AL8-C7102-in-1 Bluetooth/USB Peripheral Corded headset

Human Factors | Blue Pacific UI document | 05.17.11 Confidential and Proprietary Information 3 PASSIVE INDICATORS Triple flash blue (BT)/ green (PC) / 2s 3 rapid low tones. BT: In-Band tones over-rule earcon. PC: always in-band tones. Incoming call while already on call: 3 rapid low tones only. Blue (BT)/ green (PC) pulse every 2s low intensity. Open SCO (low-low-high) for mobile AND PC calls. No recurring standby indicator. 1 short flash for Status Check upon hook-switches or volume button press. INCOMING CALL BATTERY LOW / CRITICAL CHARGING/ CHARGED Battery Low (30 to 10min of talk-time left): double red flash every 10min – also indicated when Powering ON. Battery Critical (10min of talk-time left): triple red flash every 30s - also indicated when Powering ON. Battery Low: double high-tone + voice- prompt: “Battery Low”, repeated every 10min - also indicated when Powering ON. Battery critical: triple high-tone + voice-prompt: “Recharge headset”, repeated every 2mins until battery is recharged (or dies). Charging: Solid red until fully charged or removed from charger. Charged: LED turns off. (No earcon). Visual status shown on PC if user has PURE. OUT OF RANGE Reconnect behavior 0-15min: every 15s 15-30min: every 30s 30-90min: every 60s Bluetooth Off STANDBY/ STATUS-CHECK CALL STATUS BATTERY STATUS CONNECTIVITY USER ACTIVATED FUNCTIONS PC hook-switch (push button) Volume up/dn (momentary toggle) (No visual indicators) Short high tone + v-p: “Lost connection”. Low tone if reconnection is successful, high tone if unsuccessful. Via PCP or PEM only BT Off- triple blue flash BT On- solid blue 2s (No audio indicator) ON A CALL Power On: press 2s BT hook-switch Power Off: press 4s BT hook-switch Power On: plug into PC, unplugging from PC does not Power Off BT. Power Off possible while plugged in PC. Power ON: solid blue 2s, OFF: solid red 2s. No visual battery status when Power On unless battery level is low/ critical or unless connected to PC. Power ON: voice-prompt “Power On” followed by “Battery Low” OR “Recharge Headset”, followed by “Phone Connected”. If BT not connected when Power On: v-p: “No Phone Is Connected”. If Power On pressed during Incoming Call: Power On v-p sequence is interrupted by Incoming Call earcon. Power OFF: voice-prompt “Power Off”. No audio battery status when Power On unless battery level is low/ critical or unless connected to PC. POWER ON/OFF CALL BACK (connects to last AG) Double tap, BT Hook-switch button (No visual indicators) Double low tone TRANSFER AUDIO FROM PHONE to HEADSET and HEADSET TO PHONE Press 2s, BT Hook-switch button, if On a Call Don/ Doff headset (No visual indicators) Single 1s low tone BACK IN RANGE/ RECONNECT Tap <1s (tap), BT Hook-switch button Don headset Flash behavior matches current headset state v-p: “Phone connected”. If Reconnect fails: v-p: “Lost connection” MUTE Mute: tap <1s, Mute button Unmute: tap <1s, Mute button Mute On: solid red Mute Off: no visual indicator Activate Mute: Low-high tone, followed by voice- prompt: “Mute On”, then low-high tone every 15min Deactivate Mute: voice-prompt “Mute Off”. Volume : Tap <1s (tap) Volume up/ down while connected and on a call to go through 8-steps in A2DP: 24-steps for PC. Volume can be adjusted while connected. Press & hold to automated skip through Vol down/up levels. Default at start-up: Volume medium. Volume after 1 st time: latest setting. (No visual indicator) Tone volume corresponding to volume level, and to increasing / decrease pitch (see p.2). High limit: double high tone for high limit and double low tone at low limits. Evenly timed tones when in skip mode. Mute On/ Off (push button) Red LED Voice prompts during SCO and ACL. BT battery levels shown in Pure. No PC GUI without Pure. View from User’s perspective Nominal setting at medium. BUTTONS 2 and 3 (in BT Connected state): Status Check: 1 short green flash. Single low tone with every press. 2 BT hook- switch/Power button (push button) PAIRING (while BT is Off. Can be initiated via PCP) Pairing: with BT OFF, hold BT hook-switch for 6s. Pairing last 10 mins then go in standby mode. Whether Pairing is successful or fails, headset goes in standby mode. To interrupt Pairing: press BT hook-switch for 4s (= Off). Flashes blue and red, solid blue for 2s when paired Pairing begins: v-p: “Pairing”, cycle repeated every 2 minutes until paired. Once paired: v-p: “Pairing Successful” If Pairing fails, or after 10min of searching: high tone + voice-prompt: “Pairing incomplete, restart headset”. V-p de-activated when Pairing occurs through PURE. Paul to check SRD. NO MULTIPOINT. NO ON-DEMAND BATTERY INDICATOR. CALL ANSWER/END (Bluetooth) Tap <1s (tap), BT hook-switch button Don to answer (No visual indicators) Button: single low tone (ans. /end) Don: v-p: “Answering Call” 2 1 1 VOICE DIALING (phone capability) Press 2s, BT Hook-switch button (No visual indicators) Single low tone 2s into button press (phone may prompt: “Name Please”) Press 1s, BT Hook-switch, sends call to vmail (No visual indicators) Single low tone on BT CALL REJECT 3 4 3 4 1 Green LED Red/blue LED CALL ANSWER/END (PC) Tap <1s (tap), PC hook-switch button Don to answer (confirmed w/ Ramesh) (No visual indicators) Button: single low tone (ans. /end) Don: v-p: “Answering Call” 2 VOLUME UP/ DOWN TOGGLE Paul Ewer Alex Soto Wilmer Lau R. Theivendran/ Kevin Lin Roger Li Blanca Pedra S. Gougherty, & D. Elabidi (HF) UI GUIDING PRINCIPLES • See next page for Guiding principles on voice-prompts (v-p) • Battery status (no longer indicated when powering on except if battery low): flash red 1 ce when full, 2 ce when 2/3 full, 3 ce when 1/3 full. • Use blue (BT)/ green (PC) LED for talk states, red for critical states. Match earcon to LED behavior (double red LED = double high tone). • Use only High and Low earcons, no Medium tones. Reserve high tone earcons for critical states (low battery, out of range, pairing failed). • Functions related to On a Call should have no more than 2-to…

