APV‐200C User Manual Asiatelco Technologies Co. Proprietary/Confidential APV‐200C User Manual R1.4 Author Revision Changes Date twu 1.1 Initial version 2014‐05‐04 Robin song 1.2 Change GPS requirement and some description 2014‐05‐12 twu 1.3 Add App scene; Test Plan 2014‐05‐21 changyu 1.4 Change OTA Parameters 2014‐06‐01 Twu 1.4 Change Project Name 2014‐06‐04 Confidential Material: This document contains information that is proprietary and confidential, reading and copying this document is prohibited without permissionfrom Asiatelco Technologies Co. APV‐200C User Manual Asiatelco Technologies Co. Proprietary/Confidential Contents 1 Introduction .............................................................................................................................. 3 ID and Tooling Design ........................................................................................................................ 4 2 Hardware Design ....................................................................................................................... 5 2.1 Basic Hardware .................................................................................................................. 5 2.2 Basic RF Performance ........................................................................................................ 7 2.3 Certification and Safety ..................................................................................................... 9 3 Software Features ................................................................................................................... 10 3.1 Basic Software ................................................................................................................. 10 3.2 Remote Update ............................................................................................................... 10 3.2.1 Auto Execute ........................................................................................................... 10 3.3 Power Modes .................................................................................................................. 10 3.4 AT Command ................................................................................................................... 11 3.5 Report .............................................................................................................................. 13 3.6 Reset ................................................................................................................................ 13 3.6.1 Context Preservation ............................................................................................... 13 3.7 Startup Banner ................................................................................................................ 13 4 Test Method ............................................................................................................................ 14 4.1 Hardware ......................................................................................................................... 14 4.2 Software Test ................................................................................................................... 14 APV‐200C User Manual Asiatelco Technologies Co. Proprietary/Confidential 1 Introduction The APV‐200C is a self‐contained vehicle tracking device that combines GPS location with CDMA connectivity. Logically, the ION appears to a user or a server application as a single endpoint device. It can be queried, updated and configured either through a serial connection, or an over the air CDMA IP connection, or through SMS messaging. The APV‐200C presents itself over these connections as an enhanced cellular modem with attached functional elements. These elements include: GPS location engine 2 General Purpose Bidirectional I/O (GPIO) pins 1 Relay drive pin output Serial UART port Input voltage monitor (optional) Timers Watchdog lockup protection (Dedicated watchdog circuit is optional) Factory l oad option for motion detection Access to these elements and general purpose interfaces is done through an extended AT command set as defined herein. Application scene: This product will be designed based on the VIA CBP8.2 CDMA 1X 800M&1900M Baseband chipset, which includes GPS functionality, ARM CPU and CDMA protocol. This baseband external connection 256M serial flash, CDMA 800M/1900M/GPS RF Transceiver, and RF Front end circuit. The device will use one dual band antenna（CDMA800&CDMA1900）and one dedicate GPS antenna. APV‐200C User Manual Asiatelco Technologies Co. Proprietary/Confidential ID and Tooling Design The housing will be provided by customer. The product appearance is shown as follows: Item Definition Dimension 76.8( L )*46.5( W )*19.1( H )mm Weight / APV‐200C User Manual Asiatelco Technologies Co. Proprietary/Confidential 2 Hardware Design 2.1 Basic Hardware Items Requirement Baseband Chipset VIA CBP8.2C/CBP8.2D RF Transceiver FCI7790 Memory Serial Flash 256Mb PSRAM 128Mb/64Mb (optional) Air Interface CDMA 2000 1x, GPS Frequency CDMA2000 1x: 800MHz,1900MHz Antenna Internal Antenna(800M&1900M) GPS Antenna Dedicate high performance ceramic antenna UIM requirement No‐UIM mode, UIM card connector optional Interface UART TX UART RX 12V DC Input（1A current） Relay Drive (12V Output ,500mA current) GPIO1 GPIO2 Battery Monitor internal analog input scaled (Optional) Build in battery manager Supported Dedicate Timers No Watchdog Supported(Dedicate Watchdog is Optional) Motion Detect Optional（GPS/Sensor） LED 2 LED Supported 2 LEDs(one is RED，one is Green) Battery Build in battery（80MAH Lion） Working Time 4hours Power switch No Power Cable color 8 colors Power Cable connector type 8 pin Power Consumption < 5Watts The APV‐200C provides support for specialized hardware features through extended AT commands. The features supported include the following. GPS The major functionality of the GPS module is to compute the correlation results b…

Text truncated - open the document above for the full version.

