AFJSL-1105Direct Sequence Wireless LAN Card

n Document Conventions The following notational conventions are used in this manual: lThe names of utilities, applications, windows (screens)are enclosed in square brackets ({ }). lThe names of utilities, applications, windows (screens), tabs, menus, text boxes, and check boxes are enclosed in square brackets ([ ]). lThe names of and the names of command buttons within dialog boxes are enclosed in less-than and greater-than signs (<>). n Description of the setup screens in this manual The setup screens used in this manual are for the SL- 1100. Please read those parts written with SL-1100 as for the SL-1105. n ‹This LAN card is designed for use with PCMCIA card slots that operate at 5.0V. n lA computer satisfying the system requirements described above. lThe CD-ROM for the operating system used (Windows 95, Windows 98, Windows 2000 or Windows NT 4.0). lThe SL-1105 wireless LAN card. lThe two floppy disks label ed "Instruction Manual (1/2)" and "Instruction Manual (2/2)." lThe two floppy disks labeled "Utility Software (1/2)" and "Utility Software (2/2)." lFour blank 3.5-inch floppy disks (for backing up the Instruction Manual and Utility Software disks). n ‹If you are using Windows 95, follow the instructions provided in "3 Using in a Windows 98 Environment." The settings utility does not support Windows 95. Use the setting screen described in "3-4 SL-1105 Settings" to perform settings for the SL-1105 LAN card when using Windows 95. nBe sure to read these precautions in order to operate the LAN card safely. nGeneral precautions nPrecautions regarding the Radio Law 2. COMPONENTS AND FUNCTIONS 3. Using in a Windows 98 Environment 3-1 Checking the PC Card Driver 3-2 Installing the LAN Card Driver 3-3 Checking the LAN Card Driver and System Resources 3-4 SL-1105 Settings n Descriptions of SL-1105 setting items 3-5 Connecting to a Wireless Network n Example of settings for peer-to-peer connection A.Checking and adding protocol B.Adding Microsoft Networks Sharing Service C.TCP/IP settings D.Identification settings E.Sharing folders 3-6 Checking the Wireless Network Connection 3-7 What to Do When the Other Computer(s) Cannot Be Recognized 3-8 Removing the SL-1105 from the Card Slot 3-9 Uninstalling the LAN Card Driver 3-10 Checking the Network Setting Values 4. Using the Settings Utility 4-1 About the ICOM SL-1105 Utility 4-2 Installing the ICOM SL-1105 Utility 4-3 Starting and Terminating the ICOM SL-1105 Utility 4-4 Description of the ICOM SL-1105 Utility Screen Tabs 4-5 Relationship between the Wireless Network and Station Type 4-6 Uninstalling the ICOM SL-1105 Utility 4-7 Updating the Firmware 5. Troubleshooting with the Ping Command 6. Specifications and Maintenance n Trademark Information WAVEMASTER is a registered trademark of ICOM Inc. Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries. The screen shots that appear within this text are used with permission of Microsoft Corporation. Other product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. 1 Safety Precautions CAUTIONS NEVER expose the LAN card to rain, snow or any liquids. DO NOT use or place the LAN card in areas with temperatures below 0 °C (+32 °F) or above +55 °C (+122 °F) or, in areas subject to direct sunlight. AVOID placing the LAN card in excessively dusty environments. AVOID the use of chemical agents such as benzine or alcohol when cleaning, as they damage the LAN card surfaces. Place unit in a secure place to avoid inadvertent use by children. For U.S.A. only (FCC information) CAUTION: Changes or modifications not expressly approved by Icom Inc. could void the user's authority to operate this LAN card. Class B digital device users This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide r easonable protection against harmful interference in a residential installation. This e quipment generates, uses and can radiate radio frequency energy and, if not installed a nd used in accordance with the instruction manual, may cause harmful interference to r adio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio o r television reception, which can be determined by turning the equipment off and on, t he user is encouraged to try to correct the interference by one or more of the following measures: ! Reorient or relocate the receiving antenna. ! Increase the separation between the equipment and LAN card. ! Connect the equipment into an outlet on a circuit different from that to which th e LAN card is connected. ! Consult the dealer or an experienced radio/TV technician for help. IMPORTANT RF SAFETY WARNING: To comply with FCC RF exposure compliance requirements, the following device operating configuration must be satisfied: The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. For Canada only Operation is subject to the following two conditions: (1) this device may not cau se i nterference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. " Be sure to read these precautions in order to operate the LAN card safely. ! These precautions are intended to ensure that the LAN card is operated safely an d correctly. Follow these instructions to avoid property damage and prevent personal injury to yourself (user) or others in the vicinity. ! Before reading the rest of this manual, read and understand the precautions liste d under "Warning" and "Caution" below. ! This manual includes precautions regarding both the SL-1105 and the enti re computer system with which the SL-110…

