APV-2650MBRemote location monitoring unit.

LMU-2650 Scope LMU32 vs EdgeCore Platform Differences LMU-2650/3640/2630 Hardware Differences I/O Mapping & Wake-up sources Stream Settings LMU-2650 Hardware Specifications Cellular/Network Data Support Satellite Location (GNSS) Battery Environmental Physical/Design LMU-2650 Connectors Comprehensive I/O Primary Connector Compatible Cabling/Accessories Connectors/Antennas/SIM Access 3-Axis Accelerometer Input Status LEDs PEG2 PEG2 File Header Configuration Parameters Script Section End of File (EOF) and CRC PEG2 TAG Definitions Multiple Modifiers PEG1 -> PEG2 Conversion Installation Instructions Size and Placement of LMU Unit Access to the SIM Card Protection from Heat Visibility of Diagnostic LEDs Cable Length Moisture and Weather Protection Preventing Accidental or Unauthorized Modification Installation Verification Comm Verification GPS Verification Inbound Verification Verification via SMS Scope This document provides an overview of CalAmp’s Telematics EdgeCore platform, referred as EdgeCore hereafter, the associated products, highlights, and major features. It also serves as a training manual on ‘how-to’ get started with an EdgeCore device (e.g. LMU-2650). Lastly, this document serves to describe the major differences between EdgeCore and the LMU32 predecessor platforms. LMU32 vs EdgeCore Platform Differences LMU-2650/3640/2630 Differences LMU-2650 LMU-3640 LMU-2630 SIM card Externally accessible Nano (4FF) Internal Mini (2FF) Internal Mini (2FF) Pinout 24 pin 24 pin 20 pin Battery Technology Lithium iron phosphate Lithium-ion Lithium-ion Battery Capacity Current Draw BLE 5.0 4.2 4.2 Embedded Intelligence Engine PEG2 PEG1 PEG1 On/Off Switch I/O Mapping & Wake-up sources I/O LMU-2650 (EdgeCore) LMU-2630 (LMU32) Input-0 Ignition Ignition Input-1 In-1 sel In-1 sel Input-2 In-2 sel In-2 sel Input-3 In-3 sel In-3 sel Input-4 In-4 sel In-4 sel Input-5 Motion Input-6 Pwr State Input-7 Vbatt Low Input-8 Motion Hi Temp Input-9 VBUS Active Input-10 Pwr State Batt Virt Ign Input-11 Vbatt Low Input-12 1BB Detect 1BB Detect Input-13 Batt Virt Ign Input-14 Pure Virt Ign Pure Virt Ign Input-15 Input-16 Motion Wake Input-17 Input-18 Input Power Wake Input-19 Input-20 Input-21 Input-22 Input-23 Radio Active Wake Input-24 BLE Wake Input-25 VBUS Wake Input-26 Input-27 Crank Detect Wake Input-28 RTC Wake Input-29 GPS Active Input-30 Hyb Crank Detect Output-0 Out-0 Out-0 Output-1 Out-1 Out-1 Output-2 Out-2 Out-2/ADC-7 Output-3 Output-4 Pwr Switch Output-5 Chrg Disable Output-6 Output-7 Pwr Switch Output-8 Chrg Disable Output-9 Output-10 Output-11 Output-12 Output-13 Switched VOUT Output-14 ADC-0 Vin Vin ADC-1 Ext-1 Ext-1 ADC-2 Ext-2 GPS Ant. ADC-3 HWID (LMU) uP Temp. ADC-4 Vref ADC-5 Battery ADC-6 Temp Sensor ADC-7 uP Temp Vcc_Sys/Ext ADC-8 Audio Sensor ADC-9 VBATT (LMU) ADC-10 ADC-11 ADC-12 LED-1 GPS (Green) GPS (Green) LED-2 Comm (Orange) Comm (Orange) LED-3 BT (Blue) Stream Settings Debug information will be sent through the USB port (Aux3), while Aux1 will