TTU-2820 Hardware & Installation Guide TTU-2830™ Hardware and Installation Guide 1 Introduction Welcome to the TTU-2830™ Hardware and Installation Guide. This manual is intended to give you information on the basic setup and installation of the CalAmp TTU-2830™ product(s) including hardware descriptions, environmental specifications, wireless network overviews and device installation. 1.1 About This Manual The TTU-2830™ is one of the most flexible economy mobile tracking hardware products available. In order to accurately describe the functionality of these units we have broken this manual into the following sections: • Hardware Overview – Describes the physical characteristics and interfaces of the TTU-2830™. • Installation and Verification – Provides guidance for the installation of the TTU-2830™ in a vehicle and instructions on how to verify the installation is performing adequately. 1.2 About the Reader In order to limit the size and scope of this manual, the following assumptions have been made about the reader. • You are familiar with GPS concepts and terminology • You have some experience with installing equipment in vehicles 1.3 About the CalAmp Location Messaging Unit-TTU-2830™ The CalAmp Location and Messaging Unit-TTU-2830™ (TTU-2830™) is a mobile device that resides in private, commercial or government vehicles. The TTU-2830™ is a single box enclosure incorporating a processor, a GPS receiver, a wireless data modem, and a vehicle-rated power supply. The TTU-2830™ also supports inputs and outputs to monitor and react to the vehicular environment and/or driver actions. 2 System Overview 2.1 Overview The entire purpose behind a fleet management system is to be able to remotely contact a vehicle, determine its location or status, and do something meaningful with that information. This could include displaying the vehicle location on a map, performing an address look-up, providing real-time driving directions, updating the vehicles ETA, monitoring vehicle and driver status or dispatching the vehicle to its next pick up. These functions, of course, are completely dependent on the capabilities of the vehicle management application. The role of the CalAmp TTU-2830™ is to deliver the location information when and where it is needed. A typical fleet management system based on a CalAmp device includes the following components: • A wireless data network • An TTU-2830™ • Backend mapping and reporting software from Actsoft which typically includes mapping and fleet reporting functions 2.2 Component Descriptions 2.2.1 Wireless Data Network The Wireless Data Network provides the information bridge between the Actsoft servers and the TTU-2830™. Wireless data networks can take a variety of forms, such as cellular networks, satellite systems or local area networks. 2.2.3 Backend Software Backend software is provided by Actsoft. Regardless of its purpose, one of its primary functions is to parse and present data obtained from the TTU-2820. This allows the application to do any of the following: • Display location database on reports received from the TTU-2830™ in a variety of formats • Present historic information received from the TTU-2830™, typically in a report/chart style format • Request location updates from one or more TTU-2830s™ 3 Hardware Overview 3.1 Location Messaging Unit-TTU-2830™ Anytime the sub assembly is shipped and it is not fully packaged in its final housing it must be sealed in an ESD safe bag. Electrical Over-Stress (EOS) The GPS receiver can be damaged if exposed to an RF level that exceeds its maximum input rating. Such exposure can happen if a nearby source transmits an RF signal at sufficiently high level to cause damage. Storage and Shipping One potential source of EOS is proximity of one TTU-2830™ GPS Antenna to another TTU-2830™ CELLULAR Antenna. Should one of the units be in a transmit mode the potential exists for the other unit to become damaged. Therefore any TTU-2830™ GPS Antenna should be kept at least four inches apart from any active TTU-2830™ CELLULAR Antenna or any other active high power RF transmitter with power greater than 1 Watt. 3.1.2 Battery Back-up devices Please properly dispose of the battery in any of the CalAmp products that utilize one, do not just throw used batteries, replaced batteries, or units containing a back-up battery into the trash. Consult your local waste management facility for proper disposal instructions. 3.1.3 Environmental Specifications The TTU-2830™ is designed to operate in environments typically encountered by fleet vehicles, including wide temperature extremes, voltage transients, and potential interference from other vehicle equipment. To ensure proper operation in such an environment, the TTU-2830™ was subjected to standard tests defined by the Society of Automotive Engineers (SAE). The specific tests included temperature, shock, vibration, and EMI/EMC. These tests were performed by independent labs and documented in a detailed test report. In accordance with Appendix A of SAE J1113 Part 1, the Unit is considered a “Functional Status Class B, Performance Region II” system that requires Threat Level 3 Testing. The following shows the environmental conditions the LMU is designed to operate in and the relevant SAE tests that were performed. No formal altitude tests were conducted. Size 4.3" long x 3.2" wide x 1.6" high 110 mm long x 80m wide x 40mm high Weight 9.6 oz (272 g) Operating Temperature -30° C to 70° C Storage Temperature -40° C to 85° C 20° C to 50° C (Internal Battery Power) Humidity 0% to 95% relative humidity, non-condensing Shock and Vibration SAE Test: SAE J1455 Compliant Mil Standard 202G and 810F Compliant Ground vehicle environment with associated shock and vibration Electromagnetic Compatibility (EMC/EMI) SAE Test: SAE J1113 Parts 2, 12, 21 and 41 Compliant FCC Part 15B Compliant Industry Canada Compliant EMC compliant for a ground vehicle environment Operating Voltage Range 9 – 32VDC Back-up Battery 5.2…