Text truncated - open the document above for the full version.

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 34 of 56 Document Number: 2000453 18 EXTERNAL PHOTOGRAPHS TOP view BOTTOM VIEW

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 31 of 56 Document Number: 2000453 16 LABEL INFORMATION FCC LABEL AND LOCATION OF LABEL ON EUT Please see the following page.

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 35 of 56 Document Number: 2000453 19 INTERNAL PHOTOGRAPHS Top view of the board Top view of the board without the main cover 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 36 of 56 Document Number: 2000453 Top view of the board without covers 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 37 of 56 Document Number: 2000453 Bottom view of the board Bottom view of the board without cover 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 38 of 56 Document Number: 2000453 Bottom cover Top cover 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 39 of 56 Document Number: 2000453 Top plastic cover Bottom plastic cover 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 40 of 56 Document Number: 2000453 Frame

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 30 of 56 Document Number: 2000453 15 PRODUCT DESCRIPTION The model SL-1105 (referred to as the EUT in this report) is a Direct Sequence Spread Spectrum wireless LAN, PCMCIA network card. The EUT provides wireless communications between computers. The EUT is designed to be installed into the PCMCIA slot of a notebook computer or desktop computer with a PCMCIA slot. The EUT communicates with other wireless LAN cards using the frequency range from 2.413 GHz to 2.463 GHz. The EUT is powered from the PCMCIA slot, and does not have an external power supply. The EUT uses an internal PCB trace antenna. The EUT uses 2- bits encoded to 4 complex code words; 2-DQPSK CCK modulation technique with 8 Chips per symbol, spread clock rate is 1.375 MHz symbol/sec, and the data rate = 11 MBPS.

14 RF Exposure Calculations for High Gain Antennas From FCC 1.1310 table 1A, the maximum permissible RF exposure for an uncontrolled environment is 1mW/cm 2. The Electric field generated for a 1mW/cm 2 exposure (S) is calculated as follows: S = E 2 /Z where: S = Power density E = Electric field Z = Impedance. E = √S x Z 1mW/cm 2 = 10 W/m 2 The impedance of free space is 337 ohms, where E and H fields are perpendicular. Thus: E = √10 x 377 = 61.4 V/m which is equivalent to 1mW/cm 2 Using the relationship between Electric field E, Power in watts P, and distance in meters d, the corresponding Antenna numeric gain G and the transmitter output power and solving for d, d = √ P eak x 30 x G E Example using the Stub Omni-directional antenna 1. The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log –1 (dB gain/10) G = Log –1 2.15 = 1.64 Notice in Installation Manual: While installing and operating this transmitter and antenna combination the radio frequency exposure limit of 1mW/cm 2 may be exceeded at distances close to the antennas installed. Therefore, the user must maintain a minimum distance of 20 cm from the antenna at all time. The table below identifies the distances where the 1mW/cm 2 exposure limits may be exceeded during continuous transmission using the internal antenna Antenn a Type Gain (dBi) Gain Numeric Peak output EIRP Power (mW) Calculated RF Exposure Separation Distance (cm) Minimum RF Exposure Separation Distance (cm) Internal 2.15 1.64 33.1 2.1 20

