C5F7NF63MO7000Microwave Oven

FRONT VIEW(DOOR CLOSED) < FCC ID : C5F7NF63MO7000 >

FRONT VIEW(DOOR OPENED) < FCC ID : C5F7NF63MO7000 >

REAR VIEW < FCC ID : C5F7NF63MO7000 >

IDENTIFICATION LABEL < FCC ID : C5F7NF63MO7000 >

ID LABEL LOCATION < FCC ID : C5F7NF63MO7000 >

SIDE VIEW(LEFT) < FCC ID : C5F7NF63MO7000 >

SIDE VIEW(RIGHT) – DAEWOO M.G.T. < FCC ID : C5F7NF63MO7000 >

SIDE VIEW(RIGHT) – LG M.G.T. < FCC ID : C5F7NF63MO7000 >

TOP VIEW – DAEWOO M.G.T. < FCC ID : C5F7NF63MO7000 >

TOP VIEW – LG M.G.T. < FCC ID : C5F7NF63MO7000 >

WIRING DIAGRAM < FCC ID : C5F7NF63MO7000 >

< FCC ID : C5F7NF63MO7000 > < FCC ID : C5F7NF63MO7000 > < FCC ID : C5F7NF63MO7000 > < FCC ID : C5F7NF63MO7000 >

2 / 14 NVLAP Code : 200040-0 Report No. : 00431-4521-F0088 LG Electronics Inc. Quality & Reliability Center, 36, Munlae-dong, 6-ga, Youngdungpo-gu, Seoul, Korea Tel:+82-2-2630-3077, Fax:+82-2-2635-5543 CONTENTS Page 1. CLIENT INFORMATION..............................................................................................................................................3 2. EQUIPMENT UNDER TEST (EUT)..............................................................................................................................3 2.1 IDENTIFICATION OF THE EUT...............................................................................................................................3 2.2 ADDITIONAL INFORMATION ABOUT THE EUT..................................................................................................3 3. TEST SITE.......................................................................................................................................................................4 3.1 SEMI-ANECHOIC CHAMBER....................................................................................................................................4 4. CALIBRATIONS OF MEASURING INSTRUMENTS.............................................................................................4 5. DESCRIPTION OF TEST CONDITION....................................................................................................................4 5.1 RADIATED EMISSIONS MEASUREMENTS...............................................................................................................4 6. MEASURING INSTRUMENTS AND SET-UP...........................................................................................................6 6.1 RADIATED EMISSIONS..............................................................................................................................................6 6.2 FREQUENCY MEASUREMENTS................................................................................................................................6 7. RF POWER OUTPUT MEASUREMENT AND RESULTS......................................................................................7 8. TEST DATA.....................................................................................................................................................................8 8-1. RADIATED EMISSIONS (SECTION 18.305)............................................................................................................8 8-2. FREQUENCY MEASUREMENTS..............................................................................................................................9 9. LIST OF INSTRUMENTS USED...............................................................................................................................10 APPENDIX A THE TEST GRAPH...............................................................................................................................11 APPENDIX B THE PHOTOGRAPHS OF TEST SET-UP.......................................................................................14 3 / 14 NVLAP Code : 200040-0 Report No. : 00431-4521-F0088 LG Electronics Inc. Quality & Reliability Center, 36, Munlae-dong, 6-ga, Youngdungpo-gu, Seoul, Korea Tel:+82-2-2630-3077, Fax:+82-2-2635-5543 1. CLIENT INFORMATION The EUT has been tested by request of: Company:Daewoo Electronics Co.,Ltd. #412-2, Chongchon 2-dong, Pupyung-ku, Incheon, Korea, 403-032 Name of contact:W. P. Hong Telephone:+82-32-510-7922 Fax:+82-32-527-7461 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of the EUT Equipment:Microwave oven Model:KOR-631H9 Brand name:Daewoo Serial number:N/A Manufacturer:#412-2, Chongchon 2-dong, Pupyong-ku, Incheon, KOREA, 403-032 Country of origin:Korea Rating:120V~, 60Hz 2.2 Additional information about the EUT The EUT consists of the following parts: ComponentType / modelTechnical dataMaker Magnetron2M2142,450MHzLG Electronics 4 / 14 NVLAP Code : 200040-0 Report No. : 00431-4521-F0088 LG Electronics Inc. Quality & Reliability Center, 36, Munlae-dong, 6-ga, Youngdungpo-gu, Seoul, Korea Tel:+82-2-2630-3077, Fax:+82-2-2635-5543 3. TEST SITE 3.1 Semi-anechoic chamber Measurement of radiated emissions from EUT was made at semi-anechoic chamber that has been in compliance with Federal Communications Commissions(FCC) requirements of clause 2.948 according to ANSI C63.4-1992 on April 21, 1998. 4. CALIBRATIONS OF MEASURING INSTRUMENTS All measurements were made with instruments calibrated according to the recommendation by manufacturer. Measurement of radiated emissions was made with instruments conforming to American National Standard Specification, ANSI C63.4-1992. The calibration of measur- ing instrument, including any accessories that may affect test results, was performed accord- ing to the recommendation by manufacturer. 5. DESCRIPTION OF TEST CONDITION 5.1 Radiated emissions measurements 5.1.1 Test site Measurements were made in semi-anechoic chamber as described at 3.1 in this report. 5.1.2 Detector function selection and bandwidth In radiated emissions measurement, field strength meters that has CISPR quasi-peak and average detector were used. The bandwidth of the detector of instrument is 120 KHz over frequency range of 30 to 1000 MHz, and 1 MHz over frequency range of 1 to 18 GHz. Emissions to be measured are detected in average mode. 5.1.3 Unit of measurement. Test results of radiated emissions measurement are reported in microvolts per meter at the specific distance. Using the unit of dBuV on the test instrument, the indication unit was converted to field strength unit of uV/m as following method; F / S = 10 {(R+AF+CF)/20} (uV/m) here, F / S : Field Strength in uV/m,R : Meter Reading Level in dB(uV), AF : Antenna Factor in dB/m CF : Conversion Factor * 30 MHz ~ 1 GHz : CF = CL * Above 1 GHz :CF = CL – PG + FL + AL CL : Cable Loss (dB) PG : Preamplifier Gain (dB) FL : Filter Loss (dB) AL : Attenuator Lo…
