C5F7NFCMC526X15-inch Color Monitor

Model No : 526X COLOR MONITOR USER’S GUIDE 1. Read all of these instructions.2. Save these instructions for later use. 3. Unplug this monitor from thewall outlet before cleaning. Do notuse liquid cleaners or aerosolcleaners. Use a damp cloth forcleaning. 4. Do not use attachments not recommended bythe monitor manufacturer as they may causehazards. 5. Do not use this monitor near water, e.g., near abathtub, washbowl, kitchen sink, or laundry tub,in a wet basement, or near a swimming pool, etc. 6. Do not place this monitor on anunstable cart, stand, or table. Themonitor may fall, causing seriousinjury to a child or adult, andserious damage to the appliance. 7. Slots and openings in thecabinet and the back or bottom areprovided for ventilation, to ensurereliable operation of the monitor,and to protect it from overheating. These openings must not be blocked or covered.The openings should never be blocked byplacing the monitor on a bed, sofa, rug, or othersimilar surface. This monitor should never beplaced near or over a radiator or heat register.This monitor should not be placed in a built-ininstallation such as a bookcase unless properventilation is provided. 8. This monitor should be operatedonly from the type of power sourceindicated on the marking label. Ifyou are not sure of the powersupplied to your home, consult your monitor dealer or local power company. 9. This monitor is equipped with a3-wire grounding-type plug, Thatis, a plug having a third(grounding) pin. This plug willonly fit into a grounding-type power outlet. This is a safety feature. If you areunable to insert the plug into the outlet, contactyour electrician to replace your obsolete outlet.Do not defeat the purpose of the grounding-typeplug. 10. Do not allow anything to reston the power cord. Do not locatethis monitor where the cord will beabused by people walking on it. 11. Follow all warnings and instructions markedon the monitor. IMPORTANT SAFEGUARDS 12. For added protection for this monitor during a lightning storm,or when it is left unattended andunused for long periods of time,unplug it from the wall outlet. This will prevent damage to the monitor and/or thecomputer due to lightning and power line surges. 13. Do not overload wall outlets and extensioncords as this can result in fire or electric shock. 14. Never push objects of any kind into thismonitor through cabinet slots, as they may touchdangerous voltage points or short out parts thatcould result in a fire or electric shock. Never spillliquid of any kind on the monitor. 15. Do not attempt to service thismonitor yourself, as opening orremoving covers may expose youto dangerous voltages or otherhazards. Refer all servicing to qualified service personnel. 16. Unplug this monitor from the wall outlet andrefer servicing to qualified service personnelunder the following conditions: a. When the power cord or plug is damaged orfrayed. b. If liquid has been spilled into the monitor. c. If the monitor has been exposed to rain orwater. d. If the monitor does not operate normally byfollowing the operating instructions. Adjust onlythose controls that are covered by the operatinginstructions, as improper adjustment of othercontrols may result in damage and will oftenrequire extensive work by a qualified technicianto restore normal operation. e. If the monitor has been dropped or the cabinethas been damaged. f. When the monitor exhibits a distinct change inperformance, this indicates a need for service. 17. When replacement parts arerequired be sure the servicetechnician has used replacementparts specified by the manufacturerthat have the same characteristics as the original part. Unauthorized substitutionsmay result in fire, electric shock, or otherhazards. 18. Upon completion of any service or repairs tothis monitor, ask the service technician toperform routine safety checks to determine thatthe monitor is safe to operate. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Theselimits are designed to provide reasonable protection against harmfulinterference in a residential installation. This equipment generates, uses andcan radiate radio frequency energy and, if not installed and used inaccordance with the instructions, may cuase harmful interference to radiocommunications. However, there is no guarantee that interference will notoccur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined byturning the equipment off and on, the user is encouraged to try to correct theinterference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio or TV technician for help. CAUTION : Any changes or modifications not expressly approved by the party responsible for compliance could void the user ’ s authority to operate the equipment. CANADIAN NOTICEAVIS CANADIEN This Class B digital apparatus meets all requirements of the CanadianInterference-Causing Equipment Regulations. Cet appareil numérique de la Class B respecte toutes les exigences duRèglement sur le matériel brouilleur du Canada. Bitte lesen Sie alle diese Informationen, bevor Sie das Gerät in Betriebnehmen! Lesen Sie sich außerdem die Bedienungsanleitung komplettund sorgfältig durch, da nur in diesem Fall eine problemloseInbetriebnahme erwartet werden kann. • Achten Sie darauf, daß das Gerät nur in eine 230V Schuko-Steckdose eingesteckt wird. • Die Steckdose sollte jederzeit frei zugänglich sein um bei einemevtl. auftretenden Notfall das Gerät schnell vom Netz zu trennen. • Achten Sie desweiteren darauf, daß die Netzanschlußleitung nichtmechanis…

Text truncated - open the document above for the full version.

2. BLOCK DIAGRAM R,G,B SCLSDA EPROM ( 24LC08) MCU (KS88C6224) H.OSC & V.DRV (1888CT) SCL H.SYNC V.SYNC SDA ABL ADJUST DEGAUSSING CIRCUIT DEGAUSS CONTROL DPMS CONT. OUTPUT REGULATOR MAIN POWER SYNC TRANS (DST-603) H.DRV SYNC. TRIGGERING SMPS TRANSFORMER SMPS CONTROL (KA3842) +12V,+5V VIDEO POWER FBT H.DY V.DRV AMP (TDA8172) H.DRV B+ CONTROL (uPC1555C) V. DY H.SIZE & G/D C0NTROL. H. LIN COIL H.CS BLOCK H.SIZE FB SCAN B+ X-RAY PROTECT H/V CONTROL (KA7500) HV.DRV BUCK TRANS LED HCS FBP G1 CONTROL G1 MUTE CLAMP&BLANKING PULSE HIGH VOLTAGE SCREEN & FOCUS 15PIN D-SUB RECEPTACLE (02WE4E1) VIDEO PREAMP (KA2500) VIDEO OUTPUT AMP (TDA9532) OSD IC (KS2508) TACT S/W BUTTON (4 BUTTON) POWER TACT S/W 526X BLOCK DIAGRAM CRT BRIGHT CONTROL R,G,B BIAS MAIN BLOCK DIAGRAMVIDEO BLOCK DIAGRAM 80V 12V, 5V 100V, 12V 50V, -12V 5V, 6.3V B+ BUCK L. H.SYN V.SYNC ROTATION (OPTION) F/B

January 17, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:DAEWOO Electronics Co., Ltd. FCC ID: C5F7NFCMC526X Gentlemen: Submitted herewith, on behalf of DAEWOO Electronics Co., Ltd., is an application for certification of the following 15-inch color monitor: FCC ID:C5F7NFCMC526X MODEL:526X TRADE NAME:DAEWOO EUT TYPE:15-inch Color Monitor Max. Resolution:1024 x 768 Non-interlaced @ 48kHz/60Hz 800 X 600 Non-interlaced @ 54kHz/85Hz Attached is the authorization letter, measurement report (Radiation emission data, Line Conducted emission data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Joon H. Lee Chief of EMC Group DAEWOO Electronics Co., Ltd. ISRC
