INSTRUCTION MANUAL iM92D VHF MARINE TRANSCEIVER This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. iii IN CASE OF EMERGENCY If your vessel requires assistance, contact other vessels and the Coast Guard by sending a distress call on Channel 16. Or, transmit your Distress call using digital selective calling on Channel 70. USING CHANNEL 16 DISTRESS CALL PROCEDURE 1. “MAYDAY MAYDAY MAYDAY.” 2. “THIS IS ...............” (name of vessel). 3. Say your call sign or other indication of the vessel (AND 9-digit DSC ID if you have one). 4. “LOCATED AT ...............” (your position). 5. State the nature of the distress and assistance re- quired. 6. Give any other information which might facilitate the rescue. USING DIGITAL SELECTIVE CALLING (Ch 70) DISTRESS CALL PROCEDURE 1. While lifting up the key cover, push and hold [DISTRESS] for 3 seconds until you hear 3 short beeps change to one long beep. 2. Wait for an acknowledgment on Channel 70 from a coast station. • After the acknowledgement is received, Channel 16 is automatically selected. 3. Push and hold [PTT], then transmit the appropriate infor- mation as listed above. 1 RECOMMENDATION CLEAN THE TRANSCEIVER THOROUGHLY WITH FRESH WATER after exposure to saltwater. Otherwise, the trans- ceiver's keys, switches and controllers may become inoper- able due to salt crystallization. NOTE: DO NOT wash the transceiver in water if there is any reason to suspect the waterproofing may not be effective. For example, in cases where the battery pack rubber seal is dam- aged, the transceiver/battery pack is cracked or broken, or has been dropped, or when the battery pack is detached from the transceiver. 2 FOREWORD Thank you for purchasing this Icom product. The IC-M92D v h f m a r i n e t r a n s c e i v e r is designed and built with Icom’s state of the art technology and craftsmanship. With proper care this radio should provide you with years of trouble-free operation. IMPORTANT READ ALL INSTRUCTIONS carefully and com- pletely before using the transceiver. SAVE THIS INSTRUCTION MANUAL—This instruction manual contains important operating instructions for the IC-M92D. This instruction manual includes some functions which are usable only when they are pre-programmed by your dealer. Ask your dealer for details. EXPLICIT DEFINITIONS WORDDEFINITION RDANGER! Personal death, serious injury or an ex- plosion may occur. RWARNING! Personal injury, fire hazard or electric shock may occur. CAUTION Equipment damage may occur. NOTE If disregarded, inconvenience only. No risk of personal injury, fire or electric shock. FEATURES ☞ 3 PRECAUTIONS CAUTION: MAKE SURE the flexible antenna, bat- tery pack and jack cover are securely attached to the trans- ceiver, and that the antenna and battery pack are dry before attachment. Exposing the inside of the transceiver to dust or water will result in serious damage to the transceiver. DO NOT operate the transceiver near unshielded electri- cal blast ing caps or in an explosive atmosphere. DO NOT push [PTT] when not actually intending to transmit. DO NOT use or place the transceiver in direct sunlight or in areas with temperatures below –20°C (–4°F) or above +60°C (+140°F). The basic operations, transmission and reception of the transceiver are guaranteed within the specified operating temperature range. However, the LCD display may not be operate correctly, or show an indication in the case of long hours of operation, or after being placed in extremely cold areas. DO NOT use harsh solvents such as benzine or alcohol when cleaning, as they will damage the transceiver surfaces. R WARNING! NEVER connect the transceiver to an AC outlet. This may pose a fire hazard or result in an electric shock. R WARNING! NEVER hold the transceiver so that the antenna is very close to, or touching exposed parts of the body, especially the face or eyes, while transmitting. The transceiver will perform best if the microphone is 5 to 10 cm (2 to 4 inches) away from the lips and the transceiver is verti- cal. R WARNING! NEVER operate the transceiver with other audio accessories at high volume levels. Hearing ex- perts advise against continuous high volume operation. If you experience a ringing in your ears, reduce the volume level or discontinue use. DO NOT modify the transceiver. The transceiver warranty does not cover any problems caused by unauthorized modification. BE CAREFUL! The transceiver will become hot when operating it continuously for long periods of time. KEEP the transceiver and microphone at least 1 m away from the vessel’s magnetic navigation compass. KEEP the transceiver out of the reach of children. 4 FCC INFORMATION BE CAREFUL! The IC-M92D meets IPX7* requirements for dust-tight and waterproof protection. However, once the transceiver has been dropped, dust-tight and waterproof pro- tection cannot be guaranteed because of possible damage to the transceiver’s case or the waterproof seal. * Only when the jack cover or the optional HM-167 is at- tached. Even when the transceiver power is OFF, a slight current still flows in the circuits. Remove the battery pack or batteries from the trans ceiver when not using it for a long time. Other- wise, the installed battery pack or batteries will become ex- hausted, and will need to be recharged or replaced. MAKE SURE to turn the transceiver power OFF before connect ing the supplied/optional equipment. For U.S.A. only: CAUTION: Changes or modifications to this transceiver, not expressly approved by Icom Inc., could void your authority to operate this transceiver under FCC regulations. PRECAUTIONS (Continued) Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor- porated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries. CAUTION: Changes or modifications to this device, not expressly approved by Icom Inc., could void your authorit…

Text truncated - open the document above for the full version.

