A E R C E P T D A T A R A D I O L A N D C E L L O M E G A S M A R T L I N K www.calamp.com CalAmp / Mobile resource Management MRM/M2M Products 2177 Salk Ave, STE 200 Carlsbad, CA 92008 PH: (760) 438-9010 – Fax: (760) 438-5835 A ugust 14, 2015 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Re: FCC ID: APV-4230CBT Dir Sir and Madam, We CalAmp 2177 Salk Ave, STE 200, Carlsbad, CA 92008 hereby authorize Alex Chang TUV SUD America, Inc. 10040 Mesa Rim Road, San Diego, CA 92121 Tel: (858) 678-1466 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expire on August 13, 2016 Sincerely, Product Certification Manager Imad Rizk Phone number: (760) 814-9697 Email: [email protected]
CalAmp / Mobile resource Management MRM/M2M Products 2177 Salk Ave, STE 200 Carlsbad, CA 92008 PH: (760) 438-9010 – Fax: (760) 438-5835 !!" Confidentiality Request FCC ID: #$%&' Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, CalAmp Wireless networks hereby requests permanent confidential treatment of information accompanying this application as: - Block Diagram - Operation description - Schematic - Part list Also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days: - Internal photos - External photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. () &%' ! * + , -. /0123'45 $#6362 7 (0-.8 ( 9
AER C E P T D A T A R A D I O L A N D C E L L O M E G A S M A R T L I N K w w w . c a l a m p . c o m CalAmp / Mobile resource Management MRM/M2M Products 2177 Salk Ave, STE 200 Carlsbad, CA 92008 PH: (760) 438-9010 – Fax: (760) 438-5835 September 9, 2015 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Re: FCC ID: APV-4230CBT M/N: LMU4230CV, LMU4231CV Dir Sir and Madam, The LMU4230CV and LMU4231CV are fleet management and tracking device that resides in private, it is a single box enclosure incorporating a processor, a GPS receiver, a wireless data modem, vehicle-rated power supply and Vehicle bus interface. The LMU4230CV and LMU4231CV are electrically identical. The products do not support data transfer to or from a computer via cable connection during normal operation mode. The LMU4230CV also supports inputs and outputs to monitor and react to the vehicular environment and/or driver actions. The LMU4230H contains the same BT radios already certified by TUV under model: LMU30H30BT3 with FCC ID: APV-3030HBT and IC ID: 5843C-3030HBT Sincerely, Product Certification Manager Imad Rizk Phone number: (760) 814-9697 Email: [email protected]
AER C E P T D A T A R A D I O L A N D C E L L O M E G A S M A R T L I N K w w w . c a l a m p . c o m CalAmp / Mobile resource Management MRM/M2M Products 2177 Salk Ave, STE 200 Carlsbad, CA 92008 PH: (760) 438-9010 – Fax: (760) 438-5835 September 9, 2015 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Re: FCC ID: APV-4230CBT M/N: LMU4230CV, LMU4231CV Dir Sir and Madam, The LMU4230CV, LMU4231CV are fleet management and tracking device that resides in private, it is a single box enclosure incorporating a processor, a GPS receiver, a wireless data modem, vehicle-rated power supply and Vehicle bus interface. The LMU4230CV and LMU4231CV are electrically identical. The LMU4230CV also supports inputs and outputs to monitor and react to the vehicular environment and/or driver actions. The LMU4230H contains the same BT radios already certified by TUV under model: LMU30H30BT3 with FCC ID: APV-3030HBT and IC ID: 5843C-3030HBT Sincerely, Product Certification Manager Imad Rizk Phone number: (760) 814-9697 Email: [email protected]
TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 TÜV SÜD America Inc. (San Diego) September 21, 2015 TUV SUD BABT Octagon House, Concorde Way Segensworth Rd N, Fareham PO15 5RL RE: FCC ID: APV-4230CBT Company Description of GSM850/1900 technology Model # Report No. Telit Communications S.p.A. CDMA (Cellular and PCS bands) CE910-DUAL NK-12-R-098 CalAmp Wireless Networks Corp. Bluetooth Classic LMU30H30BT3 SC1409996A CalAmp Wireless Networks Corp. Bluetooth LE LMU30H30BT3 SC1409996B SUMMARY OF MEASUREMENT Current FCC Part 2, 22 and 24 rules Verdict Transmitter Conducted Output Power 2.1046 Compliant Effective Radiated Power (ERP) 22.913(a)(2), 2.1046 Compliant Equivalent Isotropic Radiated Power (EIRP) 24.232(c), 2.1046 Compliant Occupied Bandwidth 2.1049, 22.917(b), 24.238(b) Compliant