AL8-C05XWireless Communications System Base Unit

Guide de démarrage rapide Guía de inicio rápido Guia de Início Rápido quick start guide CS540 ™ Wireless Headset System en What’s in the box Telephone interface cable Power supply Base Headband Extra eartips and earloops Headset with pre-installed battery, eartip and earloop check font size and letting with Helios for con- sistency en en Welcome to the CS540 wireless headset system. This quick start guide will show you how to set up your system and use its key features. Please refer to the separate safety instructions for important product safety information prior to installing or using the product. step 1 Customize your headset assemble your headset1 The headset comes configured for your right ear with a small eartip and medium earloop pre-installed. Note Refer to the complete User Guide at Plantronics.com/cs540 for information on how to configure your headset for your left ear, install a different sized eartip and earloop, or install the headband. Wearing your headset2 When you wear the headset the microphone should rest as close to your cheek as possible without touching. Slide the headset over and behind your ear and fit the eartip into your ear.• Place your index finger on the headset LED and gently push in towards • your cheek. step 2 Connect and configure your phone Connect the power1 Connect the power supply into the power jack on the back of the base. Plug the other end into a working power outlet. The Power LED on the base will be solid white. Base overview Headset overview en en Configure your desk phone4 Set your desk phone’s volume to mid-range.• Pick up the desk phone handset and listen for a clear dial tone.• Note If you do not hear a dial tone or the dial tone is not clear, look at the bottom panel of your base and slide the configuration switch to a different letter until the dial tone is clear. step 3 Call call from your desk phone1 Wearing your headset, press the headset call button. • Remove the handset from the cradle. You should hear a dial tone. • Note This step will be automatic if you install a lifter or Electronic Hookswitch Cable (EHS) accessory. For a complete list of accessories, visit: plantronics.com/ accessories. Dial the number using your desk phone. • To end the call, press the headset call button and hang up the handset. • charge the headset 2 Place the headset in the charge cradle. The charging LED on the base will flash green when charging and turn solid green when the headset is fully charged. = 20. Note Charge for at least 20 minutes prior to the first use. A full charge takes 3 hours. This product has a replaceable battery. Use only the battery type supplied by Plantronics. Connect your desk phone3 Connect one end of the telephone interface cable to the back of the base.• Disconnect the handset coil cord from the base of the desk phone and re-• connect it to the telephone cable junction box. Finally connect the remaining end of the telephone cable into the open • handset port on the desk phone. Note Your desk phone handset will continue to work; it’s just hooked up differently. en en Adjust the headset volume2 Fine-tune your headset volume by pressing the volume/mute button up • (increase) or down (decrease), if you wear your headset on the right. If you wear it on the left, it’s opposite: press down (increase) and up (decrease). Do not use headphones/headsets at high volumes for an extended period of time. Doing so can cause hearing loss. Always listen at moderate levels. See plantronics.com/healthandsafety for more information on headsets or hearing. Make general volume adjustments with the base volume dials.• Mute a call 3 To mute/unmute your headset, press the headset volume button in. When a call is muted, the call/mute LED will be solid red on the base and you will still be able to hear the caller. Automated sound test4 Make a test call (toll free) to test and optimize your system. Call 866-210-2157. Learn More To learn more about system features and read troubleshooting tips, refer to the user guide online at plantronics.com/cs540. For technical support contact us at plantronics.com/support or at 800-544-4660. Plantronics, inc. 345 Encinal Santa Cruz, CA 95060 United States tel: 800-544-4660 plantronics.com/support © 2010 Plantronics, Inc. All rights reserved. Plantronics, the logo design, CS540, and Sound Innovation are trademarks or registered trademarks of Plantronics, Inc. All other trademarks are the property of their respective owners. Patents Pending 84725-01 (10.10) Fcc requirements Part 15 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on another circuit that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Fcc registration information — Part 68 This equipment complies with Part 68 of the FCC rules and the requirements adopted by ACTA. On the exterior of this equipment is a label that contains a product identifier in the format US:AAAEQ##TXXXX. If requested, this information must be provided to your telephone company. A plug and jack used to connect this equipment to the premises wiring and teleph…

