AL8-M70Bluetooth Headset

Wearing your headset, power it on. The first time you do, you will be prompted to select your language from a set of three options. When completed, you will hear "pairing", go to the "settings" menu on your phone to connect to your headset. SELECT LANGUAGE 1 When the headset indicator lights flashes red and blueactivate Bluetooth® on your phone and set it to search for new devices. •iPhone* Settings > Bluetooth > On •Android ™ Smartphones* Settings > Wireless & Networks > Bluetooth: On > Scan for devices 2 If necessary, enter four zeros (0000) for the passcode or accept the connection. Once successfully paired, the indicator lights stops flashing. GET PAIREDTAKE CONTROL Answer or end a call Tap the Call button . Decline a call Press the Call button for 2 seconds. Adjust the volume Tap the Volume up (+) or down (–) button. Mute on During a conversation, simultaneously tap the Volume (+) and (–) buttons. You will hear “mute on”, this voice alert will be repeated once. After that an alert tone repeats every 15 minutes when mute is on. Activate voice dial (phone feature) Press the Call button for 2 seconds, wait for the phone prompt and then tell the phone to dial the name of a stored contact. Change language Reselect the headset language at any time by putting your headset into pair mode. Press the Call button until the indicator light flashes red and blue and you hear "pairing, please select a different language." Redial To call your last number dialed, double tap the Call button . The universal-fit eartip has a thin loop that bends to gently tuck into the contours of either ear. To adjust the fit, you can rotate the eartip on the headset or add the optional clip-on earloop. ADJUST THE FIT For the best voice pickup, always check that the headset points toward the corner of your mouth. Your new headset has enough power to pair and make a few calls. It takes 2 hours to fully charge the headset; the indicator light turns solid blue once charging is complete. CHARGE FCC statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generate, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF exposure warning · The equipment complies with FCC RF exposure limits set forth for anuncontrolled environment. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter. NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. IC Radiation Exposure Statement for Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. If you leave your headset powered on but out of range of your paired phone for more than 90 minutes, your headset will conserve its battery power by entering into a DeepSleep ™ mode. Once back in range with your phone, tap the Call button to exit DeepSleep mode. If your phone is also ringing, tap the Call button again to answer your call. SAVE POWER Your headset tells you about status changes in English. For example: “Power on” “Pairing successful” “Talk time (x) hours” “Mute on” "Incoming call" "Answering call" “Lost connection” “Recharge headset” HEAR IT WHISPER Once you have paired your two phones, it's easy to answer calls from either phone. When on a call, you will hear a ringtone notification of an incoming call from the second paired phone. To answer the second call, you must first end your current call (tap the Call button) so new call automatically answers. To pair a second phone or a new phone see "Change language" in the Take Control section. USE TWO PHONES Bluetooth has a working “range” of up to 33 feet (10 meters) between the phone and headset before audio degrades and the connection is lost. If you lose connection your headset will try to reconnect once you move back into range. For best audio reception, keep your phone and headset on the same side of your body. STAY CONNECTED If your headset loses the Bluetooth ® connection with your phone, it will automatically try to reconnect. If your headset can't reconnect, tap the Call button once or manually c…

Text truncated - open the document above for the full version.

Plantronics, Inc. Date: 2013.9.27 Federal Communications Commission Authorization and Evaluation Division FCC ID: AL8-M70 ATTESTATION FCC ID: AL8-M70 Product: Bluetooth Headset Model: M70, M90, M95 We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, __________________ Peter Clark Sr. Manager, WW Compliance Engineering Plantronics, Inc.

