iA23iA5VHF AIR BAND TRANSCEIVER INSTRUCTION MANUAL This device complies with Part 15 of the FCC rules. Operation is sub-ject to the following two conditions: (1) This device may not causeharmful interference, and (2) this device must accept any interferencereceived, including interference that may cause undesired operation. i FOREWORDREAD ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This in- struction manual contains important operating instructions forthe IC-A23/A5. EXPLICIT DEFINITIONSThe explicit definitions below apply to this instruction manual. CAUTIONR WARNING! NEVER hold the transceiver so that the antenna is very close to, or touching exposed parts of thebody, especially the face or eyes, while transmitting. Thetransceiver will perform best if the microphone is 5 to 10 cmaway from the lips and the transceiver is vertical. R WARNING! NEVER operate the transceiver with a headset or other audio accessories at high volume levels.Hearing experts advise against continuous high volume op-eration. If you experience a ringing in your ears, reduce thevolume level or discontinue use.NEVER connect the transceiver to an AC outlet or to a power source of more than 14 V DC. Such a connection willdamage the transceiver. NEVER connect the transceiver to a power source that is DC fused at more than 5 A. Accidental reverse connection willbe protected by this fuse, higher fuse values will not give anyprotection against such accidents and the transceiver will beruined. NEVER short the terminals of the battery pack. Also, cur- rent may flow into nearby metal objects, such as a necklace, WORD DEFINITION R WARNING Personal injury, fire hazard or electric shockmay occur. CAUTION Equipment damage may occur. NOTE Inconvenience only. No risk of personal injury, fire or electric shock. FCC caution: Changes or modifications to this transceiver, not expressly approved by Icom Inc., could void your authority tooperate this transceiver under FCC regulations. (U.S.A. only) ii etc. Therefore, be careful when carrying with, or placing nearmetal objects, carrying in handbags, etc. DO NOT allow children to play with any radio equipment containing a transmitter. DO NOT operate the transceiver near unshielded electrical blasting caps or in an explosive atmosphere. AVOID using or placing the transceiver in direct sunlight or in areas with temperatures below –10°C (+14°F) or above+60°C (+140°F).The use of non-Icom battery packs/chargers may impairtransceiver performance and invalidate the warranty.Even when the transceiver power is OFF, a slight current stillflows in the circuits. Remove the battery pack or case fromthe transceiver when not using it for a long time. Otherwise,the battery pack or installed dry cell batteries will become ex-hausted. SUPPLIED ACCESSORIESAccessories included with the transceiver: Qty. q Antenna ........................................................................... 1 w Belt clip............................................................................ 1 e Battery pack (BP-200L)*.................................................. 1 r Wall charger* .................................................................. 1 • Carrying case (LC-147)* ............................................... 1• HEADSET ADAPTER (OPC-967)* ............................... 1 * The battery pack, wall charger, HEADSET ADAPTER or carry- ing case may differ depending on version. Some versions do notinclude a battery pack, wall charger, HEADSET ADAPTER orcarrying case. q w e r FOREWORD .................................................................................... iEXPLICIT DEFINITIONS ................................................................. iCAUTIONS ....................................................................................... iSUPPLIED ACCESSORIES............................................................. iiTABLE OF CONTENTS .................................................................. iii1 ACCESSORY ATTACHMENT .................................................. 12 PANEL DESCRIPTION ........................................................ 2 – 7  Panel description ............................................................... 2 – 5  Function display ................................................................ 6 – 7 3 BASIC OPERATION ............................................................ 8 – 7  DIAL ↔ [ Y ]/[ Z ] trade function ...................................................8  Setting a frequency ................................................................ 8  Lock function .......................................................................... 8  Accessing 121.5 MHz emergency frequency ......................... 8  Setting a squelch level ........................................................... 9  Side tone function .................................................................. 9  Display backlighting ............................................................... 9  Low battery indicator .............................................................. 9  Receiving ............................................................................. 10  Transmitting .......................................................................... 10  Selecting a weather channel ................................................. 11  Side tone function .................................................................. 6  Lock function .......................................................................... 6  Display backlighting ............................................................... 6  Low battery indicator .............................................................. 6  Dial select function ................................................................. 7 4 MEMORY OPERATION .......................................................... 12  Memory channel selection ...........................…

Text truncated - open the document above for the full version.

