AY5PS3DModel PS3D Handset

Exhibit 3 Photograph 1 shows the outside front view. Photograph 2 shows the outside back view.

Content of FCC label Installation of this equipment is subject to notification and coordination with UTAM, Inc. Any relocation of this equipment must be coordinated through, and approved by UTAM. UTAM may be contacted at (800) 429-8826. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID AY5PS3D Canada No. Caution – To reduce risk of fire replace only with Sanyo Electric Co., Ltd Type 1UF812248-TO Remove a battery cover FCC label

Exhibit 9 Photograph 1 shows the keyboard and display. Photograph 2 shows the component side of the PC board.

SAR EVALUATION CERTIFICATE OF COMPLIANCE FCC ID: AY5PS3D APPLICANT: NEC America Inc. EUT: NEC Model PS3D Handset Date of Receipt:July 21, 2003 Device Category:Part 15 C RF exposure environment:Uncontrolled RF exposure category:Portable Power supply:Powered by Battery and AC/DC adaptor Antenna:Integrated Antenna Production/prototype:Identical Prototype Measured Standards:Oet 65 Supplement C Modulation:TDMA Crest Factor:8 TX Range:1920.35 – 1929.65 MHz RX Range:1920.35 – 1929.65 MHz Used TX Channels:Low: ch.1 1920.35 MHzCenter: ch 10 1924.55MHzHigh: ch20 1929.65MHz Maximum RF Power Output:0.026W Conducted (PEP) and 0.04 W EIRP Maximum SAR Measurement (averaged over: 1g) 0.019 W/kg Body Len Knight EMC Lab Manager APPLICANT NAME AND ADDRESS: DATE OF TEST:July 21-22, 2003 NEC America Inc. TEST LOCATION:MET LABORATORIES 6535 N. State Highway 161 914 West Patapsco Ave. Irving, Texas 75039-2402 Baltimore, Maryland 21230 This wireless portable device has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (July 2001), and has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1 - 1992. I attest to the accuracy of this data. All reported measurements were performed by me, or were made under my supervision, and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. I also certify that no party to this application has been denied the FCC benefits pursuant to Section 5.301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. NEC America Inc. Model PS3D Handset July 23, 2003 EMC14132-SARCopyright 2003, MET Laboratories, Inc.Page 2 of 49 July 23, 2003 NEC America Inc. 6535 N. State Highway 161 Irving Texas 75039 - 2402 Reference: Model PS3D Handset Dear Ms. Pat Von Praysing: Enclosed is the EMC SAR Evaluation Report for the NEC Model PS3D Handset was tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C:01-01 and shown to be capable to be in compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in FCC OET 65 Supplement C:01-01. Thank you for using the testing services of MET Laboratories. If you have any questions regarding these results or if MET can be of further assistance to you, please feel free to contact me. We appreciate your business and look forward to working with you again soon. Kindest Regards, MET LABORATORIES, INC. Marianne T. Bosley EMC Administrator Enclosures: DOCTEM-23 Jan 02 Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. The Nation’s First Licensed Nationally Recognized Testing Laboratory NEC America Inc. Model PS3D Handset July 23, 2003 EMC14132-SARCopyright 2003, MET Laboratories, Inc.Page 3 of 49 Dosimetric Assessment Test Report for the NEC America Inc. Model PS3D Handset Tested and Evaluated In Accordance With FCC OET 65 Supplement C:01-01 MET REPORT: EMC14132-SAR July 23, 2003 PREPARED FOR: NEC America Inc. 6535 N. State Highway 161 Irving Texas 75039 - 2402 PREPARED BY: MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, Maryland 21230-3432 NEC America Inc. Model PS3D Handset July 23, 2003 EMC14132-SARCopyright 2003, MET Laboratories, Inc.Page 4 of 49 Dosimetric Assessment TEST REPORT for the NEC America Inc. Model PS3D Handset In Accordance With FCC OET Supplement C: 01-01 Prepared for NEC America Inc. 6535 N. State Highway 161 Irving Texas 75039 - 2402 Report Prepared By Marianne T. Bosley EMC ADMINISTRATOR Report Reviewed By Liming Xu TEST ENGINEER Final Review By EMC LAB MANAGER Len Knight EMC LAB MANAGER Engineering Statement: The measurements shown in this report were made in accordance with the procedures specified in Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [FCC 2001] for uncontrolled exposure. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment evaluated is capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992.  NEC America Inc. Model PS3D Handset July 23, 2003 EMC14132-SARCopyright 2003, MET Laboratories, Inc.Page 5 of 49 Quick Links • Summary of test Report • EUT Description • Test Conditions • Host Laptops Used • System Validation • SAR results summary • SAR Area Scans • Setup Pictures • Measurement System  NEC America Inc. Model PS3D Handset July 23, 2003 EMC14132-SARCopyright 2003, MET Laboratories, Inc.Page 6 of 49 OBJECTIVE The objective of the procedure was to perform a dosimetric assessment one of the TDMA UPCS handset. The measurements have been carried out with the dosimetric assessment system “SARA2", and were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [FCC 2001] for evaluating compliance of mobile and portable devices with FCC limits for human exposure in the general population to radio frequency emissions. INTRODUCTION In the United States, the most recent FCC RF exposure criteria is documented in the publication OET 65 Supplement C Edition 01-01 [FCC 2001], which sets limits for human exposure to radio frequency electromagnetic fields in the frequency range 3kHz to 300GHz. The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Resp…

