C5F7NF22MO110NMicrowave Oven

ABOUT THIS MANUAL ABOUT THIS MANUAL 담 당장형석 님 F.MODELKOR-226(3)SBFBUYERGE B.MODELPEB7226BRANDGE 언 어영어COUNTRYU.S.A 일 정 1차 2차 3차 4차 5차 제 판인 쇄애드컴 규 격 MEMO 접수 : VISION CREATIVE. INC . 서울 종로구 통의동 6번지 이룸빌딩 4층 (총 28p)_CS3 130108 - 신규 총 29p(1~28) (총 29p) 130111 - 신규 총 2p(목차, 21)_페이지 추가됨. 130114 - 수정 총 2p(10,17,19,21) 연락처 VISION 담 당 방 문 수(choi’s) TEL : 730-0660 FAX : 730-3788 KOR-2263SBF_PEB7226_OM(영).indd 12013-01-14 오후 2:32:55 ge.com Owner’s Manual Countertop Microwave Oven PEB7226 3513913700 49-40510-1 01-10 JR KOR-2263SBF_PEB7226_OM(영).indd 12013-01-14 오후 2:32:56 3 Before using your oven Read this manual carefully. It is intended to help you operate and maintain your new microwave oven properly. Keep it handy for answers to your questions. Write down the model & serial numbers See the Features of Your Oven section for model and serial number location. These numbers are also on the Consumer Product Ownership Registration Card included in this manual. Before sending in this card, please write these numbers here: Model Number Serial Number Use these numbers in any correspondence or service calls concerning your microwave oven. If you received a damaged oven Immediately contact the dealer (or builder) that sold you the oven. Save time & money Before you request service, check the Problem Solver in the back of this manual. It lists causes of minor operating problems that you can correct yourself. If you need service To obtain service, see the Consumer Services page in the back of this manual. We’re proud of our service and want you to be pleased. If for some reason you are not happy with the service you receive, here are the steps to follow for further help. FIRST, contact the people who serviced your appliance. Explain why you are not pleased. In most cases, this will solve the problem. NEXT, if you are still not pleased, write all the details—including your phone number—to: Manager, Customer Relations GE Appliances Appliance Park Louisville, KY 40225 Consumer Information C o u n t e r t op Micro w a v e Oven 2 Introduction Your new Monogram microwave oven makes an eloquent statement of style, convenience and kitchen planning exibility. Whether you chose it for its purity of design, practical cooking features or assiduous attention to detail—or for all of these reasons—you’ll nd that your Monogram microwave oven’s superior blend of form and function will delight you for years to come. The information on the following pages will help you operate and maintain your microwave oven properly. Contents Adapter Plugs . . . . . . . . . . . . . . . . . . . . . . . . .7 Aluminum Foil . . . . . . . . . . . . . . . .5, 6, 15, 23 Appliance Registration . . . . . . . . . . . . . . . . . .3 Auto Feature . . . . . . . . . . . . . . . . . . . . . . . . .17 Auto Defrost . . . . . . . . . . . . . . . . . . . . . . .17 Care and Cleaning . . . . . . . . . . . . . . . . . . . .24 Consumer Services . . . . . . . . . . . . . . . . . .3, 28 Cooking Controls . . . . . . . . . . . . . . . . . . . . .10 Extension Cords . . . . . . . . . . . . . . . . . . . . . . .8 Features of Your Oven . . . . . . . . . . . . . . . . . .9 Grounding Instructions . . . . . . . . . . . . . . . . .7 Microwave-Safe Cookware . . . . . . . . . . . . . . .6 Model and Serial Number Location . . . . . . .3 Other Features . . . . . . . . . . . . . . . . . . . .21,22 Child Lock-Out . . . . . . . . . . . . . . . . . . . . .21 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Cooking Complete Reminder . . . . . . . . . .21 Display On/Off . . . . . . . . . . . . . . . . . . . .21 Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Sound On/Off . . . . . . . . . . . . . . . . . . . . . 22 Start/Pause . . . . . . . . . . . . . . . . . . . . . . . .21 Timer On/Off . . . . . . . . . . . . . . . . . . . . . .22 Power Levels . . . . . . . . . . . . . . . . . . . . . . . . .11 Precautions to Avoid Possible Exposure to Excessive Microwave Energy . . . . . . . . . . . . .2 Problem Solver . . . . . . . . . . . . . . . . . . . . . . .25 Time Features . . . . . . . . . . . . . . . . . . . . .12–16 Add 30 Seconds . . . . . . . . . . . . . . . . . . . . .16 Express Cook . . . . . . . . . . . . . . . . . . . . . .16 Time Cook . . . . . . . . . . . . . . . . . . . . . .12, 13 Time Defrost . . . . . . . . . . . . . . . . . . . .14, 15 Sensor Features . . . . . . . . . . . . . . . .18, 19, 20 Beverage . . . . . . . . . . . . . . . . . . . . . . . . . .18 My Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Popcorn . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Potato . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Reheat . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Vegetable . . . . . . . . . . . . . . . . . . . . . . . . . .20 Safety Instructions . . . . . . . . . . . . . . . . . . .4–8 Warranty . . . . . . . . . . . . . . . . . . . . .Back Cover PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a)Do Not Attemptto operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b)Do Not Placeany object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c)Do Not Operatethe oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d)The Oven Should Notbe adjusted or repaired by anyone except properly qualied service personnel. KOR-2263SBF_PEB7226_OM(영).indd 22013-01-14 오후 2:32:56 3 Before using your oven Read this manual carefully. It is intended to help you operate and maintain your new microwave oven properly. Keep it handy for answers to your questions. Write down the model & serial numbers See the Features of Your Oven section for model a…

