May 24, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Daewoo Electronics Co., Ltd. FCC ID: C5F7NFDVS103N Gentlemen: Submitted herewith, on behalf of Daewoo Electronics Co., Ltd. is an application for Certification of the following: FCC ID:C5F7NFDVS103N EUT TYPE:Video Cassette Player (VHS) Equipment Class:TV Interface Device (HID) RF Frequency Out:60 – 72 MHz Tuner Rx Freq.:54 – 806 MHz Attached is the authorization letter, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, schematic diagrams, operational description, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Seung Deug, Park Chief of Technical Planning Team Daewoo Int’l. Standards Research Center

Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd.

© 1999 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd. Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Date(s): May 19-21, 1999TV Interface Device © 1999 PCTEST LabFCC ID: C5F7NFDVS103N NVLAP Lab Code: 100431-0 DAEWOO Electronics Co., Ltd.

© 1999 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.com http://www.pctestlab.com CERTIFICATE OF COMPLIANCE DAEWOO Electronics Co., Ltd.Dates of Tests: May 19-21, 1999 International Standards Research CenterTest Report S/N: HID.990506282.C5F 543, Dangjung-Dong, Kunpo-City,Test Site: PCTEST Lab., MD U.S.A. Kyonggi-Do 435-030, KOREA Attn: Seung Deug Park – Chief of Tech. Planning Team FCC ID C5F7NFDVS103N APPLICANT DAEWOO ELECTRONICS CO., LTD. FCC Rule Part(s):Part 15.115; ANSI C63.4 (1992); MP-3 Equipment Class:TV Interface Device (HID) EUT Type:AC/DC Video Cassette Player (VHS) Tuner/RF Modulator:Hansae Mechatronics HSM-3450MV1 RF Frequency Range:60 – 72 MHz Tuner Rx Frequency:54MHz – 806MHz Trade Name(s): DAEWOO © Model(s):DV-S103N, DV-S123N This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992 (Note Codes: #37). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) Lab Code 100431-0 TV Interface Device (HID) © 1999 PCTEST Engineering Laboratory, Inc. FCC Part 15.115 TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED)5-6 LIST OF SUPPORT EQUIPMENT 7 TEST DATA (CONDUCTED) 8 TEST DATA (RADIATED) 9 OUTPUT TERMINAL SIGNAL MEASUREMENTS 10 TRANSFER SWITCH ISOLATION MEASUREMENTS 11 PLOTS OF EMISSIONS 12 ACCURACY OF MEASUREMENT 13 LIST OF TEST EQUIPMENT 14 TEST SOFTWARE USED 15 RECOMMENDATION / CONCLUSION 16 ATTACHMENT D: FCC ID LABEL & LOCATION ATTACHMENT E SCHEMATIC DIAGRAMS ATTACHMENT F:TUNER SPECIFICATIONS ATTACHMENT G:TEST SETUP PHOTOGRAPHS ATTACHMENT H: EXTERNAL PHOTOGRAPHS ATTACHMENT I: INTERNAL PHOTOGRAPHS ATTACHMENT J:USER’S MANUAL PRODUCT EVALUATION REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name:DAEWOO ELECTRONICS CO., LTD. International Standards Research Center Address:543, Dangjung-Dong, Kunpo-City Kyonggi-Do 435-030, KOREA Attention:Seung Deug, Park - Chief of Technical Planning Team •FCC ID:C5F7NFDVS103N •Classification: TV Interface Device (HID) •EUT Type:AC/DC VHS Video Cassette Player •Models : DV-S103N, DV-S123N •Tuner/RF Modulator:Hansae Mechatronics Co., Ltd. HSM-3450MV1 •FCC Rule Part(s):§ 15.115 •Test Procedures: MP-3; ANSI C63.4 (1992) •RF Freq. Range :60 - 72 MHz •RF Channels:Ch. 3/Ch. 4 •Dates of Tests: May 19-21, 1999 •Place of Tests: PCTEST Lab, Columbia, MD U.S.A. •Report Serial No.:HID.990506282.C5F NOTE: The tuner (TV receiver) were tested under the verification procedure and complied with Section 15.117 of the FCC rules. Lab Code 100431-0 Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Dates: May 19-21, 1999TV Interface Device DAEWOO FCC ID: C5F7NFDVS103N1 © 1999 PCTEST LabVHS Video Cassette Player (2 Models) Introduction The measurement procedures described in MP-3, entitled ‘‘FCC Methods of Measure- ments of Output Signal Level, Output Terminal Conducted Spurious Emissions, Trans- fer Switch Characteristics, and Radio Noise Emissions From TV Interface Devices,’’ and ANSI C63.4-1992 were used in determining EME emanating from DAEWOO Electron- ics Co., Ltd. Video Cassette Player FCC ID: C5F7NFDVS103N. These measurement tests were conducted at PCTEST Engineering Laboratory facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site ad- dress is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39°11’15" N latitude and 76°49’38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of PCTEST meas- urement facility was found to be in compliance with Federal Communications Commis- sion requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Fig. 1. The map above shows the Columbia vicinity area. The map also shows PCTest Lab, FCC Lab and BWI airport. (Scale 1"=2miles) Test Report S/N: HID.990506282.C5FFCC Part 15.115 Test Dates: May 19-21, 1999TV Interface Device DAEWOO FCC ID: C5F7NFDVS103N2 © 1999 PCTEST LabVHS Video Cassette Player (2 Models) Product Information Equipment Description: The Equipment Under Test (EUT) is the DAEWOO (Models: DV-S103N, DV- S123N) 2-head AC/DC VHS Video Cassette Player FCC ID: C5F7NFDVS103N. Format: VHS standard Video Signal:NTSC (3.58) color signal Scanning System:Rotary, slant azimuth, two-head helical scan system Video Input:1.0Vp-p, 75 ohms unbalanced, sync. negative(Phone Jack) Video Output:1.0Vp-p, 75 ohms unbalanced, sync. negative(Phone Jack) Video S/N:More than 45dB SP standard Resolution of picture:More than 210lines SP standards Tuner/RF Modulator:Hansae Mechatronics Co., Ltd. HSM-3450MV1 RF Frequency Out:60MHz - 72MHz Tuning Frequency:5…