Text truncated - open the document above for the full version.

en Safety Instructions ar ةمالسلا لوح تاداشرإ bg Инструкции за безопасност cs Bezpečnostní pokyny da Sikkerhedsvejledning de Sicherheitshinweise el Οδηγίες για την ασφάλεια es Instrucciones de seguridad fa ینمیا یاه لمعلاروتسد fr Instructions de sécurité he תוחיטב תוארוה hr Sigurnosne upute hu Biztonsági előírások it Informazioni sulla sicurezza mk Безбедносни упатства nl Veiligheidsinstructies no Sikkerhetsinstruksjoner pl Instrukcje bezpieczeństwa pt Instruções de Segurança ro Instrucţiuni de siguranţă ru Инструкции по безопасности sl Varnostna navodila sv Säkerhetsanvisningar tr Instrucţiuni de siguranţă AR EN ةمالسلا لوح تاداشرإ ظافتحالا ىجري .Plantronics جتنم مادختسا لبق ةيلاتلا ليغشتلاو ةمالسلا تاداشرإ ةءارق ىجري ةمالسلا تاريذحتو ريبادت عابتا بجي ،جتنملا اذه مادختسا دنع .اهيلإ عوجرلل تاداشرإلا هذهب رطخو ةيدسجلا تاباصإلاو ةيئابرهكلا تامدصلاو قيرحلا رطخ نم فيفختلل هذه ةيساسألا .ةيداملا رارضألا تاريذحت .اذه Plantronics ماظن عم مادختسالل ةممصملا Plantronics تاجتنم طقف مدختسا ةريغصلا عطقلا ببستت دق ذإ قالطإلا ىلع جتنملاب بعللاب لافطألل حمست ال .لافطألا .قانتخالاب .هيلإ لوصولا لهسي يذلاو زاهجلا ىلإ برقألا ذخأملاب بوانتملا رايتلا لّوحم لّصو لّوحم وأ رفوملا نحاشلا طقف مدختسا ،قيرح وأ راجفنا وأ ،ةيئابرهك ةمدص ثودح رطخ نم فيفختلل 60 ،تلوف 120 ًالثم( ةيتلوفلا ةجرد نأ نم دكأت .سأرلا ةعامس نحشل 2 Class بوانتملا رايتلا .همادختسا يونت يذلا ةقاطلا ردصم قباطت )زتره Safety Instructions Please read the following safety and operational instructions before using your Plantronics product. Please keep these instructions for your reference. When using this product, these basic safety precautions and warnings should be followed to reduce the risk of fire, electric shock, injury to persons and damage to property. General Operating, charging and storage temperature is 0ºC to 40ºC (32ºF to 104ºF). Warnings • Only use those Plantronics products designed for use with this Plantronics system. • CHILDREN. Never allow children to play with the product—small parts may be a choking hazard. • Plug the AC adapter into the outlet nearest the equipment that is easily accessible. • To reduce the risk of electric shock, explosion or fire, use only the supplied charger or Class 2 AC adapter to charge the headset. Ensure that the voltage rating (e.g. 120v, 60 Hz) corresponds to the power supply you intend to use. • Do not disassemble the product or AC adapter as this may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock or fire when the product is subsequently used. • Do not insert anything into the product because this may cause damage to the internal components or cause injury to you. • If this system includes a mobile phone headset, check local laws regarding use of a mobile phone and headset while driving. If you use the headset while driving, ensure your attention and focus remain on driving safely. • Use of a headset that covers both ears will impair your ability to hear other sounds. Use of such a headset while operating a motor vehicle or riding a bicycle may create a serious hazard to you and/or others, and is illegal in most states and regions. • If this system includes a Bluetooth headset, observe all signs or instructions that require an electrical device or RF radio product to be switched off in designated areas, such as hospitals, blasting areas, potentially explosive atmospheres, and aircraft. • Avoid contact with liquids. Do not locate this product near water, for example, near a bathtub, or sink, in a wet basement, or near a swimming pool. • Discontinue use of product and contact Plantronics if the product overheats, has a damaged cord or plug, if the product has been dropped or damaged, or if the product has come into contact with liquids. • This product should never be placed over or near a heat register and should not be placed in locations without which do not have proper ventilation. • If you experience a skin irritation after using this product, discontinue use and contact Plantronics. • Exposure to high volume sound levels or excessive sound pressure may cause temporary or permanent damage to your hearing. Although there is no single volume setting that is appropriate for everyone, you should always use your headset/headphones with the volume set at moderate levels and avoid prolonged exposure to high volume sound levels. The louder the volume, the less time is required before your hearing could be affected. You may experience different sound levels when using your headset /headphones with different devices. The device you use and its settings affect the level of sound you hear. If you experience hearing discomfort, you should stop listening to the device through your headset/headphones and have your hearing checked by your doctor. To protect your hearing, some hearing experts suggest that you: 1. Set the volume control in a low position before putting your headset or headphones on your ears and use as low a volume as possible. 2. Avoid turning up the volume to block out noisy surroundings. Whenever possible, use your headset or headphones in a quiet environment with low background noise. 3. Limit the amount of time you use headsets or headphones at high volume levels. 4. Turn the volume down if the sound from the headset/headphones prevent you from hearing people speaking near you. See www.plantronics.com/healthandsafety for more information on headsets/headphones and hearing. To avoid the risk of electric shock, explosion, fire or leakage of corrosive or toxic chemicals, please observe the following charging and battery warnings: Charging Warnings • Use only the charger supplied by Plantronics to charge the product. Do not use the charger for any other purpose. Ensure that the voltage rating corresponds to the power supply you intend to use. • Charge the headset/headphones according to the instructions supplied with the unit. • Plug the AC adapter or charger into an outlet that is near the equipment and will be easily accessible. • Never charge the batte…

