AX2NX603Car Navigation

This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device. Le présent appareil est conforme aux la partie 15 des règles de la FCC et CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping the radiator at least 20cm or more away from person’s body (excluding extremities: hands, wrists, feet and ankles). Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles les radioélectriques (RF) de la FCC lignes directrices d'exposition dans le Supplément C à OET65 et d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet une énergie RF très faible qui est considérée conforme sans évaluation de l’exposition maximale autorisée. Cependant, cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre le dispositive rayonnant et le corps (à l’exception des extrémités : mains, poignets, pieds et chevilles). FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

Owner’s manualNX603FX503DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION & 6.2-INCH TOUCH PANEL CONTROLMULTIMEDIA STATION & 6.2-INCH TOUCH PANEL CONTROL Thank you for purchasing the Clarion NX603 or FX503. ● Please read this owner ’ s manual thoroughly before operating this equipment. ● After reading this manual, be sure to keep it on hand for future reference. ● Check the contents of the enclosed warranty card and keep it carefully with this manual. ● The provided disc (CD-ROM manual) cannot be played back on this unit. In particular, read the descriptions in “To Ensure Safe Use.” This describes cautions to ensure safe use of the unit without inflicting harm or damage on yourself or others. p P. 3 ● The content of this manual may differ in part with that of the actual product due to modifications, etc. to the specifications. ● The content of this manual may be changed in part without notice. When transferring or reselling the unit or disposing of it, delete (initialize) all data saved on it to protect your personal information and copyright protection. ■ Meanings of Symbols Used in This Manual WARNING Preparations This indicates the possibility that failure to follow this instruction might lead to death or serious injury. This explains what must be done beforehand to operate the product. CAUTION Notice This explains things that may cause injury if instructions are not followed. This explains limitations related to operations. Attention MEMO Though this does not fall under the category of “WARNING” or “CAUTION”, this indicates that there is the danger of money or time being lost. This explains supplementary information for mastering use of the unit. CLARION PRODUCT REGISTRATION INFORMATION For USA and Canada only www .clarion.com Dear Customer:Congratulations on your purchase of a Clarion mobile electronic product. We areconfident that you’ll enjoy your Clarion experience.There are many benefits to registering your product. We invite you to visit our website atwww .clarion.com to register your Clarion product. We have made product registration simple with our easy to use website. The registrationform is short and easy to complete. Once you’re registered, we can keep you informed ofimportant product information.Register at www .clarion.com - it’s easy to keep your Clarion product up to date. INFORMATIONS DE L’ENREGISTREMENT DE PRODUITS CLARION Pour les Étas Unis et le Canada seulement www .clarion.com Cher client:Nous vous remercions d’avoir acheté ce produit électronique mobile Clarion. Nous sommesconfiants que vous apprécierez votre expérience Clarion.Il y a beaucoup d’avantage à enregistrer votre produits. Nous vous invitons à visiter notre siteWeb www .clarion.com pour enregistrer votre produit Clarion. Nous avons facilité la tache d’enregistrement de pr oduit simple et facile grâce à notre site Web. Le formulaire d’enregistrement est court et facile à compléter. Lorsque vous êtes enregistrer,nous pouvons vous tenir informé des informations important de produits.Enregistrer à www .clarion.com - c’est facile de mettre à jour votre produit Clarion. INFORMACIÓN DEL REGISTRO DE PRODUCTO DE CLARION Para USA y Canada nomas www .clarion.com Querido Cliente:Felicitaciones por su compra de producto electrónico móvil de Clarion. Estamos seguros queusted gozará de su experiencia con el producto de Clarion.Hay muchas ventajas al registrar su producto. Le invitamos a que visite nuestro sitio en internet www .clarion.com para registrar su producto de Clarion. Hemos hecho el registro de producto fácil en nuestr o sitio. La forma de registro es corta y fácil de completar. Una vez que lo registre, podremos proporcionarle la información de su producto. Registrese en www .clarion.com - es fácil mantener su producto de Clarion actualizado. NX603/FX503 1 English ■ Hard buttons and touch keys In operation descriptions in this manual, hard buttons on the main unit are indicated by dotted frames as the example shown below.Example: MENU The unit uses a touch panel system that you can operate simply by touching the screen with your fingertip.In this manual, operations performed by touching keys on screen are indicated by the grayed out keys as the example shown below.Example: Tuner NX603 Hard button Touch key FX503 Touch key Hard button To Ensure Safe Use ........................ 3 Symbols relating to safety .................. 3 WARNING....................................... 3 CAUTION ....................................... 4 Request and Notice ........................ 4 Before Starting Operations ............ 5 Features available on the unit ............ 5 Expanding Systems ........................... 5 PRECAUTIONS .............................. 6 Operation Panel/Generalities ............... 6 Names and functions of parts ............ 7 Basic method of use ..................... 9 Turning the power on ........................ 9 How to use menus ........................... 9 Using the shortcut menu .................. 9 How to enter text ........................... 9 Operating lists ................................. 9 Moving between pages in a list ............ 9 Using the index to select a list ............... 9 Adjusting numerical values .................. 10 Inserting and removing discs (NX603 only) ....................................... 10 How to insert discs.............................. 10 How to remove discs ........................... 10 Inserting and removing the microSD card (NX603) ................................. 10 How to insert the microSD card ............ 10 How to remove the microSD card ......... 10 Inserting and removing the microSD card (FX503) .................................... 10 How to insert the microSD card ............ 10 How to remove the microSD card ......... 10 Adjusting the audio volume ............ 11 Switching the display screen (NX603 only) ....................................... 11 Switching to the audio screen ............... 11 Switching to the map screen ............... 1…

