AFJ279100VHF Air Band Transceiver

INSTRUCTION MANUAL iA6 iA24 VHF AIR BAND TRANSCEIVER This device complies with Part 15 of the FCCRules. Operation is subject to the conditionthat this device does not cause harmful inter-ference. IC-A24-Nocl.qxd 04.9.1 5:50 PM Page i i SAFETY TRAINING INFORMATION Your Icom radio generates RF electromagnetic energy during transmit mode. This radio is designed for and classified as“Occupational Use Only”, meaning it must be used only dur-ing the course of employment by individuals aware of the haz-ards, and the ways to minimize such hazards. This radio isNOT intended for use by the “General Population” in an un-controlled environment. This radio has been evaluated for compliance at the distance of 2.5 cm withthe FCC RF exposure limits for “Occupational Use Only”. In addition, your Icomradio complies with the following Standards and Guidelines with regard to RFenergy and electromagnetic energy levels and evaluation of such levels for ex-posure to humans: • FCC OET Bulletin 65 Edition 97-01 Supplement C, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electro-magnetic Fields. • American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Elec-tromagnetic Fields, 3 kHz to 300 GHz. • American National Standards Institute (C95.3-1992), IEEE Recommended Practice for the Measurement of Potentially Hazardous ElectromagneticFields– RF and Microwave. • The following accessories are authorized for use with this product. Use of accessories other than those specified may result in RF exposure levelsexceeding the FCC requirements for wireless RF exposure.; Belt Clip (MB-86/103), Rechargeable Ni-MH Battery Pack (BP-210N) and Alkaline Bat-tery Case (BP-208N). To ensure that your expose to RF electromagnetic en-ergy is within the FCC allowable limits for occupationaluse, always adhere to the following guidelines: WARNING • DO NOT operate the radio without a proper antenna attached, as this may damaged the radio and may also cause you to exceed FCC RF exposurelimits. A proper antenna is the antenna supplied with this radio by the man-ufacturer or antenna specifically authorized by the manufacturer for usewith this radio. • DO NOT transmit for more than 50% of total radio use time (“50% duty cycle”). Transmitting more than 50% of the time can cause FCC RF expo-sure compliance requirements to be exceeded. The radio is transmittingwhen “ ” appears on the function display. You can cause the radio to transmit by pressing the “PTT” switch. • ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the body when transmitting and only use the Icom belt-clips which are listed onpage 31 when attaching the radio to your belt, etc., to ensure FCC RF ex-posure compliance requirements are not exceeded. To provide the recipi-ents of your transmission the best sound quality, hold the antenna at least5 cm (2 inches) from your mouth, and slightly off to one side. The information listed above provides the user with the information needed tomake him or her aware of RF exposure, and what to do to assure that this radiooperates with the FCC RF exposure limits of this radio. Electromagnetic Interference/CompatibilityDuring transmissions, your Icom radio generates RF energy that can possiblycause interference with other devices or systems. To avoid such interference,turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such ashospitals and blasting sites. Occupational/Controlled UseThe radio transmitter is used in situations in which persons are exposed asconsequence of their employment provided those persons are fully aware ofthe potential for exposure and can exercise control over their exposure. CAUTION IC-A24-Nocl.qxd 04.9.1 5:50 PM Page ii ii FOREWORDThank you for purchasing this Icom product. The IC-A24/A6VHF AIR BAND TRANSCEIVER is designed and built withIcom’s state of the art technology and craftsmanship. Withproper care this product should provide you with years oftrouble-free operation.IMPORTANTREAD ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This in- struction manual contains important operating instructions forthe IC-A24/A6. EXPLICIT DEFINITIONS SUPPLIED ACCESSORIESAccessories included with the transceiver: Qty. q Antenna .......................................................................... 1 w Belt clip ........................................................................... 1 e Handstrap ....................................................................... 1 r Battery pack* or battery case .......................................... 1 t Wall charger* .................................................................. 1 y Carrying case* ................................................................ 1 u Headset adapter* ........................................................... 1 * The battery pack, wall charger, headset adapter or carrying case may differ depending on version. Some versions do not include abattery pack, wall charger, headset adapter or carrying case. WORD DEFINITION R WARNING CAUTION NOTE Personal injury, fire hazard or electric shock may occur.If disregarded, inconvenience only. No risk of personal injury, fire or electric shock.Equipment damage may occur. qwe t r y u IC-A24-Nocl.qxd 04.9.1 5:50 PM Page iii iii PRECAUTIONSR WARNING! NEVER hold the transceiver so that the antenna is very close to, or touching exposed parts of thebody, especially the face or eyes, while transmitting. Thetransceiver will perform best if the microphone is 5 to 10 cmaway from the lips and the transceiver is vertical.R WARNING! NEVER operate the transceiver with a headset or other audio accessories at high volume levels.Hearing experts advise against continuous high volume op-eration. If you experience a ringing in your ears, reduce thevolume level or dis…