Peak-Average Ratio 24.232(d) Compliant Band Edge/Conducted Spurious Emissions 2.1051, 22.917(a), 24.238(a) Compliant Field Strength of Spurious Radiation 2.1053, 22.917(a), 24.238(a) Compliant Frequency Stability 2.1055, 22.355, 24.235 Compliant CDMA (Cellular and PCS bands) TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 TÜV SÜD America Inc. (San Diego) SUMMARY OF MEASUREMENT Current FCC Part 15.247 Verdict Carrier Frequency Separation 15.247(a)(1) Compliant Number of Hopping Frequencies 15.247(a)(1)(iii) Compliant Time of Occupancy (Dwell Time) 15.247(a)(1)(iii) Compliant 20 dB Bandwidth 15.215(c) Compliant Peak Output Power 15.247(b)(1) Compliant Band-Edge Compliance of RF Conducted Emissions 15.247(d) Compliant Spurious Radiated Emissions 15.247(d) Compliant Radiated Immediate Restricted Bands 15.247(d) Compliant Bluetooth Classic SUMMARY OF MEASUREMENT Current FCC Part 15.247 Verdict Peak Output Power 15.247(b)(3) Compliant Minimum 6dB RF Bandwidth 15.247(a)(2) Compliant Band-Edge Compliance of RF Conducted Emissions 15.247(d) Compliant Spurious Radiated Emissions 15.247(d) Compliant Radiated Immediate Restricted Bands 15.247(d) Compliant Power Spectral Density for Digitally Modulated Device 15.247(e) Compliant Bluetooth LE By my signature below, I attest that the supplied test report above mentioned are representative and applicable for this product and meet the current version of FCC rules. Sincerely, Alex Chang EMC/Wireless Test Engineer
FCC ID: APV-4230CBT Report No.: SD72107926-0715 Model: LMU4230CV FCC ID: APV-4230CBT Report No.: SD72107926-0715 Model: LMU4230CV FCC ID: APV-4230CBT Report No.: SD72107926-0715 Model: LMU4230CV FCC ID: APV-4230CBT Report No.: SD72107926-0715 Model: LMU4231CV FCC ID: APV-4230CBT Report No.: SD72107926-0715 Model: LMU4231CV
FCC ID: APV-4230CBT Report No.: SD72107926-0715 ID Label for LMU4230CV ID Label for LMU4231CV FCC ID: APV-4230CBT Report No.: SD72107926-0715 Label Location
Test Report No.: NK-12-R-098 FCC and IC Certification Telit Communications S.p.A. FCC ID: RI7CE910-DUAL / IC: 5131A-CE910DUAL Page 51 of 52 ● Inside View of EUT without Shield
FCC ID: APV-4230CBT Report No.: SD72107926-0715 FCC ID: APV-4230CBT Report No.: SD72107926-0715 FCC ID: APV-4230CBT Report No.: SD72107926-0715 FCC ID: APV-4230CBT Report No.: SD72107926-0715
TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 August 14, 2105 TUV SUD BABT Octagon House, Concorde Way Segensworth Rd N, Fareham PO15 5RL Attention: Director of Certification RE: Analysis of RF Exposure for Portable use per Title 47, Part 1 Subpart I, §1.1310, Title 47, Part 2 Subpart J, §2.1091 and RSS-102 Issue 4 March 2010. FCC ID: APV-4230CBT 1. Mobile MPE Calculation Summary using a 20cm separation distance: Mode Output Power Antenna Gain Power Density (mW/m 2 ) Cellular 24.65 dBm @ 824.7 MHz 5.12 dBi 0.1887 PCS 24.44 dBm @ 1908.75 MHz 6.12 dBi 0.2263 Bluetooth 100.4 dBμV/m @ 3 meters 0 dBi 0.00065441 Bluetooth LE 86.6 dBμV/m @ 3 meters 0 dBi 0.00002728 2. Co-Located Transmitters transmission table: Transmitter type Transmitter type that can transmit at the same time Cellular Bluetooth Cellular Bluetooth LE PCS Bluetooth PCS Bluetooth LE Bluetooth Cellular Bluetooth LE Cellular Bluetooth PCS Bluetooth LE PCS 3. Simultaneous Transmission MPE (Worst Case Combination): Transmitter type MPE (mw/cm 2 ) Limit (mW/cm 2 ) MPE ratio (MPE/Limit) Cellular/PCS 0.2263 1.0 0.2263 Bluetooth 0.00065441 1.0 0.00065441 Sum of the ratios (should be <1.0) 0.22695441 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 4. Mobile MPE Calculation using a 20cm separation distance (Cellular): Using Power Density formula: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to isotropic R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 24.65 (dBm) Maximum peak output power at antenna input terminal: 291.74 (mW) Antenna gain(typical): 5.12 (dBi) Maximum antenna gain: 3.251 (numeric) Prediction distance: 20 (cm) Sourse Based Time Average Duty Cycle: 100 (%) Prediction frequency: 824.7 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 0.550 (mW/cm 2 ) Power density at prediction frequency: 0.1887 (mW/cm 2 ) Power density at prediction frequency: 1.887 (W/m 2 ) Margin of Compliance: -4.64 (dB) 5. Mobile MPE Calculation using a 20cm separation distance (PCS): Maximum