AFJ325100VHF Amateur Transceiver

VHF TRANSCEIVER This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. INSTRUCTION MANUAL i FOREWORD Thank you for purchasing this Icom radio. The IC-2300H VHF TRANSCEIVER is designed and built with Icom’s state of the art technology and craftsmanship. With proper care this radio should provide you with years of trouble-free operation. D FEATURES ❍ 65 W* — high transmit output power (*except Korea/Taiwan versions) ❍ Tone squelch, DTCS squelch standard ❍ Three color (amber, yellow & green) back- lightLCD screen ❍ Remote control microphone available IMPORTANT READ ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL— This instruction manual contains important operating instructions for the IC-2300H. EXPLICIT DEFINITIONS Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United King- dom, Germany, France, Spain, Russia and/or other countries. SUPPLIED ACCESSORIES q Microphone (HM-133V) . . . . . . . . . . . . . . . . . . . 1 w Fuse (20 A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 e DC power cable (3 m) . . . . . . . . . . . . . . . . . . . . . 1 r Mobile mounting bracket . . . . . . . . . . . . . . . . . . 1 t Mounting screws, nuts and washers . . . . . . .1 set y Microphone hanger † . . . . . . . . . . . . . . . . . . . . . . 1 † Not supplied, depending on the version. q w e r t y † OPTIONS HM-133V REMOTE-CONTROL MICROPHONE HM-154 HAND MICROPHONE SP-10 EXTERNAL SPEAKER OPC-440A MIC EXTENSION CABLE OPC-589 ADAPTER CABLE OPC-1132A/OPC-347 DC POWER CABLES CS-2300H CLONING SOFTWARE OPC-478/OPC-478UC CLONING CABLES OPC-474 CLONING CABLE WORDDEFINITION R WARNING! Personal injury, fi re hazard or electric shock may occur. CAUTION Equipment damage may occur. NOTE Recommended, only inconvenience. No risk of personal injury, fi re or elec- tric shock. FCC INFORMATION • FOR CLASS B UNINTENTIONAL RADIATORS: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in- stalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep- tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit dif- ferent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. ii RWARNING RF EXPOSURE! This device emits RadioFrequency (RF) energy. Extreme caution should be ob- served when operating this device. If you have any questions regarding RF exposure and safety standards, please refer to the Federal Communications Commission Offi ce of Engineering and Technology’s report on Evaluating Compliance with FCC Guide- lines for Human Radio frequency Electromagnetic Fields (OET Bulletin 65). RWARNING! NEVER connect the transceiver to an AC outlet. This may pose a fi re hazard or result in an electric shock. RWARNING! NEVER cut the DC power cable between the DC plug and fuse holder. If an incorrect connection is made after cutting, the transceiver may be damaged. RWARNING! NEVER operate the transceiver while driving a vehicle. Safe driving requires your full attention—any- thing less may result in an accident. RWARNING! NEVER connect the transceiver to a power source of more than 16 V DC or use reverse polarity. This could cause a fi re or damage the transceiver. CAUTION: NEVER expose the transceiver to rain, snow or any liquids. The transceiver may be damaged. RWARNING! NEVER operate or touch the transceiver with wet hands. This may result in an electric shock or damage the transceiver. RWARNING! NEVER place the transceiver where nor- mal operation of the vehicle may be hindered or where it could cause bodily injury. RWARNING! NEVER let metal, wire or other objects touch any internal part of the transceiver. This may result in an electric shock. DO NOT push the PTT when not actually intending to trans- mit. KEEP the transceiver out of the reach of children. During mobile operation, DO NOT operate the transceiver without running the vehicle’s engine. When the transceiver’s pow- er is ON and your vehicle’s engine is OFF, the vehicle’s battery will soon become exhausted. BE CAREFUL! The transceiver will become hot when op- erating it continuously for long periods of time. DO NOT set the transceiver in a place without adequate ventilation. Heat dissipation may be affected, and the transceiver may be damaged. DO NOT use or place the transceiver in direct sunlight or in areas with temperatures below –10°C (+14 ̊F) or above +60°C (+140 ̊F). DO NOT use harsh solvents such as benzine or alcohol when cleaning, as they will damage the transceiver’s surfaces. USE only Icom microphones (supplied or optional). Other man- ufacturer’s microphones have different pin assignments and may damage the transceiver if attached. Approved Icom optional equipment is designed for optimal per- formance when used with an Icom transceiver. Icom is not responsible for the destruction or damage to an Icom transceiver in the event the Icom transceiver is used with equip- ment that is not manufacture…

Text truncated - open the document above for the full version.

UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NvLap Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] November 21, 2011 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Certification Testing in Accordance with FCC CFR 47, Part 15, Subpart B - Scanning Receivers Applicant: ICOM Incorporated Product: VHF Transceiver Model: IC-2300H FCC ID: AFJ325100 Dear Sir/Madam: As appointed agent for ICOM Incorporated, we submit the application for certification of the above product. Please review all files uploaded to your electronic filing site. If you have any queries, please do not hesitate to contact us: Yours truly, Dharmajit Solanki Dharmajit Solanki Authorized Agent

VHF Transceiver Model No.: IC-2300H FCC ID: AFJ325100 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku Osaka, Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 15, Subpart B, Scanning Receivers UltraTech's File No.: ICOM-284_FCC15.121 This Test report is Issued under the Authority of Tri M. Luu, BASc Vice President of Engineering UltraTech Group of Labs Date: November 21, 2011 Report Prepared by: Dharmajit Solanki Issued Date: November 21, 2011 Tested by: Wei Wu Test Dates: Oct. 31 to Nov. 9, 2011  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] FCC Korea KCC-RRL 91038 1309 46390-2049 NvLap Lab Code 200093-0 SL2-IN-E-1119R CA2049 FCC Part 15, Subpart B, Section 15.121 Contents i VHF Transceiver, M/N: IC-2300H FCC ID: AFJ325100 ULTRATECH GROUP OF LABS File #: ICOM-284_FCC15.121 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 21, 2011 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) .................................................................................................................. 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ............................................................................................ 2 2.3. EUT’S TECHNICAL SPECIFICATIONS ................................................................................................................. 3 2.4. LIST OF EUT’S PORTS............................................................................................................................................. 3 2.5. ANCILLARY EQUIPMENT ...................................................................................................................................... 3 2.6. TEST SETUP BLOCK DIAGRAM............................................................................................................................ 4 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 5 3.1. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS............................................. 5 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 6 4.1. LOCATION OF TESTS.............................................................................................................................................. 6 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ............................................................. 6 4.3. MODIFICATIONS REQUIRED FOR COMPLIANCE............................................................................................. 6 EXHIBIT 5. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS............................... 7 5.1. TEST PROCEDURES................................................................................................................................................. 7 5.2. MEASUREMENT UNCERTAINTIES ...................................................................................................................... 7 5.3. MEASUREMENT EQUIPMENT USED ................................................................................................................... 7 5.4. RECEIVER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§15.111(A)] ............. 8 5.5. SPURIOUS/HARMONIC RADIATED EMISSIONS FROM RECEIVER AND CLASS B UNINTENTIONAL RADIATORS (DIGITAL DEVICES) [§ 15.109(A)] ............................................................................................... 12 5.6. REQUIREMENTS FOR SCANNING RECEIVERS [§ 15.121].............................................................................. 15 5.7. SCANNING RECEIVERS CELLULAR BAND REJECTION [§ 15.121(B)] ........................................................ 18 EXHIBIT 6. TEST EQUIPMENTS LIST ....................................................................................................................... 20 EXHIBIT 7. MEASUREMENT UNCERTAINTY.........................................................................................................21 7.1. LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY ................................................................ 21 7.2. RADIATED EMISSION MEASUREMENT UNCERTAINTY .............................................................................. 21 FCC Part 15, Subpart B, Section 15.121 Page 1 VHF Transceiver, M/N: IC-2300H FCC ID: AFJ325100 ULTRATECH GROUP OF LABS File #: ICOM-284_FCC15.121 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Novemb…

Text truncated - open the document above for the full version.

ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated VHF Transceiver, Model IC-2300H FCC ID: AFJ325100 A1 - 1 Radiated Emission at 3m Distance ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated VHF Transceiver, Model IC-2300H FCC ID: AFJ325100 A1 - 2 Radiated Emission at 3m Distance ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated VHF Transceiver, Model IC-2300H FCC ID: AFJ325100 A1 - 3 Radiated Emission at 3m Distance
