BEJLN240Cellular/PCS CDMA Phone with Bluetooth

- 1 - User Manual LN240 Ver. 1.1 2009. 09. 24 Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. - 11 - Getting Started Unlocking Your Phone If you received your LN240 in the mail, you may need to unlock it before making calls. 1. Press the END/PWR Switch for 2~3 seconds. 2. Press soft key Unlock. 3. Enter your four-digit lock code. For security purposes, the code will not be visible as you type. Note: If you can’t recall your lock code, try using the last four digits of your Social Security number, the last four digits of your Phone Number or 0000. - 13 - View of Phone 1. END/PWR Switch: Lets you power the phone on or off. 2. Antenna: Retractable antenna provides optimum reception for 800 MHz & 1900 MHz frequencies. 3. Power On Indicator: Illuminates red when the phone powers on or when you receive incoming calls. Flashes red when you have messages of scheduled alarms. 4. Headset Jack: Provides connection for an optional headset. 5. Volume Control Keys: Adjust the Ring Volume in the Main Menu or the Voice Volume during a call. The keys also scroll through mouths in the Calendar or pages in the MiniBrowser. 6. Mouse Key: Allows quick and easy scrolling through the menus. 7. OK: Lets you place a call, receive a call, end a call or select menu options. 8. CLR: Lets you clear an entry or back-up in the menu. 9. Folder : Lets you answer or end calls. ===============page 3 Installing and Removing the Battery To install the battery, insert the bottom of the battery into the openi ng on the back of the phone. Then, push the battery down until the latch clicks. To remove the battery, press down on the latch and remove the battery from the phone. Turning Your Phone On and Off To turn your phone on, move the On/Off Switch ( near the antenna) to the ON position. Y our phone performs a short self-test before letting you know it is operational. If your phone does not turn on, make sure the battery is installed correctly and is ade quately charged or has external power (via the AC Adapter, Cigarette Lighter Adapter or Hands-Free Car Kit). - 14 - To turn your phone off, move the On/Off Switch to the OFF position. Main Menu When your phone acquires Service, the G reeting (a banner of text), the current time and date and the Main Menu are displayed. If you are in authorized analog cellular provider’s service area, you are ready to send and receive calls. Power Save Mode When the phone is in an area without service for 15 minutes, it stops searching for service and enters into the power Save Mode. When your phone activates this feature, Power Save is displayed on your screen. The phone automatically checks for service periodically or you can check manually by pressing any key. - 15 - Menu Navigation The Mouse Key lets you scroll circularly through menus quickly and easily. As you navigate through a menu, the options are highlighted (Highlighted Test Example ) . Select an option by highlighting it and pressing . The scroll bar at the right of the menu keeps track of your position in the menu at all times. For example, if you want to view your last incoming call: 1. From the Main Menu, select RECENT CALLS and press 2. (It may already be highlighted.) 2. Press the Mouse Key down to highlight and press . If you have received any calls, they are displayed on the screen. Entering Characters Using the Keypad(T9) To ent er a let ter, pun ctuation or n umber when c reating P hone Bo ok or S cheduler ent ries, press t he corresponding key until the desired character appears. By default, the first letter of a word is capitalized and following letters are lowercase. Characters in the following order: 1 . ? , ‘ & - @ ( ) / ~ P Q R S 7 p q r s A B C 2 a b c 2 T U V 8 t u v 8 D E F 3 d e f 3 W X Y Z 9 w x y z 9 G H I 4 g h i 4 Next 0 J K L 5 j k l 5 Shift M N O 6 m n o 6 Space Incoming 1 7 PQRS 9WXYZ 8TUV 6MNO 5J 4G 3DEF ABC 1 * 0Space - 16 - After a character is entered, the cursor automatically advances to the next space after two seconds. You can also advance the cursor by pressing or entering a character not on the same key. If you…

Text truncated - open the document above for the full version.