RF_160, Issue 02 Plantronics, Inc. We Name: Plantronics, Inc. Address: 345 Encinal Street, Santa Cruz, CA95060 USA City: California. Country: United States . Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Bluetooth Headset ............ Type designation: M70, M90, M95  Trademark: Plantronics on our behalf. Date:  2013-9-27 .. City:  Santa Cruz .. Name:  Peter Clark.. Function: ...... Sr. Manager, WW Compliance Engineering................ Signature: ............................................................ Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Plantronics, Inc. Date：2013.9.27 Federal Communications Commission Authorization and Evaluation Division FCC ID: AL8-M70 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Block Diagram 3 Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 DFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices.. We are requesting the commission to grant forty-five days short-term confidentiality request on the following attachments: External Photos Internal Photos Test Setup Photos User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Peter Clark Sr. Manager, WW Compliance Engineering Plantronics, Inc.

To FCC: FCC ID: AL8‐M70 Date: 12/13/2013 We, QuieTek Technology (Suzhou) Co., Ltd., made the grantee, Plantronics, Inc., aware that the docs were available to public from 12AM 12/6 until about 1PM 12/6. ________________ Ivan Cui/ Manager QuieTek Technology (Suzhou) Co., Ltd.

Report No.:136S028R-ITUSP01V02 Page: 1 of 5 ¾ EUT Photograph (1) EUT Photo (2) EUT Photo Report No.:136S028R-ITUSP01V02 Page: 2 of 5 (3) EUT Photo (4) EUT Photo Report No.:136S028R-ITUSP01V02 Page: 3 of 5 (5) EUT Photo (6) EUT Photo Report No.:136S028R-ITUSP01V02 Page: 4 of 5 (7) EUT Photo (8) EUT Photo Report No.:136S028R-ITUSP01V02 Page: 5 of 5 (9) EUT Photo

ARTMASTER # Starfish Regulatory Marking REV. #:DESCRIPTION:SHEET #: PREPARED BY:DATE: 1 of 1 200841-0026Pierre Harper 06.03.13 Scale: 1 = 1 Driver housing outside surface REGULATORY LABEL XX XX FCC ID : A L8-M70 I C : 457A-M70 R Model: M70 MSIP-CRM -PLT-M70 P 0890T8 203- J N 0129 CCAH12L XX XX FCC I D : A L8- M70 I C : 457A-M70 R Model: M70 MSIP-CRM -PL T-M70 P 0890T 8 203- J N 0129 CCAH12L CMIIT ID : XXXXX XXXXX CMIIT I D : XXXXX XXXXX AB&SS Not For Sale AB&SS Not For Sale

ARTMASTER # Starfish Regulatory Marking REV. #:DESCRIPTION:SHEET #: PREPARED BY :DATE: 1 of 1 200841-0026 Pierre Harper 06.03.13 Scale: 1 = 1 Driver housing outside surface REGULATORY LABEL XX XX FCC ID:AL8-M70 IC : 4 57A- M 70 R Model: M90 M S I P - CRM -PLT- M 70 P0890T8 2 0 3- JNXXXX CCAH12L X X X X C C F I D : A 8 L - 0 7 M I C 7 5 4 : - A 0 7 M R 0 9 M : l e d o M R C - P I S M M P - L - T 0 7 M P 0 9 8 0 T 8 3 0 2 - J N XXXX H A C C 2 1 L CMIIT ID: XXXXX XXXX X T I I M C I D : X X X X X X X X X X A B & S S N o t F o r S a le e l a S r o F t o N S S & B A

ARTMASTER # Starfish Regulatory Marking REV. #:DESCRIPTION:SHEET #: PREPARED BY :DATE: 1 of 1 200841-0026 Pierre Harper 06.03.13 Scale: 1 = 1 Driver housing outside surface REGULATORY LABEL XX XX FCC ID:AL8-M70 IC : 4 57A- M 70 R Model: M95 M S I P - CRM -PLT- M 70 P0890T8 2 0 3- JNXXXX CCAH12L X X X X C C F I D : A 8 L - 0 7 M I C 7 5 4 : - A 0 7 M R 5 9 M : l e d o M R C - P I S M M P - L - T 0 7 M P 0 9 8 0 T 8 3 0 2 - J N XXXX H A C C 2 1 L CMIIT ID: XXXXX XXXX X T I I M C I D : X X X X X X X X X X A B & S S N o t F o r S a le e l a S r o F t o N S S & B A