remain as a command-only stream. Default Stream Settings (needs correction) Stream Port Rate Word 0 USER0 1 MODEM 4 :PORTID_RADIO 921600 8/N/1 2 USER1 3 DEBUG 10:PORTID_AUX3 115200 8/N/1 4 NMEA_OUT 5 DUN 6 PEG_SERIAL 7 VBUS 1 :PORTID_AUX2 921600 8/N/1 8 GPS 5 :PORTID_GPS 921600 8/N/1 9 ALTMDM 10 EA_0 11 EA_1 12 EA_2 13 UNDEF 14 BT 17:PORTID_VUART_BLE921600 8/N/1 15 ATCMD_1 16 ATCMD_2 17 SATMDM 18 SBB 19 WSP 20DB 21 CONSOLE 22 PERIPHDRV 23 PSM 24 COPDBG LMU-2650 Hardware Specifications Cellular/Network LTE Cat M1: 2100 (B1)/1900 (B2)/1800 (B3)AWS 1700 (B4)/850 (B5/B26)/900 (B8)/700 (B12/B13/B28)/800 (B18/B19/B20)/1900 (B39/B25) MHz GSM/GPRS: 850/900/1800/1900 MHz Data Support SMS, UDP Packet Data, TCP Satellite Location (GNSS) Constellation Support: GPS/GLONASS Tracking Sensitivity: -161 dBm Acquisition Sensitivity: -16 dBm (hot start) -145 dBm (cold start) Location Accuracy: ~2.5 CEP open sky Battery Battery capacity: 1100 mA Battery technology: Lithium iron phosphate Charging temperature: 0 to +45° C Environmental Temperature: o-40° to +60° C (connected to primary power) o-20° to +60° C (operating on internal battery) o-20° to +25° C ≤ 6 months (long term storage with battery) Humidity: 85% RH @ 55° C non-condensing Shock and Vibration: U.S. Military Standards 202G, 810F SAEJ1455 ESD: IEC 61000-4-2 Ingress Protection: IP67 (CalAmp Assembled) Physical/Design Dimensions: 4.0” x 2.2” x 0.8” (106 mm x 57 mm x 22 mm) Weight: 3.4 oz. (97 g) LMU-2650 Connectors Comprehensive I/O Ignition Inputs: 1 fixed bias Digital Inputs: 4 (high/low bias selectable 0-32 VDC) Digital Outputs: 3 (open collector relay 150mA) Analog Inputs: 2 (external ADC input 0-32 VDC) Accelerometer: Built in, triple-axis (driver behavior, impact detection, motion sensing, tilt detection) Serial Interface: 2 TTL ports USB Interface: 1 serial port (with switch) DC Power Output: 3 (2 switched 3.3V & 1 switched VIN (Pin 12 on 24 pin connector) 1-Wire® Interface 1 (driver ID/temperature sense) Status LEDs: 3 (GPS, cellular, Bluetooth) Primary Connector Pin Signal Name 5C360 Color 1 Input 1 Blue 2 Input 2 Blue/Orange 3 Input 3 Violet 4 Input 4 Grey 5 ADC 1 Pink 6 ADC 2 Black/Red 7 AUX1 TX Brown/Blue 8 AUX1 RX Brown/Green 9 GND Black 10 GND Black 11 GND Black 12 VIN SW Blue/Red 13 Input 0 White 14 VCC 3V3 AUX1 Brown/Orange 15 VCC 3V3 AUX2 Yellow/Orange 16 1BB T DATA Green/Black 17 AUX2 RX Yellow/Green 18 AUX2 TX Yellow/Blue 19 OUT 0 Green 20 OUT 1 Brown 21 OUT 2 Yellow 22 GND Black 23 VIN 1 Red 24 VIN 2 Orange Compatible Cabling/Accessories DPod LMU-364x compatible cables (1 bit bus not supported until march) Connectors/Antennas/SIM Access Power, I/O: 24 pin 3mm Pitch SIM Access: Externally accessible (4FF SIM) BLE Antenna: Internal Cellular Antenna: Internal GPS Antenna: Internal USB 3-Axis Accelerometer Input The LMU-2650™ supports an internal 3 Axis Precision Accelerometer as one of its discreet inputs. When the LMU is moved in any direction, the associated i…

Text truncated - open the document above for the full version.