Text truncated - open the document above for the full version.

5. Block Diagram

Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 49 of 67 APPENDIX C – EUT PHOTOGRAPHS  Front View of EUT Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 50 of 67  Rear View of EUT

Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 44 of 67 APPENDIX A – SAMPLE LABEL The sample label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase.  FCC ID Location of EUT Labeling Requirements

Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 51 of 67  Door open View of EUT Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 52 of 67  Left View of Inside Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 53 of 67  Right View of Inside Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 54 of 67  Top View of Inside Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 55 of 67  Front View of Magnetron Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 56 of 67  Rear View of Magnetron Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 57 of 67  Front View of Main Board

Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 58 of 67  Rear View of Main Board Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 59 of 67  Front View of Filter Board Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 60 of 67  Rear View of Filter Board Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 61 of 67  Front View of Trans Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 62 of 67  Rear View of Trans Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 63 of 67  Front View of Capacitor Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 64 of 67  Rear View of Capacitor

7. Operation Description

1 2 3 4 5 6 7 Several Several Several 2100VAC 1.05UF CL04-12A 500MA 12000V 120V 60HZ OEM-15DWX1-C07 49TYD-16A1 16 A, 125/250 V ac TRAY MOTOR Manufacturer DAEWOO DPC Several Several Parts MAGNETRON TRANS H.V. CAPACITOR H.V. INTERLOCK SWITCH 8. Part List FAN MOTOR DIODE H.V. SPEC. RM269 DYAS12A0-22A S

