children. During mobile operation, NEVERplace the transceiver where air bag deployment may be obstructed. During mobile operation, DO NOTplace the transceiver where hot or cold air blows directly onto…

Text truncated - open the document above for the full version.

November 8, 2005 AmericanTCB, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 Subject: Certification Testing in accordance with FCC CFR 47, Part 15, Subpart B - Scanning Receivers Operating in the Frequency Bands 30 kHz -199.999999 MHz and 400-470 MHz Product: HF/VHF/UHF All Mode Transceiver Model No.: IC-7000 FCC ID: AFJ242700 Dear Sir/Madam As appointed agent for ICOM Incorporated, we would like to submit the application for FCC certification of the above product. Please review all files uploaded to AmericanTCB electronic filing site. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 SL2-IN-E-1119R 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

HF/VHF/UHF All Mode Transceiver Model No.: IC-7000 FCC ID: AFJ242700 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku Osaka, Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 15, Subpart B Scanning Receivers Operating in the Frequency Bands 30 kHz – 199.999999 MHz and 400-470 MHz UltraTech's File No.: ICOM-118F15B121 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: November 8, 2005 Report Prepared by: Dan Huynh Issued Date: November 8, 2005 Tested by: Wayne Wu, EMI/RFI Technician Test Dates: October 11 - November 7, 2005 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] 2 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 00-034 FCC Part 15, Subpart B, Part 15.121 Contents i HF/VHF/UHF All Mode Transceiver, Model IC-7000 FCC ID: AFJ242700 ULTRATECH GROUP OF LABS File #: ICOM-118F15B121 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 8, 2005 Tel.: 905-829-1570, Fax. : 905-829-8050 All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST .......................................................................................................................................1 EXHIBIT 2. INTRODUCTION .........................................................................................................................................................2 2.1. SCOPE .........................................................................................................................................................................................2 2.2. RELATED SUBMITTAL(S)/GRANT(S)....................................................................................................................................2 2.3. NORMATIVE REFERENCES ....................................................................................................................................................2 EXHIBIT 3. PERFORMANCE ASSESSMENT ..............................................................................................................................3 3.1. CLIENT INFORMATION ...........................................................................................................................................................3 3.2. EQUIPMENT UNDER TEST (EUT) INFORMATION..............................................................................................................3 3.3. EUT’S TECHNICAL SPECIFICATIONS...................................................................................................................................4 3.4. LIST OF EUT’S PORTS..............................................................................................................................................................4 3.5. ANCILLARY EQUIPMENT .......................................................................................................................................................4 3.6. DRAWING OF TEST SETUP .....................................................................................................................................................5 EXHIBIT 4. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS................................................2 4.1. CLIMATE TEST CONDITIONS................................................................................................................................................2 4.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS ..............................................................2 EXHIBIT 5. SUMMARY OF TEST RESULTS...............................................................................................................................7 5.1. LOCATION OF TESTS...............................................................................................................................................................7 5.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ...............................................................................7 5.3. MODIFICATIONS REQUIRED FOR COMPLIANCE ..............................................................................................................7 EXHIBIT 6. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ...............................................8 6.1. TEST PROCEDURES .................................................................................................................................................................8 6.2. MEASUREMENT UNCERTAINTIES ..................................................................................................... ..................................8 6.3. MEASUREMENT EQUIPMENT USED ....................................................................................................................................8 6.4. POWER LINE CONDUCTED EMISSIONS [§ 15.107(a)].........................................................................................................9 6.5. RADIATED EMISSIONS FROM CLASS B UNINTENTIONAL RADIATORS (DIGITAL DEVICES) [§ 15.109(a)].........12 6.6. RECEIVER SPURIOUS/HARMONIC RADIATED EMISSIONS [§ 15.109(a)] .....................................................................15 6.7. RECEIVER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§15.111(a)] ...............................18 6.8. REQUIREMENTS FOR SCANNING RECEIVERS [§ 15.121] ....................................................…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS Icom Incorporated HF/VHF/UHF All Mode Transceiver, Model IC-7000 FCC ID: AFJ242700 A1 - 1 Power Line Conducted Emission ANNEX 1 - TEST SETUP PHOTOGRAPHS Icom Incorporated HF/VHF/UHF All Mode Transceiver, Model IC-7000 FCC ID: AFJ242700 A1 - 2 Power Line Conducted Emission ANNEX 1 - TEST SETUP PHOTOGRAPHS Icom Incorporated HF/VHF/UHF All Mode Transceiver, Model IC-7000 FCC ID: AFJ242700 A1 - 3 Radiated Emission at 3 Meters Distance ANNEX 1 - TEST SETUP PHOTOGRAPHS Icom Incorporated HF/VHF/UHF All Mode Transceiver, Model IC-7000 FCC ID: AFJ242700 A1 - 4 Radiated Emission at 3 Meters Distance
