AL8-WH500Wireless Communications System Headset

Savi ™ W440 Wireless Headset System Quick Start Guide Guide de démarrage rapide Guia de Início Rápido 3 en Welcome Congratulations on purchasing your new Plantronics product. This Quick Start Guide contains instructions for setting up and using your Savi W440 (D100 + WH500 Headset) Wireless Headset System. Please refer to the separate safety instructions for important product safety information prior to installation or use of the product. System Requirements The minimum system requirements for Savi W440 are as follows: • Supported Operating Systems: Windows XP®, Windows Vista®, Windows® 7 • Processor: 400 MHz Pentium® processor or equivalent (Minimum); 1 GHz Pentium processor or equivalent (Recommended) • RAM: 96 MB (Minimum); 256 MB (Recommended) • Hard Disk: 280 MB (Minimum); 500 MB (Recommended) • Display: 800 x 600, 256 colors (Minimum); 1024 x 768 high color, 32-bit (Recommended) • Internet Explorer® V6 or better must be on the user’s system (Required) Complete User Guide and Plantronics Software We highly recommend that you refer to the complete user guide located on the CD. The user guide provides full details on how to use your system. We also recommend that you install the Plantronics Unified Runtime Engine and Control Panel located on the CD. With Plantronics software installed you can: • Remotely answer incoming softphone calls • Customize your headset and USB adapter settings to your personal preferences • Automatically manage your PC multimedia so you never miss a call • Quickly access links to product support and software/firmware upgrade information Registering Your Product Visit plantronics.com/productregistration to register your product online so we can provide you with the best service and technical support. Getting Assistance The Plantronics Technical Assistance Center is ready to assist you. You can find answers to frequently asked questions, ask a question using e-mail, receive service over the internet, or speak directly with a representative. Visit plantronics.com/support. 1 6.6 6.7 1.1 1.2 2 5 6 3 4 45 en en 1 Connecting USB Adapter to PC 1-1. Insert the USB adapter into USB Port on PC. The indicator light on the USB adapter will be solid red to indicate the USB adapter is powered on and will turn solid green when it finds the headset. 1-2. The USB adapter can be folded as shown. NOTE The headset may need to be charged before the USB adapter can find it. IMPORTANT NOTE It is recommended that Windows be updated with Service Pack levels listed below: Microsoft Windows XP Service Pack 3 (SP3) or later Microsoft Windows Vista Service Pack 1 (SP1) or later 2 Connecting Power Supply to Charger Base 2-1. Connect the base power supply into the power jack on the charger base. 2-2. Connect the power supply to the outlet. The power indicator light will be solid green. 3 Installing Battery to Headset 3-1. Position the battery as shown on headset and slide into position until the battery snaps into place. NOTE This product has a replaceable battery. Use only the battery type supplied by Plantronics. 4 Choosing Wearing Style 4-1. If you prefer the over-the-ear style, attach the earloop first and then the eartip to the headset. NOTE Ensure the large end of the eartip faces down towards the microphone. 4-2. If you prefer the over-the-head style, attach the headband to the headset. 5 Docking and Charging Headset 5-1. Gently push the headset into the charge cradle. The indicator light on the headset will flash white to indicate that the headset battery is charging. 5-2. Charge for at least 20 minutes prior to the first use. A full charge takes 3 hours. NOTE The USB charging cable can also be used to charge the headset. To successfully charge your headset with the USB cable the PC must be on and in an active state (not standby). The charging time will vary according to the number of other devices drawing power from the PC’s USB port(s). Charging time 20 min ..................... minimum charge before first use 3 hours ................... Full charge Base power supply USB Charging Cable USB adapter Indicator light Subscription button CD includes: • Plantronics Software • Complete User Guide Charger base Power Indicator Light Indicator Light Microphone Call Control Button Volume Button (Press in to mute/ unmute) Headset Headband Earloops Eartips Battery 67 es en 6 Making a Test Call 6-1. While wearing your headset, press the call control button on the headset. The USB adapter indicator light will flash green indicating a radio link is active with the headset. 6-2. Place a test call using your softphone or UC application. 6-3. Adjust the receive and transmit volume to comfortable levels using the volume control in your softphone or UC application audio set up. 6-4. You can also fine tune the listening volume on the headset. When wearing the headset on your right ear, push the volume button up to increase the volume and push the volume button down to decrease the volume. The opposite is true when wearing on left ear. 6-5. Press the volume button in to mute/unmute the call. The USB adapter indicator light will flash red when the headset is muted. 6-6. To end the test call, press the call control button on the headset. Do not use headphones / headsets at high volumes for an extended period of time. Doing so can cause hearing loss. Always listen at moderate levels. See plantronics.com/healthandsafety for more information on headsets and hearing. Bienvenido Felicidades por su compra de un nuevo producto Plantronics. Esta guía de inicio rápido contiene instrucciones para configurar y utilizar el sistema de audífonos inalámbricos Savi W440 (D100 + audífono WH500). Antes de instalar o utilizar el producto, consulte las instrucciones de seguridad (aparte) para obtener información importante acerca de la seguridad del producto. Requisitos del sistema Los requisitos mínimos del sistema para Savi W440 son: • Sistemas operativos compatibles: Windows XP®, Windows Vista®, Windows® 7 • Procesador: pr…

