APV-3642MBLTE CAT-M1 Telematics Gateway

CalAmp

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Jul 11, 2023
Application Purpose: Original Equipment
Date of Application: Jul 05, 2023
Equipment Note: LTE CAT-M1 Telematics Gateway
Frequency Range: 824.10000000 - 848.90000000
Company: CalAmp
Country: United States
