AFJ288000Communications Receiver

ICOM Incorporated
Communications Receiver - FCC ID AFJ288000 - ICOM Incorporated
Click to zoom

Application Details

Equipment Class
CSR - Scanning Receiver
Date of Grant
Jan 26, 2006
Application Purpose
Original Equipment
Date of Application
Jan 26, 2006
Equipment Note
Communications Receiver
Frequency Range
0.01000000 - 1000.00000000
Company
ICOM Incorporated
Country
Japan

Documents & Files

Select a file to view

Users Manual

↗
↗

Attestation Statements

↗

Cover Letter(s)

↗
↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

INSTRUCTION MANUAL New2001 iR1500COMMUNICATIONS RECEIVER This device complies with Part 15 of the FCC rules. Operation is sub-ject to the following two conditions: (1) This device may not causeharmful interference, and (2) this device must accept any interferencereceived, including interference that may cause undesired operation. ! IC-R1500.qxd 05.10.21 10:07 AM Page A (1,1) i New2001 FOREWORDThank you for purchasing this Icom product. The IC-R1500COMMUNICATIONS RECEIVER is designed and built with Icom’s state of the art technology and craftsmanship. With proper care,this product should provide you with years of trouble-free oper-ation. We want to take a couple of moments of your time to thankyou for making your IC-R1500 your radio of choice, and hopeyou agree with Icom’s philosophy of “technology first.” Manyhours of research and development went into the design ofyour IC-R1500. DD FEATURES ❍ Wide frequency coverage with all mode re-ceive ❍ Real-time bandscope function ❍ IF shift function function ❍ ANF and NR functions available (Only when the DSP unit is installed.) IMPORTANTREAD ALL INSTRUCTIONS carefully and completely before using the receiver. SAVE THIS INSTRUCTION MANUAL— This in- struction manual contains important operating instructions forthe IC-R1500. EXPLICIT DEFINITIONS WORD DEFINITION R WARNING! CAUTION NOTE Personal injury, fire hazard or electric shockmay occur.Equipment damage may occur.Recommended for optimum use. No risk ofpersonal injury, fire or electric shock. Icom, Icom Inc. and the logo are registered trademarks of Icom Incor- porated (Japan) in the United States, the United Kingdom, Germany, France,Spain, Russia and/or other countries. ! IC-R1500.qxd 05.10.21 10:07 AM Page i (1,1) ii New2001 R WARNING RF EXPOSURE! This device emits Radio Frequency (RF) energy. Extreme caution should be observed whenoperating this device. If you have any questions regarding RF expo-sure and safety standards please refer to the Federal Communica-tions Commission Office of Engineering and Technology’s report onEvaluating Compliance with FCC Guidelines for Human Radio fre-quency Electromagnetic Fields (OET Bulletin 65). R WARNING! NEVER connect the receiver to an AC outlet. This may pose a fire hazard or result in an electric shock.R WARNING! NEVER operate the receiver while driving a vehicle. Safe driving requires your full attention—anything less mayresult in an accident. NEVER connect the receiver to a power source of more than 16 V DC. This will damage the receiver. NEVER connect the receiver to a power source using reverse po- larity. This will damage the receiver.NEVER cut the DC power cable between the DC plug and fuse holder. If an incorrect connection is made after cutting, the receivermay be damaged. NEVER expose the receiver to rain, snow or any liquids. The re- ceiver may be damaged. NEVER operate or touch the receiver with wet hands. This may result in an electric shock or damage the receiver. NEVER place the receiver where normal operation of the vehicle may be hindered or where it could cause bodily injury. NEVER let objects impede the operation of the cooling fan on the rear panel. AVOID using or placing the receiver in direct sunlight or in areas with temperatures below –10°C (+14°F) or above +60°C (+140°F). BE CAREFUL! The receiver will become hot when operating it continuously for long periods.AVOID setting the receiver in a place without adequate ventilation. Heat dissipation may be affected, and the receiver may be damaged. AVOID the use of chemical agents such as benzine or alcohol when cleaning, as they can damage the receiver’s surfaces. USE Icom microphones only (supplied or optional). Other manu- facturer’s microphones have different pin assignments and may dam-age the receiver if attached.For U.S.A. onlyCAUTION: Changes or modifications to this device, not ex- pressly approved by Icom Inc., could void your authority tooperate this device under FCC regulations. PRECAUTION ! IC-R1500.qxd 05.10.21 10:07 AM Page ii (1,1) iii New2001 TABLE OF CONTENTS SUPPLIED ACCESSORIESq Antenna ...............................................................1 w AC adapter .........................................................1 e USB cable .........................................................1 r CD .....................................................................1 t Leg pad ...............................................................1 FOREWORD ........................................................................................... iIMPORTANT ............................................................................................ iEXPLICIT DEFINITIONS ......................................................................... iPRECAUTION ........................................................................................ iiSUPPLIED ACCESSORIES .................................................................. iiiTABLE OF CONTENTS ......................................................................... iiiQUICK REFERENCE GUIDE ............................................................. I–X  Installation ....................................................................................... I  Your first contact .......................................................................... VII  Repeater operation ....................................................................... IX  Programming memory channels..................................................... X 1 PANEL DESCRIPTION ................................................................. 1–5  Front panel— controller ................................................................. 1  Function display ............................................................................. 3  Rear panel ..................................................................................... 5 2 SETTING A FREQUENCY ............................................................ 6–8  Turning power ON/OFF …