February 21, 2012 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 (Marine in 156.025-157.425 MHz Band) - Non-Broadcast Radio Transceivers. Applicant: ICOM Incorporated Product: VHF Marine Transceiver Model: IC-M92D FCC ID: AFJ339400 Dear Sir/Madam: As appointed agent for ICOM Incorporated, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E-Filing Site. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

IC-M92D Serial Seal Location Serial Seal

75 1 SAFETY TRAINING INFORMATION Your Icom radio generates RF electromagnetic energy during transmit mode. This radio is designed for and classified as “General Population Use” in an uncontrolled environment. This radio has been evaluated for compliance at the distance of 2.5 cm (1 inch) with the FCC RF exposure limits for “ Gen- eral Population Use. ” In addition, your Icom radio complies with the following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans: • FCC OET Bulletin 65 Edition 01-01 Supplement C, Evaluating Compli- ance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. • American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. • American National Standards Institute (C95.3-1992), IEEE Recom- mended Practice for the Measurement of Potentially Hazardous Electro- magnetic Fields– RF and Microwave. • The following accessories are authorized for use with this product. Use of accessories other than those specified may result in RF exposure levels exceeding the FCC requirements for wireless RF exposure.; Belt Clip (MB-109), Rechargeable Li-Ion Battery Pack (BP-275). To ensure that your expose to RF electromagnetic en- ergy is within the FCC allowable limits for general popu- lation use, always adhere to the following guidelines: • DO NOT operate the radio without a proper antenna attached, as this may damaged the radio and may also cause you to exceed FCC RF ex- posure limits. A proper antenna is the antenna supplied with this radio by the manufacturer or antenna specifically authorized by the manufacturer for use with this radio. • DO NOT transmit for more than 50% of total radio use time (“50% duty cycle”). Transmitting more than 50% of the time can cause FCC RF expo- sure compliance requirements to be exceeded. The radio is transmitting when the “transmit indicator” appears on the LCD. You can cause the radio to transmit by pressing the “PTT” switch. • ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the body when transmitting and only use the Icom belt clip which is listed on page 28 when attaching the radio to your belt, etc., to ensure FCC RF exposure compliance requirements are not exceeded. To provide the re- cipients of your transmission the best sound quality, hold the antenna at least 5 cm (2 inches) from your mouth, and slightly off to one side. The information listed above provides the user with the information needed to make him or her aware of RF exposure, and what to do to assure that this radio operates with the FCC RF exposure limits of this radio. Electromagnetic Interference/Compatibility During transmissions, your Icom radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blasting sites. WARNING CAUTION

VHF Marine Transceiver Model No.: IC-M92D FCC ID: AFJ339400 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku, Osaka Japan 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 2, Part 80 (Marine in 156.025-157.425 MHz) UltraTech's File No.: ICOM-291F80 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: February 16, 2012 Report Prepared by: Dan Huynh Issued Date: February 16, 2012 Tested by: Wei Wu, RF Technician Test Dates: January 25 - 31, 2012 The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] FCC Korea KCC-RRL 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R CA2049 FCC Parts 2, 80 (Marine in 156.025-157.425 MHz), Non-Broadcast Radio Transceivers Contents i VHF Marine Transceiver, Model: IC-M92D FCC ID: AFJ339400 ULTRATECH GROUP OF LABS File #: ICOM-291F80 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 February 3, 2012 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION.............................................................................................................................................. 1 1.1. SCOPE ........................................................................................................................................................................ 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ........................................................................................................................ 1 1.3. NORMATIVE REFERENCES ...................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT ................................................................................................................... 2 2.1. CLIENT INFORMATION .............................................................................................................................................. 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ................................................................................................... 2 2.3. EUT’S TECHNICAL SPECIFICATIONS....................................................................................................................... 3 2.4. LIST OF EUT’S PORTS............................................................................................................................................... 3 2.5. ANCILLARY EQUIPMENT ........................................................................................................................................... 3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS .............................................. 4 3.1. CLIMATE TEST CONDITIONS .................................................................................................................................... 4 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS....................................................... 4 EXHIBIT 4. SUMMARY OF TEST RESULTS ..................................................................................................................... 5 4.1. LOCATION OF TESTS ................................................................................................................................................ 5 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS .......................................................................5 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ................................................ 5 4.4. DEVIATION OF STANDARD TEST PROCEDURES................................................................................................... 5 EXHIBIT 5. TEST DATA ..................................................................................................................................................... 6 5.1. RF POWER OUTPUT [§§ 2.1046 & 80.215] ................................................................................................................ 6 5.2. MODULATION CHARACTERISTICS - AUDIO FREQUENCY RESPONSE [§§ 2.1047(a) & 80.213(e)]..................... 7 5.3. MODULATION LIMITING [§ 80.213 & § 2.1047(b)] ................................................................................................... 10 5.4. EMISSION MASK [§§2.1049, 80.205 & 80.211] ........................................................................................................ 13 5.5. TRANSMITTER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§ 80.211(f)(3)]............ 21 5.6. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§ 80.211(f)(3)]................................................. 26 5.7. FREQUECNY STABILITY [§§ 2.1055 & 80.209] ....................................................................................................... 27 EXHIBIT 6. TEST EQUIPMENT LIST ............................................................................................................................... 29 EXHIBIT 7. MEASUREMENT UNCERTAINTY ................................................................................................................ 30 7.1. LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY.......................................................................... 30 7.2. RADIATED EMISSION MEASUREMENT UNCERTAINTY .......................…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M92D FCC ID: AFJ339400 Radiated Emission at 3m (Orthogonal Position 1) ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M92D FCC ID: AFJ339400 Radiated Emission at 3m (Orthogonal Position 2) ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M92D FCC ID: AFJ339400 Radiated Emission at 3m (Orthogonal Position 3)