Text truncated - open the document above for the full version.

en Safety Instructions ar ةمالسلا لوح تاداشرإ bg Инструкции за безопасност cs Bezpečnostní pokyny da Sikkerhedsvejledning de Sicherheitshinweise el Οδηγίες για την ασφάλεια es Instrucciones de seguridad fa ینمیا یاه لمعلاروتسد fr Instructions de sécurité he תוחיטב תוארוה hr Sigurnosne upute hu Biztonsági előírások it Informazioni sulla sicurezza mk Безбедносни упатства nl Veiligheidsinstructies no Sikkerhetsinstruksjoner pl Instrukcje bezpieczeństwa pt Instruções de Segurança ro Instrucţiuni de siguranţă ru Инструкции по безопасности sl Varnostna navodila sv Säkerhetsanvisningar tr Instrucţiuni de siguranţă AR EN ةمالسلا لوح تاداشرإ ظافتحالا ىجري .Plantronics جتنم مادختسا لبق ةيلاتلا ليغشتلاو ةمالسلا تاداشرإ ةءارق ىجري ةمالسلا تاريذحتو ريبادت عابتا بجي ،جتنملا اذه مادختسا دنع .اهيلإ عوجرلل تاداشرإلا هذهب رطخو ةيدسجلا تاباصإلاو ةيئابرهكلا تامدصلاو قيرحلا رطخ نم فيفختلل هذه ةيساسألا .ةيداملا رارضألا تاريذحت .اذه Plantronics ماظن عم مادختسالل ةممصملا Plantronics تاجتنم طقف مدختسا ةريغصلا عطقلا ببستت دق ذإ قالطإلا ىلع جتنملاب بعللاب لافطألل حمست ال .لافطألا .قانتخالاب .هيلإ لوصولا لهسي يذلاو زاهجلا ىلإ برقألا ذخأملاب بوانتملا رايتلا لّوحم لّصو لّوحم وأ رفوملا نحاشلا طقف مدختسا ،قيرح وأ راجفنا وأ ،ةيئابرهك ةمدص ثودح رطخ نم فيفختلل 60 ،تلوف 120 ًالثم( ةيتلوفلا ةجرد نأ نم دكأت .سأرلا ةعامس نحشل 2 Class بوانتملا رايتلا .همادختسا يونت يذلا ةقاطلا ردصم قباطت )زتره Safety Instructions Please read the following safety and operational instructions before using your Plantronics product. Please keep these instructions for your reference. When using this product, these basic safety precautions and warnings should be followed to reduce the risk of fire, electric shock, injury to persons and damage to property. General Operating, charging and storage temperature is 0ºC to 40ºC (32ºF to 104ºF). Warnings • Only use those Plantronics products designed for use with this Plantronics system. • CHILDREN. Never allow children to play with the product—small parts may be a choking hazard. • Plug the AC adapter into the outlet nearest the equipment that is easily accessible. • To reduce the risk of electric shock, explosion or fire, use only the supplied charger or Class 2 AC adapter to charge the headset. Ensure that the voltage rating (e.g. 120v, 60 Hz) corresponds to the power supply you intend to use. • Do not disassemble the product or AC adapter as this may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock or fire when the product is subsequently used. • Do not insert anything into the product because this may cause damage to the internal components or cause injury to you. • If this system includes a mobile phone headset, check local laws regarding use of a mobile phone and headset while driving. If you use the headset while driving, ensure your attention and focus remain on driving safely. • Use of a headset that covers both ears will impair your ability to hear other sounds. Use of such a headset while operating a motor vehicle or riding a bicycle may create a serious hazard to you and/or others, and is illegal in most states and regions. • If this system includes a Bluetooth headset, observe all signs or instructions that require an electrical device or RF radio product to be switched off in designated areas, such as hospitals, blasting areas, potentially explosive atmospheres, and aircraft. • Avoid contact with liquids. Do not locate this product near water, for example, near a bathtub, or sink, in a wet basement, or near a swimming pool. • Discontinue use of product and contact Plantronics if the product overheats, has a damaged cord or plug, if the product has been dropped or damaged, or if the product has come into contact with liquids. • This product should never be placed over or near a heat register and should not be placed in locations without which do not have proper ventilation. • If you experience a skin irritation after using this product, discontinue use and contact Plantronics. • Exposure to high volume sound levels or excessive sound pressure may cause temporary or permanent damage to your hearing. Although there is no single volume setting that is appropriate for everyone, you should always use your headset/headphones with the volume set at moderate levels and avoid prolonged exposure to high volume sound levels. The louder the volume, the less time is required before your hearing could be affected. You may experience different sound levels when using your headset /headphones with different devices. The device you use and its settings affect the level of sound you hear. If you experience hearing discomfort, you should stop listening to the device through your headset/headphones and have your hearing checked by your doctor. To protect your hearing, some hearing experts suggest that you: 1. Set the volume control in a low position before putting your headset or headphones on your ears and use as low a volume as possible. 2. Avoid turning up the volume to block out noisy surroundings. Whenever possible, use your headset or headphones in a quiet environment with low background noise. 3. Limit the amount of time you use headsets or headphones at high volume levels. 4. Turn the volume down if the sound from the headset/headphones prevent you from hearing people speaking near you. See www.plantronics.com/healthandsafety for more information on headsets/headphones and hearing. To avoid the risk of electric shock, explosion, fire or leakage of corrosive or toxic chemicals, please observe the following charging and battery warnings: Charging Warnings • Use only the charger supplied by Plantronics to charge the product. Do not use the charger for any other purpose. Ensure that the voltage rating corresponds to the power supply you intend to use. • Charge the headset/headphones according to the instructions supplied with the unit. • Plug the AC adapter or charger into an outlet that is near the equipment and will be easily accessible. • Never charge the batte…

