AFJIC-F221SIC-F221S

iF111SVHF TRANSCEIVER INSTRUCTION MANUAL UHF TRANSCEIVERiF121SiF211SiF221S IC-F111S_F121S_F211S_F221S 02.10.3 11:54 AM Page a (1,1) i IMPORTANTEXPLICIT DEFINITIONS R WARNING! NEVER connect the transceiver to an AC outlet. This may pose a fire hazard or result in an electricshock. CAUTION! NEVER touch the transceiver (especially the heat sink ) when transmitting continuously for long peri- ods. It will become hot. NEVER connect the transceiver to a power source of more than 16 V DC such as a 24 V battery. This connection will ruinthe transceiver. NEVER cut the DC power cable between the DC plug and fuse holder. If an incorrect connection is made after cutting,the transceiver might be damaged. NEVER place the transceiver where normal operation of the vehicle may be hindered or where it could cause bodilyinjury. NEVER allow children to touch the transceiver. NEVER expose the transceiver to rain, snow or any liquids. PRECAUTION WORD DEFINITION R WARNING Personal injury, fire hazard or electric shockmay occur. CAUTION Equipment damage may occur. NOTE If disregarded, inconvenience only. No riskof personal injury, fire or electric shock. READ ALL INSTRUCTIONS carefully and com- pletely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This instruction manual contains important operating instructionsfor the IC-F111S/F121S VHF TRANSCEIVER and IC- F211S/F221S UHF TRANSCEIVER . Icom, Icom Inc. and the logo are registered trademarks of Icom Incorporated (Japan) in the United states, the UnitedKingdom, Germany, France, Spain, Russia and/or other coun-tries.SmarTrunk II™ is a Trademark of SmarTrunk Systems, Inc. IC-F111S_F121S_F211S_F221S 02.10.3 11:54 AM Page i (1,1) ii USE the supplied microphone only. Other microphones have different pin assignments and may damage the trans-ceiver. DO NOT use or place the transceiver in areas with tempera- tures below –22°F (–30°C) or above +140°F (+60°C), or in areassubject to direct sunlight, such as the dashboard of a vehicle. AVOID operating the transceiver without running the vehi- cle’s engine. The vehicle’s battery will quickly run out if thetransceiver is in transmission while the vehicle’s engine OFF.AVOID placing the transceiver in excessively dusty envi- ronments. AVOID placing the transceiver against walls. This will obstruct heat dissipation. AVOID the use of chemical agents such as benzine or alco- hol when cleaning, as they damage the transceiver surfaces.For U.S.A. onlyCAUTION: Changes or modifications to this transceiver, not ex- pressly approved by Icom Inc., could void your authority to operatethis transceiver under FCC regulations. TABLE OF CONTENTSIMPORTANT .................................................................................... iEXPLICIT DEFINITIONS ................................................................. iPRECAUTION .................................................................................. iTABLE OF CONTENTS .................................................................. ii1 PANEL DESCRIPTION ........................................................... 1–5  Front panel ............................................................................... 1  Function LED ........................................................................... 2  Programmable function keys .................................................... 3 2 OPERATION ............................................................................ 6–8  Turning power ON .................................................................... 6  Channel selection ..................................................................... 6  Receiving and transmitting ....................................................... 7 D Transmitting notes ................................................................. 7 D Scrambler function ................................................................ 8 D User set mode ....................................................................... 8 3 CONNECTION AND MAINTENANCE .................................. 9–13  Rear panel and connection ...................................................... 9  Supplied Accessories ............................................................. 10  Mounting the transceiver ......................................................... 11  Optional UT-108 installation ................................................... 11  Optional UT-109/UT-110 installation ...................................... 12  Optional OPC-617 installation................................................. 12  Antenna ................................................................................... 13  Fuse replacement .................................................................. 13  Cleaning ................................................................................. 13 4 OPTIONS ................................................................................... 145 SAFETY TRAINING INFORMATION ........................................ 15 IC-F111S_F121S_F211S_F221S 02.10.3 11:54 AM Page ii (1,1) 1 1 PANEL DESCRIPTION TX/RX 1 2 3 4 q w e r Function LED (p. 2)  Front panel q AF VOLUME CONTROL KNOB ➥ Rotate the knob to adjust the audio output level. • Minimum audio level is pre-programmed. w MICROPHONE CONNECTOR ➥ Connect the supplied microphone or optional DTMF micro-phone. NEVER connect non-specified microphones. The pin assignments may be different and the transceiver maybe damaged. e DEALER-PROGRAMMABLE KEYS [P0] to [P3] ➥ Desired functions can be programmed independently byyour Dealer. r POWER SWITCH [POWER] ➥ Push to turn the power ON and OFF. • The following functions are available at power ON as options: - Automatic scan start- Password prompt- Set mode IC-F111S_F121S_F211S_F221S 02.10.3 11:54 AM Page 1 (1,1) 2 1 PANEL DESCRIPTION  Function LED q CHANNEL INDICATORS ➥ Indicates the operating channel. ➥ Blinks when receiving a signal during scanning opera-tion. ➥ All LEDs blink whil…