Text truncated - open the document above for the full version.

Letter of Agency Date: May 30, 2013 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan FCC ID: AX2NX603 To Whom It May Concern: Please be advised Clarion Co., Ltd. authorizes Yoshinobu Asai of Application Section, WiSE Japan, UL Verification Service, UL Japan, Inc. to act on our behalf, until otherwise notified, for applications submitted for Federal Communication Commission Radio equipment applications submitted to UL Japan, Inc. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. The application for the subject equipment has not been submitted to another TCB for certification. Thank you for your attention to this matter. Sincerely, Masahiko Shibata Experimental Evaluation Dept. Clarion Co., Ltd.

Request for Confidentiality Date: May 30, 2013 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan RE: Certification Application FCC ID: AX2NX603 Please be advised that the following information is to be held confidential on behalf of Clarion Co., Ltd., referring to the FCC rules 0.457 and 0.459: Schematics Diagram Block Diagram Theory of Operation The application contains technical information which Clarion Co., Ltd. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, Masahiko Shibata Experimental Evaluation Dept. Clarion Co., Ltd.

QY-1010U-A External Photos External PhotosExternal Photos External Photos NX603 Front View NX603 Rear View Radio Antenna GPS Antenna Clarion Confidential1/3 QY-1010U-A External Photos External PhotosExternal Photos External Photos NX603 Right side View NX603 Left side View Clarion Confidential2/3 QY-1010U-A External Photos External PhotosExternal Photos External Photos NX603 Top View NX603 Bottom View Clarion Confidential3/3

