C5F7NF1AMO110NMicrowave Oven

Microwave Oven 164D3370P21049-40249-2 04-02 JR KOR-1A5A Owner’s Manual www.GEAppliances.com Safety Instructions . . . . . . . .2–6 Operating Instructions Convenience Features . . . .13–15 Microwave Terms . . . . . . . . . . .18 Oven Features . . . . . . . . . . . .7, 8 Other Features . . . . . . . . . .16, 17 Power Levels . . . . . . . . . . . . . . .9 Time Features . . . . . . . . . .10–12 Care and Cleaning . . . . . . . .19 Troubleshooting Tips . . . . . .20 Things That Are Normal . . . . .20 Consumer Support Consumer Support . . .Back Cover Warranty . . . . . . . . . . . . . . . . .23 Write the model and serial numbers here: Model # __________________ Serial #__________________ You can find them on a label inside the oven. Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips IMPORTANT SAFETY INSTRUCTIONS. READ ALL INSTRUCTIONS BEFORE USING. For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. IMPORTANT SAFETY INSTRUCTIONS. This microwave oven is not approved or tested for marine use. Use this appliance only for its intended purpose as described in this Owner’s Manual. Read and follow the specific precautions in the Precautions to Avoid Possible Exposure to Excessive Microwave Energysection above. This appliance must be grounded. Connect only to a properly grounded outlet. See the Grounding Instructionssection on page 5. Install or locate this appliance only in accordance with the provided installation instructions. Be certain to place the front surface of the door 3′′or more back from the countertop edge to avoid accidental tipping of the appliance in normal usage. Do not mount this appliance over a sink. Do not mount the microwave oven over or near any portion of a heating or cooking appliance. Do not store anything directly on top of the microwave oven surface when the microwave oven is in operation. Do not operate this appliance if it has a damaged power cord or plug, if it is not working properly, or if it has been damaged or dropped. Do not cover or block any openings on the appliance. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This microwave oven is specifically designed to heat, dry or cook food, and is not intended for laboratory or industrial use. Do not store this appliance outdoors. Do not use this product near water—for example, in a wet basement, near a swimming pool, or near a sink. Keep power cord away from heated surfaces. Do not immerse power cord or plug in water. Do not let power cord hang over edge of table or counter. To reduce the risk of fire in the oven cavity: – Do not overcook food. Carefully attend appliance if paper, plastic or other combustible materials are placed inside the oven while cooking. – Remove wire twist-ties and metal handles from paper or plastic containers before placing them in the oven. – Do not use the oven for storage purposes. Do not leave paper products, cooking utensils or food in the oven when not in use. – If materials inside the oven should ignite, keep the oven door closed, turn the oven off and disconnect the power cord, or shut off power at the fuse or circuit breaker panel. If the door is opened, the fire may spread. See door surface cleaning instructions in the Care and cleaning of the microwave ovensection of this manual. GE does not support any servicing of the microwave. We strongly recommend that you do not attempt to service the microwave yourself. As with any appliance, close supervision is necessary when used by children. SAVE THESE INSTRUCTIONS WARNING! (a) Do Not Attemptto operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. ( b) Do Not Placeany object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do Not Operatethe oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The Oven Should Notbe adjusted or repaired by anyone except properly qualified service personnel. PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 2 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions GEAppliances.com ARCING If you see arcing, press the CLEAR/OFFpad and correct the problem. Arcing is the microwave term for sparks in the oven. Arcing is caused by: Metal or foil touching the side of the oven. Foil not molded to food (upturned edges act like antennas). Metal, such as twist-ties, poultry pins or gold- rimmed dishes, in the microwave. Recycled paper towels containing small metal pieces being used in the microwave. FOODS Do not pop popcorn in your microwave oven unless in a special microwave popcorn accessory or unless you use popcorn labeled for use in microwave ovens. Some products such as whole eggs and sealed containers—for example, closed jars—will explode and should not be heated in this microwave oven. Such use of the microwave oven could result in injury. Do not boil eggs in a microwave oven. Pressure will build up inside egg yolk and will cause it to burst, possibly resulting in injury. Operating the microwave with no food inside for more than a minute or two may cause damage to the oven and could start a fire. It increases the heat around the magnetron and can shorten the life of the oven. Foods with unbroken outer “skin” such as potatoes, hot dogs, sausages, tomatoes, apples, chicken livers and other giblets and egg yolks should be pierced to allow steam to escape during cooking. SUPERHEATED WATER Microwaved water and other liquids do not always b…