Text truncated - open the document above for the full version.

iF111SVHF TRANSCEIVER INSTRUCTION MANUAL UHF TRANSCEIVERiF121SiF211SiF221S IC-F111S_F121S_F211S_F221S-1 02.12.20 10:36 AM Page a (1,1) i IMPORTANTEXPLICIT DEFINITIONS R WARNING! NEVER connect the transceiver to an AC outlet. This may pose a fire hazard or result in an electricshock. CAUTION! NEVER touch the transceiver (especially the heat sink ) when transmitting continuously for long peri- ods. It will become hot. NEVER connect the transceiver to a power source of more than 16 V DC such as a 24 V battery. This connection will ruinthe transceiver. NEVER cut the DC power cable between the DC plug and fuse holder. If an incorrect connection is made after cutting,the transceiver might be damaged. NEVER place the transceiver where normal operation of the vehicle may be hindered or where it could cause bodilyinjury. NEVER allow children to touch the transceiver. NEVER expose the transceiver to rain, snow or any liquids. PRECAUTION WORD DEFINITION R WARNING Personal injury, fire hazard or electric shockmay occur. CAUTION Equipment damage may occur. NOTE If disregarded, inconvenience only. No riskof personal injury, fire or electric shock. READ ALL INSTRUCTIONS carefully and com- pletely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This instruction manual contains important operating instructionsfor the IC-F111S/F121S VHF TRANSCEIVER and IC- F211S/F221S UHF TRANSCEIVER . Icom, Icom Inc. and the logo are registered trademarks of Icom Incorporated (Japan) in the United states, the UnitedKingdom, Germany, France, Spain, Russia and/or other coun-tries.SmarTrunk II™ is a Trademark of SmarTrunk Systems, Inc. IC-F111S_F121S_F211S_F221S-1 02.12.20 10:36 AM Page i (1,1) ii USE the supplied microphone only. Other microphones have different pin assignments and may damage the trans-ceiver. DO NOT use or place the transceiver in areas with tempera- tures below –22°F (–30°C) or above +140°F (+60°C), or in areassubject to direct sunlight, such as the dashboard of a vehicle. AVOID operating the transceiver without running the vehi- cle’s engine. The vehicle’s battery will quickly run out if thetransceiver is in transmission while the vehicle’s engine OFF.AVOID placing the transceiver in excessively dusty envi- ronments. AVOID placing the transceiver against walls. This will obstruct heat dissipation. AVOID the use of chemical agents such as benzine or alco- hol when cleaning, as they damage the transceiver surfaces.For U.S.A. onlyCAUTION: Changes or modifications to this transceiver, not ex- pressly approved by Icom Inc., could void your authority to operatethis transceiver under FCC regulations. TABLE OF CONTENTSIMPORTANT .................................................................................... iEXPLICIT DEFINITIONS ................................................................. iPRECAUTION .................................................................................. iTABLE OF CONTENTS .................................................................. ii1 PANEL DESCRIPTION ........................................................... 1–5  Front panel ............................................................................... 1  Function LED ........................................................................... 2  Programmable function keys .................................................... 3 2 OPERATION ............................................................................ 6–8  Turning power ON .................................................................... 6  Channel selection ..................................................................... 6  Receiving and transmitting ....................................................... 7 D Transmitting notes ................................................................. 7 D Scrambler function ................................................................ 8 D User set mode ....................................................................... 8 3 CONNECTION AND MAINTENANCE .................................. 9–13  Rear panel and connection ...................................................... 9  Supplied Accessories ............................................................. 10  Mounting the transceiver ......................................................... 11  Optional UT-108 installation ................................................... 11  Optional UT-109/UT-110 installation ...................................... 12  Optional OPC-617 installation................................................. 12  Antenna ................................................................................... 13  Fuse replacement .................................................................. 13  Cleaning ................................................................................. 13 4 OPTIONS ................................................................................... 145 SAFETY TRAINING INFORMATION ........................................ 15 IC-F111S_F121S_F211S_F221S-1 02.12.20 10:36 AM Page ii (1,1) 1 1 PANEL DESCRIPTION TX/RX 1 2 3 4 q w e r Function LED (p. 2)  Front panel q AF VOLUME CONTROL KNOB ➥ Rotate the knob to adjust the audio output level. • Minimum audio level is pre-programmed. w MICROPHONE CONNECTOR ➥ Connect the supplied microphone or optional DTMF micro-phone. NEVER connect non-specified microphones. The pin assignments may be different and the transceiver maybe damaged. e DEALER-PROGRAMMABLE KEYS [P0] to [P3] ➥ Desired functions can be programmed independently byyour Dealer. r POWER SWITCH [POWER] ➥ Push to turn the power ON and OFF. • The following functions are available at power ON as options: - Automatic scan start- Password prompt- Set mode IC-F111S_F121S_F211S_F221S-1 02.12.20 10:36 AM Page 1 (1,1) 2 1 PANEL DESCRIPTION  Function LED q CHANNEL INDICATORS ➥ Indicates the operating channel. ➥ Blinks when receiving a signal during scanning opera-tion. ➥ All LED…