1st MIX TA31136FN IC1 VCO RF UNIT LOGIC UNIT IC1 : CPU M38267M6L ANT 1st.IF:30.05MHz CHASSIS UNIT 2nd MIX PLLDA,PLLCK,PLLST 2nd IF AMP (450kHz) 2nd.LO: 29.6MHz EMBI AFC WXC ANLC 6 5 4 3 2 1 BCDEFGHIJA ABCDEFGHIJ REVISSIONS 1 2 3 4 5 6 7 8 9 12 10 11 APPD.CHKD. DWN.BY: DATE MODEL DWN.NO. .. . . . . . . . . . . .. . . . . . . . . . . ICOMIcom Inc. TXC KEY MATRIX UP DOWN IC-A23 BLOCK DIAGRAM 2000.05.26 VORDET VORON VORO VORS VORC REC/PLAY MICMUTE ALCC CLOUT PLIN AF POWER OUT EXT MIC & CLONE I/O +5V BATT V-DET COMMON TX RX DATA NOTES BATTERY PACK + - 9.6V 6 5 4 3 2 1 TX = 118.000 ~ 136.975MHz RX = 108.000 ~ 136.975MHz RX = 161.600 ~ 163.275MHz AM FM Freq data BPF CTRL-V 1st Lo AM=7 8.85~107.825MHz FM=132.45~13 4.125MHz TX =118.0~136.975MHz AM=78.85~107.825MHz FM=132.45~134.125MHz RX (5.039MHz) T+5 R5 BATT V-DET BATT CHG CNT CHASSIS UNIT EL-VOL DATA RF DETV LED SW RF DETV & LED SW LED CTRL LED CTRL UNLK LPF LOOP FIL FM-DET S OUT NOISE DET D1:MA77 D8,D9:MA77 ANT SW D13 MA304 BPF D14,D15,D16 MA304 BPF FI1 FL-325 XTAL BPF LPF D2:MA728 D3:MA728 PWR DET Q2 2SK2974 AMP PWR Q3 2SK2973 AMP YGR Q29 2SC4403 BUFF Q33 2SC4116 VCO V CURRENT AMP Q31,Q32 D24:MA304 2SC4226 IC3 TB31207FN PLL IC Q18 2SC4211 DET AM X1 CDBCA450CX24 IC505 M52429FP EL- VOL Q1 UMS1 ALC CTRL Q35:2SB1201 Q36:XP1501 AF OUT CTRL X2 CR-683 (29.600MHz) IC6 TA7368F AMP PWR IC2 TC4W53F AM/FM SW IC13 NJM2107F RSSI AMP IC4 M62354GP D-A CONVERT IC5:BU4094BCFV SHIFT RESISTOR Q21 UN9210 ANL SW D18 MA111 ANL D26 HVU17 freq-ADJ IC7 HN58X2432 EEPROM X1 CR-534 DS1 2378LED LCD Q1:2SB1132 Q2:2SC4116 LED DRV Q8:XP1201 LED DRV Q9:XP1201 LED DRV DS4 LT1EP53A Q7:2SB1132 Q8:2SC4211 TX CTRL D7:MA111 S5 POWER SW D4:DA112 D3:DAP202U INITIAL SET Q10:2SB1462 D14:MA2S111 PTT DET IC9 BA3308F MIC-ANL AMP R41 IC8 BU4094BCFV SHIFT RESISTOR Q19 UN9210 VOR SW CMP BUFF AMP TIMIL BPFBPF IC15 ISD1420SI VOICE REC/PLAY Q11 XP4315 ALC CTRL Q15:XP4315 VOR CTRL Q25:2SB1132 Q26:UN9211 D23:MA133 D27:MA111 EXT MIC CTRL Q12 UN9211 MIC MUTE IC11NJM2903V FM DET LPF IC13NJM2904V PHASE SHIFT IC12NJM2902V BIAS IC2 S-80945ALMP RESET IC14 NJM2903V CMP Q13:2SC4211 D17:MA2S111 AMP IC3:S-81350HG D9:MA728 +5 REG IC16 S-81250SG +5 REG Q7:XP1501 Q4:2SB1132 POWER SW D10:MA2S111 Q24HAT1024R POW SW J1 DC 12V in SP1 INT SP J2 EXT SP/MIC D20:SB07-03C D21:MA133 BATT CHG SW Q22:2SB1132 D22 MA2S728 12V/ BATT SW VCC HV +5V D11:MA2S111 Q5:UN9210 CLONE I/O D25:MA77 Q34:UN9210 RX SHIFT Q20 UN9115 RX CTRL D5 1SV246 MOD ATT LO SW D6:MA77 D17:MA77 MP1 123 123 THERMO DETECT R37 :NTCCM16084LH Q6 2SC4403 BUFF Q30 2SC4403 BUFF Q27,Q28 2SC4403 BUFF 2SC3357 Q4 PRE DRIVE S1 DIAL E UP DN MC1 EM-140 MIC Q11 3SK230 AMP RF Q12 3SK151 IC510 TC75W51F AMP AF AMP IF Q15 2SC4215 AMP IF Q16 2SC4215 AMP IF Q13 2SC4215 AMP IF FI2 CFWC450E BPF CERAMIC ATT D4 1SV246 ALC Q6 UN9213 BUFF S2 PTT SW +5V Q23UN9210 BUFF LPF Q5 2SC4211 AMP ALC D7:MA8100 D8:MA2S111 Q3:2SD2216 CHG V-SENS Q14 2SD1819A AMP AGC Q10 2SD1819A AMP AGC Q17 2SC4215 AMP IF S1 LED SW DS2~DS3 LNJ310MURA DS5~DS10 LN1371G X6