Text truncated - open the document above for the full version.

Worldwide Headquarters 345 Encinal Street Santa Cruz, CA 95060 April 8, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Long Term Confidentiality FCC ID: AL8-C05X To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Sincerely, Peter Clark Compliance Manager

Worldwide Headquarters 345 Encinal Street Santa Cruz, CA 95060 April 8, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Short Term Confidentiality FCC ID: AL8-C05X To Whom It May Concern: Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short- term confidentiality request on the following attachments until September 1, 2011. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Peter Clark Compliance Manager

From: Ilarina, Alvin Sent: Tuesday, April 26, 2011 7:22 PM To: PCTEST TCB/CB Subject: RE: Questions Regarding FCC ID: AL8-C05X Hi Greg, Please see the response below. Let me know if you need more. Thanks! Alvin Ilarina Compliance Engineer Plantronics Simply Smarter Communications™ 345 Encinal St., Santa Cruz, CA 95060 From: PCTEST TCB/CB Sent: Tuesday, April 26, 2011 11:08 AM To: Ilarina, Alvin Subject: Questions Regarding FCC ID: AL8-C05X To: Mr. Alvin Ilarina / Plantronics From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: AL8-C05X Applicant: PLANTRONICS Correspondence Reference Number: AL8100504 Co nfirmation Number: 1Y1104140504 Date of Original Email: April 26, 2011 Subject: Request for additional information I n regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Section 15.311 requires an additional statement (located in that Section) be placed on the EUT’s l abel. Please revise the label accordingly and resubmit it. Please reference the Public Notice at the following link: http://hraunfoss.fcc.gov/edocs_public/attachmatch/DA -05-1005A1.pdf From page 2: 2. The RF section of the block diagram shows an unlabeled VCO. Please revise to show the value of all clocks/oscillators. Please see attached: “5_Block Diagram for FCC Ebenezer Base_r2.pdf” 3. Please provide the measurement data referenced on p. 14 of the test report as “made at CCS.” P lease see attached: “11U13721-1 C054 FCC ITE Report.pdf” The item indicated above must be submitted before pro cessing can continue on the above referenced application. Sincerely, Gr egory Czumak Senior Certification Engineer C ONFIDENTIALITY NOTICE: This e-mail transmission, and any documents, files or previous e-mail messages attached to it, may contain information that is confidential and/or legally privileged. If you are not the intended recipient, or a person responsible for delivering it to the intended recipient, please DO NOT disclose the contents to another person, store or copy the information in any medium, or use any of the information contained in or attached to this transmission for any purpose. If you have received this transmission in error, please immediately notify the sender by reply email or at [email protected], and destroy the original transmission and its attachments without reading or saving in any manner. For further information about Plantronics - the Company, its products, brands, partners, please visit our website www.plantronics.com. PCTEST TCB/CB Tel. 1.410.290.6652 Fax. 1.410.290.6654 [email protected] www.pctesttcb.com
Please consider the environment before printing this e-mail. This communication and its attachments contain information from PCTEST TCB/CB and are intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