CalAmp Request for Confidentiality Date: 2014-9-22 Subject: Confidentiality Request for: APV-200C Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: (Insert Explanation as Necessary) CalAmp has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Sincerely, By: / Certification Manager Imad Rizk (Signature/Title) (Print name)

External Photo

69.8x36.8mm

Internal photo GPS antenna CDMA antenna

Report No.: RXA1409-0217MPE Page 1 of 5 : MPE REPORT Product Name LMU-200C CDMA Model Name LMU-200C Brand Name CalAmp FCC ID APV-200C Applicant CalAmp Wireless Networks corp. Manufacture AsiaTelco Technologies Co. Date of issue September 16, 2014 Approved by Kai Xu Director Revised by Minbao Ling SAR Manager Performed by Jian Qi SAR Engineer Test By Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai,China Contact: Yang Weizhong Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] TA Technology (Shanghai)Co.,Ltd. Test Report Report No.: RXA1409-0217MPE Page 2 of 5 Maximum Permissible Exposure Type of EUT: LMU-200C CDMA FCC ID: APV-200C Manufacturer: AsiaTelco Technologies Co. Model: LMU-200C Maximum conducted output power (measured) and antenna Gain: According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible exposure (MPE) are as following Band Time-average maximum tune up procedure (dBm) Antenna Gain (dBi) CDMA Cellular 25 2 CDMA PCS 24 2 TA Technology (Shanghai)Co.,Ltd. Test Report Report No.: RXA1409-0217MPE Page 3 of 5 Note1. Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational / controlled limits apply provided he or she is made aware of the potential for exposure. Note2: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. TA Technology (Shanghai)Co.,Ltd. Test Report Report No.: RXA1409-0217MPE Page 4 of 5 The maximum permissible exposure for 300~1500MHz is f/1500, 1500~100,000MHz is 1.So IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. No change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. Band The maximum permissible exposure CDMA Cellular 0.56 CDMA PCS 1.00 TA Technology (Shanghai)Co.,Ltd. Test Report Report No.: RXA1409-0217MPE Page 5 of 5 RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided. This calculation is based on the conducted power, considering maximum power and antenna gain. The formula shown in KDB 865664 D01 is used in the calculation. Equation from KDB 865664 D01, Edition 97-01 is: S= PG / 4∏R 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = Time-average maximum tune up procedure (in appropriate units, e.g., mW) G = the numeric gain of the antenna R = distance to the center of radiation of the antenna ( 20 cm = limit for MPE) So, the numeric gain (G) of the antenna with a gain specified in dB is determined by Numeric gain (G)=10^(antenna gain/10)=10^(2/10)=1.58 dB CDMA Cellular: PG = 25dBm+ (1.58dB) =26.58dBm=455mW CDMA PCS: PG = 24dBm+ (1.58dB) =25.58dBm=361.41mW R =20 cm ∏= 3.1416 Solving for S, the power density at 20 cm is Band Test Result (mW/cm 2 ) Limit Value (mW/cm 2 ) CDMA Cellular 0.09 0.56 mW/cm² CDMA PCS 0.07 1 mW/cm² Note: For mobile or fixed location transmitters, minimum separation distance is 20cm, even if calculations indicate MPE distance is less.

Report No.: RXA1409-0217RF01R1 Page 1of 33 TESTING No. L2264 Part 22 TEST REPORT Product Name LMU-200C CDMA Model Name LMU-200C Brand Name CalAmp FCC ID APV-200C Applicant CalAmp Manufacturer AsiaTelco Technologies Co. Date of issue October 10, 2014 TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1409-0217RF01R1 Page 2of 33 GENERAL SUMMARY Reference Standard(s) FCC CFR47 Part 2 (2013) Frequency Allocations And Radio Treaty Matters; General Rules And Regulations FCC CFR 47 Part 22H (2013) Public Mobile Services(850MHz) ANSI/TIA-603-C(2004) Land mobile FM or PM Communications Equipment Measurements and Performance Standards. KDB 971168 D01 Power Meas License Digital Systems v02r01 Measurement Guidance for Certification of Licensed Digital Transmitters Conclusion This fixed equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 2 of this test report are below limits specified in the relevant standards. General Judgment: Pass Comment The test result only responds to the measured sample. Approved by Kai Xu Director Revised by Lingling Kang RF Manager Performed by Changxu Wan RF Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1409-0217RF01R1 Page 3of 33 TABLE OF CONTENT 1. General Information ..................................................................................................................... 4 1.1. Notes of the test report ......................................................................................................... 4 1.2. Testing laboratory ................................................................................................................. 5 1.3. Applicant Information ............................................................................................................ 5 1.4. Manufacturer Information ...................................................................................................... 5 1.5. Information of EUT ................................................................................................................ 6 1.6. Test Date .............................................................................................................................. 6 2. Test Information ........................................................................................................................... 7 2.1. Summary of test results ........................................................................................................ 7 2.2. RF Power Output .................................................................................................................. 8 2.3. Effective Radiated Power .................................................................................................... 10 2.4. Occupied Bandwidth ........................................................................................................... 13 2.5. Band Edge Compliance ...................................................................................................... 16 2.6. Peak-to-Average Power Ratio (PAPR) ............................................................................... 19 2.7. Frequency Stability ........................................................................................................... .. 22 2.8. Spurious Emissions at Antenna Terminals ......................................................................... 24 2.9. Radiates Spurious Emission ............................................................................................... 27 3. Main Test Instruments ................................................................................................................ 31 ANNEX A: EUT Appearance and Test Setup ..................................................................................... 32 A.1 EUT Appearance ................................................................................................................ 32 A.2 Test Setup ........................................................................................................................... 33 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1409-0217RF01R1 Page 4of 33 1. General Information 1.1. Notes of the test report TA Technology (Shanghai) Co., Ltd. has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L2264. TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 428261. TA Technology (Shanghai) Co., Ltd. has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 8510A. TA Technology (Shanghai) Co., Ltd. guarantees the reliability of the data presented in this test report, which is the results of measurements and tests performed for the items under test on the date and under the conditions stated in this test report and is based on the knowledge and technical facilities available at TA Technology (Shanghai) Co., Ltd. at the time of execution of the test. TA Technology (Shanghai) Co., Ltd. is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the items under test and the results of the test. The sample under test was selected by the Client.This report only refers to the item that has undergone the test. This report standalone dose not constitute or imply by its own an approval of the product by the certification Bodies or competent Authorities. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of TA Technology (Shanghai) Co., Ltd. and the Accreditation Bodies, if it applies. If the electrical report is inconsistent with the printed one, it should be subject to the…

