C9O-BLPB2Wireless Blip with BLE and AIREA Radios

USER MANUAL AXS BlipBox ™ and Remote Shifter Buttons AXS BlipBox and Remote Shift Buttons User Manual Manuel d'utilisateur de AXS BlipBox et des boutons de commande des dérailleurs Manual do Utilizador de AXS BlipBox e Botões Remotos de Mudanças Bedienungsanleitung für AXS BlipBox und Fernbedienungstasten Manuale dell'utente per AXS BlipBox e pulsanti di cambio remoto AXS BlipBox およびリモート・シフト・ ボタンユーザー・マニュアル Manual de usuario de los botones de cambio a distancia, el módulo BlipBox y el desviador AXS AXS BlipBox en externe schakelknoppen Gebruikershandleiding AXS BlipBox 和遥控变速按钮用户手册 95-3018-021-000 Rev C © 2020 SRAM, LLC DRAFT 2 SAFETY INSTRUCTIONS You must read and understand the Safety Instructions document included with your product before proceeding with installation. Improperly installed components are extremely dangerous and could result in severe and/or fatal injuries. If you have any questions about the installation of these components, consult a qualified bicycle mechanic. This document is also available on www.sram.com. CONSIGNES DE SÉCURITÉ Vous devez lire et comprendre le document consacré aux instructions de sécurité livré avec votre produit avant de procéder à son installation. Des composants installés de manière inappropriée sont extrêmement dangereux et peuvent provoquer des blessures graves, voire mortelles. Pour toute question concernant l’installation de ces composants, consultez un mécanicien vélo professionnel. Ce document est également disponible sur www.sram.com. INSTRUÇÕES DE SEGURANÇA Tem que ler e compreender o documento de Instruções de Segurança, incluído com o seu produto, antes de proceder com a instalação. Os componentes instalados de forma incorrecta são extremamente perigosos e poderão resultar em lesões graves e/ou fatais. Se tiver quaisquer perguntas sobre a instalação destes componentes, consulte um mecânico de bicicletas qualificado. Este documento também está disponível em www.sram.com. SICHERHEITSHINWEISE Bevor Sie mit der Installation beginnen, müssen Sie die Ihrem Produkt beiliegenden Sicherheitshinweise gelesen und verstanden haben. Falsch montierte Komponenten stellen eine erhebliche Gefahr dar und könnten zu schweren und/oder tödlichen Verletzungen führen. Wenn Sie Fragen zur Montage dieser Komponenten haben, wenden Sie sich an einen qualifizierten Fahrradmechaniker. Dieses Dokument steht auch unter www.sram.com zur Verfügung. ISTRUZIONI DI SICUREZZA L'utente deve leggere e comprendere il documento di Istruzioni di sicurezza accluso al prodotto, prima di procedere all’installazione. I componenti, se installati in modo improprio, sono estremamente pericolosi e potrebbero essere all’origine di ferite gravi e/o mortali. In caso di domande sull’installazione di questi componenti, consultare un meccanico per biciclette qualificato. Il presente documento è disponibile anche sul sito www.sram.com. 安全にお使いいただくために 取り付けを開始する前に、製品に付属し ている安全に関する記述を必ず読み、内 容を理解してください。