AL8‐C05X/457A‐C05X External Photos Front Back Left Right Top Bottom

AL8‐C05X/457A‐C05X Label and Location

AL8‐C05X/457A‐C05X Internal Photos PCB TOP PCB Bottom – no shield

RF Exposure Requirements for FCC ID: AL8-C05X Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s Guidelines. Limits: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact to human exposure to radiofrequency (RF) radiation as specified in Sec 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this Chapter. Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 MPE Calculation: Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 where, S = Power Density (W/m 2 ) P = Power Input to antenna (18.1 dBm; 0.065Watts) G = Antenna Gain, in numeric (3 dBi; 1.995 numeric) R = distance to the center of radiation of the antenna (0.2 m) S = 0.065W*1.995 / 4*3.14*(0.2m) 2 = 0.258 W/m 2 EUT complies with 20cm distance exposure.

1/102 Exhibit #11 Conducted RF and Spectral Etiquette Measurements to Support the Certification of the Wireless Office Base FCC ID AL8-C05X. Plantronics, John Mihelic & Andy Ward, 4-April, 2011, Alvin Ilarina 8-April, 2011 I. Background 2 A. EUT description 2 B. Manufacturer’s attestations, mandatory declarations and descriptions 2 C. Standard test configurations 4 D. Calibration 7 II. Test Results Summary Base EUT 12 III. Tests of clause 6, Base EUT 23 A. Clause 6.1 Emissions tests for the Base EUT 23 B. Clause 6.2 Tests of frequency and time stability for the Base EUT 59 IV. Tests of clause 7, Base EUT 65 A. Clause 7.3.2 Upper threshold for EUTs which implement the LIC procedure, Base EUT 65 B. Clause 7.3.3 Least interfered channel (LIC) procedure test, Base EUT 67 C. Clause 7.3.4 Selected channel confirmation, Base EUT 71 D. Clause 7.4 Threshold monitoring bandwidth Base EUT 71 E. Clause 7.5 Reaction time and monitoring interval, Base EUT 72 V. Tests of clause 8, Base EUT 81 A. Clause 8.1.1 Access Criteria Test Interval, Base EUT 81 B. Clause 8.2.1 Acknowledgement, Base EUT 89 C. Clause 8.2.2 Transmission duration, Base EUT 93 VI. Appendix A WBM (Wide Band Mode), Base EUT 94 A. Clause 6.1.2 Peak transmit power, Base EUT in WBM 95 B. Clause 6.1.3 Emission bandwidth B, Base EUT in WBM 96 C. Clause 6.1.6 Emissions, Base EUT in WBM maximum power 96 VII. Appendix B Power Control-minimum output power, Base EUT 97 A. Clause 6.1.3 Emission bandwidth, Base EUT, in minimum power mode and WBM 98 B. Clause 6.1.6 Emissions, Base EUT 101 2/102 I. Background A. EUT description The Plantronics’ C05x product line is a family of wireless base station units which can receive and transmit audio to/from a companion headset assembly. The family consists of the C052, C053 and C054 base stations, each of which utilizes the DECT/DECT 6.0 technology. The C052, C053 and C054 base stations share identical electronics and embedded firmware, differing only in the mechanics of the headset docking cradle interface (different docking interfaces are available to support multiple headset types). The base unit replaces a telephone handset connection to a standard telephone. The telephone’s handset then plugs into the base unit. This report includes only compliance relative to the DECT/DECT 6.0 RF portion of the base unit. Compliance submittals for individual headsets are covered in separate reports. The base unit provides a docking cradle for charging a headset, and is provided with an AC power adapter. Other accessories (on-line