Text truncated - open the document above for the full version.

iF111SVHF TRANSCEIVER INSTRUCTION MANUAL UHF TRANSCEIVERiF121SiF211SiF221S IC-F111_121_211_221S-1.qxd 03.1.8 1:34 PM Page a (1,1) i IMPORTANTEXPLICIT DEFINITIONS R WARNING! NEVER connect the transceiver to an AC outlet. This may pose a fire hazard or result in an electricshock. CAUTION! NEVER touch the transceiver (especially the heat sink ) when transmitting continuously for long peri- ods. It will become hot. NEVER connect the transceiver to a power source of more than 16 V DC such as a 24 V battery. This connection will ruinthe transceiver. NEVER cut the DC power cable between the DC plug and fuse holder. If an incorrect connection is made after cutting,the transceiver might be damaged. NEVER place the transceiver where normal operation of the vehicle may be hindered or where it could cause bodilyinjury. NEVER allow children to touch the transceiver. NEVER expose the transceiver to rain, snow or any liquids. PRECAUTION WORD DEFINITION R WARNING Personal injury, fire hazard or electric shockmay occur. CAUTION Equipment damage may occur. NOTE If disregarded, inconvenience only. No riskof personal injury, fire or electric shock. READ ALL INSTRUCTIONS carefully and com- pletely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This instruction manual contains important operating instructionsfor the IC-F111S/F121S VHF TRANSCEIVER and IC- F211S/F221S UHF TRANSCEIVER . Icom, Icom Inc. and the logo are registered trademarks of Icom Incorporated (Japan) in the United states, the UnitedKingdom, Germany, France, Spain, Russia and/or other coun-tries.SmarTrunk II™ is a Trademark of SmarTrunk Systems, Inc. IC-F111_121_211_221S-1.qxd 03.1.8 1:34 PM Page i (1,1) ii USE the supplied microphone only. Other microphones have different pin assignments and may damage the trans-ceiver. DO NOT use or place the transceiver in areas with tempera- tures below –22°F (–30°C) or above +140°F (+60°C), or in areassubject to direct sunlight, such as the dashboard of a vehicle. AVOID operating the transceiver without running the vehi- cle’s engine. The vehicle’s battery will quickly run out if thetransceiver is in transmission while the vehicle’s engine OFF.AVOID placing the transceiver in excessively dusty envi- ronments. AVOID placing the transceiver against walls. This will obstruct heat dissipation. AVOID the use of chemical agents such as benzine or alco- hol when cleaning, as they damage the transceiver surfaces.For U.S.A. onlyCAUTION: Changes or modifications to this transceiver, not ex- pressly approved by Icom Inc., could void your authority to operatethis transceiver under FCC regulations. TABLE OF CONTENTSIMPORTANT .................................................................................... iEXPLICIT DEFINITIONS ................................................................. iPRECAUTION .................................................................................. iTABLE OF CONTENTS .................................................................. ii1 PANEL DESCRIPTION ........................................................... 1–5  Front panel ............................................................................... 1  Function LED ........................................................................... 2  Programmable function keys .................................................... 