BGBX1T263IMB11101Low Power Tx below 1.705MHz

Mitsubishi Electric Corp
Low Power Tx below 1.705MHz - FCC ID BGBX1T263IMB11101 - Mitsubishi Electric Corp
Click to zoom

Application Details

Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant
Nov 03, 2004
Application Purpose
Original Equipment
Date of Application
Nov 03, 2004
Equipment Note
Low Power Tx below 1.705MHz
Frequency Range
0.13445000 - 0.13445000
Company
Mitsubishi Electric Corp
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Test Report

Test report No. : 24JE0011-HO-1 Page : 2 of 13 Issued date : October 14 , 2004 FCC ID : BGBX1T263IMB11101 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) CONTENTS PAGE SECTION 1: Client information .................................................................................................................... 3 SECTION 2: Equipment under test (E.U.T.)................................................................................................ 3 SECTION 3: Test specification, procedures & results................................................................................. 4 SECTION 4: Operation of E.U.T. during testing ......................................................................................... 6 SECTION 5: Radiated emission (Fundamental and Spurious Emission and –26dB Bandwidth) ............ 7 APPENDIX 1: Photographs of test setup ...................................................................................................... 8 Spurious Emission (Radiated) ................................................................................................................ 8 Worst Case Position (X-axis:Horizontal / X-axis:Vertical) .................................................................. 9 APPENDIX 2: Test instruments .................................................................................................................. 10 APPENDIX 3: Data of EMI test................................................................................................................... 11 Radiated emission (Fundamental and Spurious Emission) ................................................................11 –26dB Bandwidth and 99% Occupied Bandwidth ............................................................................. 13 Test report No. : 24JE0011-HO-1 Page : 3 of 13 Issued date : October 14 , 2004 FCC ID : BGBX1T263IMB11101 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) SECTION 1: Client information Company Name : Mitsubishi Electric Corporation Himeji Works Address : 840 CHIYODA-MACHI, HIMEJI HYOUGO 670-8677 JAPAN Telephone Number : +81-792-98-8896 Facsimile Number : +81-792-98-9262 Contact Person : Yosiharu Goto SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : The Immobilizer System Model No. : IMB111-01 Serial No. : 20040909 Rating : DC12.0V(Car Battery) Country of Manufacture : Japan Receipt Date of Sample : September 13, 2004 Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) 2.2 Product Description Model No: IMB111-01 (referred to as the EUT in this report) is the Immobilizer System. Clock frequency 4MHz Feature of EUT The Immobilizer System for vehicle (anti-theft device) Equipment Type Transceiver Frequency band Lower limit 131.45kHz Upper limit 137.45kHz Frequency of Operation 134.45kHz Type of Modulation FSK (Frequency Shift Keying) Antenna Type Inductive loop Mode of Operation Simplex Power Supply DC 5.0V (Transformed from DC 12V/Car Battery) Operating temperature range -40deg.C. to +80deg.C. FCC 15.31 (e) The power supply of this EUT is transformed to DC 5V and provides stable voltage (DC5.0V) constantly to Radio part. Therefore, this EUT complies with the requirement. FCC Part 15.203 Antenna requirement Loop Antenna (Tx section) is installed outside the vehicle’s key cylinder and users cannot detach it from vehicle. Therefore, the equipment complies with the antenna requirement of Section 15.203. Test report No. : 24JE0011-HO-1 Page : 4 of 13 Issued date : October 14 , 2004 FCC ID : BGBX1T263IMB11101 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part15 Subpart C : 2004 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.205 Restricted bands of operation : 2004 Section 15.209 Radiated emission limits, general requirements : 2004 3.2 Procedures and results No. Item Test Procedure Specification Remarks Deviation Worst margin Results 1 Electric Field Strength of Fundamental Emission ANSI C63.4:2003 13. Measurement of intentional radiators FCC Section 15.209 Radiated N/A 30.0dB, 134.72kHz, 0 deg., AV Complied 2 Electric Field Strength of Spurious Emission ANSI C63.4:2003 13. Measurement of intentional radiators FCC Section 15.205 FCC Section 15.209 Radiated N/A 2.2dB, 160.351MHz, Horizontal Complied 3 -26dB Bandwidth ANSI C63.4:2003 13. Measurement of intentional radiators N/A Radiated N/A N/A N/A Note: UL Apex’s EMI Work Procedures No.QPM05. Uncertainty: Spurious Emission (Radiated) The measurement uncertainty (with a 95% confidence level) for this test using Biconical antenna is ±4.5dB(3m)/ ±4.7dB(10m). The measurement uncertainty (with a 95% confidence level) for this test using Logperiodic antenna is ±5.2dB(3m)/ ±3.8dB(10m). The measurement uncertainty (with a 95% confidence level) for this test using Horn antenna is ±6.6dB. The result is within Head Office EMC lab’s uncertainty. *These tests were performed without any deviations from test procedure except for additions or exclusions. 3.3 Addition to standards No. Item Test Procedure Specification Remarks Deviation Worst margin Results 1 99 % Occupied Band Width RSS-210(issue 5): 2001 + Amendment:2002 + Amendment2:2003 + Amendment3:2004 RSS-210(issue 5): 2001 + Amendment:2002 + Amendment2:2003 + Amendment3:2004 Radiated N/A N/A Complied Test report No. : 24JE0011-HO-1 Page : 5 of 13 Issued date : October 14 , 2004 FCC ID : BGBX1T263IMB11101 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-…