(1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo

For FCC Standalone SAR test exclusion considerations FCC ID: AL8-M70 Tunable Range F(GHz) Low F(GHz) High 2.402 2.480 According to KDB 447498 D01 General RF Exposure Guidance v05 4.3.1 Standalone SAR test exclusion considerations The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR Note: when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Based on the Maximum measured transmitter power: Pout Conducted (dBm) Maximum Antenna Gain (dBi) Pout EIRP (mW) 2.47 1.11 2.29 Maximum TX Power is 1.77 mW Conducted and 2.29 mW EIRP [(1.77 mW/5 mm)* √2.441(GHz)]=0.55 <3.0 Conclusion: Bluetooth SAR was not required.

Test Report Industry Canada RSS-Gen Issue 3/RSS-210 Issue 8 FCC Part15 Subpart C Product Name : Bluetooth Headset Model No. : M70, M90, M95 FCC ID : AL8-M70 IC : 457A-M70 Applicant : Plantronics, Inc. Address : 345 Encinal Street, Santa Cruz, CA95060 USA Date of Receipt : 02/09/2013 Test Date : 02/09/2013~17/09/2013 Issued Date : 23/09/2013 Report No. : 139S003R-RF-US-P06V01 Report Version : V 1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No.: 139S003R-RF-US-P06V01 Page: 2 of 120 Test Report Certification Issued Date : 23/09/2013 Report No. : 139S003R-RF-US-P06V01 Product Name : Bluetooth Headset Applicant : Plantronics, Inc. Address : 345 Encinal Street, Santa Cruz, CA95060 USA Manufacturer : Weifang GoerTek Electronics Co,.Ltd. Address : Gaoxin 2 Road, Free Trade Zone, Weifang, Shandong, 261205, P.R.China Model No. : M70, M90, M95 FCC ID : AL8-M70 IC : 457A-M70 EUT Voltage : DC 3.7V Trade Name : Plantronics Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.4: 2009; ANSI C63.10: 2009 Industry Canada RSS-Gen Issue 3/RSS-210 Issue 8 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392; IC Lab Code: 4075B Documented By : Reviewed By : Approved By : Report No.: 139S003R-RF-US-P06V01 Page: 3 of 120 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. : BSMI, NCC, TAF Germany : TUV Rheinland Norway : Nemko, DNV USA : FCC Japan : VCCI China : CNAS Report No.: 139S003R-RF-US-P06V01 Page: 4 of 120 TABLE OF CONTENTS Description Page 1. General Information ................................................................................................................ 7 1.1. EUT Description ...................................................................................................................... 7 1.2. Mode of Operation .................................................................................................................. 9 1.3. Tested System Details ........................................................................................................... 10 1.4. Configuration of Tested System ............................................................................................ 11 1.5. EUT Exercise Software ......................................................................................................... 12 2. Technical Test ........................................................................................................................ 13 2.1. Summary of Test Result ........................................................................................................ 13 2.2. Test Environment .................................................................................................................. 14 3. Conducted Emission ............................................................................................................. 15 3.1. Test Equipment ..................................................................................................................... 15 3.2. Test Setup ............................................................................................................................. 15 3.3. Limit ....................................................................................................................................... 16 3.4. Test Procedure ...................................................................................................................... 16 3.5. Uncertainty ............................................................................................................................ 16 3.6. Test Result ............................................................................................................................ 17 4. Radiated Emission ................................................................................................................ 19 4.1. Test Equipment ..................................................................................................................... 19 4.2. Test Setup ..........................................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photograph Test Mode: Mode 1 Description: Front View of Conducted emission Test Setup Test Mode: Mode 1 Description: Side View of Conducted emission Test Setup Description: Radiated Emission Test Setup for Below 30MHz Description: Radiated Emission Test Setup for Below 1GHz Description: Radiated Emission Test Setup for 1~18GHz Description: Radiated Emission Test Setup for Above 18GHz