peak output power at antenna input terminal: 24.44 (dBm) Maximum peak output power at antenna input terminal: 277.97 (mW) Antenna gain(typical): 6.12 (dBi) Maximum antenna gain: 4.093 (numeric) Prediction distance: 20 (cm) Sourse Based Time Average Duty Cycle: 100 (%) Prediction frequency: 1908.75 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.000 (mW/cm 2 ) Power density at prediction frequency: 0.2263 (mW/cm 2 ) Power density at prediction frequency: 2.263 (W/m 2 ) Margin of Compliance: -6.45 (dB) TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 6. Mobile MPE Calculation using a 20cm separation distance (Bluetooth): Measured Field Strength --Radiated: 100.4 (dBuV/m) Maximum peak output power --Radiated: 0.0032894 (W) Antenna gain(typical): 0.00 (dBi) Maximum antenna gain: 1.00 (numeric) Prediction distance: 20.00 (cm) Prediction frequency: 319.00 (MHz) Limit from table below: 1 (mW/cm 2 ) Power density at prediction frequency: 0.00065441 (mW/cm 2 ) Margin of Compliance: -31.84 (dB) 7. Mobile MPE Calculation using a 20cm separation distance (Bluetooth LE): Measured Field Strength --Radiated: 86.6 (dBuV/m) Maximum peak output power --Radiated: 0.0001371 (W) Antenna gain(typical): 0.00 (dBi) Maximum antenna gain: 1.00 (numeric) Prediction distance: 20.00 (cm) Prediction frequency: 319.00 (MHz) Limit from table below: 1 (mW/cm 2 ) Power density at prediction frequency: 0.00002728 (mW/cm 2 ) Margin of Compliance: -45.64 (dB) *Notes: Power level and worst case channel information for the cellular radio were derived from the test reports of the original filing, reference Test Report #: NK-12-R-098 from Nemko Korea Co., Ltd. provided by the client. And for Bluetooth FHSS and Bluetooth LE were derived from the test reports of the original filing, reference Test Reports # SC1409996A and SC1409996B from TUV SUD America. Sincerely, Alex Chang Name Authorized Signatory Title: EMC/Wireless Test Engineer
Report No. SC1409996A October 2014 America Report On Application for Grant of Equipment Authorization of the CalAmp Wireless Networks Corp. LMU-3030 Tracking Unit with OBD-II Interface FCC Part 15 Subpart C §15.247 IC RSS-210 Issue 8 December 2010 FCC ID APV-3030HBT IC: 5843C-3030HBT Report No. SC1409996A Page 2 of 91 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 REPORT ON TEST REPORT NUMBER PREPARED FOR Radio Testing of the CalAmp Wireless Networks Corp. Tracking Unit with OBD-II Interface SC1409996A CalAmp Wireless Networks Corp. 1401 N Rice Ave. Oxnard, CA 93030 CONTACT PERSON Imad Rizk Carrier & Product Certifications Manager (805) 987-9000 [email protected] PREPARED BY Ferdinand S. Custodio Name Authorized Signatory Title: EMC/Wireless Test Engineer APPROVED BY Chip R. Fleury Name Authorized Signatory DATED October 14, 2014 FCC ID APV-3030HBT IC: 5843C-3030HBT Report No. SC1409996A Page 3 of 91 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Revision History SC1409996A CalAmp Wireless Networks Corp. LMU-3030 Tracking Unit with OBD-II Interface DATE OLD REVISION NEW REVISION REASON PAGES AFFECTED APPROVED BY 10/14/2014 Initial Release Chip R. Fleury FCC ID APV-3030HBT IC: 5843C-3030HBT Report No. SC1409996A Page 4 of 91 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 CONTENTS Section Page No 1 REPORT SUMMARY ............................................................................................................................... 5 1.1 Introduction ................................................................................................................................................ 6 1.2 Brief Summary Of Results ........................................................................................................................... 7 1.3 Product Information ................................................................................................................................... 8 1.4 EUT Test Configuration ............................................................................................................................. 10 1.5 Deviations From The Standard ................................................................................................................. 12 1.6 Modification Record ................................................................................................................................. 