AFJ292702UHF Transceiver

INSTRUCTION MANUAL This device complies with Part 15 of the FCC Rules. Operationis subject to the condition that this device does not cause harmfulinterference. iF3023T/SiF3021T/SVHF TRANSCEIVERS The photo shows the 10-keyversion VHF transceiver. iF4023T/SiF4021T/SUHF TRANSCEIVERS !IC-F3021_F4021-1.qxd 06.4.12 3:25 PM Page a (1,1) PRECAUTIONS i R CAUTION! NEVER hold the transceiver so that the antenna is very close to, or touching exposed parts of thebody, especially the face or eyes, while transmitting. Thetransceiver will perform best if the microphone is 2 to 4 in. (5to 10 cm) away from the lips and the transceiver is vertical. R CAUTION! NEVER operate the transceiver with a headset or other audio accessories at high volume levels. R CAUTION! NEVER short the terminals of the bat- tery pack. DO NOT push [PTT] when not actually desiring to trans- mit. AVOID using or placing the transceiver in direct sunlight or in areas with temperatures below +22°F (–30°C) or above+140°F (+60°C).The basic operations, transmission and reception of the trans-ceiver are guaranteed within the specified operating temper-ature range. However, the LCD display may not be operatecorrectly, or show an indication in the case of long hours ofoperation, or after being placed in extremely cold areas. WORD DEFINITION R WARNING Personal injury, fire hazard or electric shockmay occur. CAUTION Equipment damage may occur. NOTE If disregarded, inconvenience only. No riskof personal injury, fire or electric shock. READ ALL INSTRUCTIONS carefully and com- pletely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This instruction manual contains important operating instructionsfor the IC-F3021T/S , IC-F3023T/S VHF TRANSCEIVERS and the IC-F4021T/S , IC-F4023T/S UHF TRANSCEIVERS . IMPORTANTIcom, Icom Inc. and the logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom, Germany,France, Spain, Russia and/or other countries.EXPLICIT DEFINITIONS !IC-F3021_F4021-1.qxd 06.4.12 3:25 PM Page i (1,1) ii DO NOT modify the transceiver for any reason. KEEP the transceiver from the heavy rain, and Never immerse it in the water. The transceiver construction is water resistant , not waterproof. The use of non-Icom battery packs/chargers may impairtransceiver performance and invalidate the warranty.For U.S.A. onlyCAUTION: Changes or modifications to this transceiver, not expressly approved by Icom Inc., could void your authority tooperate this transceiver under FCC regulations. !IC-F3021_F4021-1.qxd 06.4.12 3:25 PM Page ii (1,1) iii IMPORTANT ........................................................................ iEXPLICIT DEFINITIONS ..................................................... iPRECAUTIONS ................................................................... iTABLE OF CONTENTS ...................................................... iii1 ACCESSORIES ......................................................... 1–3  Supplied accessories ................................................. 1  Accessory attachments .............................................. 1 2 PANEL DESCRIPTION ............................................. 4–9  Front panel ................................................................. 4  Function display ......................................................... 6  Programmable function keys ..................................... 7 3 BASIC OPERATION ............................................. 10–15  Turning power ON .................................................... 10  Channel selection ..................................................... 11  Call procedure ........................................................... 11  Receiving and transmitting........................................ 12  User Set mode .......................................................... 14  Emergency transmission .......................................... 14  Scrambler function .................................................... 14  Stun function ............................................................ 15  Priority A channel selection ...................................... 15 4 BATTERY CHARGING .......................................... 16–20  Caution ..................................................................... 16  Optional battery chargers ......................................... 18 5 BATTERY CASE ......................................................... 21  Optional battery case (BP-240) ................................ 21 6 OPTIONAL SWIVEL BELT CLIP .......................... 22–23  MB-93 contents ........................................................ 22  Attaching .................................................................. 22  Detaching ................................................................. 23 7 OPTIONS ............................................................... 24–258 SAFETY TRAINING INFORMATION .................... 26–27 TABLE OF CONTENTS !IC-F3021_F4021-1.qxd 06.4.12 3:25 PM Page iii (1,1) 1 1 ACCESSORIES 1  Supplied accessories NOTE: Some accessories are not supplied with depending on versions.  Accessory attachments D Flexible antenna Connect the supplied flexible anten-na to the antenna connector. CAUTION! • NEVER HOLD by the antenna when carrying the transceiver. • Transmitting without an antenna may damage the transceiver. Flexible antenna Battery pack Belt clip Unit cover(double-sided tape)* Jack cover(with screws) *Use the unit cover as a spare. Ask your dealer for details. !IC-F3021_F4021-1.qxd 06.4.12 3:25 PM Page 1 (1,1) 2 1 ACCESSORIES ï Battery pack To attach the battery pack:Slide the battery pack in the direction of the arrow ( q ), then lock it with the battery release button.• Slide the battery pack until the battery release button makes a ‘click’ sound. To release the battery pack:Slide the battery release button in the direction of the arrow( w ) as shown below. The battery pack is then released. NEVER…

