INSTRUCTION MANUAL iM506 VHF MARINE TRANSCEIVER This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. i FOREWORD Thank you for purchasing this Icom product. The IC-M506 VHF MARINE TRANSCEIVER is designed and built with Icom’s state of the art technology and craftsmanship. With proper care, this product should provide you with years of trouble- free operation. We appreciate you making the IC-M506 your radio of choice, and hope you agree with Icom’s philosophy of “technology first.” Many hours of research and development went into the de sign of your IC-M506. FEATURES D M Built-in Class D DSC M Integrated AIS Receiver M NMEA 2000™ Connectivity M 2 Minutes Last Call Voice Recording M Superb Active Noise Cancelling M 25W Two-Way Hailer and Horn M IPX8 Submersible Plus™ M Optional COMMANDMIC IV™ HM-195 IMPORTANT READ ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This in- struction manual contains important operating instructions for the IC-M506. EXPLICIT DEFINITIONS WORDDEFINITION RWARNING! Personal injury, fire hazard or electric shock may occur. CAUTION Equipment damage may occur. NOTE If disregarded, inconvenience only. No risk of personal injury, fire or electric shock. CLEAN THE TRANSCEIVER AND MICROPHONE THOR- OUGHLY WITH FRESH WATER after exposure to water including salt, otherwise, the keys and switch may become inoperable due to salt crystallization. For Canada: This device complies with RSS-310 of Industry Canada. Op- eration is subject to the condition that this device does not cause harmful interference. Cet appareil est conforme au CNR-310 d’Industrie Canada. Son exploitation est autorisee sous reserve que l’appareil ne cause pas de brouillage prejudiciable. If your vessel requires assistance, contact other vessels and the Coast Guard by sending a Distress call on Channel 16. Or, transmit your Distress call using digital selective calling on Channel 70. USING CHANNEL 16 DISTRESS CALL PROCEDURE 1. “MAYDAY MAYDAY MAYDAY.” 2. “THIS IS ...............” (name of vessel). 3. Say your call sign or other description of the vessel (AND 9 digit DSC ID if you have one). 4. “LOCATED AT ...............” (your position). 5. State the nature of the distress and assistance re- quired. 6. Give any other information which might facilitate the rescue. USING DIGITAL SELECTIVE CALLING (Ch 70) DISTRESS CALL PROCEDURE 1. While lifting up the key cover, hold down [DIS- TRESS] for 3 seconds until you hear 3 short beeps and then one long beep. 2. Wait for an acknowledgment on Channel 70 from a coast station. s!FTERTHEACKNOWLEDGEMENTISRECEIVED #HANNELIS automatically selected. 3. Hold down [PTT], then transmit the appropriate in- formation as listed above. ii IN CASE OF EMERGENCY iii RADIO OPERATOR WARNING WARNING Icom requires the radio operator to meet the FCC Requirements for Radio Frequency Expo- sure. An omnidirectional antenna with gain not greater than 9 dBi must be mounted a mini- mum of 5 meters (measured from the lowest point of the antenna) vertically above the main deck and all possible personnel. This is the minimum safe separation distance estimated to meet all RF exposure com- pliance requirements. This 5 meter distance is based on the FCC Safe Maximum Permissible Exposure (MPE) distance of 3 meters added to the height of an adult (2 meters) and is appropriate for all vessels. For watercraft without suitable structures, the antenna must be mounted so as to maintain a minimum of 1 meter verti- cally between the antenna, (measured from the lowest point of the antenna), to the heads of all persons AND all persons must stay outside of the 3 meter MPE radius. Do not transmit with radio and antenna when persons are within the MPE radius of the antenna, unless such persons (such as driver or radio operator) are shielded from antenna field by a grounded metallic barrier. The MPE Radius is the minimum distance from the antenna axis that person should maintain in order to avoid RF exposure higher than the al- lowable MPE level set by FCC. FAILURE TO OBSERVE THESE LIMITS MAY ALLOW THOSE WITHIN THE MPE RADIUS TO EXPERIENCE RF RADIATION ABSORPTION WHICH EXCEEDS THE FCC MAXIMUM PERMISSIBLE EXPOSURE (MPE) LIMIT. IT IS THE RESPONSIBILITY OF THE RADIO OPERATOR TO ENSURE THAT THE MAXIMUM PERMISSIBLE EXPO- SURE LIMITS ARE OBSERVED AT ALL TIMES DURING RADIO TRANSMISSION. THE RADIO OPERATOR IS TO ENSURE THAT NO BYSTANDERS COME WITHIN THE RADIUS OF THE MAXIMUM PERMISSIBLE EXPOSURE LIMITS. Determining MPE Radius THE MAXIMUM PERMISSIBLE EXPOSURE (MPE) RA- DIUS HAS BEEN ESTIMATED TO BE A RADIUS OF ABOUT 3M PER OET BULLETIN 65 OF THE FCC. THIS ESTIMATE IS MADE ASSUMING THE MAXIMUM POWER OF THE RADIO AND ANTENNAS WITH A MAXI- MUM GAIN OF 9dBi ARE USED FOR A SHIP MOUNTED SYSTEM. iv 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 AVERTISSEMENT POUR LES OPÉRATEURS RADIO Icom exige que l'opérateur radio se conforme aux exigences de la FCC en matière d'exposition aux radiofréquences. Une antenne omnidirectionnelle dont le gain ne dépasse pas 9dBi doit être fixée à une distance minimale de 5 mètres (mesurée depuis le point le plus bas de l'antenne) verticale- ment au-dessus du pont principal et de tout le personnel qui peut s'y trouver. Il s'agit de la distance de sécurité minimale prévue pour satisfaire aux exigences de conformité en matière d'exposition aux RF. Cette distance de 5 mètres est établie en fonction de l'exposition maximale admissible sécuritaire de 3 mètres établie par la FCC, à laquelle on ajoute la hauteur d'un adulte (2 mètres); cette distance convient pour tous les navires. Dans le cas des embarcations sans structure convenable, l'antenne doit être fixée de façon à maintenir une distance minimale de 1 mètre verticalement entre cette antenne (mesurée depuis son point le plus bas) et la tête de toute personne présente; toutes les personnes présentes doivent s…

