BGBX1T458SKE11A01Vehicle Door Lock Transceiver

Test report No. : 24HE0134-HO-1 Page : 1 of 16 Issued date : November 22, 2004 FCC ID : BGBX1T458SKE11A01 Revised Date :December 7, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) EMI TEST REPORT Test Report No. : 24HE0134-HO-1 Applicant : Mitsubishi Electric Corporation Himeji Works Type of Equipment : Smart keyless system (Transceiver) Model No. : SKE11A-01 Test standard : FCC Part 15 2004 Subpart C Section 15.209, Section 15.231 (Certification) FCC Part 15 Subpart B : 2004 Section 15.109 (Verification) FCC ID : BGBX1T458SKE11A01 Test Result : Complied 1. This test report shall not be reproduced in full or partial, without the written approval of UL Apex Co., Ltd. 2. The results in this report apply only to the sample tested. 3. This equipment is in compliance with above regulation. We hereby certify that the data contain a true representation of the EMC profile. 4. The test results in this report are traceable to the national or international standards. Date of test: November 2, 5 and 19, 2004 . Tested by: _____________________ _____________________ Yutaka Yoshida Norihisa Hashimoto EMC Service EMC Service Approved by : ______________________________ Naoki Sakamoto Group Leader of EMC Service Test report No. : 24HE0134-HO-1 Page : 2 of 16 Issued date : November 22, 2004 FCC ID : BGBX1T458SKE11A01 Revised Date :December 7, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) CONTENTS PAGE SECTION 1: Client information...............................................................................................3 SECTION 2: Equipment under test (E.U.T.) ..........................................................................3 SECTION 3: Test specification, procedures & results ...........................................................4 SECTION 4: Operation of E.U.T. during testing....................................................................6 SECTION 5: Radiated emission (Fundamental and Spurious Emission) ............................8 APPENDIX 1: Photographs of test setup.................................................................................9 Radiated emission(Worst case position) ............................................................................9 Worst Case Position (Horizontal : X-axis/ Vertical: Y-axis)..........................................10 APPENDIX 2:Test Instruments...............................................................................................12 APPENDIX 3: Data of EMI test ..............................................................................................13 Radiated Emission (Electric Field Strength of Fundamental and Spurious Emission)13 -20dB Bandwidth and 99% Occupied Bandwidth ..........................................................15 Automatically deactivate ...................................................................................................16 Test report No. : 24HE0134-HO-1 Page : 3 of 16 Issued date : November 22, 2004 FCC ID : BGBX1T458SKE11A01 Revised Date :December 7, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) SECTION 1: Client information Company Name : Mitsubishi Electric Corporation Himeji Works Address : 840 CHIYODA-MACHI HIMEJI HYOUGO 670-8677 JAPAN Telephone Number : +81-792-98-8896 Facsimile Number : +81-792-98-9262 Contact Person : Yoshiharu Goto SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Smart keyless system (Transceiver) Model No. : SKE11A-01 Serial No. : 3 (For Radiated Emission; Transmitter Fundamental and Spurious Emission only), 4 (For other test) Country of Manufacture : Japan Receipt Date of Sample : October 15, 2004 Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) 2.2 Product Description Model No: SKE11A-01 is the Smart keyless entry system. The clock frequency of EUT is 5MHz(CPU). Equipment Type : Transceiver Frequency operation : 315MHz(Transmitter), 132.45kHz(Receiver) Type of modulation : FSK(Frequency shift keying) Mode of operation : Simplex Antenna Type : Pattern Antenna (Transmitter)/ Inductive loop (Receiver) Method of Frequency Generation : SAW RESONATOR (Transmitter) Synthesizer (Receiver) Power Supply : DC 3.0V Temperature of operation : -40 deg.C. – 85deg.C. FCC 15.31 (e) This test was performed with the New Battery (DC 3.0V) and the constant voltage was supplied to this EUT during the tests. Therefore, this EUT complies with the requirement. FCC Part 15.203 Antenna requirement It is impossible for end users to replace the antenna, because the antenna is mounted inside of the EUT. Therefore, the equipment complies with the antenna requirement of Section 15.203. Test report No. : 24HE0134-HO-1 Page : 4 of 16 Issued date : November 22, 2004 FCC ID : BGBX1T458SKE11A01 Revised Date :December 7, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part 15 Subpart C 2004 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.231 Periodic operation in the band 40.66 - 40.70MHz and above 70MHz Test Specification : FCC Part 15 Subpart B : 2004 Title : FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators Section 15.109 Radiated emission limits 3.2 Procedures and results 1) FCC Part 15 Subpart C: 2004 No. Item Test Procedure Specification Deviation Worst margin Results 1 Automatically Deactivate ANSI C63.4:2003 13. Measurement of intentional radiat…

Text truncated - open the document above for the full version.

Test report No. : 24HE0134-HO-1 Page : 9 of 16 Issued date : November 22, 2004 FCC ID : BGBX1T458SKE11A01 Revised Date :December 7, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) APPENDIX 1: Photographs of test setup Radiated emission(Worst case position)(Transmitting mode) Front Rear Test report No. : 24HE0134-HO-1 Page : 10 of 16 Issued date : November 22, 2004 FCC ID : BGBX1T458SKE11A01 Revised Date :December 7, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) Worst Case Position (Horizontal : X-axis/ Vertical: Y-axis) (Transmitting mode) X-axis Y-axis Z-axis Test report No. : 24HE0134-HO-1 Page : 11 of 16 Issued date : November 22, 2004 FCC ID : BGBX1T458SKE11A01 Revised Date :December 7, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) Radiated emission(Worst case position)(Receiving mode) Front Rear