Text truncated - open the document above for the full version.

July 11, 2006 AmericanTCB, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 Subject: Equipment Authorization under FCC 47 CFR, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the Frequency Band 450-520 MHz (25 KHz, 12.5 KHz and 6.25 KHz Channel Spacings). Applicant: ICOM Incorporated Product: UHF Transceiver Model: IC-F4021T/S FCC ID: AFJ292702 Dear Sir/Madam, As appointed agent for ICOM Incorporated, we would like to submit the application to Federal Communications Commission for certification of the above product. Please review all files uploaded to ATCB electronic filing site. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.: 1-877-747-6381 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering UltraTech Group of Labs Ultratech’s Accreditations: 0685 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

SERIAL LOCATION CAUTION LABEL FCC ID LABEL

26 8 SAFETY TRAINING INFORMATION Your Icom radio generates RF electromagnetic energy during transmit mode. This radio isdesigned for and classified as “Occupational UseOnly”, meaning it must be used only during thecourse of employment by individuals aware of thehazards, and the ways to minimize such hazards. This radio is NOT intended for use by the “General Population” inan uncontrolled environment.This radio has been tested and complies with the FCC RF expo-sure limits for “Occupational Use Only”. In addition, your Icomradio complies with the following Standards and Guidelines withregard to RF energy and electromagnetic energy levels and eval-uation of such levels for exposure to humans: • FCC OET Bulletin 65 Edition 97-01 Supplement C, Evaluating Compliance with FCC Guidelines for HumanExposure to Radio Frequency Electromagnetic Fields. • American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to Human Exposureto Radio Frequency Electromagnetic Fields, 3 kHz to 300GHz. • American National Standards Institute (C95.3-1992), IEEE Recommended Practice for the Measurement of PotentiallyHazardous Electromagnetic Fields– RF and Microwave. • The following accessories are authorized for use with this product. Use of accessories other than those specified mayresult in RF exposure levels exceeding the FCC require-ments for wireless RF exposure.; Belt Clip (MB-94),Rechargeable Li-Ion Battery Pack (BP-231) and Speaker-microphone (HM-159L/HM-158L). To ensure that your expose to RF electromag- netic energy is within the FCC allowable limitsfor occupational use, always adhere to the fol-lowing guidelines: • DO NOT operate the radio without a proper antenna attached, as this may damaged the radio and may alsocause you to exceed FCC RF exposure limits. A properantenna is the antenna supplied with this radio by the manu-facturer or antenna specifically authorized by the manufac-turer for use with this radio. • DO NOT transmit for more than 50% of total radio use time (“50% duty cycle”). Transmitting more than 50% of the timecan cause FCC RF exposure compliance requirements to beexceeded. The radio is transmitting when the TX indicatorlights red. You can cause the radio to transmit by pressingthe “PTT” switch. • ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the body when transmitting and only use the Icom belt-clips listed on page 24 when attaching the radio to your belt,etc., to ensure FCC RF exposure compliance requirementsare not exceeded. To provide the recipients of your transmis-sion the best sound quality, hold the antenna at least 5 cm(2 inches) from your mouth, and slightly off to one side. The information listed above provides the user with the informa-tion needed to make him or her aware of RF exposure, and whatto do to assure that this radio operates with the FCC RF expo-sure limits of this radio. CAUTION WARNING !IC-F3021_F4021-1.qxd 06.4.12 3:25 PM Page 26 (1,1) 27 8 SAFETY TRAINING INFORMATION 8 Electromagnetic Interference/CompatibilityDuring transmissions, your Icom radio generates RF energy thatcan possibly cause interference with other devices or systems.To avoid such interference, turn off the radio in areas where signsare posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals,aircraft, and blasting sites.Occupational/Controlled UseThe radio transmitter is used in situations in which persons areexposed as consequence of their employment provided thosepersons are fully aware of the potential for exposure and canexercise control over their exposure. !IC-F3021_F4021-1.qxd 06.4.12 3:25 PM Page 27 (1,1)

