AFJ262700FRS UHF FM Transceiver

INSTRUCTION MANUAL FRS UHF FM TRANSCEIVER i4088A This device complies with Part 15 of the FCC rules. Oper-ation is subject to the following two conditions: (1) This de-vice may not cause harmful interference, and (2) thisdevice must accept any interference received, including in-terference that may cause undesired operation. IC-4088A_3_Draft.qxd 03.7.16 21:05 Page A (1,1) i Safety Training InformationYour FRS radio generates RF electromagnetic energy during trans-mit mode. This radio is intended for use by “General Population” inuncontrolled environment.This radio has been tested and complies with the FCC RF expo-sure limits for “General population.” In addition, your Icom radiocomplies with the following Standards and Guidelines with regard toRF energy and electromagnetic energy levels and evaluation ofsuch levels for exposure to humans: • FCC OET Bulletin 65 Edition 01-01 Supplement C, Evaluating Compliance with FCC Guidelines for Human Exposure to RadioFrequency Electromagnetic Fields. • American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to Human Exposure toRadio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. • American National Standards Institute (C95.3-1992), IEEE Rec- ommended Practice for the Measurement of Potentially Haz-ardous Electromagnetic Fields- RF and Microwave. • The following accessories are authorized for use with this prod- uct. Use of accessories other than those specified may result inRF exposure levels exceeding the FCC requirements for wire-less RF exposure.; Belt Clip, Rechargeable Ni-Cd Battery Pack(BP-202), Speaker microphones (HM-46/HM-75A/HM-131),Earphone microphone (HM-128), Headset (HS-85) andVOX/PTT case (VS-1) + Microphones (HS-94/HS-95/HS-97). IC-4088A_3_Draft.qxd 03.7.16 21:05 Page i (1,1) ii fety Training Information To ensure that your expose to RF electromagnetic energy iswithin the FCC allowable limits for general population/uncon-trolled use, always adhere to the following guidelines: • DO NOT transmit for more than 50% of total radio use time (“50% duty cycle”). Transmitting more than 50% of the time cancause FCC RF exposure compliance requirements to be ex-ceeded. The radio is transmitting when the “TX indicator” lightsred. You can cause the radio to transmit by pressing the "PTT"switch. The information listed above provides the user with the informationneeded to make user aware of RF exposure, and what to do to as-sure that this radio operates with the FCC RF exposure limits of thisradio.SUPPLIED ACCESSORY • Belt clip ....................................... 1 Icom, Icom Inc. and the are registered trademarks of Icom Incor- porated (Japan) in the United States, the United Kingdom, Germany,France, Spain, Russia and/or other countries. IC-4088A_3_Draft.qxd 03.7.16 21:05 Page ii (1,1) iii IMPORTANTREAD ALL INSTRUCTIONS carefully and completely before using the transceiver.SAVE THIS INSTRUCTION MANUAL— This instruction man- ual contains important operating instructions for the transceiver.PRECAUTIONR DANGER! NEVER operate the transceiver near un- shielded electrical blasting caps or in an explosive atmosphere. R WARNING! NEVER hold the transceiver so that the antenna is very close to, or touching exposed parts of the body,especially the face or eyes, while transmitting. The transceiverwill perform best if the microphone is 2 to 4 in. (5 to 10 cm)away and the transceiver is vertical. R WARNING! NEVER operate the transceiver with a headset or other audio accessories at high volume levels. Hear-ing experts advise against continuous high volume operation. Ifyou experience a ringing in your ears, reduce the volume or dis-continue use. NEVER attempt to charge alkaline cell batteries. Be aware that external DC power connections will charge batteries insidethe battery case. This will damage not only the battery case butalso the transceiver. DO NOT push the PTT when not actually desiring to trans- mit. IC-4088A_3_Draft.qxd 03.7.16 21:05 Page iii (1,1) iv PRECAUTION— continued USE the optional AC adapter or cigarette lighter cable only for both operating the transceiver and charging the battery. Othermanufacturer’s AC adapter, cigarette lighter cable or DC powercable with external power supply may damage the transceiver.Place the unit in a secure place to avoid inadvertent use by chil-dren. AVOID using or placing the transceiver in direct sunlight or in areas with temperatures below –4 ̊F (–20°C) or above +122 ̊F(+50°C).The use of non-Icom battery packs/chargers may impair trans-ceiver performance and invalidate the warranty.Even when the transceiver power is OFF, a slight current stillflows in the radio. Remove the alkaline cells or battery packfrom the transceiver when not using it for a long time. Other-wise, the installed batteries will become exhausted. FCC WARNING: NEVER open the transceiver’s case to make any internal adjustments, changes or modifications by a personwho not expressly approved by Icom Inc., could void your au-thority to operate this transceiver under FCC regulations. Any transceiver’s adjustments, replacement must be made by aqualified technician using the proper test equipment. IC-4088A_3_Draft.qxd 03.7.16 21:05 Page iv (1,1) v TABLE OF CONTENTSSafety Training Information ............................................................ iSUPPLIED ACCESSORY ............................................................... iiIMPORTANT .............................................................................. iiiPRECAUTION ........................................................................ iii–ivTABLE OF CONTENTS ............................................................... v1 PREPARATION ..................................................................... 1  Belt clip attachment ............................................................... 1  Battery installation ............................................................... 1 2 PANEL DESCRIPTION ...............................…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 10, 2003 RE: Icom Incorporated FCC ID: AFJ262700 I have a few comments on the above referenced Application. 1) Please provide: a) DC voltages & /currents applied into the several elements of the final radio frequency amplifying device for normal operation over the power range. b) Parts List for this device. c) Description of all circuitry and devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation, and for limiting power. 2) Please explain how the device is compliant with 95.193(b). Be sure to include an explanation of the various tones (including ATS ) and how these are considered compliant. 3) Please explain how the device is compliant with 95.647 4) The occupied bandwidth should be measured to the outside of the emissions noted. Please correct. 5) The emissions designator in the users manual does not match the 731 form. Please explain and correct the exhibits. 6) Specific users manual information specified by 95.653 does not appear to be in the users manual. Please explain and/or correct the users manual. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

From: Mr. Tri Luu (uelrfiatcb) In reply to your recent questions: 1) Please provide: a) DC voltages & /currents applied into the several elements of the final radio frequency amplifying device for normal operation over the power range. DC Voltage (V) Transmitter Current (mA) Receiver Current (mA) 7 279 47 6 287 47 5 299 47 4 310 47 3.2 210 45 b) Parts List for this device. See Parts List uploaded to ATCB electronic filing site. c) Description of all circuitry and devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation, and for limiting power. See Circuit Description uploaded to ATCB electronic filing site. 2) Please explain how the device is compliant with 95.193(b). Be sure to include an explanation of the various tones (including ATS) and how these are considered compliant. See Icom explanation uploaded to ATCB electronic filing site and revised manual. <file name: “TransmitterOfSubAudibleTone_IC-4088A.pdf”> 3) Please explain how the device is compliant with 95.647 See Icom explanation uploaded to ATCB electronic filing site. <file name: “TransmitterAntennas_IC-4088A.pdf”> 4) The occupied bandwidth should be measured to the outside of the emissions noted. Please correct. See revised manual. To: <[email protected]> Cc: <[email protected]>, <[email protected]> Subject: MESSAGE attached to AFJ262700_ATCB000486 by uelrfiatcb Page 1 of 2In 6/26/2003Printed for "Timothy R. Johnson" <[email protected]> 5) The emissions designator in the users manual does not match the 731 form. Please explain and correct the exhibits. See revised manual (page 22) for emissions designator correction. 6) Specific users manual information specified by 95.653 does not appear to be in the users manual. Please explain and/or correct the users manual. See revised manual. Page 2 of 2In 6/26/2003Printed for "Timothy R. Johnson" <[email protected]>

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 26, 2003 RE: Icom Incorporated FCC ID: AFJ262700 I have a few comments on the above referenced Application. 1) The explanation regarding compliance 95.193(b) mentions that the ATS tone is a 10 second audible tone. The information in the manual (page 20) states that this signal gets sent automatically every 60 seconds. Since this is automatically generated for 10 seconds every 60 seconds and is audible, it appears that this mode can interfere with the requirement given in 95.193(d). Please provide further information to explain how the ATS function is considered compliant to the rules. For instance, does the unit check for open channel prior to sending the ATS tone, etc. 2) The answer to previous question 4 does not appear to have been addressed. The occupied bandwidth shown in the test report (pages 20 & 21 and reported in 6.8.6) should have been measured to the outside of the emissions sidelobes at the level noted. Please correct. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