Letter of Authorization and Anti- Drug Statement Applicant Name: Calamp Address: 2200 Faraday Ave, Suite 220 Carlsbad, CA 92008 Product Name: LMU2650 CAT M1 Model Number: LMU2650MB FCC ID: APV-2650MB We authorize CETECOM Inc., to act on our behalf on all matters concerning the above named equipment. We declare that CETECOM Inc. is allowed to forward all information related to the approval project to the Federal Communications Commission and discuss any issues concerning the approval application. The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? ☒ Yes I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. Full Name: Imad Rizk Position / Title: Director of Certification Place of Issue: 2200 Faraday Ave, Suite 220 Carlsbad, Ca 92008. USA Date: February 13, 2023

Federal Communication Commission 7435 Oakland Mills Road Columbia, MD 21046 Attestation Statement according to 2.911(d)(5)(i) and 2.911(d)(5)(ii) FCC ID: APV-2650MB TO WHOM IT MAY CONCERN: Hereby we certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Further we certify that, as of the date of the filing of the application, Calamp is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Full Name: Peter Douglas Position / Title: VP, Supply Chain Place of Issue: 15635 Alton Parkway, Suite 250 Irvine, CA 92618 USA Date: March 14, 2023

Federal Communication Commission 7435 Oakland Mills Road Columbia, MD 21046 Attestation Statement according to 2.911(d)(7) Manufacturer: Calamp Model: LMU2650MB FCC ID: APV-2650MB IC: 5843C-2650MB TO WHOM IT MAY CONCERN: We, Calamp, located in 2200 Faraday Ave, Suite 220 Carlsbad, CA 92008 With Head Quarter located in: 15635 Alton Parkway, Suite 250 Irvine, CA 92618. confirms to maintain legal representation for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment Full Name: Imad Rizk Position / Title: Director of Certification Place of Issue: 2200 Faraday Ave, Suite 220 Carlsbad, Ca 92008. USA Date: February 13, 2023

Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, and KDB 726920, CalAmp hereby requests permanent confidentiality for documents filed under the following exhibit types: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational Description These items contain detailed system and equipment description and related information about the product which Calamp considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Calamp also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Best Regards Full Name: Imad Rizk Position / Title: Director of Certification Place of Issue: 2200 Faraday Ave, Suite 220 Carlsbad, Ca 92008. USA Date: February 13, 2023

Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Subject: Request for Short Term Confidentiality FCC-ID: APV-2650MB To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, CalAmp hereby requests short term confidentiality for documents filed under the following exhibit types: 1. External Photographs 2. Internal Photographs 3. User / Instruction Manual 4. Test Set-up Photographs Until the product will be publicly announced. Short term confidentiality release date / period: 180 days from grant issue date. These items contain detailed system and equipment description and related information about the product which Calamp considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Calamp also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are informed and aware of our obligation that we have to inform the involved TCB in written and in due time if we intend to market the product prior to the above specified confidentiality release date so that the short term confidentiality classification can be reset prior to product launch. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Full Name: Imad Rizk Position / Title: Director of Certification Place of Issue: 2200 Faraday Ave, Suite 220 Carlsbad, Ca 92008. USA Date: February 13, 2023

