BOOKP-20-XXXAndroid mini PC

Model:SY-20-19VC Manual iPazzPort R The Pearl FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 1.Specifications and Feature: a. R.F 2.4G wireless conncet ( Microphone+speaker) Max distance:10m b. Multi-touch and Scrolling bar c. QWERTY keyboard d. The usual shortcut e. – Support Voice Input ,Search ,Call ,Control – Play voice at remote as wactching video alone, no effect family – Android 4.1 OS, rich preloaded applications software for home education, entertainment, travel presentation, etc – Using voice speaker and microphone of the remote control, also can like smartphones QQ and Skype – WiFi inside – Simple and easy interface, mini TV cabinet modelling HDMI output f. CPU:Dual-core 1.6GHz (Max) – HD video decoder(1080P@60FPS) – HD video encoder(1080P@30FPS) – Memory:DDR3: 1G – Flash: 4G g. Remote Size:158*60*15.4mm/Weight:100g Rechargeable Lithium-ion battery Battery capacity:400mA charge voltage: DC 5V/300mA standby time: 400 hours Working Voltage:3.3V Box Size:124*90mm/Weight:281g Power Supply:5V/2A 2. Package: a. Pearl b. USB line c. Power supply d. User munanl e. HDMI line f. AV line 4. Product overview: 1 5 3 6 7 9 8 10 11 4 2 1 2 3 4 5 6 3.System requirement: - Windows - Linux - Android/Google/Smart TV - Mac OS Camera Keyboard wedge Keyboard front Keyboard back 7 8 9 10 11 AV port Network port SD slot USB port Power supply USB port HDMI port charge lamp Voice prompt indicator Indicator Headset jack Page up/down LED button Power swith Power LED 5. User munanl 5.1 Plug HDMI pearl to your TV, power on your TV and set signal to “HDMI” 5.2 Switch: accessories in one end of the power cord is connected to the player's power connector, the other end of access to home AC player blue lights indicate normal boot. Power HDMI 5.3 Come from the player above the keyboard, open the keyboard power switch to the right of the two light flashes and then turns off, The connection is successful, the finger on the touchpad the mobile indicator will flash, as shown: Power switch 6. Function description of keyboard: Nunber key Function Operation Enter standby or Start from standby Press this button Mute Enter the picture browser Open the browser Open the video Open the music Open the skype Open the explorer Open the voice search Open the settings Open the email Open the google play Open the Apps Open the menu Zoom in Zoom out Home Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Google play Apps Menu Home Audio Press Corresponding button Volume up Volume down Previous Stop/play Next Return to main page Back to previous page Delete Backspace Open the facebook Function Operation ON/OFF voice Repeat Cursor up,down,left, right Ensure End Del Facebook Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button Press this button End 7.Wi-Fi connect 7.1 Press the keyboard “settings” button to enter the “settings interface”, select the mane of your router 7.2 If your router has password, enter the password. If there is no password. After a successful conncet, the lower right corner of the screen there will be a Wi-Fi ion. 7.3 If your router name is not found in the list, you can search by scanning in the upper-right corner, until the list the name of your router. 8. Voice search 8.1 Keyboard settings Click the voice swith, it lights up, then you can use the keyboard voice capabilities to chat, listen to music, etc; to turn off voice feature, simply click on corner voice to voice indicator will turn off. Press this button ON/OFF voice 8.2 Box settings 8.2.1 Settings voice input 8.2.1.1 Press the keyboard “settings” button to enter the “settings interface”, 8.2.1.2 Go to Language & input > KEYBOARD&INPUT METHODS Press this button 8.3 Using voice search Voice Search is a free app that lets you speak your search queries instead of typing. Follow the instructi…

Text truncated - open the document above for the full version.

Date:2013-7-07 FCC ID: BOOKP-20-XXX Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Dengyi Title: Engineer Tel: +86-769-83367802-8016

Unisen limited Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2013-7-07 SUBJECT: FCC Application for ( FCCID: BOOKP-20-XXX) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Date:2013/7/07 Name: Dengyi Title: Engineer Tel: +86-769-83367802-8016

Unisen limited Model Difference FCC ID: BOOKP-20-XXX Model : SY-20-19VC，SY-20-XXX (XXX in the model designation may be any alphanumeric characters denoting different configuration options） All the models are the same circuit and RF module, except the mode names. Regards, Client’s signature Signature Client’s name / title : Dengyi / Engineer Contact information / address : Room 907, Fook Hong Industrial Bldg.,19 Sheung Yuet Road, Kowloon Bay,Kowloon, Hong Kong