From: Mr. Tri Luu (uelrfiatcb) RE: Icom Incorporated FCC ID: AFJ262700 In reply to your recent questions: 1) The explanation regarding compliance 95.193(b) mentions that the ATS tone is a 10 second audible tone. The information in the manual (page 20) states that this signal gets sent automatically every 60 seconds. Since this is automatically generated for 10 seconds every 60 seconds and is audible, it appears that this mode can interfere with the requirement given in 95.193(d). Please provide further information to explain how the ATS function is considered compliant to the rules. For instance, does the unit check for open channel prior to sending the ATS tone, etc. See ICOM reply uploaded to ATCB website <File Name: “FCCRuleParts95.193(d)_IC-4088A.pdf”> 2) The answer to previous question 4 does not appear to have been addressed. The occupied bandwidth shown in the test report (pages 20 & 21 and reported in 6.8.6) should have been measured to the outside of the emissions sidelobes at the level noted. Please correct. The 99% occupied bandwidth shown on pages 20 & 21 were measured using the AUTOMATIC (99% bandwidth) built in function/feature of the spectrum analyzer. To: <[email protected]> Cc: <[email protected]>, <[email protected]> Subject: MESSAGE attached to AFJ262700_ATCB000486 by uelrfiatcb 6/27/2003file://C:\DOCUME~1\TIMOTH~1.JOH\LOCALS~1\Temp\eud184.htm

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 27, 2003 RE: Icom Incorporated FCC ID: AFJ262700 I have a few comments on the above referenced Application. 1) Below are proposed grant conditions. Note that according to our procedures, we must evaluate SAR for TX's if certain user to antenna distances exist during expected use and the conducted or EIRP power exceeds certain values. For instance for this particular device, if the conducted or EIRP values are > 128 mW (60/freq) with < 2.5 cm spacing in body worn configurations, SAR must be evaluated. For > 2.5 cm spacing, if the conducted or EIRP values are > 257 mW (120/freq), then SAR must be evaulated. For this radio the conducted power was highest. Assuming up to a 50% duty cycle for PTT radios, the conducted value becomes 50% of 488 mW = 244 mW. This value is just under the 257 mW threshold for devices that meet the 2.5 cm distance. From drawings in the manual, it appears that a 2.5 cm distance will exist between the user and antenna if a belt clip is used. Therefore please confirm if in a body worn confirmation the use of the belt clip provides 2.5 cm spacing from the body by providing a photograph or drawing as appropriate that shows this distance is met. Also, please note that even if the device does meet the 2.5 cm requirement, if the FCC has any concerns during an audit of this application they could still require review of the SAR results (full review of report, calibration information, verification information, photographs, measurement uncertainty, etc.). If the belt clip does not provide the 2.5 cm spacing, SAR results are required to be submitted and reviewed. Please note that review of SAR results are subject to additional review costs. Proposed Grant Conditions: Power Output listed is ERP. This device and its antenna must operate with a separation distance of at least 2.5 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This device must transmit with an operational-based push-to-talk duty cycle not to exceed 50%. End-users must be provided with specific operating instructions for satisfying RF exposure compliance. 2) FYI. For future applications, please ensure that the occupied bandwidth test measures to the outside lobes of the waveform. Your plots reported 8.85 kHz occupied bandwidth which was measured using the automatic measurement feature of the spectrum analyzer. Carefully evaluation of your plots show that by measuring to the outside lobes yields about 10.2 - 10.4 kHz, which agrees with Carson's Rule of 11.0 kHz. For FCC submittals the occupied bandwidth measurements are typically compared to Carson's Rule to assure that they agree. Also, please note that the FCC has expressed concern for use of the automatic feature when it does not measure to the outside of the lobes. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2June 27, 2003 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Hi Mr. Johnson, I will upload the SAR test report to so that we can have the EUT approved with SAR without a restriction of 2.5 cm distance. Please proceed with your SAR assessment ASAP. Thanks. Tri Luu

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 9, 2003 RE: Icom Incorporated FCC ID: AFJ262700 I have a few comments on the above referenced Application. This response addresses the SAR report recently uploaded. 1) The FCC ID given throughout the SAR report does not match the information given in the filing. Please adjust. 2) The SAR scans do not appear to have covered the entire antenna area. Scans should have been performed over the whole antenna and device to ensure that no secondary hot spots occurred in these areas. Was this done during prescans? Please explain. 3) Please provide a justification for not providing all SAR plots for each configuration tested on page 54 (i.e. if they had similar SAR distributions, a plot of the highest SAR for each test configuration should be sufficient; otherwise additional plots should be included to document the different SAR distributions – purpose is to identify peak locations relative to device and phantom). 