Text truncated - open the document above for the full version.

From: Ilarina, Alvin Sent: Friday, June 25, 2010 6:34 PM To: PCTEST TCB/CB Subject: RE: Questions Regarding FCC ID: AL8-WH500 Hi Greg, Please see the response below. If you need additional information please let me know. Have a great weekend! A lvin Ilarina Compliance Engineer PLANTRONICS From: PCTEST TCB/CB S ent: Friday, June 25, 2010 2:48 PM To: Ilarina, Alvin Subject: Questions Regarding FCC ID: AL8-WH500 To: Mr. Alvin Ilarina/ Plantronics From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: AL8-WH500 Applicant: Plantronics Co rrespondence Reference Number: AL8Y100757 Confirmation Number: Y1006160757 Date of Original Email: June 25, 2010 Subject: Request for additional information In regards to your recent TCB application referenced a bove, we kindly request that you provide the following additional information. 1. The EUT, in wideband mode, utilizes 2 time slots of 24, which is a duty factor of 8.3%, as stated in the KDB to the FCC as well as the RFx analysis. Page 2 of the Operational Description, however, lists the wideband duty factor as 7.8%. Please clarify. The duty factor of 8.3% is the calculated maximum for 2 of 24 time slots. The duty factor of 7.8% reported in the o perational description was measured as shown in Figure 4 of the operational description document. The duty factor for the system will not exceed 8.3%. 2. FYI: in the future, please include more detail regarding the RF section of the transmitter in the block diagram. Noted, we will include more detail in our next filing. The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. CONFIDENTIALITY NOTICE: This e-mail transmission, and any documents, files or previous e-mail messages a ttached to it, may contain information that is confidential and/or legally privileged. If you are not the intended recipient, or a person responsible for delivering it to the intended recipient, please DO NOT disclose the contents to another person, store or copy the information in any medium, or use any of the information contained in or attached to this transmission for any purpose. If you have received this transmission in error, please immediately notify the sender by reply email or at [email protected], and destroy the original transmission and its attachments without reading or saving in any manner. For further information about Plantronics - the Company, its products, brands, partners, please visit our website www.plantronics.com.