JAPAN 530-1710kHz87.9-107.9MHz THIS DEVICE COMPLIES WITH DHHS RULES 21 CFR CHAPTER I SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE. This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a license from MSLG P. MANU FACTURED: NCL 276-1168-00 QY-1010U-A IC: 419C-NX603 Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. FCC ID:AX2NX603 Bluetooth QD ID No.: B020554 65 mm 65 mm NX603 CLARION CO.,LTD. 7-2,SHIN TOSHIN,CHUO-KU,SAITAMA-SHI,SAITAMA-KEN,JAPAN This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s).Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,including ineterference that may cause undesired operation of this device. Le presnt appareil est conforme aux la partie 15 des regles de la FCC et CNR d’lndustrie Canada applicables aux appareils radio exempts de licence.L’exploitation est autorisee aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage,et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi,meme si le brouillage est susceptible d’en compromettre le fonctionnement 6 NX603/FX503 English PRECAUTIONS WARNING s฀ For your safety, the driver should not watch the DVD video/movie data or operate the controls while driving. Please note that watching and operating the DVD video/movie data while driving are prohibited by law in some countries. Also, while driving, keep the volume to a level at which external sounds can be heard. 1. When the inside of the car is very cold and the player is used soon after switching on the heater, moisture may form on the disc (DVD/CD) or the optical parts of the player and proper playback may not be possible. If moisture forms on the disc (DVD/CD), wipe it off with a soft cloth. If moisture forms on the optical parts of the player, do not use the player for about one hour. The condensation will disappear naturally allowing normal operation. 2. Driving on extremely bumpy roads which cause severe vibration may cause the sound to skip. 3. This unit uses a precision mechanism. Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts. 4. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to consult the dealer or an experienced radio/TV technician for help. 5. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. n INFORMATION FOR USERS: CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BY THE MANUFACTURER WILL VOID THE WARRANTY AND WILL VIOLATE FCC APPROVAL. NX603FX503 Operation Panel/GeneralitiesFor a longer service life, be sure to read the following cautions. l Do not allow any liquids on the set from drinks, umbrellas, etc. Doing so may damage the internal circuitry. l Do not disassemble or modify the set in any way. Doing so may result in damage.Also, subjecting the operation panel to shocks may result in breakage, deformation, or other damage. l Do not let cigarettes burn the display. Doing so may damage or deform the cabinet. l If a problem should occur, have the set inspected at your store of purchase. l The optional remote control unit may not work if the remote control sensor is exposed to direct sunlight. l In extremely cold weather, the display movement may slow down and the display may darken, but this is not a malfunction. The display will work normally when the temperature increases. l Small black and shiny spots inside the operation panel are normal for LCD products. l The touchkeys on the display operate when slightly touched. Do not press the touchkey screen with much force. l Do not push the case surrounding the touchkey panel with much force. This may cause malfunctioning of the touchkeys.

QY-1010U-A Internal Photos Internal PhotosInternal Photos Internal Photos <NX603 Internal> Clarion Confidential1/3 QY-1010U-A Internal Photos Internal PhotosInternal Photos Internal Photos <Bluetooth RF Antenna on CPU PCB Assy F2 layer> Bluetooth Bluetooth Bluetooth Bluetooth RF Antenn RF AntennRF Antenn RF Antenna aa a Clarion Confidential2/3 QY-1010U-A Internal Photos Internal PhotosInternal Photos Internal Photos <Bluetooth part on CPU PCB ASSY F1 layer> <Bluetooth part> Bluetooth Bluetooth Bluetooth Bluetooth part partpart part Clarion Confidential3/3

UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Applicant: Clarion Co., Ltd. T ype of Equipment : Car Navigation M odel No. : NX603 FCC ID: AX2NX603 Clarion Co., Ltd. declares that M odel : Car Navigation complies with FCC radiation exposure requirement specified in the FCC Rules 2.1091. The “NX603“ has 1.01 mW of conducted Peak O utput power and 0.22 mW of EIR P. This kind of equipment is below SAR Threshold (KDB447498 D01 v05) The Following calculation is the reference data for 20cm distance. RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the “NX603“ as calculated from FCC OET Bulletin 65 Appendix A, Table (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0mW/cm^2 uncontrolled exposure limit. The Friis formula used was: S = (P * G) / (4* π * r 2 ) Where P = 1.01 mW (M aximum peak output power) G = 0.22 Numerical Antenna gain; equal -6.60 dBi r =20.0 cm For: NX603S = 0.00004mW/cm 2 No. : 10003129S-A RF Ex posure / SAR Statement