4) The SAR test report should include: a) statement of compliance with FCC RF exposure (§2.1093) b) mobile or portable transmitter device category identified c) test device is production unit or identical prototype (47 CFR §2.908)? d) brief description handset holders 5) The user manual does not appear to contain any specific information regarding SAR compliance. If it is expected that the users manual will be updated for this information, please provide an updated users manual for review. 6) Testing appears to have taken place over a 2 day period (5/12 & 5/13). Note that dipole validation test results for each date of device testing must be provided, but it appears to only have been provide for 5/12. 7) The test date on the cover of the report 5/14 does not appear to match the actual test dates. Please correct. 8) P1528 specifies the use of a phantom @ 450 MHz to be 700x600mm with a thickness of 6.3 mm as shown in table 8.2. FCC information from various training has stipulated L and W at >= 0.6 λ (apprx. 400 mm at 450 MHz) and < 6.5 ± 0.2 mm with < 0.5% sagging. It appears that the phantom used was 2 mm thickness. Please explain how compliance with the sag requirements if the phantom was achieved with only a 2 mm thickness. 9) The calibration of the probe does not appear to have shown boundary effect error measurements or measurement uncertainty issues addressed in its calibration. Please provide this information. 10) Please provide further information regarding the reference dipole (i.e. manufacturer, model, serial, etc.). Also, please provide a plot of return loss data for the dipole used. Is original manufacturer calibration information available? 11) Although the dipole verification may have been performed for 450 MHz, the FCC asks to provide the liquid dielectric parameters measured at device mid-band frequencies as well for each day of testing. 12) It appears as if probe boundary effect compensation was not used (section 5.6.4.4). The FCC has specified that when probe boundary effect compensation is not used the probe tip should be positioned at least half a probe tip diameter from the phantom surface during area and zoom scans. It appears that the closest measurements were made at 4mm (page 60) while the probe diameter is also 4 mm (page 62). Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2July 9, 2003 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Re: ICOM Incorporated FCC ID: AFJ262700 In reply to your recent questions: 1) The FCC ID given throughout the SAR report does not match the information given in the filing. Please adjust A1) See revised SAR report 2) The SAR scans do not appear to have covered the entire antenna area. Scans should have been performed over the whole antenna and device to ensure that no secondary hot spots occurred in these areas. Was this done during prescans? Please explain. A2) Since the D.U.T. power drift was found to be significant over the time, we need to minimize the scan area in order to minimize the effect. BUT prescan for the entire D.U.T. was performed prior to the series of scans in order to identify the hot spot and to check the existence of the second peak as well. 3) Please provide a justification for not providing all SAR plots for each configuration tested on page 54 (i.e. if they had similar SAR distributions, a plot of the highest SAR for each test configuration should be sufficient; otherwise additional plots should be included to document the different SAR distributions - purpose is to identify peak locations relative to device and phantom). A3) In our previous report formats, we used to include all the plots and test results into our test reports. But it happened to increase the size of test report unnecessarily in a certain case where the number of combinations of test configurations resulted in many prescans (multiplying by number of frequencies sometime resulted in more than a hundred scans). As a result we had changed our report format so that we reported the complete set of results and plots for the worst case configuration and only the SAR number for prescans as long as the distributions are similar among them (only accessories were permutated), the FCC and other TCBs have accepted all of our applications in this manner. 4) The SAR test report should include: a) statement of compliance with FCC RF exposure (?.1093) b) mobile or portable transmitter device category identified c) test device is production unit or identical prototype (47 CFR ?.908)? d) brief description handset holders A4) a) See certificate b) See certificate and page 4; Portable c) See page 5; Production unit d) See page 47; The handset holders is mainly made of PVC and contains no metallic component at all in order to minimize field perturbation. Velcro and elastic band were used to attach the DUT on the plate of handset holder. 5) The user manual does not appear to contain any specific information regarding SAR compliance. If it is expected that the users manual will be updated for this information, please provide an updated users manual for review. A5) See revised user manual. 