Text truncated - open the document above for the full version.

Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 32 of 40 APPENDIX C – EUT PHOTOGRAPHS z Front View of EUT Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 33 of 40 z Rear View of EUT Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 34 of 40 z Open View of EUT

Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 27 of 40 APPENDIX A – SAMPLE LABEL The sample label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. z FCC ID Location of EUT Labeling Requirements ID LABEL LOCATION

Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 35 of 40 z Side View of EUT Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 36 of 40 z Side View of EUT Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 37 of 40 z Top View of EUT

WIRING DIAGRAM ( SCHEMATICS ) FCC ID: C5F7NF1AMO11ØN

Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 1 of 40 Nemko Korea Co., Ltd. 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Kyungki-Do, KOREA TEL:+82 31 322 2333 FAX:+82 31 322 2332 Applicant : Daewoo Electronics Corporation. Dates of Issue : May 09, 2005 M/W Oven Div. R&D Center, 412-2, Test Report No. : NK2FE237 Chungchun-Dong, Bupyong-Gu, Incheon, Test Site : Nemko Korea Co., Ltd. 403-032, Korea EMC site, Korea Attn : Mr. Gun-Woo, Ro FCC ID Brand Name Contact Person Applied Standard: Part 18 & 2 Classification : Consumer ISM equipment EUT Type: Microwave oven The device bearing the brand name and FCC ID specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in MP-5:1986. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tested By : S. H. Baek Reviewed By : H.H. Kim Engineer Manager & Chief Engineer C5F7NF1AMO110N DAEWOO Daewoo Electronics Corporation. M/W Oven Div. R&D Center, 412-2, Chungchun-Dong, Bupyong-Gu, Incheon, 403-032, Korea Mr. Gun-Woo, Ro Telephone No. : +82 32 510 7923 Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 2 of 40 TABLE OF CONTENTS SCOPE INTRODUCTION (Site Description) DESCRIPTION OF TESTS (Radiation Hazad) DESCRIPTION OF TESTS (Input Power Measurement) DESCRIPTION OF TESTS (RF Output Power Measurement) DESCRIPTION OF TESTS (Operating Frequency Measurements) DESCRIPTION OF TESTS (Conducted Emissions) DESCRIPTION OF TESTS (Radiated Emissions) TEST DATA (Radiation Hazad) TEST DATA (Input Power Measurement) TEST DATA (RF Output Power Measurement) TEST DATA (Operating Frequency Measurements) TEST DATA (Conducted Emissions) TEST DATA (Radiated Emissions) PLOT OF EMISSIONS (Operating Frequency Measurements) PLOT OF EMISSIONS (Conducted Emissions Diagram) ACCURACY OF MEASUREMENT LIST OF TEST EQUIPMENT APPENDIX A - SAMPLE LABEL APPENDIX B - PHOTOGRAPHS OF TEST SET-UP APPENDIX C - EUT PHOTOGRAPHS APPENDIX D - SCHEMATIC DIAGRAM APPENDIX E - USER’S MANUAL APPENDIX F - BLOCK DIAGRAM 2 4 5 5 5 5 6 7 8 8 8 9 11 12 14 23 25 26 27 28 32 38 39 40 Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 3 of 40 SCOPE Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under FCC part 18. Responsible Party : Contact Person : Manufacturer : Factory : Daewoo Electronics Corporation. Mr. Gun-Woo. Ro Tel No.: +82 32 510 7923 Daewoo Electronics Corporation. M/W Oven Div. R&D Center, 412-2, Chungchun-Dong, Bupyong-Gu, Incheon, 403-032, Korea 1) Daewoo Microwave Oven Co., Ltd. 981-1, Jangduck-Dong, Gwangsan-Gu, Kwangju-Shi, 506-251, Korea 2) Daewoo Electronics