REVISIONS UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: FRACTIONS DECIMALS ANGLES ±1/32 .XX ±.01 ±0°30’ .XXX ± .005 USED ON DRAWN: CHECKED: ISSUED: TITLE DO NOT SCALE DRAWING SIZE CAGE CODE DWG NO. REV A 6T925 SHEET 1 OF 1 SCALE ITEM NO. QTY REQD IDENTIFYING NO. DESCRIPTION MKTG: 1 1 NOTES: UNLESS OTHERWISE SPECIFIED 1. APPLICABLE STANDARDS / SPECIFICATIONS; MIL-STD-100E, ENGINEERING DRAWING PRACTICES. ANSI Y14.5M-1982, DIMENSIONS AND TOLERANCES. 2. FONT (TYPICAL) : CALIBRI (VARIOUS SIZES), ARIAL (VARIOUS SIZES). IF REQUIRED, BARCODE FORMAT : CODE 128 OR DATA MATRIX ECC200, BLACK INK 3. IF REQUIRED, DATE CODE SHALL BE DEFINED AS : WWYY WW – TWO DIGIT WORK WEEK YY – TWO DIGIT YEAR 4. IF REQUIRED, CURRENT DATE SHALL BE DEFINED AS : MM/DD/YYYY MM – MONTH DD – DAY YYYY – YEAR 5. MATERIAL MUST BE LEAD (Pb) FREE PER THE EUROPEAN UNION’S RESTRICTION OF HAZARDOUS SUBSTANCE (RoHS) DIRECTIVE. 6. COUNTRY OF ORIGIN (COO) IN THE LABEL IMAGE WILL BE REPLACED BY THE COUNTRY LISTED PER THE TABLE BELOW ON ACTUAL PRINTED LABEL. LABEL BLANK, COATED MATTE, 2.75 X 1.56, 1" SPOOL SIZE 79969-2 LABEL FILE: COO Label Information Assembled in China Assembled in Taiwan 6 Assembled in Malaysia Assembled in Mexico Assembled in USA REV ECO NO. DESCRIPTION DATE APPROVED A 000602 PRODUCTION RELEASE 01/13/2023 E. RAMOS LBL00217_A_LMU2650MB-H000-G1000_G_DB.btw SEE OMNIFY E. RAMOS 01/05/2023 SEE OMNIFY LABEL MARKING, UNIT, LMU2650, CATMB, BG96, BLE, INT ANT, 1100MAH BATT, DM-CTC, US LBL00217 A LMU2650MB-H000-G10US 3 6 Elec. File: LBL00217_A.docx