Test report No. : 10003129S-A Page : 2 of 51 Issued date : May 24, 2013 FCC ID : AX2NX603 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 REVISION HISTORY Original Test Report No.: 10003129S-A Revision Test report No. Date Page revised Contents - (Original) 10003129S-A May 24, 2013 - - Test report No. : 10003129S-A Page : 3 of 51 Issued date : May 24, 2013 FCC ID : AX2NX603 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Contents Page SECTION 1: Customer information ..................................................................................... 4 SECTION 2: Equipment under test (E.U.T.) ....................................................................... 4 SECTION 3: Test specification, procedures & results ......................................................... 5 SECTION 4: Operation of E.U.T. during testing ................................................................. 8 SECTION 5: Carrier frequency separation ........................................................................ 11 SECTION 6: 20dB bandwidth & Occupied bandwidth (99%) ......................................... 11 SECTION 7: Number of hopping frequency ...................................................................... 11 SECTION 8: Dwell time ...................................................................................................... 11 SECTION 9: Maximum peak output power ...................................................................... 11 SECTION 10: Spurious emissions (Antenna port conducted) ........................................... 11 SECTION 11: Radiated emission........................................................................................ 12 Contents of APPENDIXES ................................................................................................... 14 APPENDIX 1: Data of Radio tests ...................................................................................... 15 APPENDIX 2: Test instruments ......................................................................................... 50 APPENDIX 3: Photographs of test setup ........................................................................... 51 Test report No. : 10003129S-A Page : 4 of 51 Issued date : May 24, 2013 FCC ID : AX2NX603 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 SECTION 1: Customer information Company Name : Clarion Co., Ltd. Address : 7-2 Shintoshin, Chuo-ku, Saitama-shi, Saitama, 330-0081 Japan Telephone Number : +81-48-601-3602 Facsimile Number : +81-48-601-3802 Contact Person : Matsuhiro Hirano SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Car Navigation Model Number : NX603 Serial Number : Refer to 4.2 in this report. Rating : DC12V Country of Mass-production : Japan Condition of EUT : Engineering prototype (Not for Sale: This sample is equivalent to mass-produced items.) Receipt Date of Sample : April 16, 2013 Modification of EUT : No modification by the test lab. 2.2 Product description Model: NX603 (referred to as the EUT in this report) is a Car Navigation. Clock frequency(ies) in the system : 41.6MHz (Xtal), 333MHz (DDR3) Radio specification: Equipment type : Transceiver Frequency of operation : 2402-2480MHz Bandwidth & Channel spacing : 79MHz & 1MHz Type of modulation : GFSK, π/4DQPSK, 8DPSK Antenna type : Pattern Antenna gain : -6.6dBi Antenna connector type : None ITU code : F1D Operation temperature range : -20 to +60 deg.C FCC 15.31 (e) The EUT provides stable voltage (DC3.3V) constantly to the wireless transmitter regardless of input voltage. Therefore, this EUT complies with the requirement. FCC 15.203 The antenna is not removable from the EUT. Therefore the equipment complies with the requirement. Test report No. : 10003129S-A Page : 5 of 51 Issued date : May 24, 2013 FCC ID : AX2NX603 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 SECTION 3: Test specification, procedures & results 3.1 Test specification Test specification : Test specification: FCC Part 15 Subpart C: 2012, final revised on December 27, 2012 and effective January 28, 2013 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.207 Conducted limits Section 15.209 Radiated emission limits, general requirements Section 15.247 Operation within the bands 902-928MHz, 2400-2483.5MHz, and 5725-5850MHz The EUT has been tested for compliance with FCC Part 15 Subpart B. Refer to the test report: 10003129S-C. 3.2 Procedures & Results Item Test Procedure Specification Remarks DeviationWorst Margin Results Conducted emission ANSI C63.4:2009 7. AC powerline conducted emission measurements FCC 15.207 - N/A *1) N/A N/A Carrier frequency separation FCC Public Notice DA 00-705 & ANSI C63.4:2009 13. Measurement of intentional radiators FCC 15.247 (a)(1) ConductedN/A *See data. Complied 20dB bandwidth FCC Public Notice DA 00-705 & ANSI C63.4:2009 13. Measurement of intentional radiators FCC 15.247 (a)(1) ConductedN/A - Number of hopping frequency FCC Public Notice DA 00-705 & ANSI C63.4:2009 13. Measurement of intentional radiators FCC 15.247 (a)(1)(iii) ConductedN/A Complied Dwell time FCC Public Notice DA 00-705 & ANSI C63.4:2009 13. Measurement of intentional radiators FCC 15.247 (a)(1)(iii) ConductedN/A Complied Maximum peak output power FCC Public Notice DA 00-705 & ANSI C63.4:2009 13. Measurement of intentional radiators FCC 15.247 (b)(1) ConductedN/A Complied Band edge compliance & Spurious emission FCC Public Notice DA 00-705 & ANSI C63.4:2009 13. Measurement of intentional radiators FCC 15.247 (d) 15.209 Conducted/ Radia…

Text truncated - open the document above for the full version.