SERIAL NUMBER PLATE. IC-A23

IC-A23/A5 Circuit Description 1. RF Board (PLL/VCO) VCO consists of Q31,Q32 and D24, and Q34 and D25 are oscillator shift circuit for receive mode. The signals form VCO are amplified by Q29 and Q30, and a fed to pin 8 of IC-3. IC-3 is PLL IC, and the signals from Q30 are divided by 1/N data, which set by the serial data from CPU, and then are fed to phase detector. X2 is reference crystal oscillator, and the signals from oscillator are divided by reference programable counter, and then are out from IC-3 as phase pulse The signals from IC-3 are pass through loop filter, and are fed to D24 on VCO for controlling oscillating frequency signals. 2. Receiver (RF) The incoming signals from antenna are pass through low pass filer, consists of L1-L3 and C3-C7, and are fed to antenna switching circuit The antenna switching circuit uses quarter wave diode switching circuit, and in receive mode, D1, D8 and D9 are turned off. The incoming signals from the antenna switching circuit are pass through the band pass filter, which consists of D13, C58, C60 and L18, and are fed to Q11. The amplified signals from Q11 are filtered by the band pass filter, which consists of D14-D16, C70-C79, and are fed to Q12. Q12 is 1 st mixer and mixes the incoming receive signals with 1 st LO signals, and puts out 30.05MHz, 1 st IF signals. (1 st IF) The incoming signals from 1 st mixer is filtered by FI-1 (Crystal filter), and are fed to Q13 and IC-1. (2 nd IF) IC-1 is 2 nd IF IC, and the IC contains 2 nd LO oscillator, 2 nd mixer, IF amplifier, FM detector and S-meter circuit. The incoming 1 st IF signals (30.5MHz) from Q13 are fed to the IC-1 and are mixed with 2nd LO signals (29.6MHz) from PLL reference crystal for generating 2 nd IF signals. The incoming 2 nd IF signals (450MHz) are filtered by FI-2 (Ceramic filter), and are fed to AM or FM demodulating circuit through Q15. For FM mode, the signals from Q15 are amplified by IC-1 and pin 9 of IC-1 puts out AF signals after de-modulated by FM detector. For AM mode, the signals from Q15 are amplified by Q16 nad Q17, and then are de- modulated by Q18. (AF) The de-modulated incoming signals are path through IC2 (Analog switch), amplified by amplifier (IC-510), filtered by low pass filter (IC-510), amplified by IC-14, volume controlled by IC-505, amplified by IC-6 and the fed to speaker (SQL) The s-meter signals from pin 12 of IC-1 are amplified by IC-13, and fed to pin3 of CPU. The SQL control signals from CPU are fed to Q35 and Q36, and controls IC-6 3. Transmitter (TX) The transmitting signals from VCO are amplified by Q30, Q27 and Q28, and are fed to AM modulator circuit (D5) through D6. The modulated transmitting signals from D5 are amplified by Q6,Q4,Q3 and Q2, and are fed to antenna through antenna switching