Model No : L510B TFT LCD-MONITOR USER’S GUIDE http://display.dwe.co.kr 1. Read all of these instructions.2. Save these instructions for later use. 3. Unplug this monitor from thewall outlet before cleaning. Donot use liquid cleaners or aerosolcleaners. Use a damp cloth forcleaning. 4. Do not use attachments not recommendedby the monitor manufacturer as they maycause hazards. 5. Do not use this monitor near water, e.g.,near a bathtub, washbowl, kitchen sink, orlaundry tub, in a wet basement, or near aswimming pool, etc. 6. Do not place this monitor onan unstable cart, stand, or table.The monitor may fall, causingserious injury to a child or adult,and serious damage to the appliance. 7. Slots and openings in thecabinet and the back or bottomare provided for ventilation, toensure reliable operation of themonitor, and to protect it from overheating. These openings must not beblocked or covered. The openings shouldnever be blocked by placing the monitor on abed, sofa, rug, or other similar surface. Thismonitor should never be placed near or over aradiator or heat register. This monitor shouldnot be placed in a built-in installation such asa bookcase unless proper ventilation isprovided. 8. This monitor should beoperated only from the type ofpower source indicated on themarking label. If you are not sureof the power supplied to your home, consult your monitor dealer or localpower company.9. This monitor is equipped with a polarizedalternating-current line plug, This is a safetyfeature. If you’re unable to insert the plugfully into the outlet. If the plug still fails to fit,contact an electrican to replace your obsoleteoutlet. 10. Do not allow anything to reston the power cord. Do not locatethis monitor where the cord willbe abused by people walking onit. 11. Follow all warnings and instructionsmarked on the monitor. IMPORTANT SAFEGUARDS 12. For added protection for this monitor during a lightning storm,or when it is left unattended andunused for long periods of time,unplug it from the wall outlet. This will prevent damage to the monitorand/or the computer due to lightning andpower line surges. 13. Do not overload wall outlets and extensioncords as this can result in fire or electricshock. 14. Never push objects of any kind into thismonitor through cabinet slots, as they maytouch dangerous voltage points or short outparts that could result in a fire or electricshock. Never spill liquid of any kind on themonitor. 15. Do not attempt to service thismonitor yourself, as opening orremoving covers may expose youto dangerous voltages or otherhazards. Refer all servicing to qualified service personnel. 16. Unplug this monitor from the wall outletand refer servicing to qualified servicepersonnel under the following conditions: a. When the power cord or plug is damaged orfrayed.b. If liquid has been spilled into the monitor.c. If the monitor has been exposed to rain orwater.d. If the monitor does not operate normally byfollowing the operating instructions. Adjustonly those controls that are covered by theoperating instructions, as improper adjustmentof other controls may result in damage andwill often require extensive work by aqualified technician to restore normaloperation.e. If the monitor has been dropped or thecabinet has been damaged.f. When the monitor exhibits a distinct changein performance, this indicates a need forservice. 17. When replacement parts arerequired be sure the servicetechnician has used replacementparts specified by themanufacturer that have the same characteristics as the original part.Unauthorized substitutions may result in fire,electric shock, or other hazards. 18. Upon completion of any service or repairsto this monitor, ask the service technician toperform routine safety checks to determinethat the monitor is safe to operate. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Theselimits are designed to provide reasonable protection against harmfulinterference in a residential installation. This equipment generates, uses andcan radiate radio frequency energy and, if not installed and used inaccordance with the instructions, may cuase harmful interference to radiocommunications. However, there is no guarantee that interference will notoccur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined byturning the equipment off and on, the user is encouraged to try to correct theinterference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio or TV technician for help. CAUTION : Any changes or modifications not expressly approved by the party responsible for compliance could void the user ’ s authority to operate the equipment. CANADIAN NOTICEAVIS CANADIEN This Class B digital apparatus meets all requirements of the CanadianInterference-Causing Equipment Regulations. Cet appareil numérique de la Class B respecte toutes les exigences duRèglement sur le matériel brouilleur du Canada. Bitte lesen Sie alle diese Informationen, bevor Sie das Gerät in Betriebnehmen! Lesen Sie sich außerdem die Bedienungsanleitung komplettund sorgfältig durch, da nur in diesem Fall eine problemloseInbetriebnahme erwartet werden kann. • Achten Sie darauf, daß das Gerät nur in eine 230V Schuko-Steckdose eingesteckt wird. • Die Steckdose sollte jederzeit frei zugänglich sein um bei einemevtl. auftretenden Notfall das Gerät schnell vom Netz zu trennen. • Achten Sie desweiteren darauf, daß die Netzanschlußleitung nichtmechanisch beansprucht oder sonstwie beschädigt wird. • Offnen Sie das Gerät niemals! Im Inneren befinden s…

Text truncated - open the document above for the full version.