Worldwide Headquarters 345 Encinal Street Santa Cruz, CA 95060 June 15, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Long Term Confidentiality FCC ID: AL8-WH500 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Sincerely, Peter Clark Compliance Manager

Worldwide Headquarters 345 Encinal Street Santa Cruz, CA 95060 June 15, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Short Term Confidentiality FCC ID: AL8-WH500 To Whom It May Concern: Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short- term confidentiality request on the following attachments until December 15, 2010. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Peter Clark Compliance Manager

Exhibit 8 – External Photos for WH500 Top Bottom Left Right

Exhibit 3 – Label and Location Label Location WH500 Made in Mexico MY FCC ID: AL8-WH500 IC: 457A-WH500

Exhibit 9 – Internal Photos for WH500 PCB Installed PCB Top with shield PCB Top without shield PCB Bottom

Applicant: Plantronics Inc. Model: WH500 FCC ID: AL8-WH500 IC: 457A-WH500 DUT Type: Portable UPCS/LE-PCS DECT Wireless Headset Freq. Range: 1921.536 - 1928.448 MHz 2010 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 3 RFx Exhibit Serial No. 051810AL8-T1020-S15D RFx Exhibit Issue Date June 18, 2010 RFx Exhibit Revision No. Rev. 1.1 (2nd Release) Test Lab Certificate No. 2470.01 FCC RF EXPOSURE EXHIBIT Plantronics Model: WH500 DECT UPCS Wireless Headset FCC ID: AL8-WH500 Device Mode of Operation The system (base and headset together) can be unlinked, linked but with no voice path open (idle locked state) or linked with voice paths open. Unlinked is when the ends of the system are out of range. Linked but no voice path open is when the system is ready for use but no voice path is active (idle locked), and linked with voice paths open is when the system is in use for voice communication. Audio can be provided from the telephone and/or the USB interface. Transmission Mode The headset unit is mated with the base unit (subscribed to each other) under normal operation. The communications link is custom (double-slot) TDMA (UPCS standard), and is symmetrical; both ends of the link transmit using the same protocol. Maximum Duty Cycle Maximum Duty Cycle occurs when the headset and base are in a wideband audio link. Maximum duty cycle (wideband audio mode) is approximately 8.3%. For each end of the active link in wideband audio mode, a unit transmits for 2 out of 24 timeslots Æ 2:24 duty cycle. The DECT frame rate is 10ms, so each end of the link transmits for approximately 800 uS every 10ms when the system is linked and active. In narrowband audio mode, the duty cycle is exactly half that in wideband audio mode, so approximately 4.1%. When the system is linked but voice paths are not open (headset is “idle-locked” to the base) the base transmits with a 1.3% duty cycle (130uS every 10mS). In this mode the headset will transmit link maintenance information every thirty seconds. When unlinked and out of range (the headset cannot hear the base), the headset does not transmit, and the base transmits at a 1.3% duty cycle (130uS every 10mS). Two time slots are used for wideband audio, effectively doubling the duty cycle, minus idle time. Maximum RF Output Power Manufacturer’s Rated Maximum Peak Conducted Power = 19.7 dBm (93.3 mW) Manufacturer’s Specified Source-Based Time-Averaged Duty Cycle = 8.3% Max. Source-Based Time-Averaged Output Power = 8.9 dBm (7.8 mW) Device Operating Configuration(s) and Exposure Conditions The Plantronics WH500 Headset can be worn on either the left or right ear and is worn over-the-ear. The Plantronics WH500 Headset is intended for use within the General Population / Uncontrolled RF exposure environment. See photographs (next page) of device and antenna placement. Antenna-to-Ear Separation Distance 15 mm (manufacturer measurement) Analysis Summary Based on the transmission modes, operating configurations and maximum source-based time-averaged output power and duty cycle as described in this document, SAR compliance is demonstrated for the Plantronics WH500 DECT UPCS Headset without routine SAR measurements (in accordance with the FCC’s response to KDB Inquiry Tracking Number 309465). Applicant: Plantronics Inc. Model: WH500 FCC ID: AL8-WH500 IC: 457A-WH500 DUT Type: Portable UPCS/LE-PCS DECT Wireless Headset Freq. Range: 1921.536 - 1928.448 MHz 2010 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 3 RFx Exhibit Serial No. 051810AL8-T1020-S15D RFx Exhibit Issue Date June 18, 2010 RFx Exhibit Revision No. Rev. 1.1 (2nd Release) Test Lab Certificate No. 2470.01 Device Photos Antenna Location Applicant: Plantronics Inc. Model: WH500 FCC ID: AL8-WH500 IC: 457A-WH500 DUT Type: Portable UPCS/LE-PCS DECT Wireless Headset Freq. Range: 1921.536 - 1928.448 MHz 2010 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 3 of 3 RFx Exhibit Serial No. 051810AL8-T1020-S15D RFx Exhibit Issue Date June 18, 2010 RFx Exhibit Revision No. Rev. 1.1 (2nd Release) Test Lab Certificate No. 2470.01 Antenna Distance to User