Text truncated - open the document above for the full version.

Exhibit 6: Test Report TEST REPORT FROM: COMMUNICATION CERTIFICATION LABORATORY 1940 W. Alexander Street Salt Lake City, Utah 84119-2039 Type of Report: Certification TEST OF: PS3D FCC ID: AY5PS3D To Part 15 Subpart D of the FCC Rules and Regulations Test Report Serial No: 73-7889 Applicant: NEC AMERICA, INC. 6535 North State Hwy 161 Irving, TX 75039-2402 Date(s) of Test: July 7 - 10, 2003 Issue Date: July 16, 2003 Equipment Receipt Date: July 7, 2003 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7889 FCC ID: AY5PS3D Page 1 of 72 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Communication Certification Laboratory to evaluate the device described below with the requirements of FCC Part 15, Subpart D. Specific identifying information for the device tested is given below. - Applicant NEC AMERICA, INC. 6535 North State Hwy 161 Irving, TX 75039-2402 - Manufacturer: NEC Corporation 7-1 5 Chome Shiba Minato-Ku Tokyo, 108-01 Japan - Trade Name: NEC - Model Number: PS3D - FCC ID Number: AY5PS3D On this 16 th day of July 2003, I, individually, and for Communication Certification Laboratory, certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. COMMUNICATION CERTIFICATION LABORATORY Tested by: Jeffrey L. Draney EMC Technician COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7889 FCC ID: AY5PS3D Page 2 of 72 SECTION 1 GENERAL INFORMATION 1.1 Product Description The PS3D is the handset (PS) portion of a wireless PBX system. The system consists of a PBX, Wireless Communication system (WCS) (installed inside of the PBX), ZT and handset (PS). The ZT’s are installed throughout the coverage area and hard wired to the base station controller. The user carrier a wireless PS which allows the user access to the PBX functions from any location within the coverage area. This application is for the PS which is identified by FCC ID: AY5PS3D. The ZT portion of the system is unchanged from the original certification identified by FCC ID: AY5SN933WEK. The ZT (MN:SN933 WEK-A) performs all of the channel monitoring and selection functions. The ZT was not changed, and all of the test data on the ZT was taken from the original certification report. This PS is functional the same as a previously certified PS (FCC ID: AY5SN531PSTH); therefore, it can be installed with the previously certified PS’s and will also work with the previously certified ZT’s (FCC ID: AY5SN933WEK). 1.2 Test Specification The PS3D is an Isochronous device that operates in the 1920- 1930 MHz sub-band; therefore the PS3D is subject to the provisions of FCC Part 15, Subpart D. Unlicensed Personal Communications Service Devices. 