Dimming control Red(E/O) 16 Green(E/O) 16 Blue(E/O) 16 3 Dot clock Clock timing & phase Current & resistance Offset & amplifier TDA8752 R,G,B BLOCK DIAGRAM of L510B 15PIN DSUB PRE-AMP Controller Buffer (74ACT14) R(8bits) H/V sync ADC PLL Sampling clock ADI Controller Micom (MTV212M) I2C bus Power Board AC input rate - Voltage: 100~240Vac - Frequency: 50/60Hz +5V, 6.2V, +3.3V & +12V out DC-AC inverter +12V Scalar OSD Address & data line(8bits) Panel driver Back light Panel ASI320 H sync, V sync, DE & dot clock Input Video Rate - H: 30~62kHz, V: 56~85Hz - Resolution: up to 1024*768 650Vac 50KHz G(8bits) B(8bits) V sync H sync Power on/off EEPROM I2C bus +3.3V H sync 2 3 8 Clamp 12MHz 14.318MHz On-Off Output Video Rate - H: 48~62kHz, V: 60 ~ 85Hz - Resolution: only 1024*768 - Dot clock: 65 ~ 80MHz

letter to ist.jpg (1076x1328x24b jpeg)

DAEWOO Electronics Co., Ltd. Operational Description of 15inch LCD Monitor L510B (Please, refer to a block diagram attached) 1. Power The part, power supplier of SMPS type, is make DC voltage 3.3V, 5Vs, 5Va, 5Vd, 6.2V, 12V to operate a main board and a inverter from input voltage AC 100~240V of mains network. The DC3.3V & the 6.2V are supply to main board as soon as applied AC 100~240V to this board. And others is supply to a main board after to be detected on-signal from a micro controller. - DC 3.3V is supply into a scaling IC(ASI320)and LCD(LM151M-2)panel. - DC 5Vs is supply into 8-bits micro controller(MTV212MV64U). - DC 5Va is supply into a analog part of ADC IC(TDA8752B). - DC 5Vd is supply into a digital part of ADC IC(TDA8752B). - DC 6.2V is to switch ON-OFF of 3.3V supplied into LCD(LM151M-2) panel. - DC 12V is to generate a AC high voltage to light 4-back light lamp of LCD panel on a inverter. 2. Video Processing (Analog-Digital Converting) The part, ADC IC(TDA 8752B) and around circuit, is convert an analog R, G, B signals applied from a video source into a digital R, G, B data, 8bits each used by a scaling IC(ASI320). A dot clock of the ADC IC, applies to a scalier IC, is max 80MHz, but it is change according to a video resolution and a vertical refresh rate. 3. Video processing (image process) The part, scaling IC(ASI320) and around circuit, is change a resolution applied from a video source into 1024*768 and R, G, B data, 8bits each to display on LCD panel. LCD panel only supports a resolution 1024*768 and vertical refresh, 60Hz~75Hz to display. And then if applied other resolutions, the IC changes a resolution to 1024*768 and controls a frame size to fit a LCD’s needs. 14.318MHz from a crystal and a pixel clock from ADC IC are applied to operate the IC. A panel output interface of the IC is all 48bits wide low voltage TTL type, R, G, B data, 8bits(even-odd) each, And supplies Hsyn(Horizontal frequency), Vsyn(Vertical frequency), Data Enable clock, and pixel clock depending to vertical refresh to LCD panel. 4. Inverter The part only is invert DC 12V to AC 650V to light 4-back light lamp of LCD panel. And, excluding DC 12V from power supplier, supplies On- Off (active high, 5V), and brightness control signal(DC 0V~3V) from a main board. During operating to invert, transformer is switching about 50kHz to generate a AC high voltage. DAEWOO Electronics Co., Ltd. 5. 8-bits micro controller(MTV212MV64U) The part, a micro controller(MTV212MV64U) and around circuit, is control a digital level in the ADC IC, an image scaling in the scaling IC, and power functions as ON-OFF, DPMS by program. And the controller has an I 2 C(SCL, SDA) interface to communicate with ADC IC and a direct- bus to communicate with scaling IC. And an operating clock of the controller is a 12MHz. LCD Monitor Group Monitor R&D Center Display Business Division

