  1. Home/
  2. WINIA Electronics Co., Ltd./
  3. C5FDLN-17D3

C5FDLN-17D317" LCD Monitor

WINIA Electronics Co., Ltd.
17" LCD Monitor - FCC ID C5FDLN-17D3 - WINIA Electronics Co., Ltd.
Click to zoom

Application Details

Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
Date of Grant
Nov 17, 2004
Application Purpose
Original Equipment
Date of Application
Nov 17, 2004
Equipment Note
17" LCD Monitor
Company
WINIA Electronics Co., Ltd.
Country
South Korea

Documents & Files

Select a file to view

Users Manual

↗

Block Diagram

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

LCD TELEVISION INSTRUCTION MANUAL DLN-15D3SHS DLN-17D3SHS DLN-20D3AHS IMPORTANT INFORMATION FCC RF INTERFERENCE STATEMENT NOTE : This equipment has been tested and found to comply with the limit for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If these equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measure. • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Correct the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio, TV technical for help. • Only shielded interface cable should be used. 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” with- in the product’s enclosure that may be of sufficient magnitude to constitute a risk electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance. IMPORTANT INFORMATION WARNING: FCC regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. U.S.A. ONLY Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance : www.eia.org 3 SAFETY PRECAUTIONS The present set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in the present unit will protect you if you observe the following procedures in installing, using and servicing. The present unit is fully transistorized and does not contain any element that can be repaired by the user. • Read these instructions: All functional instructions must be read and understood before operating the product. • Keep these instructions: It is recommended to keep these safety guidelines and operating instructions in a safe place for future reference. • Heed all warnings: All warnings on the product and in the instructions must be observed closely. • Follow all instructions: All operating instructions must be followed. • Attachments / Accessories: Only use the attachments / accessories specified by the manufacturer. Using inadequate attachments can result in accidents. • Power source:This product must operate according to the power source indicated on the specification label. If you are not sure of the type of power supply used in your home, consult your dealer or local electric company. For the units designed to operate on batteries or another power source, refer to the operating instructions. • Power cord protection: Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Overloading: Do not overload AC outlets or extension cords. Overloading can cause fire or electric shock. • Influx of objects and liquids : Never let objects into the productthrough vents or openings. Due to the high voltage flows in the product, inserting a foreign object in the product can cause electric shock and/or shorten internal elements. For the same reason, be careful not to spill water or other liquids over the product. • Servicing: Do not attempt to service the product yourself. Removing covers can expose you to high voltage and other dangerous conditions. Request a qualified service person to perform servicing. • Repair: Unplug the AC cord from the outlet, and request a qualified service person to perform repairs when: a. The power cord or plug is damaged. b. A liquid is spilled on or an object is dropped into the product. c. The product has been exposed to rain or water. d. The product does not function properly as described in the operating instructions. Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls out of the instructions can cause damage, which often requires a qualified technician for extensive adjustments. e. The product has been dropped or damaged. f. The product displays an abnormal condition. Any noticeable abnormality in the product indicates that the product needs servicing. 4 SAFETY PRECAUTIONS • Replacement parts: In case the product needs certain parts to be replaced, make sure that the service engineer uses the replacement elements either specified by the manufacturer, or with the same characteristics and performance as original ones. Using unauthorized parts can resu…

Text truncated - open the document above for the full version.

Cover Letter(s)

1 Helen Zhao Subject:FW: Daewoo Electronics Corporation, FCC ID: C5FDLN-17D3, Assessment NO.: AN04T4352, Notice#1 -----Original Message----- From: Compliance Certification Services Client [mailto:[email protected]] Sent: Wednesday, November 17, 2004 7:47 PM To: Helen Zhao Subject: Daewoo Electronics Corporation, FCC ID: C5FDLN-17D3, Assessment NO.: AN04T4352, Notice#1 I will sent the new Block Diagram. -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Wednesday, November 17, 2004 3:56 PM To: Helen Zhao Subject: Daewoo Electronics Corporation, FCC ID: C5FDLN-17D3, Assessment NO.: AN04T4352, Notice#1 Question #1: Please indicate oscillator/crystal frequencies on the Block Diagram. Please make sure the investigation has been done up to Upper frequency of measurement range specified in FCC15.33. Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