6. Schematic Diagram

Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 2 of 67 TABLE OF CONTENTS SCOPE INTRODUCTION (Site Description) EUT INFORMATION DESCRIPTION OF TESTS (Radiation Hazard) DESCRIPTION OF TESTS (Input Power Measurement) DESCRIPTION OF TESTS (RF Output Power Measurement) DESCRIPTION OF TESTS (Operating Frequency Measurements) DESCRIPTION OF TESTS (Conducted Emissions) DESCRIPTION OF TESTS (Radiated Emissions) TEST DATA (Radiation Hazard) TEST DATA (Input Power Measurement) TEST DATA (RF Output Power Measurement) TEST DATA (Operating Frequency Measurements) TEST DATA (Conducted Emissions) TEST DATA (Radiated Emissions) PLOT OF EMISSIONS (Operating Frequency Measurements) PLOT OF EMISSIONS (Conducted Emissions Diagram) PLOT OF EMISSIONS (Radiated Emissions Diagram) ACCURACY OF MEASUREMENT LIST OF TEST EQUIPMENT APPENDIX A - SAMPLE LABEL APPENDIX B - PHOTOGRAPHS OF TEST SET-UP APPENDIX C - EUT PHOTOGRAPHS APPENDIX D - SCHEMATIC DIAGRAM APPENDIX E - USER’S MANUAL APPENDIX F - BLOCK DIAGRAM 3 4 5 6 6 6 6 7 8 9 9 9 10 12 13 16 34 36 38 43 44 45 49 65 66 67 Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 3 of 67 SCOPE Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under FCC part 18. Responsible Party : Contact Person : Manufacturer : Factory : Daewoo Electronics Corporation Mr. Seongok Kim Tel No.: + 82 32 510 7919 Daewoo Electronics Corporation Kitchen Appliances Div. R&D Center, 412-2, Cheongcheon2-Dong, Bupyeong-Gu, Incheon, 403-032, Korea Daewoo Microwave Oven Co., Ltd. Development Area, Binhai New Area Tianjjin China  FCC ID: C5F7NF22MO110N  Model: KOR-226S  Variant Model: KOR-223S PEB7226DF*WW PEB7226DF*BB PEB7226SF*SS Note) "*" May or may not include number from 0 to 9  Brand Name: DAEWOO, GE  EUT Type: Microwave Oven  Applied Standard:  Test Procedure(s):  Dates of Test:  Place of Tests:  Test Report No.: FCC Part 18 & Part 2 MP-5:1986 December 11, 2012 to January 04, 2012 Nemko Korea Co., Ltd. EMC Site NK-12-E-928 The model KOR-226S was tested and was recorded the data in test report. Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 4 of 67 INTRODUCTION The measurement procedure described in MP5:1986 for Methods of Measurement of radiated, powerline conducted radio noise, frequency and power output was used in determining emissions emanating from Daewoo Electronics Corporation. FCC ID : C5F7NF22MO110N, Microwave Oven. These measurement tests were conducted at Nemko Korea Co., Ltd. EMC Laboratory. The site address is 155 & 159, Osan-Ro, Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-852 KOREA, REPUBLIC OF The area of Nemko Korea Corporation Ltd. EMC Test Site is located in a mountain area at 80 kilometers (48 miles) southeast and Incheon International Airport (Incheon Airport), 30 kilometers (18 miles) south-southeast from central Seoul. It is located in the valley surrounded by mountains in all directions where ambient radio signal conditions are quiet and a favorable area to measure the radio frequency interference on open field test site for the computing and ISM devices manufactures. The detailed description of the measurement facility was found to be in compliance with the requirements of 2.948 according to ANSI C63.4 on 2003. Fig. 1. The map above shows the Seoul in Korea vicinity area. The map also shows Nemko Korea Corporation Ltd. EMC Lab and Incheon Airport. Nemko Korea Co., Ltd. 155 & 159, Osan-Ro, Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-852 KOREA, REPUBLIC OF Tel) + 82 31 330 1700 Fax) + 82 31 322 2332 Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 5 of 67 EUT INFORMATION EUT Information Electric Rating : a.c. 120 V, 60 Hz Clock : 4 MHz Magnetron Type : RM269 (DAEWOO) Operating Frequency : 2.45 GHz Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 6 of 67 DESCRIPTION OF TESTS Radiation Hazard A 700 ml water load was placed in the center of the oven. The power setting was set to maximum power. While the oven was operating, the Microwave Survey Meter probe was moved slowly around the door seams to check for leakage. Input Power Measurement The EUT was placed on a wooden table 0.8 m at 1 m distance Horn antenna. A 700ml water load was placed in the center of the oven and the oven set to maximum power. A 700 ml water load was chosen for its compatibility. Input power and current were measured using a Power Analyzer. Manufacturers to determine their input ratings commonly use this procedure. Output Power Measurement The Caloric Method was used to determine maximum output power. The initial temperature of a 1000 ml water load was measured. The water load was placed in the center of the oven. The oven was operated at maximum output power for 120 seconds. Then the temperature of the water re-measured. Frequency Measurements Following the above test, after operating the oven long enough to assure that stable operating temperature were obtained, the operating frequency was monitored as the input voltage was varied between 80 to 125 percent of the nominal rating. And the load quantity was reduced by evaporation to approximately 20 % of the original quantity with nominal rating. Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 7 of 67 DESCRIPTION OF TESTS Conducted Emissions The Line conducted emission test facility is located inside a 4 x 7 x 2.5 meter shielded enclosure. It is manufactured by EM engineering. The shielding effectiveness of the shielded room is in accordance with MIL-STD-285 or NSA 65-6. A 1 m X 1.5 m wooden table 0.4…

Text truncated - open the document above for the full version.

Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 45 of 67 APPENDIX B – PHOTOGRAPHS OF TEST SET-UP The Conducted Test Picture and Radiated Test Picture and show the worst-case configuration and cable placement. ● Radiation hazard Test Picture  Operating Frequency Test Picture Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 46 of 67  Conducted Test Picture (Front)  Conducted Test Picture (Rear) Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 47 of 67  Radiated Test Picture – 0.15 MHz ~ 30 MHz (Front)  Radiated Test Picture – 30 MHz ~ 1 GHz (Front) Test Report No.: NK-12-E-928 FCC Certification Daewoo Electronics Corporation FCC ID: C5F7NF22MO110N Page 48 of 67  Radiated Test Picture – 30 MHz ~ 1 GHz (Rear)  Radiated Test Picture – 1 GHz ~ 18 GHz (Front)