3 2 OPERATION ............................................................................ 6–8  Turning power ON .................................................................... 6  Channel selection ..................................................................... 6  Receiving and transmitting ....................................................... 7 D Transmitting notes ................................................................. 7 D Scrambler function ................................................................ 8 D User set mode ....................................................................... 8 3 CONNECTION AND MAINTENANCE .................................. 9–13  Rear panel and connection ...................................................... 9  Supplied Accessories ............................................................. 10  Mounting the transceiver ......................................................... 11  Optional UT-108 installation ................................................... 11  Optional UT-109/UT-110 installation ...................................... 12  Optional OPC-617 installation................................................. 12  Antenna ................................................................................... 13  Fuse replacement .................................................................. 13  Cleaning ................................................................................. 13 4 OPTIONS ................................................................................... 145 SAFETY TRAINING INFORMATION ........................................ 15 IC-F111_121_211_221S-1.qxd 03.1.8 1:34 PM Page ii (1,1) 1 1 PANEL DESCRIPTION TX/RX 1 2 3 4 q w e r Function LED (p. 2)  Front panel q AF VOLUME CONTROL KNOB ➥ Rotate the knob to adjust the audio output level. • Minimum audio level is pre-programmed. w MICROPHONE CONNECTOR ➥ Connect the supplied microphone or optional DTMF micro-phone. NEVER connect non-specified microphones. The pin assignments may be different and the transceiver maybe damaged. e DEALER-PROGRAMMABLE KEYS [P0] to [P3] ➥ Desired functions can be programmed independently byyour Dealer. r POWER SWITCH [POWER] ➥ Push to turn the power ON and OFF. • The following functions are available at power ON as options: - Automatic scan start- Password prompt- Set mode IC-F111_121_211_221S-1.qxd 03.1.8 1:34 PM Page 1 (1,1) 2 1 PANEL DESCRIPTION  Function LED q CHANNEL INDICATORS ➥ Indicates the operating channel. ➥ Blinks when receiving a signal during scanning opera-tion. ➥ All LEDs blink while enteri…

Text truncated - open the document above for the full version.

Oct. 29, 2002 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject:Type Acceptance Application under FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency bands 440-490 MHz (12.5 kHz and 25 kHz Channel Spacings). Applicant:ICOM Incorporated Product:MOBILE UHF TRANSCEIVER Model:IC-F221S FCC ID:AFJIC-F221S Dear Sir/Madam, As appointed agent for ICOM Incorporated, we would like to submit the application to Federal Communications Commission for certification of the above product. Please review all necessary files uploaded to FCC OET site. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.:1-877-765-4173 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH Encl. UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