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441 APPLICATION FOR FCC CERTIFICATION DIRECT SEQUENCE SPREAD SPECTRUM TRANSMITTER ICOM Incorporated 1-6-19 Kamikurazukuri Hirano-Ku Osaka, Japan 547 Model: WLan card SL–1105 FCC ID: AFJ SL-1105 December 7, 2000 STANDARDS REFERENCED FOR THIS REPORT PART 2: 1999 FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS PART 15: 1999 RADIO FREQUENCY DEVICES FCC 97-114 GUIDANCE ON MEASUREMENTS FOR DIRECT SEQUENCE SPREAD SPECTRUM SYSTEMS ANSI C63.4-1992 STANDARD FORMAT MEASUREMENT/TECHNICAL REPORT PERSONAL COMPUTER AND PERIPHERALS FCC Rules Parts Frequency Range Output Power (W) Freq. Tolerance Emission Designator 15.247 2413 to 2463 MHz 0.0229 This report concerns (check one): Original Grant: X Class II Change: Equipment Type: PCMCIA Board Deferred grant requested per 47 CFR 0.457 (d) (1) (ii) Yes: No: X If yes, defer until: Company name agrees to notify the Commission by: (date) of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes: No: X If no, assumed Part 15, subpart B for unintentional radiators - the new 47 CFR. [10-1-90 Edition] provision. REPORT PREPARED BY: EMC Engineer: Rachid Sehb Signature: Supervising Engineer: Desmond A. Fraser Signature: Document Number: 2000453 No part of this report may be reproduced without the full written approval of Rhein Tech Laboratories, Inc. 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 2 of 56 Document Number: 2000453 TABLE OF CONTENTS 1 INTRODUCTION....................................................................................................................................................4 1.1 RELATED SUBMITTAL (S)/GRANT (S).....................................................................................................4 1.2 TEST METHODOLOGY.................................................................................................................................4 1.3 TEST FACILITY...............................................................................................................................................4 1.4 EMISSIONS EQUIPMENT LIST....................................................................................................................5 2 SYSTEM TEST CONFIGURATION...................................................................................................................8 2.1 JUSTIFICATION...............................................................................................................................................8 2.2 EUT EXERCISE SOFTWARE........................................................................................................................8 2.3 SPECIAL ACCESSORIES...............................................................................................................................8 2.4 TEST SYSTEM DETAILS...............................................................................................................................9 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................10 3 CONFORMANCE STATEMENT......................................................................................................................11 4 FIELD STRENGTH CALCULATION..............................................................................................................12 5 CONDUCTED EMISSIONS MEASUREMENTS............................................................................................13 5.1 CONDUCTED EMISSIONS TEST...............................................................................................................14 5.1.1 CONDUCTED EMISSIONS (CHANNEL 1 WITH THE INTERNAL ANTENNA).....................15 5.1.2 CONDUCTED EMISSIONS (CHANNEL 6 WITH THE INTERNAL ANTENNA).....................16 5.1.3 CONDUCTED EMISSIONS (CHANNEL 11 WITH THE INTERNAL ANTENNA)...................17 6 RADIATED EMISSIONS MEASUREMENTS................................................................................................18 6.1 RADIATED EMISSIONS TEST.............................................................................................................................19 6.1.1 Radiated EMISSION DIGITAL noise (Channel 1 with the Internal Antenna)..............................19 6.1.2 Radiated Emission Digital noise (Channel 6 with the Internal Antenna).......................................20 6.1.3 Radiated EMISSIONS DIGITAL noise (Channel 11 with the Internal Antenna)..........................21 7 MODULATED BANDWIDTH............................................................................................................................22 8 POWER OUTPUT.................................................................................................................................................22 9 ANTENNA CONDUCTED SPURIOUS EMISSIONS.....................................................................................23 10 RADIATED SPURIOUS EMISSIONS...........................................................................................................24 10.1.1 Radiated Emissions Harmonics/spurious (Channel 1)......................................................................24 10.1.2 Radiated Emissions Harmonics/spurious (Channel 6)......................................................................25 10.1.3 Radiated Emissions Harmonics/spurious (Channel 11)....................................................................26 11 POWER SPECTRAL DENSITY.....................................................................................................................27 12 COMPLIANCE WITH THE RESTRICTED BAND EDGE................................…

Text truncated - open the document above for the full version.