6) Testing appears to have taken place over a 2 day period (5/12 & 5/13). Note that dipole validation test results for each date of device testing must be provided, but it appears to only have been provide for 5/12. A6) Dipole verification can only be carried out on brain tissue since there are no target validation values for muscle tissue. This being the case, the dipole validation must first be carried out on the brain tissue even though that is not the tissue being measured. It is then required to change the tissue in the phantom to body tissue to carry out the SAR measurements. The dipole validation can take 1/2 day to perform with the tissue change out so it becomes impractical at this point in time to carry it out daily. This will change as soon as the IEEE SCC34-2 committee provides dipole validation targets for muscle tissue. As such, the FCC and the other TCB's have not been identifying this to us as an issue. 7) The test date on the cover of the report 5/14 does not appear to match the actual test dates. Please correct. A7) See revised report 8) P1528 specifies the use of a phantom @ 450 MHz to be 700x600mm with a thickness of 6.3 mm as shown in table 8.2. FCC information from various training has stipulated L and W at >= 0.6 ?(apprx. 400 mm at 450 MHz) and < 6.5 ?0.2 mm with < 0.5% sagging. It appears that the phantom used was 2 mm thickness. Please explain how compliance with the sag requirements if the phantom was achieved with only a 2 mm thickness. A8) The flat phantom we employ is designed to have Plexiglas supports inserted lengthwise on either side of the dipole so that the only unsupported portion of the 2mm base is a small section surrounding the dipole antenna. The width of the unsupported bottom is only a couple of cm so the sag from the unsupported section is still well within the requirements of the P1528 standard. 9) The calibration of the probe does not appear to have shown boundary effect error measurements or measurement uncertainty issues addressed in its calibration. Please provide this information. A9) Below 1GHz, thermal calibration is used and care is taken to position the dipole sensors at least on probe diameter away (4mm). In our procedure, we use 6mm displacement to ensure there is no boundary effect compensation required in the thermal calibration. Boundary effect compensation is only required when the probe come closer than 1/2 probe diameter (2mm) with the phantom surface. 10) Please provide further information regarding the reference dipole (i.e. manufacturer, model, serial, etc.). Also, please provide a plot of return loss data for the dipole used. Is original manufacturer calibration information available? A10) The reference dipole was manufactured by UltraTech Labs. according to the guideline on Annex G in IEEE P1528/D1.2, April 21, 2003 standard and Table on pp 47~48 in OET 65 supplement C edition 01-01. Refer to the attached plot of return loss for the dipole used. 450 MHz verification dipole Manufacturer : UltraTech Labs. Model Number : W450 Serial Number : UT-VDP-002-052003 11) Although the dipole verification may have been performed for 450 MHz, the FCC asks to provide the liquid dielectric parameters measured at device mid-band frequencies as well for each day of testing. A11) Tissue par…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 18, 2003 RE: Icom Incorporated FCC ID: AFJ262700 I have a few comments on the above referenced Application. This response addresses the SAR report recently uploaded. 1) FYI....Your previous answer to question 6 states that the FCC and other TCB’s have not been identifying that dipole verifications are necessary on a daily basis. Please note that the FCC has given specific instructions to TCB’s in both training and checklist materials and this is one of the items we are asked to target. Please see attached checklist provided to TCB’s by the FCC. Given the levels of SAR seen for this device, we will go ahead and accept this information for this application. However please note that the FCC could require further testing or information if they deem necessary during any audit review they may perform on this application. Additionally, please note that we have been accepting validations done both in muscle tissue and brain tissue when you can present some type of traceability of the target values (i.e. previous calibration by manufacturer, etc.). It would be best to provide this information in future applications. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

FCC ID Label Serial Number Label *:A Part15 Label is mentioned in the instruction manual.

3 ‘‘ ENTERING THE ADJUSTMENT MODE ¡¡ Turn the transceiver’s power OFF. ™™ While connecting the “TEST” on the MAIN board to “GND”, and then turn power ON. ‘‘ OPERATION ON THE ADJUSTMENT MODE • Change the adjustment item: HM-75A’s [B] key • Change the adjustment value: HM-75A’s [UP]/[DN] keys • Verify the adjustment value: HM-75A’s [A] key • Change the adjustment channel: IC-4088A’s [UP]/[DN] keys • Change the adjustment group: IC-4088A’s [MODE]+ [UP]/[DN] keys ‘‘ ADJUSTMENT ITEMS When entering adjustment mode, displayed adjustment items indicator on the LCD as follow. • Reference frequecy adjustment: Displayed • Output power adjustment: Displayed • FM deviation adjustm…