Date December 4 2009 LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LG Electronics Inc. FCC ID: BEJLN240 Part2019Certification Date: December 4, 2009 Part20.19Certification To Whom It May Concern: The following are the model designations and their associated key features for this FCC ID, according to requirement in the TCB Guidance issued on June 20, 2008. FCC ID: BEJLN240 Model(s): LN240, UN240, AN240, VN240, CX240 Air Interfaces: CDMA Wireless Technologies: CDMA 1x/EvDO Bands: CDMA835 / PCS1900 Key Features: MP3 player Camera Bluetooth GPS Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA

Date: December 4, 2009 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJLN240 Part 20.19 Certification Gentlemen: We, LG Electronics USA, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: December 4, 2009 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJLN240 Eq uipment Cl ass: PCE: PCS Licensed Transmitter held to ear To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manage r LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

Model No: LN240 FCC ID : BEJLN240 S/N : Made in Korea LG Electronics Inc. LGE

LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 1 of 13 © 2009 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 2 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 3 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 4 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 5 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 6 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 7 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 8 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 9 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 10 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 11 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 12 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJLN240 Model: LN240 Internal Photos EUT Type: Cellular/PCS CDMA Phone with Bluetooth Page 13 of 13 © 2009 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC ID: BEJLN240 SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0911172131.BEJ 11/17/09 - 11/19/09 Cellular/PCS CDMA Phone with Bluetooth Page 1 of 34 © 2009 PCTEST Engineering Laboratory, Inc. REV 7.0 11/02/09 Applicant Name: Date of Testing: LG Electronics USA 11/17/09 - 11/19/09 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0911172131.BEJ F C C I D : BE J L N2 4 0 AP P L I C AN T : LG E LE CT RO NI CS US A EUT Type: Cellular/PCS CDMA Phone with Bluetooth Application Type: Certification FCC Rule Part(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): LN240, UN240, AN240, VN240, CX240 Tx Frequency: 824.70 - 848.31 MHz (Cellular CDMA) 1851.25 - 1908.75 MHz (PCS CDMA) Conducted Power: 25.19 dBm Cell. CDMA 25.32 dBm PCS CDMA Max. SAR Measurement: 1.22 W/kg Cell. CDMA Head SAR 1.05 W/kg Cell. CDMA Body SAR 1.18 W/kg PCS CDMA Head SAR 0.75 W/kg PCS CDMA Body SAR Test Device Serial No.: Pre-Production [S/N: SAR #1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com SAR COMPLIANCE EVALUATION REPORT Reviewed by: FCC ID: BEJLN240 SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0911172131.BEJ 11/17/09 - 11/19/09 Cellular/PCS CDMA Phone with Bluetooth Page 2 of 34 © 2009 PCTEST Engineering Laboratory, Inc. REV 7.0 11/02/09 T A B L E O F C O N T E N T S 1 INTRODUCTION ..............................................................................................................................3 2 TEST SITE LOCATION ....................................................................................................................4 3 SAR MEASUREMENT SETUP ........................................................................................................5 4 DASY E-FIELD PROBE SYSTEM ...................................................................................................7 5 PROBE CALIBRATION PROCESS .................................................................................................8 6 PHANTOM AND EQUIVALENT TISSUES.......................................................................................9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS....................................................................10 8 DEFINITION OF REFERENCE POINTS .......................................................................................11 9 TEST CONFIGURATION POSITIONS ..........................................................................................12 10 RF EXPOSURE LIMITS .................................................................................................................15 11 MEASUREMENT UNCERTAINTIES .............................................................................................16 12 SYSTEM VERIFICATION...............................................................................................................17 13 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS..........................................................19 14 FCC 3G MEASUREMENT PROCEDURES ...................................................................................20 15 SAR DATA SUMMARY ..................................................................................................................22 16 EQUIPMENT LIST..........................................................................................................................25 17 CONCLUSION................................................................................................................................26 18 REFERENCES ...............................................................................................................................27 19 SAR TEST SETUP PHOTOGRAPHS ............................................................................................29 Reviewed by: FCC ID: BEJLN240 SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0911172131.BEJ 11/17/09 - 11/19/09 Cellular/PCS CDMA Phone with Bluetooth Page 3 of 34 © 2009 PCTEST Engineering Laboratory, Inc. REV 7.0 11/02/09 1 I N T R O D U C T I O N The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz[2] and Health Canada RF Exposure Guidelines Safety Code 6 [26]. The measuremen…