Text truncated - open the document above for the full version.

March 04, 2014 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 (Marine in 156.025-157.425 MHz Band) - Non-Broadcast Radio Transceivers. Applicant: ICOM Incorporated Product: VHF Marine Transceiver Model: IC-M506 FCC ID: AFJ357000 Dear Sir/Madam: As appointed agent for ICOM Incorporated, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E-Filing Site. If you have any queries, please do not hesitate to contact us. Yours truly, Dharmajit Solanki Dharmajit Solanki Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E-1119R Korea KCC-RRA CA2049 TL363_B TPTDP DA1300 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

C - 16903 MADE IN JAPAN SUBMERSIBLE : 1m 60min. FCC ID : AFJ357000 IC : 202D - 357000 D Model : IC - M506 AIS FCC Part15 & 80 STICKER SERIAL No. STICKER

iii RADIO OPERATOR WARNING WARNING Icom requires the radio operator to meet the FCC Requirements for Radio Frequency Expo- sure. An omnidirectional antenna with gain not greater than 9 dBi must be mounted a mini- mum of 5 meters (measured from the lowest point of the antenna) vertically above the main deck and all possible personnel. This is the minimum safe separation distance estimated to meet all RF exposure com- pliance requirements. This 5 meter distance is based on the FCC Safe Maximum Permissible Exposure (MPE) distance of 3 meters added to the height of an adult (2 meters) and is appropriate for all vessels. For watercraft without suitable structures, the antenna must be mounted so as to maintain a minimum of 1 meter verti- cally between the antenna, (measured from the lowest point of the antenna), to the heads of all persons AND all persons must stay outside of the 3 meter MPE radius. Do not transmit with radio and antenna when persons are within the MPE radius of the antenna, unless such persons (such as driver or radio operator) are shielded from antenna field by a grounded metallic barrier. The MPE Radius is the minimum distance from the antenna axis that person should maintain in order to avoid RF exposure higher than the al- lowable MPE level set by FCC. FAILURE TO OBSERVE THESE LIMITS MAY ALLOW THOSE WITHIN THE MPE RADIUS TO EXPERIENCE RF RADIATION ABSORPTION WHICH EXCEEDS THE FCC MAXIMUM PERMISSIBLE EXPOSURE (MPE) LIMIT. IT IS THE RESPONSIBILITY OF THE RADIO OPERATOR TO ENSURE THAT THE MAXIMUM PERMISSIBLE EXPO- SURE LIMITS ARE OBSERVED AT ALL TIMES DURING RADIO TRANSMISSION. THE RADIO OPERATOR IS TO ENSURE THAT NO BYSTANDERS COME WITHIN THE RADIUS OF THE MAXIMUM PERMISSIBLE EXPOSURE LIMITS. Determining MPE Radius THE MAXIMUM PERMISSIBLE EXPOSURE (MPE) RA- DIUS HAS BEEN ESTIMATED TO BE A RADIUS OF ABOUT 3M PER OET BULLETIN 65 OF THE FCC. THIS ESTIMATE IS MADE ASSUMING THE MAXIMUM POWER OF THE RADIO AND ANTENNAS WITH A MAXI- MUM GAIN OF 9dBi ARE USED FOR A SHIP MOUNTED SYSTEM.