ID Label/Location Info

ID Label Sample Location Information

Test Report

IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 04-IST-0257 1 of 18 Certification of Compliance CFR 47 Part 15 Subpart B Test Report File No. : 04-IST-0257 Date of Issue : September 22, 2004 Model(s) : DLN-17D3SHS DLN-17D3 (Buyer Model) Kind of Product : 17” LCD Monitor Applicant : Daewoo Electronics Corp. Address 543, Dangjung-Dong, Kunpo-City, Gyunggi-Do, Korea Manufacturer : Daewoo Electronics Corp. Address 295 Kongdan-dong, Kumi-City, Kyongsangbuk-Do, Korea Daewoo Electronics Manufacturing Poland SP.ZO.O. 05-800 Ruszkow, UL. Parnziewska 18, Poland Daewoo Electronics United Kingdom LTD. Rathernraw industrial Estate 62/82 Greystone Road Antrim BT41 1NU, Northern Ireland UK Daewoo Electronics Mexico, S. A. De C. V. Samuel Occana Garcia Esq. Con Revolucion, Parque Industrial, San Luis Rio Coloado, Sonora, Mexico Test Result ■ Positive □ Negative Reviewed By Approved By J. H. Lee / EMC Group Manager G. Chung / Chief - Investigations requested : Measurement to the relevant clauses of F.C.C rules and regulations Part 15 Subpart B ( Unintentional Radiators, Class B) – Class B PC Peripherals The test report with appendix consists of 18 pages. - The test result only responds to the tested sample. - It is not allowed to copy this report even partly without the allowance of IST EMC Laboratory. - This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4 2001. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 04-IST-0257 2 of 18 TABLE OF CONTENTS Table of contents 2 Test Regulations Information of test laboratory Environmental condition Measurement Uncertainty 3 Power used Product Information 4 Description of test Conducted Emission 5 Radiated Emission 6 Equipment Under Test 7 Summary 8 Test conditions and data Conducted emissions 0.15 MHz – 30 MHz Applicable Test equipment 9 Data and plots 10-11 Radiated emissions 30 MHz – 1 GHz Applicable Test equipment 12 Data and plots 13-14 Appendix A. The EUT Photos 15-16 B. The Test Setup Photos 17-18 IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 04-IST-0257 3 of 18 TEST REGULATIONS The tests were performed according to the following regulations ; FCC Part 15, Subpart B (Unintentional Radiators, Class B) INFORMATIONS OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. (FCC Filing Lab.) San 21-8, Goan-Ri, Baekam-Myun, Yongin-City Kyonggi-Do, 449-860, Korea TEL : +82 31 333 4093 FAX : +82 31 333 4094 ENVIRONMENTAL CONDITIONS Temperature 23 °C Humidity 50 % Atmospheric pressure 1004 mbar MEASUREMENT UNCERTAINTY The measurement uncertainty was evaluated for all test items listed in this report. Also it, “ The evaluation and treatment of uncertainty “, is described in IST Quality Manual according to ISO17025 Guide. The data and results described in this report are true and include evaluated uncertainty. It may cause some deviation of uncertainty by change component or process of the test for similar products. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 04-IST-0257 4 of 18 POWER SUPPLY SYSTEM USED Power supply system AC 120Vac, 60Hz (Refer to the product information) PRODUCT INFORMATION Power Requirement AC 100V-240V~, 50/60Hz Power Consumption 40W Appearance(mm) 544x358x215 Weight 7Kg Screen Size 434.38mm Aspect Ratio 16:9 Number of Pixels 1280x768 Display Color 16.2M 8bit Pixel Pitch 0.29(H)x0.29(V) Applied LCD Panel LTM170W1-L01 (Samsung) - EMC suppression device is not used during the test . IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 04-IST-0257 5 of 18 < Concept Drawing > 215 >150 >40 80 Receiver DUT LISN 80 ≥ 80 80 40 ≥ 80 Measuring apparatus Mains Filter Mains Front side Equipment under test Coaxial cable Artificial mains networ k Screened room Non-metallic support 80 DESCRIPTIONS OF TEST Conducted Emissions: The measurement were performed over the frequency range of 0.15MHz to 30MHz using a 50 Ω /50uH LISN as the input transducer to a Spectrum Analyzer or a Field Intensity Meter. The measurements were made with the detector set for "Peak" amplitude within a bandwidth of 10KHz or for "quasi-peak" & “Average” within a bandwidth of 9KHz. - Procedure of Test The line-conducted facility is located inside a shielded room No.1. A 1m X 1.5m wooden table 80cm height is placed 40cm away from the vertical wall and 1.5m away from the other wall of the shielded room. The R/S ESH3-Z5 and EMCO 3825/2 LISN are bonded to bottom of the shielded room. The EUT is located on the wooden table with distance more than 80cm from the LISN and powered from the EMCO LISN .The peripheral equipment is powered from the other LISN. Power to the LISNs are filtered by a noise cut power line filters. All electrical cables are shielded by braided tinned steel tubing with inner φ 1.2cm. If the EUT is a DC-powered device, power will be derived from the source power supply it normally will be powered from and this supply lines will be connected to the EMCO LISN. All interconnecting cables more than 1m were shortened by non-inductive bundling to a 1m length. Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up to their normal operating conditions. The RF output of the LISN was connected to the R/S receiver to determine the frequency producing the maximum emission from the EUT. The frequency producing the maximum level was reexamined using Quasi-Peak mode by manual measurement, after scanned by automatic Peak mode for frequency range from 0.15 to 30MHz. The bandwidth of the receiver was set to 10kHz. The EUT, peripheral equipment, and interconnecting cables were arranged and manipulated to maximize each EME emission. < Side View > IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 04-IST-0257 6 of 18 DESCRIPTION OF TEST Radiated Emissions: The measurement was performed over the frequency range of 30MHz to 1GHz using antenna as the input transducer to a Spectrum analyzer …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Youjin Choi(Manager)
[email protected]82-31-639-7554Fax: 82-31-639-7961

Test Firm

IST Co., Ltd.C. W Kim
[email protected]82-31-323-3012Fax: 82-31-323-3014

Technical Specifications

#Rule PartsFrequency RangePower Output
115B--