1.3 Test Methods & Procedures The PS3D was tested in accordance with ANSI C63.17-1998. COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7889 FCC ID: AY5PS3D Page 3 of 72 SECTION 2. SUMMARY OF TEST RESULTS: 2.1 Summary of Tests: FCC Section Description Report Section ANSI C63.17 Section Result 15.307 Affidavit from UTAM, Inc. certifying participation in UTAM, Inc. 3.2.1 N/A Complies 15.309 Cross Reference to Subpart B 3.2.2 6.1.6.3 Complies 15.311 Labelling Requirements 3.2.3 N/A Complies 15.315 AC power line conducted limits 3.2.4 N/A Complies 15.317 Antenna requirement 3.2.5 N/A Complies 15.319 (a) Frequency of operation 3.2.6 N/A Complies 15.319 (b) Modulation technique 3.2.7 6.1.4 Complies 15.319 (c) Peak transmit power and emission bandwidth 3.2.8 6.1.2 Complies 15.319 (d) Power spectral density 3.2.9 6.1.5 Complies 15.319 (e) Directional gain of antenna 3.2.10 N/A Complies 15.319 (f) Automatic discontinuance of transmission 3.2.11 N/A Complies 15.319 (i) IEEE C95.1-1991 and IEEE C95.3-1991 3.2.12 N/A Complies 15.323 (a) Channel allocation 3.2.13 N/A Complies 15.323 (b) Channel packing 3.2.14 8.1.2 Complies COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7889 FCC ID: AY5PS3D Page 4 of 72 FCC Section Description Report Section ANSI C63.17 Section Result 15.232 (c) Time and Spectrum monitoring 3.2.15 Sections 7 and 8 Complies 15.323 (c)(1) Transmit window monitoring 3.2.16 7.3.2.2 7.5 Complies 15.323 (c)(2) Monitoring threshold 3.2.17 7.3.2.1 Complies 15.323 (c)(3) Transmission duration 3.2.18 N/A Complies 15.323 (c)(4) Acknowledgments 3.2.19 8.2.1 8.1.3 Complies 15.323 (c)(5) Least interfered channel 3.2.20 7.3.2.1, 7.3.2.2 8.2.1 Complies 15.323 (c)(6) Random waiting interval 3.2.21 8.1.3 8.2.1 Complies 15.323 (c)(7) Threshold monitoring bandwidth, Threshold monitoring reaction time 3.2.22 7.4 7.5 Complies 15.323 (c)(8) Threshold monitoring antenna 3.2.23 N/A Complies 15.323 (c)(9) Monitoring threshold relaxation 3.2.24 N/A Complies 15.323 (c)(10) Duplex connections 3.2.25 8.2.3 Complies 15.323 (c)(11) Alternative monitoring interval 3.2.26 8.2.4 Complies 15.323 (c)(12) Limitation on use of Section (c)(10) or (c)(11) 3.2.27 N/A Complies 15.323 (d) Spurious emissions 3.2.28 6.1.6 Complies COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7889 FCC ID: AY5PS3D Page 5 of 72 FCC Section Description Report Section ANSI C63.17 Section Result 15.323 (e) Frame repetition stability / frame period and jitter 3.2.29 6.2.3 6.2.4 Complies 15.323 (f) Frequency stability 3.2.30 6.2.2 Complies COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7889 FCC ID: AY5PS3D Page 6 of 72 SECTION 3. MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS: 3.1 General Comments This section contains the test results only. Details of the test methods used, etc., can be found in Appendix A of this report. 3.2 Test Results 3.2.1 Coordination with fixed microwave service § 15.307 Measurement Data: The affidavit from UTAM, Inc. is enclosed in Exhibit 12. 3.2.2 Cross Reference to Subpart B § 15.309 The requirements of Subpart D apply only to the radio transmitter contained in the PCS device. Other aspects of the operation of a PCS device may be subject to requirements contained elsewhere in this Chapter. In particular…

Text truncated - open the document above for the full version.

Exhibit 7 Photograph 1 shows the front view of the radiated test set-up. Photograph 2 shows the back view of the radiated test set-up.