Text truncated - open the document above for the full version.

Plantronics, Inc. Date: May 24, 2012 Federal Communications Commission Authorization and Evaluation Division FCC ID: AL8-C710 ATTESTATION FCC ID: AL8-C710 Product: Bluetooth headset Model: Blackwire C710;Blackwire C720 We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, __________________ Peter Clark/Compliance Manager Plantronics, Inc.

RF_160, Issue 02 Plantronics, Inc. We Name: Plantronics,Inc. Address: 345 Encinal Street, Santa Cruz, CA95060 USA City: California. Country: United States . Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Bluetooth headset............ Type designation: Blackwire C710; Blackwire C720 Trademark: PLANTRONICS on our behalf. Date:  2012-5-24.. City:  United States .. Name:  Peter Clark.. (2) Function: ......Compliance Manager............................ Signature: ............................................................ Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Plantronics, Inc. Date：May, 24, 2012 Federal Communications Commission Authorization and Evaluation Division FCC ID: AL8-C710 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Block Diagram 3 Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 DFR § 2.803 and the importation rules in 47 CFR § 2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices.. We are requesting the commission to grant short-term confidentiality request on the following attachments till 30-Sep-2012: External Photos Internal Photos Test Setup Photos User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________________ Peter Clark/Compliance Manager Plantronics, Inc.

EUT Photographs (1) EUT Photo (2) EUT Photo Report No: 125S010R-RF-US-P06V01 Page: 3 of 5 Appendix 2 – EUT Photograph (3) EUT Photo (C720) (4) EUT Photo (C710) Report No: 125S010R-RF-US-P06V01 Page: 4 of 5 (5) EUT Photo (6) EUT Photo Report No: 125S010R-RF-US-P06V01 Page: 5 of 5 (7) EUT Photo (8) EUT Photo

Label size:9*53mm Label location: Labeled at the switch of the headset which through by the USB Peripheral Cord. Switch Label location

(1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo

RF Exposure Evaluation Declaration Product Name : 2-in-1 Bluetooth/USB Peripheral Corded headset Model No. : Blackwire C710 and Blackwire C720 FCC ID : AL8-C710 IC : 457A-C710 Applicant : Plantronics, Inc. Address : 345 Encinal Street, Santa Cruz, CA95060 USA Date of Receipt : 07/05/2012 Issued Date : 28/05/2012 Report No. : 125S010R-RF-US-P20V01 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No: 125S010R-RF-US-P20V01 Page: 2 of 5 Test Report Certification Issued Date : 28/05/2012 Report No. : 125S010R-RF-US-P20V01 Product Name : 2-in-1 Bluetooth/USB Peripheral Corded headset Applicant : Plantronics, Inc. Address : 345 Encinal Street, Santa Cruz, CA95060 USA Manufacturer : Weifang GoerTek Electronics Co., Ltd Address : Dongfang North Road Hi-tech Industry Development District, Weifang Shandong, China Model No. : Blackwire C710 and Blackwire C720 FCC ID : AL8-C710 IC : 457A-C710 EUT Voltage : DC 3.7V Brand Name : PLANTRONICS Applicable Standard : FCC OET 65 RSS-102: Issue 4, March, 2010 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392; IC Lab Code: 4075B Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Senior Engineer: Jame Yuan) Approved By : (Engineering Manager: Marlin Chen) Report No: 125S010R-RF-US-P20V01 Page: 3 of 5 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI China :CNAS Report No: 125S010R-RF-US-P20V01 Page: 4 of 5 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No: 125S010R-RF-US-P20V01 Page: 5 of 5 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. 1.3. Test Result of RF Exposure Evaluation Product : 2-in-1 Bluetooth/USB Peripheral Corded headset Test Item : RF Exposure Evaluation Test Site : AC-6 Antenna Gain: Antenna Gain: The maximum Gain measured in fully anechoic chamber is 1.23dBi in logarithm scale. Output Power into Antenna & RF Exposure Evaluation Distance: Frequency Band (MHz) Maximum Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 2402 - 2480 MHz 3.1989 0.000845 Note: The power density Pd (4th column) at a distance of 20 cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm2.