From: [email protected] Sent: Friday, June 18, 2010 1:07 PM To: [email protected] Subject: Response to Inquiry to FCC (Tracking Number 309465) Inquiry: ---Reply from Customer on 06/16/2010--- In anticipation of the Commission's acceptance of proposed RF Exposure exhibit (per previously accepted procedures), we are hereby submitting the RF Exposure exhibit for FCC review and speed up the process. Response: 1.Please include the following grant condition: " device is a wireless headset warn on the ear and operates with a maximum duty factor of 8.3% using a maximum of 2 out of 24 Time slots. 2. Please correct or clarify the two different source-based averaged based Max tx power 7.75bBm or8.9dBm. 3. The included RF exposure report language should not use KDB response but analysis response. Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry. FCC Home | Search | RSS | Updates | E-Filing | Initiatives | Consumers | Find People Office of Engineering and Technology From: [email protected] Sent: Monday, June 21, 2010 6:12 AM To: [email protected] Subject: Response to Inquiry to FCC (Tracking Number 309465) Inquiry: ---Reply from Customer on 06/18/2010--- 1. Noted 2. Correct maximum conducted source-based time-averaged output power is 8.9 dBm. Revised KDB inquiry document ("FCC KDB Inquiry 052710 - CONFIDENTIAL - Rev1.1") was resubmitted on June 01, 2010 reflecting the corrected output power level to 8.9 dBm from the original document listing incorrect 7.75 dBm. 3. Noted. Please see attached revised RF Exposure Exhibit. Response: The KDB is now closed with the inclusion of the grant condition. please contact FCC for any other question(S) Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry. FCC Home | Search | RSS | Updates | E-Filing | Initiatives | Consumers | Find People Office of Engineering and Technology