12 1.7 Test Methodology ..................................................................................................................................... 12 1.8 Test Facility Location ................................................................................................................................. 12 1.9 Test Facility Registration ........................................................................................................................... 13 2 TEST DETAILS ...................................................................................................................................... 14 2.1 Conducted Emissions ................................................................................................................................ 15 2.2 Carrier Frequency Separation ................................................................................................................... 16 2.3 Number Of Hopping Frequencies ............................................................................................................. 18 2.4 Time Of Occupancy (Dwell Time) .............................................................................................................. 20 2.5 20 dB Bandwidth ....................................................................................................................................... 28 2.6 99% Emission Bandwidth .......................................................................................................................... 39 2.7 Peak Output Power ................................................................................................................................... 50 2.8 Band-Edge Compliance Of Rf Conducted Emissions ................................................................................. 61 2.9 Spurious Rf Conducted Emissions ............................................................................................................. 68 2.10 Spurious Radiated Emissions .................................................................................................................... 69 2.11 Radiated Immediate Restricted Bands ..................................................................................................... 79 2.12 Receiver Spurious Emissions ..................................................................................................................... 83 3 TEST EQUIPMENT USED ...................................................................................................................... 84 3.1 Test Equipment Used ................................................................................................................................ 85 3.2 Measurement Uncertainty ....................................................................................................................... 86 4 DIAGRAM OF TEST SETUP ................................................................................................................... 87 4.1 Test Setup Diagram ................................................................................................................................... 88 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................................... 90 5.1 Accreditation, Disclaimers and Copyright ...................................................................…
Text truncated - open the document above for the full version.
FCC ID: APV-4230CBT Report No.: SD72107926-0715 Test Setup Photo Below 1GHz Front and Back for model LMU4230CV (unintentional) FCC ID: APV-4230CBT Report No.: SD72107926-0715 Test Setup Photo Above 1GHz Front and Back for model LMU4230CV (unintentional) FCC ID: APV-4230CBT Report No.: SD72107926-0715 Test Setup Photo Below 1GHz Front and Back for model LMU4231CV (unintentional) FCC ID: APV-4230CBT Report No.: SD72107926-0715 Test Setup Photo Above 1GHz Front and Back for model LMU4231CV (unintentional) FCC ID: APV-4230CBT Report No.: SD72107926-0715 Test Setup Photo Below 1GHz Front and Back model LMU4231CV as represented sample (intentional) FCC ID: APV-4230CBT Report No.: SD72107926-0715 Test Setup Photo Above 1GHz Front and Back model LMU4231CV as represented sample (intentional)