circuit (D1) and high and low pass filer. (ALC) ALC voltage signals are detected by D2 and D3, and are amplified by Q5, and then fed to D4 for controlling transmit output power. (Transmit Audio) The incoming microphone audio are filtered by low pass filter (IC-510) and are fed to the D5 as transmit modulating signals 4. Power supply (Internal/External switching circuit) When the radio is used with battery pack, Q24 is turned on. When external DC is apply to the radio, Q24 is turned off D19 and D22 is reverse voltage protector (Battery Pack Charging Circuit) The charging circuit consists of D20,D21 Q22 and Q23. 5. Logic (Reset) IC-2 detect DC power voltage, and sends reset signals to pin33 of CPU when the radio is turned on (Clock Oscillator) X1 on CPU generates CPU clock signals (Lamp) Pin7 of IC-8 controls LCD and keyboard lighting on the front panel through Q1, Q2, Q8 (Clone) Clone is done by pin 19 and 20 on CPU Q5 and D11 (MIC AMP) When PLL switch is repressed, incoming mic audio are amplified by IC-9, and fed to IC-15. (PTT) Q10 detects PLL controls, and sends the status signals to CPU (DC regulator) The radio is supplying 5V DC to IC-1 and IC-7 through IC-3. When radio is on, pin54 on CPU controls Q6,Q4 and Q7, and supplying 5V DC to other circuit. (VOR) The frequencies are selected between 108MHz and 117.975MHz, pin4 on IC-8 becomes high level, and supplying DC power to VOR circuit through Q15. Also the voltages from Q15 are divided by R75 and R76, and are fed topin3 of IC-12, and supplying biased voltage from pin1 to other op amp. The VOR detected signals from RF board are fed to pin5 n IC-12 through VORDET line. Amplified signals from pin7 on IC-12 are filtered by 9960Hz band pass filter and 30Hz band pass filter (30Hz Band Pass Filter) This band pass filter consists of R83, R85-R88, C112-C113 and IC12, and filtered signals are converted the square wave signals by IC-14, and are fed to VORC line on CPU (9960Hz Band Pass Filter) This band pass filter consists of R79-R81, C108-C109 and IC-12, and filtered signals are 9960Hz reference signals, which modulated by 30Hz with 480Hz deviation. Those reference signals are amplified by IC-11. When pin1 of IC-11 is 0V, D16 is on, and C102 will be discharged. At same time pin7 of IC11 will be high. When pin1 of IC-11 is 2V, C102 will be charged through C62, and pin7 of IC-11 will become low level to high level, and becomes PWM signals. This PWM signals are filtered by LPF (R63, C114), pass through phase detector (IC-13, R66-R68, C115) and IC-14, and are fed to CPU as VORS signal line. (OFF FLAG) When Incoming signals are not VOR signals nor low level signals, pin7 of IC-12 becomes low level, and Q13 sends high level signals to CPU for turning on the “VOR OFF FLAG” (Battery Pack protecting circuit) When the temperature gets below 0 degrees C, R37 send signals to pin 5 of CPU, and cuts RF output power to half.