Corporation. Detda, Dagang District, Tianjin, Chaina z FCC ID: C5F7NF1AMO110N z Model: KOR-1A5A z Brand Name: DAEWOO z EUT Type: Microwave Oven z Applied Standard: z Test Procedure(s): z Dates of Test: z Place of Tests: z Test Report No.: FCC Part 18 & Part 2 MP-5:1986 Aril 23, 2005 to April 29,2005 Nemko Korea Co., Ltd. EMC Site NK2FE237 EUT Information Electric Rating: 120V, 60Hz AC only, 1.5kW Clock: 4MHz Magnetron Type: RM269 / Daewoo Electronics Corp. Operating Frequency 2.45GHz Rated Output Power 1100W Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 4 of 40 INTRODUCTION The measurement procedure described in MP5:1986 for Methods of Measurement of radiated, powerline conducted radio noise, frequency and power output was used in determining emissions emanating from Daewoo Electronics Corporation. FCC ID : C5F7NF1AMO110N, Microwave Oven. These measurement tests were conducted at Nemko Korea Co., Ltd. EMC Laboratory . The site address is 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Kyungki-Do, KOREA The area of Nemko Korea Corporation Ltd. EMC Test Site is located in a mountain area at 80 kilometers (48 miles) southeast and Incheon International Airport (Incheon Airport), 30 kilometers (18miles) south-southeast from central Seoul. It is located in the valley surrounded by mountains in all directions where ambient radio signal conditions are quiet and a favorable area to measure the radio frequency interference on open field test site for the computing and ISM devices manufactures. The detailed description of the measurement facility was found to be in compliance with the requirements of §2.948 according to ANSI C63.4-2003 Fig. 1. The map above shows the Seoul in Korea vicinity area. The map also shows Nemko Korea Corporation Ltd. EMC Lab and Incheon Airport. Nemko Korea Co., Ltd. OPEN AREA TEST SITE 300-2, Osan-Ri, Mohyun-Myun, Yongin- City Kyungki-Do,KOREA 449-852 Tel) +82-31-322-2333 Fax) +82-31-322-2332 Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 5 of 40 DESCRIPTION OF TESTS Radiation Hazard A 700-ml water load was placed in the center of the oven. The power setting was set to maximum power. While the oven was operating, the Microwave Survey Meter probe was moved slowly around the door seams to check for leakage. Input Power Measurement The EUT was placed on a wooden table 0.8m at 1m distance Horn antenna. A 700ml water load was placed in the center of the oven and the oven set to maximum power. A 700ml water load was chosen for its compatibility. Input power and current were measured using a Power Analyzer. Manufacturers to determine their input ratings commonly use this procedure. Output P…

Text truncated - open the document above for the full version.

Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 28 of 40 APPENDIX B – PHOTOGRAPHS OF TEST SET-UP The Conducted Test Picture and Radiated Test Picture and show the worst-case configuration and cable placement. z Radiation hazard Test Picture z RF Output Power Test Picture Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 29 of 40 z Operating Frequency Test Picture Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 30 of 40 z Conducted Test Picture (Front) z Conducted Test Picture (Rear) Test Report No.: NK2FE237 FCC Certification Daewoo Electronics Corporation. FCC ID:C5F7NF1AMO110N Page 31 of 40 z Radiated Test Picture (Front) z Radiated Test Picture (Rear)