UHF TRANSCEIVER Model No.: IC-F4021T Tested For ICOM Incorporated 2380 116 Avenue North East USA In Accordance With SAR (Specific Absorption Rate) Requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 2) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) UltraTech's File No.: ICOM-133-SAR This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: July 07, 2006 Report Prepared by: Carolyn Luu Tested by: Carolyn Luu Issued Date: July 04, 2006 Test Dates: June 15, 2006 ~ June 16, 2006 The results in this Test Report apply only to the sample(s) tested, which has been randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] SPECIFIC ABSORPTION RATE (SAR) Page 1 IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 2) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) UHF TRANSCEIVER M/N: IC-F4021T FCC ID: AFJ292702 ULTRATECH GROUP OF LABS File #: ICOM-133-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 07, 2006 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA ) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ................................................................................................................................................ 5 1.1. SCOPE ............................................................................................................................................................................... 5 1.2. REFERENCES................................................................................................................................................................... 5 EXHIBIT 2. PERFORMANCE ASSESSMENT ..................................................................................................................... 6 2.1. CLIENT AND MANUFACTURER INFORMATION ...................................................................................................... 6 2.2. DEVICE UNDER TEST (D.U.T.) DESCRIPTION.............................................................................................................. 6 2.3. LIST OF D.U.T.’S ACCESSORIES:.................................................................................................................................. 7 2.4. SPECIAL CHANGES ON THE D.U.T.’S HARDWARE/SOFTWARE FOR TESTING PURPOSES ............................. 7 2.5. ANCILLARY EQUIPMENT ............................................................................................................................................. 7 2.6. GENERAL TEST CONFIGURATIONS ........................................................................................................................... 7 2.6.1. Equipment Configuration ........................................................................................................................................... 7 2.6.2. Exercising Equipment................................................................................................................................................. 7 2.7. SPECIFIC OPERATING CONDITIONS...................................................................................................................................... 7 2.8. BLOCK DIAGRAM OF TEST SETUP ............................................................................................................................. 8 EXHIBIT 3. SUMMARY OF TEST RESULTS ...................................................................................................................... 9 3.1. LOCATION OF TESTS ..................................................................................................................................................... 9 3.2. APPLICABILITY & SUMMARY OF SAR RESULTS..................................................................................................... 9 EXHIBIT 4. MEASUREMENTS, EXAMINATIONS & TEST DATA .............................................................................. 10 4.1. TEST SETUP ................................................................................................................................................................... 10 4.2. PHOTOGRAPH OF D.U.T .................................................................................................................................................... 11 4.3. PHOTOGRAPHS OF D.U.T. POSITION ........................................................................................................................16 4.3.1. Head Front Configuration........................................................................................................................................ 16 4.3.1.1. Flexible whip antenna (M/N: FA-SC72U-1) ........................................................................................................................... 16 4.3.1.2. Push-To-Talk; Front-side in parallel to the phantom with the spacing of 25 mm .................................................................... 16 4.3.1.3. Flexible whip antenna (M/N: FA-SC73US-1) ......................................................................................................................... 17 4.3.1.4. Push-To-Talk; Front-side i…

Text truncated - open the document above for the full version.