IC-F221S FCC ID LABEL L

Your Icom radio generates RF electromag-netic energy during transmit mode. Thisradio is designed for and classified as“ Occupational Use Only ” , meaning it must be used only during the course of employ-ment by individuals aware of the hazards, and the ways to minimize such hazards. This radio isNOT intended for use by the “ General Population ” in an uncontrolled environment.• For compliance with FCC and Industry Canada RF Exposure Requirements, the transmitter antenna installationshall comply with the following two conditions: 1. The transmitter antenna gain shall not exceed 0 dBi.2. IC-F121S: The transmitter antenna is required to be located outsideof a vehicle and kept at a separation distance of 65 cen-timeters or more between the transmitter antenna of thisdevice and persons during operation. 3. IC-F221S: The transmitter antenna is required to be located outsideof a vehicle and kept at a separation distance of 52 cen-timeters or more between the transmitter antenna of thisdevice and persons during operation. To ensure that your exposure to RF elec-tromagnetic energy is within the FCCallowable limits for occupational use,always adhere to the following guidelines: • DO NOT operate the radio without a proper antenna attached, as this may damage the radio and may also causeyou to exceed FCC RF exposure limits. A proper antenna isthe antenna supplied with this radio by the manufacturer oran antenna speci fi cally authorized by the manufacturer for use with this radio. • DO NOT transmit for more than 50% of total radio use time ( “ 50% duty cycle ” ). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements tobe exceeded. The radio is transmitting when the “ TX indica- tor ” lights red. You can cause the radio to transmit by press- ing the “ PTT ” switch. Electromagnetic Interference/CompatibilityDuring transmissions, your Icom radio generates RF energythat can possibly cause interference with other devices orsystems. To avoid such interference, turn off the radio inareas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radi-ation such as hospitals, aircraft, and blasting sites. WARNING CAUTION 5 SAFETY TRAINING INFORMATION 15 IC-F111S_F121S_F211S_F221S 02.10.3 11:54 AM Page 15 (1,1)

Your Icom radio generates RF electromagneticenergy during transmit mode. This radio isdesigned for and classified as “ Occupational Use Only ” , meaning it must be used only during the course of employment by individuals awareof the hazards, and the ways to minimize such hazards. This radio is NOT intended for use by the “ General Population ” in an uncontrolled environment. • For compliance with FCC and Industry Canada RF Exposure Requirements, the transmitter antenna installation shall comply withthe following two conditions: 1. The transmitter antenna gain shall not exceed 0 dBi.2. IC-F121S: The antenna is required to be located outside of a vehicle andkept at a distance of 65 centimeters or more between the trans-mitting antenna of this device and any persons during operation.In order to ensure this distance is met, the installation of theantenna must be mounted at least 65 centimeters away from thenearest edge of the vehicle in order to protect against exposureto bystanders. 3. IC-F221S: The antenna is required to be located outside of a vehicle andkept at a distance of 52 centimeters or more between the trans-mitting antenna of this device and any persons during operation.In order to ensure this distance is met, the installation of theantenna must be mounted at least 52 centimeters away from thenearest edge of the vehicle in order to protect against exposureto bystanders. To ensure that your exposure to RF electromag-netic energy is within the FCC allowable limitsfor occupational use, always adhere to the fol-lowing guidelines: • DO NOT operate the radio without a proper antenna attached, as this may damage the radio and may also cause you to exceed FCCRF exposure limits. A proper antenna is the antenna supplied withthis radio by the manufacturer or an antenna speci fi cally authorized by the manufacturer for use with this radio. • DO NOT transmit for more than 50% of total radio use time ( “ 50% duty cycle ” ). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. The radiois transmitting when the “ TX indicator ” lights red. You can cause the radio to transmit by pressing the “ PTT ” switch. Electromagnetic Interference/CompatibilityDuring transmissions, your Icom radio generates RF energy that canpossibly cause interference with other devices or systems. To avoidsuch interference, turn off the radio in areas where signs are postedto do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blastingsites. WARNING CAUTION 5 SAFETY TRAINING INFORMATION 15 IC-F111S_F121S_F211S_F221S-1 02.12.20 10:36 AM Page 15 (1,1)