BoardLocation No.PART-NAMEPART-DESCQuantity Inverter-LCD INVERTERBAI-15031 15" TFT LCD-LCD PANELL150X1M-21 U1IC LCD CONTROLLERAS13201 U2IC ADCTDA8752BH1 U3IC MICOMMTV212MV64U1 U4IC EEPROMAT24C08N-10SC1 U5ICTC74ACT14FN1 U6IC RESETKIA7042AF1 U7IC VOLTAGE REFERENCELM385M251 Y1CRYSTAL QUARTZHC-49/SM5H 14.318MHZ 18PF1 Y2CRYSTAL QUARTZHC-49/SM5H 12MHZ 11PF1 C801C LINE ACROSSU/C/V/S/N/D/E/SV 250V1 IC801IC POWERKA3842B1 IC802IC REGULATORKA78R051 IC803IC REGULATORKA278R331 IC805IC REGULATORKA431AZ1 IC811IC REGULATORKA78R051 L801FILTER LINEDLF-23231 T801TRANS SMPSDMT-510B1 Main Board Power Board Main Parts of Daewoo 15inch LCD Monitor

L510B_LPP(2001.1.15).sch-1 - Tue Jan 16 17:31:52 2001

File No. 01-IST-003/FB IST EMC LAB. Page 1 of 15 IST EMC Lab. San 21-8 Goan-Ri, Baekam-Myun, Yongin-Si, Kyunggi-Do, KOREA International - Tel : 82-31 - 333 - 4093. Fax : 82-31 - 333 - 4094. Domestic - Tel : 031 - 333 - 4093. Fax : 031 - 333 - 4094. IST EMC LAB. EMISSION TEST REPORT Test report file No. : 01-IST-003/FB Date of issue : Jan. 30, 2001. Model / Type No. Kind of product Applicant Manufacturer Address : L510B : TFT LCD Monitor. : Daewoo Electronics Co., Ltd : Daewoo Electronics Co., Ltd : 543, Dangjung-Dong, Kunpo-City, Kyunggi-Do, Korea. Test result according to the regulation(s) n Positive o Negative at page 3. This test report without appendix consists of 15 pages. It is not allowed to copy this report even partly without the allowance of the Test Laboratory. This equipment is complied with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992. File No. 01-IST-003/FB IST EMC LAB. Page 2 of 15 IST EMC Lab. San 21-8 Goan-Ri, Baekam-Myun, Yongin-Si, Kyunggi-Do, KOREA International - Tel : 82-31 - 333 - 4093. Fax : 82-31 - 333 - 4094. Domestic - Tel : 031 - 333 - 4093. Fax : 031 - 333 - 4094. DIRECTORY A) Documentation. Page Directory Test regulations Environmental Conditions Test Conditions Equipment under Test Test Result Test-setup (Pictures) Test-setup (Figures) Summary 2 3 3 4~5 6 7 8~9 10 15 B) Test Data. Conducted emissions (Mains) Radiated emissions : 450 kHz - 30 MHz : 30 MHz – 1 GHz 11 ~ 13 14 C) Appendix File No. 01-IST-003/FB IST EMC LAB. Page 3 of 15 IST EMC Lab. San 21-8 Goan-Ri, Baekam-Myun, Yongin-Si, Kyunggi-Do, KOREA International - Tel : 82-31 - 333 - 4093. Fax : 82-31 - 333 - 4094. Domestic - Tel : 031 - 333 - 4093. Fax : 031 - 333 - 4094. TEST REGULATIONS The tests were performed according to the following regulations ;  EN 50081-1 / 2. 1991.  EN 55011 / 3. 1991. Croup 1. Croup 2.  Class A. Class B.  EN 55014 / 4. 1993. Household appliances and similar  Portable tools  Semiconductor devices - EN 55014 / A2:1990 - EN 55015 / A1:1990  - EN 55015/ 2.1987  - EN 55015 / 12.1993 - EN 55022 / 8.1994- Class A  - Class B z - FCC Part 15, Subpart B (Unintentional Devices, Class B)  - BS  - VCCI  - CISPR All testing were conducted at IST EMC Laboratory. ENVIRONMENTAL CONDITIONS Temperature Humidity Atmospheric pressure 18 45 % 999 mbar File No. 01-IST-003/FB IST EMC LAB. Page 4 of 15 IST EMC Lab. San 21-8 Goan-Ri, Baekam-Myun, Yongin-Si, Kyunggi-Do, KOREA International - Tel : 82-31 - 333 - 4093. Fax : 82-31 - 333 - 4094. Domestic - Tel : 031 - 333 - 4093. Fax : 031 - 333 - 4094. TEST CONDITIONS The measurement of the conducted emissions (Interference voltage) was performed in a shielded room. Test location : z - Shielded room. No.1  - Compact chamber 2 Used testing instruments : TypeManufacturerCalibration. DateSerial Number z ESH 3Rohde & SchwarzOct. 