Text truncated - open the document above for the full version.

November 8, 2004 AmericanTCB, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 Subject: Equipment Authorization under FCC 47 CFR, Parts 2 and 87 (Subpart D) - Non-broadcast Aviation Radio Services Operating in the Frequency Band 118-137 MHz. Applicant: ICOM Incorporated Product: VHF Air Band Transceiver Model: IC-A24 / IC-A6 FCC ID: AFJ279100 Dear Sir/Madam, As appointed agent for ICOM Incorporated, we would like to submit the application to AmericanTCB, Inc. for certification of the above product. Please review all files uploaded to AmericanTCB electronic filing site. NOTE: IC-A24 comes with VOR Navigation function and IC-A6 does not. Otherwise, the two models are identical internally. Testing was performed using the IC-A24 to represents the worst case for both models. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH Encl. UltraTech Group of Labs 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] 31040/SIT C-1376 46390-2049 200093-0 2 00-034 SL2-IN-E-1119R

Applicant: ICOM Canada Address: Glenwood Centre 150-6165 Hwy. 17 Delta, BC CANADA, V4K 5B8 Contact Person: Mr. Bob Brunkow Phone #: +1-604-952-4266 FAX #: +1-604-952-0090 Email Address: [email protected] PRODUCT UNDER TEST: VHF Air Band Transceiver MODEL NO.: IC-A24 / IC-A6 IC: 202D-279100 OPERATING FREQUENCY RANGE: 118.000 ~ 136.975 MHz RATED RF OUTPUT POWER: 1.5 W (CW) Conducted DEVICE CATEGORY: Portable EXPOSURE CATEGORY: Occupational/Controlled MAX. PEAK SPATIAL-AVERAGE SAR 1g : 0.21 W/Kg YEAR OF MANUFACTURE: 2004 STANDARD(S) TO WHICH CONFORMITY IS DECLARED: SAR (Specific Absorption Rate) requirements using guidelines established in IEEE C95.1- 1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) • For detailed information please refer to the engineering test report, UltraTech File No.: ICOM-091-SAR, dated November 10, 2004. • I, the undersigned, hereby declare that the equipment as tested is representative within manufacturing tolerance to units. Applicant: Legal Representative in Canada: Signature: Signature: Full Name: Robert W Brunkow Full Name: Robert W Brunkow Title: President Title: President Place:Delta, BC Place: Delta, BC