Text truncated - open the document above for the full version.

Report No.: RXA1409-0217RF02R1 Page 1of 36 TESTING No. L2264 Part 24 TEST REPORT Product Name LMU-200C CDMA Model Name LMU-200C Brand Name CalAmp FCC ID APV-200C Applicant CalAmp Manufacturer AsiaTelco Technologies Co. Date of issue October 10, 2014 TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1409-0217RF02R1 Page 2of 36 GENERAL SUMMARY Reference Standard(s) FCC CFR47 Part 2 (2013) Frequency Allocations And Radio Treaty Matters; General Rules And Regulations FCC CFR47 Part 24E (2013) Personal Communications Services ANSI/TIA-603-C(2004) Land mobile FM or PM Communications Equipment Measurements and Performance Standards. KDB 971168 D01 Power Meas License Digital Systems v02r01 Measurement Guidance for Certification of Licensed Digital Transmitters Conclusion This fixed wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 2 of this test report are below limits specified in the relevant standards. General Judgment: Pass Comment The test result only responds to the measured sample. Approved by Kai Xu Director Revised by Lingling Kang RF Manager Performed by Changxu Wan RF Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1409-0217RF02R1 Page 3of 36 TABLE OF CONTENT 1. General Information ..................................................................................................................... 4 1.1. Notes of the test report ......................................................................................................... 4 1.2. Testing laboratory ................................................................................................................. 5 1.3. Applicant Information ............................................................................................................ 5 1.4. Manufacturer Information ...................................................................................................... 5 1.5. Information of EUT ................................................................................................................ 6 1.6. Test Date .............................................................................................................................. 6 2. Test Information ........................................................................................................................... 7 2.1. Summary of test results ........................................................................................................ 7 2.2. RF Power Output .................................................................................................................. 8 2.3. Effective Isotropic Radiated Power ..................................................................................... 10 2.4. Occupied Bandwidth ........................................................................................................... 12 2.5. Band Edge Compliance ...................................................................................................... 15 2.6. Peak-to-Average Power Ratio (PAPR) ............................................................................... 18 2.7. Frequency Stability ........................................................................................................... .. 21 2.8. Spurious Emissions at Antenna Terminals ......................................................................... 23 2.8 Radiates Spurious Emission ............................................................................................... 30 3. Main Test Instruments ................................................................................................................ 34 ANNEX A: EUT Appearance and Test Setup ..................................................................................... 35 A.1 EUT Appearance ................................................................................................................ 35 A.2 Test Setup ........................................................................................................................... 36 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1409-0217RF02R1 Page 4of 36 1. General Information 1.1. Notes of the test report TA Technology (Shanghai) Co., Ltd. has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L2264. TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 428261. TA Technology (Shanghai) Co., Ltd. has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 8510A. TA Technology (Shanghai) Co., Ltd. guarantees the reliability of the data presented in this test report, which is the results of measurements and tests performed for the items under test on the date and under the conditions stated in this test report and is based on the knowledge and technical facilities available at TA Technology (Shanghai) Co., Ltd. at the time of execution of the test. TA Technology (Shanghai) Co., Ltd. is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the items under test and the results of the test. The sample under test was selected by the Client.This report only refers to the item that has undergone the test. This report standalone dose not constitute or imply by its own an approval of the product by the certification Bodies or competent Authorities. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of TA Technology (Shanghai) Co., Ltd. and the Accreditation Bodies, if it applies. If the electrical report is inconsistent with the printed one, it should be subject to…

Text truncated - open the document above for the full version.

1 test setup photo 1. RSE 2 2. Zoom‐in