VHF Marine Transceiver Model No.: IC-M506 FCC ID: AFJ357000 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku, Osaka Japan 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 2, Part 80 (Marine in 156.025-157.425 MHz) UltraTech's File No.: ICOM-355Q_FCC80 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: March 04, 2014 Report Prepared by: Dharmajit Solanki Issued Date: March 04, 2014 Tested by: Wei Wu, RF Technician Test Dates: February 18 to 28, 2014 The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] Korea KCC-RRA 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E- 1119R CA2049 TL363_B TPTDP DA1300 FCC Parts 2, 80 (Marine in 156.025-157.425 MHz), Non-Broadcast Radio Transceivers Contents i VHF Marine Transceiver, Model: IC-M506 FCC ID: AFJ357000 ULTRATECH GROUP OF LABS File #: ICOM-355Q_FCC80 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 March 04, 2014 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S)................................................................................................................... 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION............................................................................................. 2 2.3. EUT’S TECHNICAL SPECIFICATIONS.................................................................................................................. 3 2.4. LIST OF EUT’S PORTS ............................................................................................................................................. 3 2.5. ANCILLARY EQUIPMENT ...................................................................................................................................... 3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 4 3.1. CLIMATE TEST CONDITIONS................................................................................................................................ 4 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS ............................................. 4 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 5 4.1. LOCATION OF TESTS .............................................................................................................................................. 5 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS.............................................................. 5 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ....................................... 5 4.4. DEVIATION OF STANDARD TEST PROCEDURES ............................................................................................. 5 EXHIBIT 5. TEST DATA................................................................................................................................................... 6 5.1. RF POWER OUTPUT [§§ 2.1046 & 80.215] ............................................................................................................. 6 5.2. RF EXPOSURE REQUIREMENTS @ 1.1310 & 2.1091 .......................................................................................... 7 5.3. MODULATION CHARACTERISTICS & AUDIO FREQUENCY RESPONSE [§§ 2.1047(A) & 80.213(E)] ....... 9 5.4. MODULATION LIMITING [§ 80.213 & § 2.1047(B)] ........................................................................................... 12 5.5. EMISSION MASK [§§2.1049, 80.205 & 80.211] .................................................................................................... 15 5.6. TRANSMITTER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§ 80.211(F)(3)]29 5.7. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§ 80.211(F)(3)] ...................................... 34 5.8. FREQUECNY STABILITY [§§ 2.1055 & 80.209] .................................................................................................. 36 EXHIBIT 6. TEST EQUIPMENT LIST ......................................................................................................................... 38 EXHIBIT 7. MEASUREMENT UNCERTAINTY.........................................................................................................39 7.1. LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY ................................................................ 39 7.2. RADIATED EMISSION MEASUREMENT UNCERTAINTY .....................................…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M506 FCC ID: AFJ357000, IC:202D-357000 Radiated Emission at 3m ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M506 FCC ID: AFJ357000, IC:202D-357000 Radiated Emission at 3m ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M506 FCC ID: AFJ357000, IC:202D-357000 Radiated Emission at 3m