Measurement of Processing Gain of a Direct Sequence Spread Spectrum System Certification Report on Compliance with Respect to FCC CFR 47, Paragraph 15.247(e) Product: Icom SL-1105 Wireless LAN Card December 6, 2000 REPORT PREPARED BY: Rick McMurray Rhein Tech Laboratories, Inc. 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 (703) 689-0368 (703) 689-2056 fax Rhein Tech Laboratories, Inc. Scope This report contains the results of the processing gain testing performed on the Icom SL-1105 Wireless LAN Card. The tests were carried out in accordance with FCC CFR 47, Paragraph 15.247(e). The jamming margin method specified in 15.247(e)(2) was used to perform the processing gain testing. FCC 97-114, Guidance on Measurements for Direct Sequence Spread Spectrum Systems, was also utilized as a guiding document for the performance of the processing gain testing. FCC Requirements The processing gain of a direct sequence system shall be at least 10dB. The processing gain shall be determined from the ratio in dB of the signal-to-noise ratio with the system spreading code turned off to the signal-to-noise ratio with the system spreading code turned on, as measured at the demodulated output of the receiver. Test Equipment • Hewlett Packard Spectrum Analyzer, Model 8564E, 30Hz-40GHz (RTL Asset # 901020) • Hewlett Packard Signal Generator, Model 8648C, 100kHz-3200MHz (RTL Asset # 900917) • Weinschel Broadband Resistive Power Divider, Model 1515, DC to 18.0GHz 1 Watt (RTL Asset # 900947) • Weinschel Directional Coupler, Model 1537RA-20, 0.5 to 4.0GHz • Fujitsu Laptop Computer, Model FMV-5120NU2/W (used with transmitter) • IBM Laptop Computer, Model ThinkPad 600E (used with receiver) Method of Measurement As mentioned in the scope section, the jamming margin method was used. The following drawing titled “Processing Gain – Jamming Test Setup” illustrates a block diagram of the test setup. In this method, a signal generator was stepped in 50kHz increments across the passband of the system. At each point, the level of the signal generator required to produce the recommended Bit Error Rate (BER) was recorded. This level is the jammer level. The output power of the transmitter was also recorded at these same points. This level is the signal level. The jammer to signal ratio (J/S) was then calculated. The worst 20% of the J/S data points were discarded. The lowest remaining J/S ratio was used to calculate the processing gain for each of the channels and rates investigated. The processing gain, Gp, was calculated as follows: Gp = (S/N)o + Mj + Lsys, where Gp = the processing gain of the system, (S/N)o = signal to noise ratio required for the chosen BER, Mj = J/S ratio, and Lsys = system losses. Note that total system losses in a system, including intentional radiator and receiver, are assumed to be no more than 2dB as specified by the FCC. An ideal signal to noise ratio, also referred to as (S/N)o or (Es/No), of 13.3dB was used as specified by Intersil when calculating the processing gain when operating at 1Mbps. A value of Rhein Tech Laboratories, Inc. 16.4dB was used as specified by Intersil when calculating the processing gain when operating at 11Mbps. The Icom SL-1105 contains chip-sets from Intersil and