1/125 Exhibit #11 Conducted RF and Spectral Etiquette Measurements to Support the Certification of the Wireless Office Headset WH500, FCC ID’s AL8-WH500. Plantronics, John Mihelic and Andy Ward, 1-June, 2010. I. Background 3 EUT description 3 Manufacturer’s attestations, mandatory declarations and descriptions 3 Standard test configurations 5 Calibration 8 II. Test Results Summary Headset EUT 12 III. Tests of clause 6, headset EUT 23 Clause 6.1 Emissions tests for the headset EUT 23 Clause 6.2 Tests of frequency and time stability for the headset EUT 57 IV. Tests of clause 7, headset EUT 62 Clause 7.3.2 Upper threshold for EUTs which implement the LIC procedure, headset EUT 62 Clause 7.3.3 Least interfered channel (LIC) procedure test, headset EUT 63 Clause 7.3.4 Selected channel confirmation, headset EUT 68 Clause 7.5 Reaction time and monitoring interval, headset EUT 71 V. Tests of clause 8, headset EUT 80 Clause 8.2.1 Acknowledgements, headset EUT 80 Clause 8.2.2 Transmission duration, headset EUT 90 Clause 8.3 Duplex connections, headset EUT 92 VI. Appendix A WBM (Wide Band Mode), headset EUT 100 Clause 6.1.2 Peak transmit power, headset EUT in WBM 101 Clause 6.1.3 Emission bandwidth B, headset EUT in WBM 102 Clause 7.3.1 Lower threshold for EUTs which do not implement the LIC procedure, headset EUT in WBM 103 Clause 7.3.3 Least interfered channel (LIC) procedure test, headset EUT in WBM 104 Clause 7.5 Reaction time and monitoring interval, headset EUT in WBM 106 Clause 8.3 Duplex connections, headset EUT in WBM 109 VII. Appendix B Power Control, headset EUT in WBM (Wideband Mode) 115 Clause 6.1.2 Peak transmit power, headset EUT in minimum power mode and WBM 116 Clause 6.1.3 Emission bandwidth B, headset EUT, in minimum power mode and WBM 117 Clause 7.3.2 Lower threshold for EUTs which do not implement the LIC procedure, headset EUT in minimum power setting (WBM). 122 2/125 Clause 7.3.2 Upper threshold for EUTs which implement the LIC procedure, headset EUT, minimum power (normal mode). 123 Clause 7.3.3 Least interfered channel (LIC) procedure test, headset EUT in minimum power (normal mode). 124 3/125 I. Background EUT description The Wireless Headset WH500 are headsets which can receive and transmit audio to/from its companion Base assembly, WO1, FCC ID AL8WO1 . This document reports compliance of the headset to the test parameters of C63.17-2006. The headset EUT is capable of initiating a link in a normal mode of 60 channels and a Wide Band Audio Mode (WBM) which only supports 30 channels. The main sections of this report documents the normal mode operation in the high power setting. Appendix A documents the WBM compliance testing for any tests that do or may operate differently from the normal mode. The headset EUT also is capable of RF power control. Compliance to C63.17-2006 is documented in Appendix B which repeats any testing that may operate differently from maximum power mode, or affect the access threshold. The power control modes are fixed, or adaptive. Adaptive power control will allow the RF transmitter to adjust the output power from maximum to minimum in approximately 4-5dB steps. Fixed power mode does not allow power control. The user can select between adaptive or fixed but can not set the power range, this is done during EUT factory set up. The specific unit tested is headset SN: 05F9ED317. Manufacturer’s attestations, mandatory declarations and descriptions The Wireless Headset WH500 uses only digital modulation. Clause 4.11 in C63.17-2006 requires the following declarations to be made by the manufacturer. These declarations are used in demonstrating compliance with certain sections of 47CFR15 subpart D, and in support of test parameters within C63.17-2006. The channel plan. Five RF carriers are used, as follows: 1928.448 MHz. 1926.720 MHz. 1924.992 MHz. 1923.264 MHz. 1921.536 MHz. Maximum EUT antenna gain GA (dBi), and orientation and polarization for maximum gain. The maximum headset EUT antenna gain is 3dBi. The antenna is elliptically polarized with the major axis of polarization parallel to the headband portion of the headset disposed away from the user’s head, and with the minor axis of polarization on the same plane as the electrical board and perpendicular headband portion of the headset. Maximum peak power level Maximum specified peak conducted power level for the headset EUTs is +20.0dBm. Minimum peak power level The maximum power level at the minimum RF power setting is specified peak conducted power level for the headset EUTs is +4.0dBm. Emission bandwidth Emission bandwidth measured according to the procedures of C63.17-2006 clause 6.1.3 for the headset EUT is 1.45MHz. Nominal receive bandwidth Nominal receive bandwidth is +/-500kHz. 4/125 Frame period and time slot plan, if TDMA techniques are used The EUT system is a TDMA system which “further divides access in time” in the context of clause 6.2.2 of C63.17- 2006. Frame period is 10mS. There are 24 timeslots per frame, with one of the first 12 timeslots used for the headset transmissions and one of the last 12 timeslots used for the base transmissions. Transmit and receive timeslots are 5mS apart in time. The headset can also be set to wideband audio mode (WBM) which uses 2 of the 12 timeslots for headset transmissions and 2 of the timeslots for headset receipt. Transient events occur during which two non-adjacent timeslots may be in use by the base during the setup of the communications channel, or by both the base and the headset EUT as the system does a soft handoff in response to interference. Minimum and maximum burst length, if TDMA techniques are used Minimum burst length is 390uS, transmissions from the headset when a communications channel is open. Maximum burst length is 780uS, transmissions from the headset when a communications channel is open. Minimum and maximum operating temperature range declared to the end-user The minimum operating temperature is 0C.…

Text truncated - open the document above for the full version.