Radio Frequency Exposure Evaluation Report FOR: CalAmp Model Name: LMU2650MB Product Description: Remote location monitoring unit. FCC ID: APV-2650MB IC: 5843C-2650MB Applied Rules and Standards: CFR Part Part1 (1.1307 &1.1310), Part 2 (2.1091), FCC KDB 447498 D01 General RF Exposure Guidance v06 ISED RSS-102 Issue 5 Report number: EMC_CALAM-129-22001_MPE_Rev2 DATE: 3-30-2023 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V5.0 2015-10-27 © Copyright by CETECOM Test Report #: EMC_CALAM-129-22001_MPE_Rev2 Date of Report 3-30-2023 Page 2 of 8 1 Assessment This RF Exposure evaluation report provides evidence for compliance of the below identified device with the RF Exposure limits for mobile devices as defined in FCC CFR Part 1 (1.1307 &1.1310), Part 2 (2.1091) and ISED standard RSS-102 issue 5 under worst case conditions (measured or rated RF output power, antenna gain, distance towards human body, multiple transmitter information as presented by the applicant). In addition, maximum antenna gain or minimum distance towards the human body is calculated respectively, where relevant. The device meets the limits as stipulated by the above given FCC and ISED rule parts based on available specifications for worst-case conditions at 20 cm distance to the body. Company Description Model # CalAmp Remote location monitoring unit LMU2650MB Report reviewed by: TCB Evaluator 3-30-2023 Compliance Arndt Stoecker (Director of Regulatory Services) Date Section Name Signature Responsible for the Report: 3-30-2023 Compliance Kris Lazarov (Senior EMC Engineer) Date Section Name Signature The test results of this test report relate exclusively to the test item specified in Section3. CETECOM Inc. USA does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM Inc. USA. Test Report #: EMC_CALAM-129-22001_MPE_Rev2 Date of Report 3-30-2023 Page 3 of 8 2 Administrative Data 2.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Street Address: 411 Dixon Landing Road City/Zip Code Milpitas, CA 95035 Country USA Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Director of Regulatory Services: Arndt Stoecker Responsible Project Leader: Cathy Palacios 2.2 Identification of the Client / Manufacturer Client’s Name: CalAmp Street Address: 2200 Faraday Ave #220 City/Zip Code Carlsbad, CA 92008 Country USA 2.3 Identification of the Manufacturer Manufacturer’s Name: Same as Client Manufacturers Address: City/Zip Code Country Test Report #: EMC_CALAM-129-22001_MPE_Rev2 Date of Report 3-30-2023 Page 4 of 8 3 Equipment under Assessment Marketing name: LMU2650MB HW Version : REV 3 SW Version : 3.16.1.3 HVIN: LMU2650MB PMN: LMU2650 LTE CAT M1 Regulatory Band: Cellular Module:  GSM 850: 824.4 ~ 848.8 MHz  GSM 1900: 1850.2 ~ 1909.8 MHz  LTE BAND 2: 1850 ~ 1910 MHz  LTE BAND 4: 1710 ~ 1755 MHz  LTE BAND 5: 824 ~ 849 MHz  LTE BAND 12: 699 ~ 716 MHz  LTE BAND 13: 777 ~ 787 MHz  LTE BAND 25: 1850 ~ 1915MHz  LTE BAND 26: 814 ~ 849 MHz BLE:  Nominal band: 2400 MHz – 2483.5 MHz Integrated Cellular Module Info: Cellular:  Manufacture: Quectel  Module name/number: BG96MCE-12B-CAL  FCC ID: XMR201707BG96  IC: 10224A-201709BG96 Antenna Type: Cellular:  Model Name : KYOCERA AVX’ Universal Broadband FR4 Embedded LTE / LPWA Antenna  Part No. : 1004795  Max Gain : 3.1dBi BLE:  Type : Ceramic Antenna from Ethertronics  Part No: 1001312  Max Gain: 1.88 dBi Maximum Conducted Output Power: Cellular: From Modular Grant for FCC ID XMR201707BG96 from 03/28/2019  GSM 850: 624 mW  GSM 1900: 582 mW  LTE Band 2: 925 mW  LTE Band 4: 995 mW  LTE Band 5: 675 mW  LTE Band 12: 619 mW  LTE Band 13: 589 mW  LTE Band 25: 284 mW From Modular Grant for FCC ID XMR201707BG96 from 02/25/2019  LTE Band 26: 201 mW BLE: Declared in Operation Description:  3 mW Power Supply/ Rated Operating Voltage Range: Battery powered only: 9-30 VDC Operating Temperature Range: -30 C to 60 C Sample Revision: Production Unit; Pre-Production Test Report #: EMC_CALAM-129-22001_MPE_Rev2 Date of Report 3-30-2023 Page 5 of 8 4 RF Exposure Evaluation Methods 4.1 RF Exposure Test Exemptions for Single Source 4.1.1 FCC § 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. Single RF sources as defined in paragraph (b)(2) of FCC § 2.1091 is exempt if the ERP (watts) is no more than the calculated value prescribed for that frequency. General frequency and separation-distance dependent MPE-based effective radiated power ERP thresholds are in Table B.1 [Table 1 of § 1.1307(b)(3)(i)(C)] to support an exemption from further evaluation from 300 kHz through 100 GHz. TABLE B.1—THRESHOLDS FOR SINGLE RF SOURCES SUBJECT TO ROUTINE ENVIRONMENTAL EVALUATION RF Source Frequency Minimum Distance Threshold ERP fL MHz fH MHz λL / 2π λH / 2π W 0.3 – 1.34 159 m – 35.6 m 1,920 R 2 1.34 – 30 35.6 m – 1.6 m 3,450 R 2 /f 2 30 – 300 1.6 m – 159 mm 3.83 R 2 300 – 1,500 159 mm – 31.8 mm 0.0128 R 2 f 1,500 – 100,000 31.8 mm – 0.5 mm 19.2R2 Subscripts L and H are low and high; λ is wavelength. From § 1.1307(b)(3)(i)(C), modified by adding Minimum Distance columns. 4.1.2 Exemption Limits for Routine Evaluation to RSS-102 2.5.2 RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates at or above 300 MHz and below 6 GHz and the source- based, time-averaged maximum EIRP of the device is equal to or les…

Text truncated - open the document above for the full version.