08, 2000861742/018 z- 3725/2EMCOOct. 08, 20009102-1788 z- 3825/2EMCODec. 20, 20009103-1788 Test - accessories : TypeManufacturer z Aneroid BarometerSato z HygrometerSato Measurement Procedures : Conducted emissions measurments were made in accordance with ANSI C-63.4-1992, “FCC procedure for measuring RF Emissions from Computing Devices”. The measurement were performed over the frequency range of 0.45MHz to 30MHz using a 50Ω/ 50uH LISN as the input transducer to an EMI/Field Intensity Meter. The measurements were made with the detector set for “Peak” amplitude within an IF bandwidth of 10kHz or for “quasi-peak” within a bandwidth of 9kHz. All used test-instruments as well as the test-accessories are calibrated regularly. Test engineer : B. K, Bae. / Research Engineer IST EMC Lab. File No. 01-IST-003/FB IST EMC LAB. Page 5 of 15 IST EMC Lab. San 21-8 Goan-Ri, Baekam-Myun, Yongin-Si, Kyunggi-Do, KOREA International - Tel : 82-31 - 333 - 4093. Fax : 82-31 - 333 - 4094. Domestic - Tel : 031 - 333 - 4093. Fax : 031 - 333 - 4094. The measurement of the radiated emissions (Electric field) in the frequency range from 30 MHz to 1GHz was performed in horizontal and vertical antenna polarization at a open-site which meet the site attenuation requirement of ANSI C63.4-1992 and a test distance of : z - Open-site 1  - Compact chamber z - 3 meters.  - 10 meters Used testing instruments : TypeManufacturerCalibration. DateSerial Number z ESVPRohde & SchwarzJuly. 21, 2000861744/004 z VULB 9160SchwarzbeckJuly. 11, 20003048 Test - accessories : TypeManufacturer z Aneroid BarometerSato z HygrometerSato Measurement procedures Radiated measurements were in accordance with ANSI C63.4-1992 “FCC Procedure for measuring RF Emissions from Computing Devices.” The measurements were performed over the frequency range of 30MHz to 1GHz using antenna as the input transducer to a EMI/ Field Intensity Meter. The measurements were made with the detector set for “quasi-peak” within a bandwidth of 120kHz. All used test-instruments as well as the test-accessories are calibrated regularly. Test engineer : B. K, Bae. / Research Engineer IST EMC Lab. File No. 01-IST-003/FB IST EMC LAB. Page 6 of 15 IST EMC Lab. San 21-8 Goan-Ri, Baekam-Myun, Yongin-Si, Kyunggi-Do, KOREA International - Tel : 82-31 - 333 - 4093. Fax : 82-31 - 333 - 4094. Domestic - Tel : 031 - 333 - 4093. Fax : 031 - 333 - 4094. EQUIPMENT UNDER TEST Equipment Description The Equipment Under Test (EUT) is the TFT Color Monitor of Daewoo Electronics Co., Ltd. (FCC ID: C5F7NFCML510B) - Panel Size : 15-inch (38cm) diagonol - Pixel Pitch : 0.297 x 0.297 mm - Synchronization : Horizontal: 30-62 kHz / Vertical: 50-85 Hz - Max Resolution : 1024 x 768, 75 Hz (60 kHz) - Plug and Play : DDC1/2B/CI - Power Saving : EPA, VESA DPMS, Nutek Compliant - Power Source : 100-240 Vac, 50/60 Hz (Free Voltage) - Power Consumption : 30 W - Dimension (W x H x D) : 390 x 396 x 205 mm (with stand) 390 x 325 x 70.5 mm (without stand) - Weight (net/gross) : 4.6/6/1 kg (with stanad), 10/13.2 lbs …