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Unisen limited 2013-07-04 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Unisen limited. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Android mini PC, Model: SY-20-19VC，SY-20-XXX (XXX in the model designation may be any alphanumeric characters denoting different configuration options） FCC ID: BOOKP-20-XXX) We affirm that between SIEMIC and Unisen limited , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : Dengyi / Engineer Contact information / address : Room 907, Fook Hong Industrial Bldg.,19 Sheung Yuet Road, Kowloon Bay,Kowloon, Hong Kong

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen 3nod Information Technology Co.,Ltd. 2013-7-4 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: BOOKP-20-XXX We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Client’s name / title : Dengyi / Engineer Contact information / address : Room 907, Fook Hong Industrial Bldg.,19 Sheung Yuet Road, Kowloon Bay,Kowloon, Hong Kong

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC ID LABELING AND LOCATION FCC ID Label FCC ID: BOOKP-20-XXX Model：SY-20-19VC FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label here FCC DoC Label Model：SY-20-19VC Tested to comply with FCC Standards

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 WIFI Ant Photo 7 Photo 8 Photo 9

FCC §15.247 (i), §2.1091 – RF Exposure Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 17.74 59.43 1.259(1.0dBi)0.0118 1 Pass

FCC RADIO TEST REPORT FCC ID: BOOKP-20-XXX Product： Android mini PC Trade Name： N/A Model Name： SY-20-19VC Serial Model： SY-20-XXX(XXX in the model designation may be any alphanumeric characters denoting different configuration options) Report No.： NTEK-2013NT0606340F Prepared for Unisen limited Room 907, Fook Hong Industrial Bldg.,19 Sheung Yuet Road, Kowloon Bay,Kowloon, Hong Kong Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 66 Report No.: NTEK-2013NT0606340F TEST RESULT CERTIFICATION Applicant’s name................. : Unisen limited Address ................................. : Room 907, Fook Hong Industrial Bldg.,19 Sheung Yuet Road, Kowloon Bay,Kowloon, Hong Kong Manufacture's Name............ : Unisen limited Address ................................. : Room 907, Fook Hong Industrial Bldg.,19 Sheung Yuet Road, Kowloon Bay,Kowloon, Hong Kong Product description Product name ........................... : Android mini PC Model and/or type reference : SY-20-19VC Serial Model .............................. : SY-20-XXX(XXX in the model designation may be any alphanumeric characters denoting different configuration options) Standards............................. : FCC Part15.247 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 06 Jun. 2013 ~05 Jul. 2013 Date of Issue...........................................: 05 Jul. 2013 Test Result...............................................: Pass Testing Engineer : (Eric Wang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 66 Report No.: NTEK-2013NT0606340F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 25GHZ) 22 4 . POWER SPECTRAL DENSITY TEST 37 4.1 APPLIED PROCEDURES / LIMIT 37 4.1.1 TEST PROCEDURE 37 4.1.2 DEVIATION FROM STANDARD 37 4.1.3 TEST SETUP 37 4.1.4 EUT OPERATION CONDITIONS 37 4.1.5 TEST RESULTS 38 5 . BANDWIDTH TEST 46 5.1 APPLIED PROCEDURES / LIMIT 46 5.1.1 TEST PROCEDURE 46 5.1.2 EUT OPERATION CONDITIONS 46 Page 4 of 66 Report No.: NTEK-2013NT0606340F Table of Contents Page 5.1.3 TEST RESULTS 47 6 . PEAK OUTPUT POWER TEST 55 6.1 APPLIED PROCEDURES / LIMIT 55 6.1.1 TEST PROCEDURE 55 6.1.2 DEVIATION FROM STANDARD 55 6.1.3 TEST SETUP 55 6.1.4 EUT OPERATION CONDITIONS 55 6.1.5 TEST RESULTS 56 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 57 7.1 DEVIATION FROM STANDARD 57 7.2 TEST SETUP 57 7.3 EUT OPERATION CONDITIONS 57 7.4 TEST RESULTS 58 8 . ANTENNA REQUIREMENT 64 8.1 STANDARD REQUIREMENT 64 8.2 EUT ANTENNA 64 9 . EUT TEST PHOTO 65 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 66 Report No.: NTEK-2013NT0606340F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 66 Report No.: NTEK-2013NT0606340F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 66 Report No.: NTEK-2013NT0606340F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Android mini PC Trade Name N/A Model Name SY-20-19VC Serial Model SY-20-XXX(XXX in the model designation may be any alphanumeric characters denoting different configuration options) Model Difference All the models are the same circuit and RF module, except the model names. Product Description The EUT is a Android mini PC Operation Frequency: 802.11b/g/n(20MHz):2412~2462 MHz 802.11n(40MHz):2422~2452 Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