コンポーネント を間違って取り付けると、非常に危険な 状態になり、その結果、重度または致命 的な障害を引き起こすことがあります。 これらのコンポーネントの取り付けに関 して質問がある場合は、正規の自転車整 備士にご相談ください。このマニュアル は www.sram.comにも掲載されていま す。 INSTRUCCIONES DE SEGURIDAD Antes de proceder a la instalación de este producto, es necesario que lea y entienda perfectamente el documento de instrucciones de seguridad que lo acompaña. Unos componentes mal instalados suponen un enorme peligro y pueden ocasionar lesiones graves o incluso mortales. Si tiene alguna pregunta acerca de la instalación de estos componentes, consulte con un mecánico de bicicletas cualificado. Este documento está disponible también en la dirección www.sram.com. VEILIGHEIDSINSTRUCTIES Lees en begrijp het document met veiligheidsinstructies dat met uw product is meegeleverd voordat u met de installatie begint. Verkeerd geïnstalleerde componenten kunnen buitengewoon gevaarlijk zijn en kunnen leiden tot ernstige en/of fatale verwondingen. Als u vragen hebt over de installatie van deze componenten, raadpleeg een vakbekwame fietsenmaker. Dit document is tevens beschikbaar op www.sram.com. 安全说明 进行安装之前，您必须阅读并理解产品随 附的安全说明书。部件安装不当是极为危 险的，可能导致严重甚至致命的人身伤 害。如果您对部件安装有任何疑问，请 咨询专业自行车技工。本文件也发布在 www.sram.com上。 DRAFT 3 Tools and Supplies 7 Werkzeuge und Material Herramientas y accesorios Outils et accessoires Strumenti e forniture Gereedschap en benodigdheden Ferramentas e Produtos a Usar ツールおよび付属品 工具和用品 Compatibility 8 Kompatibilität Compatibilidad Compatibilité Compatibilità Compatibiliteit Compatibilidade 適合性 兼容性 SRAM AXS App 9 SRAM AXS App Aplicación SRAM AXS Application SRAM AXS App SRAM AXS SRAM AXS app App AXS da SRAM SRAM AXS アプリ SRAM AXS 应用程序 BlipBox Overview 10 Übersicht über die BlipBox Descripción general del BlipBox Aperçu de la BlipBox Panoramica della BlipBox BlipBox overzicht Perspectiva geral do BlipBox BlipBox の概要 BlipBox 概述 MultiClic Overview 11 Übersicht über die MultiClic-Fernbedienung Descripción general del MultiClic Aperçu des MultiClics Panoramica MultiClic MultiClic overzicht Perspectiva geral do MultiClic MultiClic の概要 MultiClic 概述 Wireless Blip Overview 12 Wireless Blip Overview Wireless Blip Overview Wireless Blip Overview Wireless Blip Overview Wireless Blip Overview Wireless Blip Overview Wireless Blip Overview Wireless Blip Overview Blip Overview 13 Übersicht über die Blip-Fernbedienung Descripción general de Blip Aperçu du Blip Panoramica Blip Blip overzicht Perspectiva geral do Blip Blip の概要 Blip 概述 Clic Overview 14 Übersicht über die Clic-Fernbedienung Descripción general de Clic Aperçu du Clic Panoramica Clic Clic overzicht Perspectiva geral do Clic Clic の概要 Clic 概述 System Pairing 15 Koppeln des Systems Emparejamiento del sistema Synchronisation du système Accoppiamento del sistema Het systeem koppelen Emparelhamento de sistema システムのペアリング 系统配对 BlipBox Installation 19 Montage der BlipBox Instalación del BlipBox Installation de la BlipBox Installazione della BlipBox BlipBox installatie Instalação do BlipBox BlipBox の取り付け BlipBox 安装 DRAFT 4 Mount Installation 19 Montage der Befestigung Instalación con soporte Inst…