operates at rates up to 11Mbps. Please see the enclosed documents “Theoretical BER curves for the IEEE 1 and 2 Mbps modulations” and “Testing for compliance with FCC rules 15-247e” by Carl Andren of Intersil Corporation for theoretical processing gain calculations for this chip-set and other information. A BER (bit error rate) of 10 -5 was used to calculate the processing gain. The monitoring software on the receiver side displays the FER (frame error rate). The use of 8% FER (or PER packet error rate) as a substitute for the recommended BER is derived in the attached document “Testing for compliance with FCC rules 15-247e” by Carl Andren of Intersil Corporation. Engineering Summary Processing Gain Results Summary: Channel Rate (Mbps) Gp(dB) 1 1 37.97 1 11 40.73 6 11 38.07 11 11 39.73 Following are the calculations and data for the one channel at 1Mbps and the three channels at 11Mbps that were investigated. 5 5 4 4 3 3 2 2 1 1 DD CC BB AA Transmitter Icom SL-1105 Wireless LAN Card Signal Generator HP 8648C Broadband Resistive Power Divider Weinschel Model 1515 Spectrum Analyzer HP 8564E Directional Coupler Weinschel Model 1537A 6dB loss 6dB loss 20dB loss Receiver Icom SL-1105 Wireless LAN Card Processing Gain - Jamming Test Setup A 11Wednesday, December 06, 2000 Rhein Tech Laboratories, Inc. Title SizeDocument NumberRev Date:Sheet of Icom SL-1105 Channel 1 Processing Gain 2412MHz 1Mbps After discarding the lowest 20% J/S data points, the lowest J/S was 22.67dB. Gp = (S/N)o + Mj + Lsys = 13.3dB + (22.67dB) + 2.0dB = 37.97dB 1Mbps Channel 1 Processing Gain Gp = (S/N)o + Mj + Lsys FrequencyGp(S/N)oMj = J/SLsysS (Tx Power)J (S/G Power) (MHz)(dB)(dB)(dB)(dB)(dBm)(dBm) 2405.0053.8013.338.502.0-31.007.5 2405.0553.6313.338.332.0-30.837.5 2405.1053.6313.338.332.0-30.837.5 2405.1553.4713.338.172.0-30.677.5 2405.2053.4713.338.172.0-30.677.5 2405.2553.3013.338.002.0-30.507.5 2405.3052.8013.337.502.0-30.007.5 2405.3552.8013.337.502.0-30.007.5 2405.4052.6313.337.332.0-29.837.5 2405.4552.3013.337.002.0-29.507.5 2405.5052.4713.337.172.0-29.677.5 2405.5551.8013.336.502.0-29.507.0 2405.6051.1313.335.832.0-29.336.5 2405.6550.4713.335.172.0-29.176.0 2405.7049.3013.334.002.0-29.005.0 2405.7548.6313.333.332.0-28.834.5 2405.8048.4713.333.172.0-28.674.5 2405.8548.3013.333.002.0-28.504.5 2405.9048.3013.333.002.0-28.504.5 2405.9547.6313.332.332.0-28.334.0 2406.0046.4713.331.172.0-28.173.0 2406.0546.4713.331.172.0-28.173.0 2406.1045.8013.330.502.0-28.002.5 2406.1545.1313.329.832.0-27.832.0 2406.2044.6313.329.332.0-27.831.5 2406.2543.6313.328.332.0-27.830.5 2406.3042.6313.327.332.0-27.330.0 2406.3542.6313.327.332.0-27.330.0 2406.4042.6313.327.332.0-27.330.0 2406.4543.1313.327.832.0-27.330.5 2406.5042.9713.327.672.0-27.170.5 2406.5542…

Text truncated - open the document above for the full version.

24 Conducted Spurious Plots

26 6dB Plots CHANNEL 1 CHANNEL 6 CHANNEL 11

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 32 of 56 Document Number: 2000453 17 TEST PHOTOGRAPHS 17.1 CONDUCTED MEASUREMENT PHOTOS Front view Rear view 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Certification Report For: ICOM America Page 33 of 56 Document Number: 2000453 17.2 RADIATED MEASUREMENT PHOTOS Front view Rear view