VHF Air Band Transceiver Model No.: IC-A24 / IC-A6 FCC ID: AFJ279100 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku Osaka Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Parts 2 and 87 (Subpart D) – Aviation Services UltraTech's File No.: ICOM-091F87 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: November 8, 2004 Report Prepared by: Dan Huynh Issued Date: November 8, 2004 Tested by: Wayne Wu, EMI/RFI Technician Hung Trinh, EMI/RFI Technician Test Dates: October 1-25, 2004 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] 2 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 00-034 FCC Parts 2 and 87, Subpart D, Non-Broadcast Aviation Radio Services Contents i VHF Air Band Transceiver, Model(s): IC-A24 / IC-A6 FCC ID: AFJ279100 ULTRATECH GROUP OF LABS File #: ICOM-091F87 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 8, 2004 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST ..........................................................................................................................................1 EXHIBIT 2. INTRODUCTION ............................................................................................................................................................2 2.1. SCOPE ............................................................................................................................................................................................2 2.2. RELATED SUBMITTAL(S)/GRANT(S).......................................................................................................................................2 2.3. NORMATIVE REFERENCES .......................................................................................................................................................2 EXHIBIT 3. PERFORMANCE ASSESSMENT .................................................................................................................................3 3.1. CLIENT INFORMATION ..............................................................................................................................................................3 3.2. EQUIPMENT UNDER TEST (EUT) INFORMATION.................................................................................................................3 3.3. EUT’S TECHNICAL SPECIFICATIONS......................................................................................................................................4 3.4. LIST OF EUT’S PORTS.................................................................................................................................................................4 EXHIBIT 4. EUT OPERATING CONDITION AND CONFIGURATIONS DURING TESTS.....................................................5 4.1. CLIMATE TEST CONDITIONS ...................................................................................................................................................5 4.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS.................................................................5 EXHIBIT 5. SUMMARY OF TEST RESULTS..................................................................................................................................6 5.1. LOCATION OF TESTS..................................................................................................................................................................6 5.2. APPLICABILITY & SUMMARY OF EMISSION TEST RESULTS............................................................................................6 5.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES............................................................6 5.4. DEVIATION OF STANDARD TEST PROCEDURES .................................................................................................................6 EXHIBIT 6. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ..................................................7 6.1. TEST PROCEDURES ....................................................................................................................................................................7 6.2. MEASUREMENT UNCERTAINTIES ..........................................................................................................................................7 6.3. MEASUREMENT EQUIPMENT USED .......................................................................................................................................7 6.4. ESSENTIAL/PRIMARY FUNCTIONS AS DECLARED BY THE MANUFACTURER ............................................................7 6.5. RF POWER OUTPUT [§§ 2.1046 & 87.131] ...................................................................................... ...........................................8 6.6. MODULATION CHARACTERISTICS - AUDIO FREQUENCY RESPONSE [§§ 2.1047(a) & 87.141(f)].............................. 10 6.7. MODULATION CHARACTERISTICS – MODULATION LIMITING [§§ 2.1047(b) & 87.141]............................................. 13 6.8. OCCUPIED BANDWIDTH AND EMISSION LIMITATIONS [§§ 2.1049, 87.135 & 87.139]..................................................17 6.9. SPURIOUS EMISSIONS AT ANTENNA TERMI…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS (Radiated Emissions at 3 Meters Distance) Icom Incorporated VHF Transceiver, Model(s) IC-A24 / IC-A6 FCC ID: AFJ279100 IC: 202D-279100 A1 - 1 Radiated Emissions Orthogonal Position #1 ANNEX 1 - TEST SETUP PHOTOGRAPHS (Radiated Emissions at 3 Meters Distance) Icom Incorporated VHF Transceiver, Model(s) IC-A24 / IC-A6 FCC ID: AFJ279100 IC: 202D-279100 A1 - 2 Radiated Emissions Orthogonal Position #1 ANNEX 1 - TEST SETUP PHOTOGRAPHS (Radiated Emissions at 3 Meters Distance) Icom Incorporated VHF Transceiver, Model(s) IC-A24 / IC-A6 FCC ID: AFJ279100 IC: 202D-279100 A1 - 3 Radiated Emissions Orthogonal Position #2 ANNEX 1 - TEST SETUP PHOTOGRAPHS (Radiated Emissions at 3 Meters Distance) Icom Incorporated VHF Transceiver, Model(s) IC-A24 / IC-A6 FCC ID: AFJ279100 IC: 202D-279100 A1 - 4 Radiated Emissions Orthogonal Position #3