A2LA Accredited IC recognized # 3462B CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V4.0 2012-07-25 © Copyright by CETECOM FCC / ISED Test Report FOR: CalAmp Model Name: LMU2650MB Product Description: Remote location monitoring unit. FCC ID: APV-2650MB IC: 5843C-2650MB Applied Rules and Standards: 47 CFR: Part 22, Part 24, Part 27 RSS-130 Issue 2; RSS-132 Issue 4; RSS-133 Issue 6; RSS-139 Issue 4 REPORT #: EMC_CALAM-129-22001_FCC_22_24_27_90S_Rev2 DATE: 3-30-2023 Test Report #: EMC_CALAM-129-22001_FCC_22_24_27_90S_Rev2 Date of Report 3-30-2023 Page 2 of 44 TABLE OF CONTENTS 1 ASSESSMENT ................................................................................................................................................................ 3 2 ADMINISTRATIVE DATA ................................................................................................................................................. 4 2.1 IDENTIFICATION OF THE TESTING LABORATORY ISSUING THE EMC TEST REPORT ............................................................................. 4 2.2 IDENTIFICATION OF THE CLIENT ............................................................................................................................................... 4 2.3 IDENTIFICATION OF THE MANUFACTURER ................................................................................................................................... 4 3 EQUIPMENT UNDER TEST (EUT) ..................................................................................................................................... 5 3.1 EUT SPECIFICATIONS ............................................................................................................................................................ 5 3.2 EUT SAMPLE DETAILS ........................................................................................................................................................... 5 3.3 ACCESSORY EQUIPMENT DETAILS ............................................................................................................................................ 6 3.4 TEST SAMPLE CONFIGURATION ............................................................................................................................................... 6 3.5 MODE OF OPERATION DETAILS ................................................................................................................................................ 6 3.6 JUSTIFICATION FOR WORST CASE MODE OF OPERATION .............................................................................................................. 6 4 SUBJECT OF INVESTIGATION ........................................................................................................................................ 7 4.1 DATES OF TESTING: .............................................................................................................................................................. 7 4.2 MEASUREMENT UNCERTAINTY ................................................................................................................................................ 7 4.3 ENVIRONMENTAL CONDITIONS DURING TESTING: ........................................................................................................................ 7 5 MEASUREMENT PROCEDURES ...................................................................................................................................... 8 5.1 RADIATED MEASUREMENT ...................................................................................................................................................... 8 5.2 SAMPLE CALCULATIONS FOR FIELD STRENGTH MEASUREMENTS ................................................................................................. 10 6 MEASUREMENT RESULTS SUMMARY .......................................................................................................................... 10 6.1 FCC 22, RSS-132: ............................................................................................................................................................ 10 6.2 FCC 24, RSS-133: ............................................................................................................................................................ 11 6.3 FCC 27, RSS-130, RSS-139: ............................................................................................................................................. 12 7 TEST RESULT DATA .................................................................................................................................................... 13 7.1 RF OUTPUT POWER VERIFICATION ........................................................................................................................................ 13 7.2 RADIATED SPURIOUS EMISSIONS ........................................................................................................................................... 14 8 TEST SETUP PHOTO .................................................................................................................................................... 43 9 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTING ........................................................................................... 43 10 REVISION HISTORY ...................................................................................................................................................... 44 Test Report #: EMC_CALAM-129-22001_FCC_22_24_27_90S_Rev2 Date of Report 3-30-2023 Page 3 of 44 1 Assessment The following device as further described in section 3 of this report was evaluated for radiated spurious emissions in simultaneous transmission of cellu…