IC-A23/A5 Alignment Procedure PLL lock voltage - Connect multi-meter between CP1 and ground - Apply the DC power to the radio, and turning radio on. - Set the display to 136.975MHz - Adjust L40 for 3.7V Transmitter idling current - Connect RF power meter to ANT connector - Apply the DC power to the radio, and turning radio on. - Transmit - Adjust R16 for 600mA Following step requires Cloning software, CS-A23 - Enable alignment mode on CS-A23 - Hold MR + CLR + SQL + PWR keys, and turning power on PLL Reference crystal - Connect 50 ohms dummy load to ANT connector - Loosely couples probe on frequency counter - Select “FREQADJ” - Transmit - Adjust up/down key for displayed frequency Transmit output power - Connect RF Power meter to ANT connector - Select “PWRADJ” - Transmit - Adjust DIAL for 1.5W carrier Transmit modulation - Connect modulation analyzer to ANT connector - Connect AF signal generator to mic terminal - Select “PWRADJ” - Apply 1KHz / 200mV signals to mic connector - Transmit - Adjust R554 on RF board for 85% - Apply 1KHz / 10mV signals to mic connector - Adjust R41 on LOGIC board for 30% Receiver BPF - Connect RF signal generator to ANT connector - Connect AC voltmeter with 4 ohm load to speaker jack - Select “BF1ADJ” - Set RF signal generator to displayed frequency - Apply –107dBm with no modulation signals to ANT connector - Adjust DIAL for initiating automatic alignment - Select “BF2ADJ” - Set RF signal generator to displayed frequency - Adjust DIAL for initiating automatic alignment - Select “BF3ADJ” - Set RF signal generator to displayed frequency - Adjust DIAL for initiating automatic alignment - Select “BF4ADJ” - Set RF signal generator to displayed frequency - Adjust DIAL for initiating automatic alignment Receiver SQL - Connect RF signal generator to ANT connector - Select “ASADJS” for AM squelch threshold - Set RF signal generator to lowest frequency of avionics band - Apply –113dBm with no modulation signals to ANT connector - Adjust DIAL for initiating automatic alignment - Select “ASADJT” for AM tight squelch - Set RF signal generator to highest frequency of avionics band - Apply –93dBm with no modulation signals to ANT connector - Adjust DIAL for initiating automatic alignment - Select “FSADJS” for FM squelch threshold - Set RF signal generator to 161.65MHz - Apply –122dBm with no modulation signals to ANT connector - Adjust DIAL for initiating automatic alignment - Select “FSADJT” for FM squelch threshold - Set RF signal generator to 161.65MHz - Apply –102dBm with no modulation signals to ANT connector - Adjust DIAL for initiating automatic alignment VOR Bering - Connect VOR signal generator to ANT connector - Select “VORADJ” - Set VOR signal generator to 113.00MHz - Apply –60dBm with “FROM 90 degrees” to ANT connector - Adjust DIAL for initiating automatic alignment VOR Off - Connect VOR signal generator to ANT connector - Select “OFFADJ” - Set VOR signal generator to 113.00MHz - Apply –90dBm with “FROM 90 degrees” to ANT connector - Adjust DIAL for initiating automatic alignment

REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS IC11140009230S.ICM38267M8L-266GPMITSUBISHI1 IC21110004750S.ICS-80945ALMP-DA9-T2SEIKO1 IC31180000800S.ICS-81350HG-KDSEIKO1 IC71130009680S.ICHN58X2432TIHITACHI1 IC81130007510S.ICBU4094BCFVROHM1 IC91110003670S.ICBA3308FROHM1 IC111110003790S.ICNJM2903VJRC1 IC121110003780S.ICNJM2902VJRC1 IC131110003800S.ICNJM2904VJRC1 IC141110003790S.ICNJM2903VJRC1 IC151190001360S.ICISD1420SI1 IC161180001170S.ICS-81250SG-QDSEIKO1 Q11520000460S.TRANSISTOR2SB1132 RROHM1 Q21530003280S.TRANSISTOR2SC4211 6SANYO1 Q31540000350S.TRANSISTOR2SD2216 SMEC1 Q41520000270S.TRANSISTOR2SB1182 F5 QROHM1 Q51590001140S.TRANSISTORUN9210MEC1 Q61590001470S.TRANSISTORUN9213MEC1 Q71590001170S.TRANSISTORXP1501 ABMEC1 Q81590002620S.TRANSISTORXP1201MEC1 Q91590002620S.TRANSISTORXP1201MEC1 Q101520000430S.TRANSISTOR2SB1462 RMEC1 *************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E1 ************************************************************************************************************************************************************************************************************** Q111590001980S.TRANSISTORXP4315MEC1 REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS Q121590001150S.TRANSISTORUN9211MEC1 Q131530003280S.TRANSISTOR2SC4211 6SANYO1 Q151590001980S.TRANSISTORXP4315MEC1 Q161590000980S.TRANSISTORDTB123EKROHM1 Q171590001940S.TRANSISTORDTC144EEROHM1 D11790001250S.DIODEMA2S111MEC1 D21790001200S.DIODEMA6S121MEC1 D31160000050S.DIODEDAP202UROHM1 D41750000240S.DIODEDA112ROHM1 D71730002330S.ZENERMA8100 MMEC1 D81790001250S.DIODEMA2S111MEC1 D91790000660S.DIODEMA728MEC1 D101790001250S.DIODEMA2S111MEC1 D111790001250S.DIODEMA2S111MEC1 D121790001250S.DIODEMA2S111MEC1 D131790000990S.ZENERMA8051 HMEC1 D141790001250S.DIODEMA2S111MEC1 D151790001330S.ZENERMA8036 LMEC1 D161790001250S.DIODEMA2S111MEC1 D171790001250S.DIODEMA2S111MEC1 D181790000990S.ZENERMA8051 HMEC1 *************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E2 ************************************************************************************************************************************************************************************************************** REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS X16050009620S.XTALCR-534DAISHINKU1 R17030003640S.RESISTOR47K ERJ3GEMACO1 R27030003680S.RESISTOR100K ERJ3GEMACO1 R37030003680S.RESISTOR100K ERJ3GEMACO1 R47030003680S.RESISTOR100K ERJ3GEMACO1 R57030003680S.RESISTOR100K ERJ3GEMACO1 R67030003560S.RESISTOR10K ERJ3GEMACO1 R77030003560S.RESISTOR10K ERJ3GEMACO1 R87030003680S.RESISTOR100K ERJ3GEMACO1 R97410000730S.ARRAYEXB-V8V 100KMACO1 R107030003680S.RESISTOR100K ERJ3GEMACO1 R117030003390S.RESISTOR390 ERJ3GEMACO1 R127030003390S.RESISTOR390 ERJ3GEMACO1 R137030003390S.RESISTOR390 ERJ3GEMACO1 R147030003500S.RESISTOR3.3K ERJ3GEMACO1 R157030003510S.RESISTOR3.9K ERJ3GEMACO1 R167030003680S.RESISTOR100K ERJ3GEMACO1 R177030003560S.RESISTOR10K ERJ3GEMACO1 R187030003560S.RESISTOR10K ERJ3GEMACO1 *************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E3 ************************************************************************************************************************************************************************************************************** R197030003800S.RESISTOR1M ERJ3GEMACO1 R207030003560S.RESISTOR10K ERJ3GEMACO1 R217030003560S.RESISTOR10K ERJ3GEMACO1 REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS R227030003520S.RESISTOR4.7K ERJ3GEMACO1 R237030003720S.RESISTOR220K ERJ3GEMACO1 R247030003680S.RESISTOR100K ERJ3GEMACO1 R257030003350S.RESISTOR180 ERJ3GEMACO1 R267030003350S.RESISTOR180 ERJ3GEMACO1 R277030003440S.RESISTOR1K ERJ3GEMACO1 R287030003400S.RESISTOR470 ERJ3GEMACO1 R307030003600S.RESISTOR22K ERJ3GEMACO1 R317030003620S.RESISTOR33K ERJ3GEMACO1 R327030003400S.RESISTOR470 ERJ3GEMACO1 R337030003560S.RESISTOR10K ERJ3GEMACO1 R347030003720S.RESISTOR220K ERJ3GEMACO1 R357030003560S.RESISTOR10K ERJ3GEMACO1 R367030003580S.RESISTOR15K ERJ3GEMACO1 R377510001160S.THERMISTORNTCCM16084LH 473KCTDK1 R387030003680S.RESISTOR100K ERJ3GEMACO1 R397030003600S.RESISTOR22K ERJ3GEMACO1 R407030003680S.RESISTOR100K ERJ3GEMACO1 R417310004320S.TRIMMERRH03APAS4 47KALPS1 R427030003270S.RESISTOR39 ERJ3GEMACO1 R437030003680S.RESISTOR100K ERJ3GEMACO1 R447030003580S.RESISTOR15K ERJ3GEMACO1 *************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E4 ************************************************************************************************************************************************************************************************************** R457030003620S.RESISTOR33K ERJ3GEMACO1 R467510000960S.THERMISTORTBPS1R104K475H5QTAIYO1 R477030003800S.RESISTOR1M ERJ3GEMACO1 R487030003680S.RESISTOR100K ERJ3GEMACO1 REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS R527030003690S.RESISTOR120K ERJ3GEMACO1 R587030003680S.RESISTOR100K ERJ3GEMACO1 R597030003680S.RESISTOR100K ERJ3GEMACO1 R607030003630S.RESISTOR39K ERJ3GEMACO1 R617030003640S.RESISTOR47K ERJ3GEMACO1 R627030003720S.RESISTOR220K ERJ3GEMACO1 R637030003580S.RESISTOR15K ERJ3GEMACO1 R647030003520S.RESISTOR4.7K ERJ3GEMACO1 R657030003720S.RESISTOR220K ERJ3GEMACO1 R667030003720S.RESISTOR220K ERJ3GEMACO1 R677030003560S.RESISTOR10K ERJ3GEMACO1 R687030003730S.RESISTOR270K ER…

Text truncated - open the document above for the full version.

REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS IC11140009230S.ICM38267M8L-266GPMITSUBISHI1 IC21110004750S.ICS-80945ALMP-DA9-T2SEIKO1 IC31180000800S.ICS-81350HG-KDSEIKO1 IC71130009680S.ICHN58X2432TIHITACHI1 IC81130007510S.ICBU4094BCFVROHM1 IC91110003670S.ICBA3308FROHM1 IC111110003790S.ICNJM2903VJRC1 IC121110003780S.ICNJM2902VJRC1 IC131110003800S.ICNJM2904VJRC1 IC141110003790S.ICNJM2903VJRC1 IC151190001360S.ICISD1420SI1 IC161180001170S.ICS-81250SG-QDSEIKO1 Q11520000460S.TRANSISTOR2SB1132 RROHM1 Q21530003280S.TRANSISTOR2SC4211 6SANYO1 Q31540000350S.TRANSISTOR2SD2216 SMEC1 Q41520000270S.TRANSISTOR2SB1182 F5 QROHM1 Q51590001140S.TRANSISTORUN9210MEC1 Q61590001470S.TRANSISTORUN9213MEC1 Q71590001170S.TRANSISTORXP1501 ABMEC1 Q81590002620S.TRANSISTORXP1201MEC1 Q91590002620S.TRANSISTORXP1201MEC1 Q101520000430S.TRANSISTOR2SB1462 RMEC1 **************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E12000/6/1 * *************************************************************************************************************************************************************************************************************** REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS Q111590001980S.TRANSISTORXP4315MEC1 Q121590001150S.TRANSISTORUN9211MEC1 Q131530003280S.TRANSISTOR2SC4211 6SANYO1 Q151590001980S.TRANSISTORXP4315MEC1 Q161590000980S.TRANSISTORDTB123EKROHM1 Q171590001940S.TRANSISTORDTC144EEROHM1 D11790001250S.DIODEMA2S111MEC1 D21790001200S.DIODEMA6S121MEC1 D31160000050S.DIODEDAP202UROHM1 D41750000240S.DIODEDA112ROHM1 D71730002330S.ZENERMA8100 MMEC1 D81790001250S.DIODEMA2S111MEC1 D91790000660S.DIODEMA728MEC1 D101790001250S.DIODEMA2S111MEC1 D111790001250S.DIODEMA2S111MEC1 D121790001250S.DIODEMA2S111MEC1 D131790000990S.ZENERMA8051 HMEC1 D141790001250S.DIODEMA2S111MEC1 D151790001330S.ZENERMA8036 LMEC1 D161790001250S.DIODEMA2S111MEC1 D171790001250S.DIODEMA2S111MEC1 D181790000990S.ZENERMA8051 HMEC1 **************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E22000/6/1 * *************************************************************************************************************************************************************************************************************** REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS X16050009620S.XTALCR-534DAISHINKU1 R17030003640S.RESISTOR47K ERJ3GEMACO1 R27030003680S.RESISTOR100K ERJ3GEMACO1 R37030003680S.RESISTOR100K ERJ3GEMACO1 R47030003680S.RESISTOR100K ERJ3GEMACO1 R57030003680S.RESISTOR100K ERJ3GEMACO1 R67030003560S.RESISTOR10K ERJ3GEMACO1 R77030003560S.RESISTOR10K ERJ3GEMACO1 R87030003680S.RESISTOR100K ERJ3GEMACO1 R97410000730S.ARRAYEXB-V8V 100KMACO1 R107030003680S.RESISTOR100K ERJ3GEMACO1 R117030003390S.RESISTOR390 ERJ3GEMACO1 R127030003390S.RESISTOR390 ERJ3GEMACO1 R137030003390S.RESISTOR390 ERJ3GEMACO1 R147030003500S.RESISTOR3.3K ERJ3GEMACO1 R157030003510S.RESISTOR3.9K