indicator, telephone handset lifter) may be connected to the base unit at the end-user’s discretion. The base unit is an intentional radiator, designed in accordance with the requirements of 47CFR15 subpart D. This document reports compliance of the Base to the test parameters of C63.17-2006 for the DECT/DECT 6.0 radio only. The Base EUT is capable of RF power control. The power control modes are fixed, or adaptive. Adaptive power control will allow the RF transmitter to adjust the output power from a maximum to minimum in four 5-7dB steps. Fixed power mode does not allow power control. The user can select between adaptive or fixed but can not set the power range, this is done during EUT factory set up. Compliance to C63.17-2006 is documented in Appendix A which repeats any testing that may operate differently from maximum power mode or affect the access threshold. The Base companion device can initiate a link in a wideband mode using the CAT-iq (P00J Longslot) configuration for transmission and receive, but the Base does not perform the access threshold check or initiate the WBM communications traffic link; the companion headset performs the proper access checks per ANSI C63.17-2006 clause 8.3.1 or 2. The specific unit tested is Base #1 for emissions bandwidth, spectral etiquette, and access criteria. The RF output power and emissions testing was performed on the test sample 0159B800E8. B. Manufacturer’s attestations, mandatory declarations and descriptions The C05X base stations use digital modulation. Clause 4.11 in C63.17-2006 requires the following declarations to be made by the manufacturer. These declarations are used in demonstrating compliance with certain sections of 47CFR15 subpart D, and in support of test parameters within C63.17-2006. The channel plan. Five RF carriers are used, as follows: 1928.448 MHz. 1926.720 MHz. 1924.992 MHz. 1923.264 MHz. 1921.536 MHz. Maximum EUT antenna gain GA (dBi), and orientation and polarization for maximum gain. The maximum Base EUT antenna gain is 3dBi. Maximum peak power level Maximum specified peak conducted power level for the Base EUTs is +18.1dBm. 3/102 Minimum peak power level The maximum power level at the minimum RF power setting is specified peak conducted power level for the headset EUTs is -4.0dBm. Emission bandwidth Emission bandwidth measured according to the procedures of C63.17-2006 clause 6.1.3 for the Base EUT is 1.45MHz. Nominal receive bandwidth Nominal receive bandwidth is +/-500kHz. Frame period and time slot plan, if TDMA techniques are used The EUT system is a TDMA system which “further divides access in time” in the context of clause 6.2.2 of C63.17- 2006. Frame period is 10mS. There are 24 timeslots per frame, with one of the first 12 timeslots used for the headset transmissions and one of the last 12 timeslots used for the base transmissions. Transmit and receive timeslots are 5mS apart in time. Transient events occur during which two non-adjacent timeslots may be in use by the base during the setup of the communications channel, or by both the base and the headset EUT as the system does a soft handoff in response to interference. Minimum and maximum burst length, if TDMA techniques are used Minimum burst length is 90uS, the beacon transmissions from the base when a communications channel is not open. Maximum burst length is 780uS, transmissions from the Base when a communications channel is open in wideband mode. Minimum …