UHF Transceiver Model No.: IC-F4021T FCC ID: AFJ292702 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku Osaka Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Parts 2 and 90 (Subpart I) UltraTech's File No.: ICOM-133F90 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: July 11, 2006 Report Prepared by: JaeWook Choi Issued Date: July 11, 2006 Tested by: Wayne Wu, Hung Trinh Test Dates: May 18 – May 23, 2006 June 15 – June 27, 2006, July 05 2006 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] 0685 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Contents i UHF Transceiver, Model IC-F4021T FCC ID: AFJ292702 ULTRATECH GROUP OF LABS File #: ICOM-133F90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 11, 2006 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST........................................................................................................................ 1 EXHIBIT 2. INTRODUCTION ......................................................................................................................................... 2 2.1. SCOPE......................................................................................................................................................................... 2 2.2. RELATED SUBMITTAL(S)/GRANT(S)................................................................................................................... 2 2.3. NORMATIVE REFERENCES ................................................................................................................................... 2 EXHIBIT 3. PERFORMANCE ASSESSMENT .............................................................................................................. 3 3.1. CLIENT INFORMATION .......................................................................................................................................... 3 3.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ............................................................................................. 3 3.3. EUT’S TECHNICAL SPECIFICATIONS ..................................................................................................................4 3.4. LIST OF EUT’S PORTS ............................................................................................................................................. 5 EXHIBIT 4. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 6 4.1. CLIMATE TEST CONDITIONS ................................................................................................................................ 6 4.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS .............................................. 6 EXHIBIT 5. SUMMARY OF TEST RESULTS ............................................................................................................... 7 5.1. LOCATION OF TESTS .............................................................................................................................................. 7 5.2. APPLICABILITY & SUMMARY OF EMISSION TEST RESULTS ........................................................................ 7 5.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ........................................ 7 5.4. DEVIATION OF STANDARD TEST PROCEDURES.............................................................................................. 7 EXHIBIT 6. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS............................... 8 6.1. TEST PROCEDURES................................................................................................................................................. 8 6.2. MEASUREMENT UNCERTAINTIES ...................................................................................................................... 8 6.3. MEASUREMENT EQUIPMENT USED.................................................................................................................... 8 6.4. ESSENTIAL/PRIMARY FUNCTIONS AS DECLARED BY THE MANUFACTURER ......................................... 8 6.5. RF POWER OUTPUT [§§ 2.1046 & 90.205] .............................................................................................................. 9 6.6. FREQUENCY STABILITY [§§ 2.1055 & 90.213]................................................................................................... 10 6.7. AUDIO FREQUENCY RESPONSE [§ 2.1047(A)]................................................................................................... 12 6.8. MODULATION LIMITING [§§ 2.1047(B) & 90.210] ............................................................................................. 17 6.9. OCCUPIED BANDWIDTH & EMISSION MASK [§§ 2.1049, 90.209 & 90.210] .................................................. 22 6.10. TRANSMITTER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§ 90.210] ..... 69 6.11. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§ 90.210] ............................................ 82 6.12. TRANSIENT FREQUENCY BEHAVIOR [§ 90.214].......................................................................................... 86 EXHIBIT 7. MEASUR…

Text truncated - open the document above for the full version.

Test Setup Photographs – ICOM UHF Transceiver (M/N: IC-F4021T)