Text truncated - open the document above for the full version.

www.KYOCERA-AVX.com 8/26/2022 Proprietary DATASHEET Part No. 1004795/1004796 Product: Embedded FR4 Broadband LTE antenna Universal Broadband FR4 Embedded LTE Antenna Low Band: 698 –1000 MHz High Band: 1700 -2400 MHz Band 7: 2500 -2700 MHz Appendix 1: 315, 400, 433, 450 MHz Appendix 2: 600-960 / 1710 -2700 MHz Electrical Specifications Typical 1004795 performance 125 x 45 mm PCB Mechanical Specifications & Ordering Part Number KYOCERAAVX’UniversalBroadbandEmbeddedLTE/LPWAantennasutilize IMDtechnology,whichoffersareducedelectricalfootprintonanycircuitboard andindependenttuningcapabilitiesforperformanceoptimization.Thislow profileFR4antennaencapsulatesIMD’shighperformanceandisolation characteristicsofferingbetterconnectivityandminimalinterference Part No. 1004795 / 1004796 Universal Broadband FR4 Embedded LTE / LPWA Antenna 315 MHz / 400 MHz / 433 MHz / 450 MHz / 600 –960 MHz / 1710 -2690 MHz Supports: Broadband LTE (OCTA-BAND), LTE CAT-M, NB-IoT, LoRa, Cellular LPWA, RPMA, ISM, 400MHz Satellite KEY BENEFITS Reduced Costs and Time-to-Market Standard antenna eliminates design fees and cycle time associated with a custom solution; getting products to market faster. Greater Flexibility with Unique Form Factors KYOCERA AVX’ technology helps you deliver more advanced ergonomic designs without adverse impact on product performance. Environmental Compliance Comply with latest RoHS requirements APPLICATIONS *Mirrored version offered as 1004796 Ordering Part #10047951004796 Dimensions (mm)36.0x 9.0x 3.236.0x 9.0x 3.2 Mounting TypeSMT(P&P) Variant1004796: Mirrored version of1004795 Weight (grams)2.1 PackagingTape and Reel Storage Temperature/ Humidity (Sealed shipping package) +5°C to +35°C 45~75% Operating Temperature-40 to +85 C Demo Board 1004795-01 (1004795) 1004796-01 (1004796) Frequency (MHz) 315,400, 433,450 600-698698-9601710-24002500-2700 PeakGain 1.6 dBi3.1 dBi1.7 dBi Average Efficiency 64%55%53% VSWRMatch < 2.5:1 < 3.0:1 Polarization Linear Power Handling 2 Watt CW Feed Point Impedance 50 Ωunbalanced The1004795/1004796LTEantennaisdesignedtosupportCAT-MandNB-IoT applications,supportingallUSandWorldwidemajorcarriers.Inaddition,the versalitytoreturntootherfrequencybands,allowsthisantennatoperformand 315MHzforRKEapplications,450MHzfortheLTEbandB31,433MHzISM bandsaswellas400MHzsatelliteapplications.Thisantennaistheperfect solutionforIoTenableddevices,offeringhighefficiencyandpeakgaininasmall formfactor,andwithareducedgroundplanesizerequirement. HighPerformanceLTEinSmallformfactor •Medical applications •Smart metering •M2M, Industrial devices •IoT •Firstnet •Point of Sale •Tracking •Satellite Communications TDS-ANT-0033 | Rev. 1 1004795 / 1004796 Universal Broadband LTE KYOCERA AVX Embedded Antenna Specifications. KYOCERA AVX produces a wide variety of standard and custom antennas to meet user needs. DATASHEET | Part No. 1004795 / 1004796 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 LTE Bands covered by (1004795/1004796) LTE BandFrequency Band (MHz)Uplink (UL) (MHz)Downlink (DL) (MHz)RegionCovered 121001920-19802110-2170Global Yes 219001850-19101930-1990NAM…