Test Report Industry Canada RSS-Gen Issue 3/RSS-210 Issue 8 FCC Part15 Subpart C Product Name : 2-in-1 Bluetooth/USB Peripheral Corded headset Model No. : Blackwire C710 and Blackwire C720 FCC ID : AL8-C710 IC : 457A-C710 Applicant : Plantronics, Inc. Address : 345 Encinal Street, Santa Cruz, CA95060 USA Date of Receipt : 07/05/2012 Test Date : 07/05/2012~18/05/2012 Issued Date : 28/05/2012 Report No. : 125S010R-RF-US-P06V01 Report Version : V 1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No: 125S010R-RF-US-P06V01 Page: 2 of 116 Test Report Certification Issued Date : 28/05/2012 Report No. : 125S010R-RF-US-P06V01 Product Name : 2-in-1 Bluetooth/USB Peripheral Corded headset Applicant : Plantronics, Inc. Address : 345 Encinal Street, Santa Cruz, CA95060 USA Manufacturer : Weifang GoerTek Electronics Co., Ltd Address : Dongfang North Road Hi-tech Industry Development District, Weifang Shandong, China Model No. : Blackwire C710 and Blackwire C720 FCC ID : AL8-C710 IC : 457A-C710 EUT Voltage : DC 3.7V Brand Name : PLANTRONICS Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2011 ANSI C63.4: 2009; ANSI C63.10: 2009 Industry Canada RSS-Gen Issue 3/RSS-210 Issue 8 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392; IC Lab Code: 4075B Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Senior Engineer: Jame Yuan) Approved By : (Engineering Manager: Marlin Chen) Report No: 125S010R-RF-US-P06V01 Page: 3 of 116 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI China :CNAS Report No: 125S010R-RF-US-P06V01 Page: 4 of 116 TABLE OF CONTENTS Description Page 1. General Information....................................................................................................7 1.1. EUT Description .........................................................................................................7 1.2. Mode of Operation .....................................................................................................9 1.3. Tested System Details..............................................................................................10 1.4. Configuration of Tested System ............................................................................... 11 1.5. EUT Exercise Software ............................................................................................12 2. Technical Test...........................................................................................................13 2.1. Summary of Test Result ...........................................................................................13 2.2. Test Environment.....................................................................................................14 3. Conducted Emission................................................................................................15 3.1. Test Equipment ........................................................................................................15 3.2. Test Setup ................................................................................................................15 3.3. Limit..........................................................................................................................16 3.4. Test Procedure.........................................................................................................16 3.5. Uncertainty ...............................................................................................................16 3.6. Test Result...............................................................................................................17 4. Radiated Emission...................................................................................................19 4.1. Test Equipment ........................................................................................................19 4.2. Test Setup ................................................................................................................20 4.3. Limit..................................................…

Text truncated - open the document above for the full version.

1. Test Setup Photograph Description: Front View of Conducted Emission Test Setup Description: Back View of Conducted Emission Test Setup Report No: 125S010R-RF-US-P06V01 Page: 2 of 5 Description: Radiated Emission Test Setup for Below 30MHz Description: Radiated Emission Test Setup for Below 1GHz Report No: 125S010R-RF-US-P06V01 Page: 3 of 5 Description: Radiated Emission Test Setup for Above 1GHz Description: Radiated Emission Test Setup for Above 18GHz Report No: 125S010R-RF-US-P06V01 Page: 4 of 5 SAR-Test Setup Photographs Test Setup Photographs Body back Body front Report No: 125S010R-RF-US-P06V01 Page: 5 of 5 Depth of the liquid in the phantom – Zoom in Note: The position used in the measurements were according to IEEE 1528 - 2003 Part 15B-Test Photograph Test Mode: Mode 1 Description: Front View of Conducted Emission Test Setup Test Mode: Mode 1 Description: Side View of Conducted Emission Test Setup Test Mode: Mode 1 Description: Front View of Radiated Emission Test Setup (Below 1GHz) Test Mode: Mode 1 Description: Front View of Radiated Emission Test Setup (Above 1GHz)