IC-F221S FCCIDLABEL WARNING STICKER LABEL

Your Icom radio generates RF electromagneticenergy during transmit mode. This radio isdesigned for and classified as “ Occupational Use Only ” , meaning it must be used only during the course of employment by individuals awareof the hazards, and the ways to minimize such hazards. This radio is NOT intended for use by the “ General Population ” in an uncontrolled environment. • For compliance with FCC and Industry Canada RF Exposure Requirements, the transmitter antenna installation shall comply withthe following two conditions: 1. The transmitter antenna gain shall not exceed 0 dBi.2. IC-F121S: The antenna is required to be located outside of a vehicle andkept at a distance of 1 meter or more between the transmittingantenna of this device and any persons during operation. Forsmall vehicle as worst case, the antenna shall be located on theroof top at any place on the centre line along the vehicle in orderto achieve 1 meter separation distance. In order to ensure thisdistance is met, the installation of the antenna must be mountedat least 1 meter away from the nearest edge of the vehicle inorder to protect against exposure to bystanders. 3. IC-F221S: The antenna is required to be located outside of a vehicle andkept at a distance of 79 centimeters or more between the trans-mitting antenna of this device and any persons during operation.For small vehicle as worst case, the antenna shall be located onthe roof top at any place on the centre line along the vehicle inorder to achieve 79 centimeters separation distance. In order to ensure this distance is met, the installation of the antenna mustbe mounted at least 79 centimeters away from the nearest edgeof the vehicle in order to protect against exposure to bystanders. To ensure that your exposure to RF electromag-netic energy is within the FCC allowable limitsfor occupational use, always adhere to the fol-lowing guidelines: • DO NOT operate the radio without a proper antenna attached, as this may damage the radio and may also cause you to exceed FCCRF exposure limits. A proper antenna is the antenna supplied withthis radio by the manufacturer or an antenna speci fi cally authorized by the manufacturer for use with this radio. • DO NOT transmit for more than 50% of total radio use time ( “ 50% duty cycle ” ). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. The radiois transmitting when the “ TX indicator ” lights red. You can cause the radio to transmit by pressing the “ PTT ” switch. Electromagnetic Interference/CompatibilityDuring transmissions, your Icom radio generates RF energy that canpossibly cause interference with other devices or systems. To avoidsuch interference, turn off the radio in areas where signs are postedto do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blastingsites. WARNING CAUTION 5 SAFETY TRAINING INFORMATION 15 IC-F111_121_211_221S-1.qxd 03.1.8 1:34 PM Page 15 (1,1)

Oct. 29, 2002 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject:Type Acceptance Application under FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency bands 440-490 MHz (12.5 kHz and 25 kHz Channel Spacings). Applicant:ICOM Incorporated Product:MOBILE UHF TRANSCEIVER Model:IC-F221S FCC ID:AFJIC-F221S Dear Sir/Madam, As appointed agent for ICOM Incorporated, we would like to submit the application to Federal Communications Commission for certification of the above product. Please review all necessary files uploaded to FCC OET site. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.:1-877-765-4173 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH Encl. UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] Oct. 29, 2002 ICOM Incorporated 1-1-32, Kamiminami Hirano-ku, Osaka Japan, 547-0003 Attn.:Mr. Takahasi Aoki Subject:Certification Testing in accordance with FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency bands 440-490 MHz (12.5 kHz and 25 kHz Channel Spacings). Product:MOBILE UHF TRANSCEIVER Model:IC-F221S Dear Mr. Aoki, The product sample has been tested in accordance with FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency bands 440-490 MHz (12.5 kHz and 25 kHz Channel Spacings), and the results and observation were recorded in the engineering report, Our File No.: ICOM-045FCC90 Enclosed you will find copy of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P.Eng Vice President - Engineering Encl. UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] MOBILE UHF TRANSCEIVER (440-490 MHz) Model No.: IC-F221S FCC ID: AFJIC-F221S Applicant: ICOM Incorporated 1-1-32, Kamiminami Hirano-ku, Osaka Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) CFR 47, PARTS 2 and 90 (Subpart I) UltraTech's File No.: ICOM-045FCC90 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: Oct. 29, 2002 Report Prepared by: Tri M. Luu, P.Eng.Tested by: Hung Trinh Issued Date: Oct. 29, 2002Test Dates: Oct. 23-28, 2002 ß The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ß This report must not be used by the cli…

Text truncated - open the document above for the full version.