ERJ3GEMACO1 R167030003680S.RESISTOR100K ERJ3GEMACO1 R177030003560S.RESISTOR10K ERJ3GEMACO1 R187030003560S.RESISTOR10K ERJ3GEMACO1 **************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E32000/6/1 * *************************************************************************************************************************************************************************************************************** REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS R197030003800S.RESISTOR1M ERJ3GEMACO1 R207030003560S.RESISTOR10K ERJ3GEMACO1 R217030003560S.RESISTOR10K ERJ3GEMACO1 R227030003520S.RESISTOR4.7K ERJ3GEMACO1 R237030003720S.RESISTOR220K ERJ3GEMACO1 R247030003680S.RESISTOR100K ERJ3GEMACO1 R257030003350S.RESISTOR180 ERJ3GEMACO1 R267030003350S.RESISTOR180 ERJ3GEMACO1 R277030003440S.RESISTOR1K ERJ3GEMACO1 R287030003400S.RESISTOR470 ERJ3GEMACO1 R307030003600S.RESISTOR22K ERJ3GEMACO1 R317030003620S.RESISTOR33K ERJ3GEMACO1 R327030003400S.RESISTOR470 ERJ3GEMACO1 R337030003560S.RESISTOR10K ERJ3GEMACO1 R347030003720S.RESISTOR220K ERJ3GEMACO1 R357030003560S.RESISTOR10K ERJ3GEMACO1 R367030003580S.RESISTOR15K ERJ3GEMACO1 R377510001160S.THERMISTORNTCCM16084LH 473KCTDK1 R387030003680S.RESISTOR100K ERJ3GEMACO1 R397030003600S.RESISTOR22K ERJ3GEMACO1 R407030003680S.RESISTOR100K ERJ3GEMACO1 R417310004320S.TRIMMERRH03APAS4 47KALPS1 R427030003270S.RESISTOR39 ERJ3GEMACO1 R437030003680S.RESISTOR100K ERJ3GEMACO1 R447030003580S.RESISTOR15K ERJ3GEMACO1 **************************************************************************************************************************************************************************************************************** *P A R T S L I S T/IC-A23LOGIC UNIT6E42000/6/1 * *************************************************************************************************************************************************************************************************************** REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS R457030003620S.RESISTOR33K ERJ3GEMACO1 R467510000960S.THERMISTORTBPS1R104K475H5QTAIYO1 R477030003800S.RESISTOR1M ERJ3GEMACO1 R487030003680S.RESISTOR100K ERJ3GEMACO1 R527030003690S.RESISTOR120K ERJ3GEMACO1 R587030003680S.RESISTOR100K ERJ3GEMACO1 R597030003680S.RESISTOR100K ERJ3GEMACO1 R607030003630S.RESISTOR39K ERJ3GEMACO1 R617030003640S.RESISTOR47K ERJ3GEMACO1 R627030003720S.RESISTOR220K ERJ3GEMACO1 R637030003580S.RESISTOR15K ERJ3GEMACO1 R647030003520S.RESISTOR4.7K ERJ3GEMACO1 R657030003720S.RESISTOR220K ERJ3GEMACO1 R667030003720S.RESISTOR220K ERJ3GEMACO1 R677030003560S.RESIST…

Text truncated - open the document above for the full version.

REFNOCODEDESCRIPTION TYPE(PARTS)MANUFATURERVERQTYSHPHREMARKS IC11110003490S.ICTA31136FN(D)TOSHIBA1 IC21130006220S.ICTC4W53FUTOSHIBA1 IC31130008830S.ICTB31207AFNTOSHIBA1 IC41110003690S.ICM62354GPMITSUBISHI1 IC51130007570S.ICBU4…