Text truncated - open the document above for the full version.

95-3018-022-000 Rev B 1 © 2019 SRAM, LLC Electronic Regulatory Compliance Manual 2 Electronic Regulatory Compliance Manual 3 Konformitätserklärung für elektronische Geräte 4 Manual de cumplimiento de la normativa electrónica 5 Manuel sur le respect des règlements concernant l'électronique 6 Manuale di Conformità Normativa Elettronica 7 Handleiding over de regelnaleving voor elektronische apparatuur 8 Manual de Conformidade com os Regulamentos de Electrónica 9 電子関連規制コンプライアンス・マニュアル 10 电子监管合规手册 11 Elektroniczny podręcznik zgodności z przepisami 12 Vedledning vedr. overholdelse af regulativer for elektronik 13 Příručka shody se zákonnými nařízeními pro elektroniku 14 Manual de conformare reglementări echipamente electronicei 15 Εγχειρίδιο ρυθμιστικής συμμόρφωσης σχετικά με τα ηλεκτρονικά 16 전자규정 준수를 위한 안내 17 電子監管合規手冊 18 Руководство по соответствию нормативным требованиям электронного устройства 2 Complies with ID A Standards D A107248 HIDF16000136 HIDF16000136 Electronic Regulatory Compliance Manual SRAM LLC certifies that this product and its packaging are in compliance with: RE Directive, the Radio Equipment Directive 2014/53/EC WEEE Directive, the Waste Electrical and Electronic Equipment Directive 2012/19/EU RoHS Directive, the restriction of the use of certain hazardous substances in electrical and electronic equipment 2002/95/EC REACh Directive, the Regulation on Registration, Evaluation, Authorization and Restriction of Chemical Directive 1907/2006/EC Batteries and Accumulators and Waste Batteries and Accumulators Directive 2006/66/EU This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. This device complies with Industry Canada’s license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The term “IC”: before the radio certification number only signifies that Industry Canada technical specifications were met. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L 'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. RF Radiation Exposure Statement: Models 00010, 00110, 00210, 12810, 12910, 13200, 00220, 12920, 00030, 00130, 00020, 00120, 13000, 13100, 00500, 00601, 00610, 65501, 00230 and 09601 have been tested and complies with IC RSS 102 RF radiation exposure limits set forth for an uncontrolled environment when used with SRAM accessories supplied or designated for this product. To satisfy IC exposure requirements, a separation distance of at least 1.5 cm must be maintained between the antenna of this device and persons during device operation. The use of any other accessories may not ensure compliance with IC RSS 102 RF exposure guidelines. Declaration d'exposition aux radiations: Les modèles 00010, 00110, 00210, 12810, 12910, 13200, 00220, 12920, 00030, 00130, 00020, 00120, 13000, 13100, 00500, 00601, 00610, 65501, 00230 et 09601 ont été testés conformemment aux normes d'exposition d'emission RF de la IC RSS 102 pour un environement non controle lors d'utilisation avec les accessoires fournis or recommendes par SRAM. Pour satisfaire aux exigences d'exposition IC, une distance de separation d'au moins 1.5 cm doit etre maintenue entre l'antenne de cet appareil et des personnes pendant le fonctionnement de l'appareil. L'utilisation d'accessoires autres que ceux recommendes par SRAM ne guarantis pas la compatibilite avec les normes d'emission RF de la IC RSS 102. Warning: Any changes or modifications not expressively approved by SRAM could void the user's authority to operate this equipment. This product is ANT+ certified and complies with the bicycle power ANT+ Device Profile. For a complete listing of ANT+ Certified Products and their specific interoperability, please visit www.thisisant.com. 3 Complies with ID A Standards D A107248 HIDF16000136 HIDF16000136 Electronic Regulatory Compliance Manual Model #FCC IDIC ID TRA Dealer No: DA51171/16 ISRAEL מספר אישור אלחוטי של משרד התקשורת אסור להחליף את האנטנה המקורית של המכשיר ולא לעשות בו כל שינוי טכני אחר Left Shifter00010C90-LSBB110161A-LSBB1ER648161/1855-00222 Right Shifter00110C90-RSBB110161A-RSBB1ER64862/1855-00223 BlipBox00210C90-BOXB110161A-BOXB1ER64863/1855-00224 Front Derailleur12810C90-FDB110161A-FDB1ER64864/1855-00225 Rear Derailleur12910C90-RDB110161A-RDB1ER64865/1855-00226 Seatpost13200C90-…

Text truncated - open the document above for the full version.

Date: April 7, 2021 UL Verification Services I nc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant Sincerely Yours, Leo Yermakov Regulatory Compliance Manager SRAM LLC

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: C9O-BLPB2 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 180 days from date of the Grant of Equipment Authorization. External Photos Internal Photos Set-up Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and that information will be available for public review once the grant of equipment authorization is issued. Best Regards Leo Yermakov Regulatory Compliance Manager SRAM LLC April 7, 2021

A DRAWING NUMBERREVISION DRAWING NAME/DESCRIPTION CONFIDENTIAL - THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO SRAM CORPORATION AND MAY NOT BE DISCLOSED WITHOUT PERMISSION. FORMAT: A3SHEET: 1/1 ALL DIMENSIONS ARE mm UNSPECIFIED LENGTH TOLERANCE X.X +/- 0.5 DO NOT SCALE DRAWING UNSPECIFIED ANGLE TOLERANCE +/- 2degrees GEOMETRIC DIMENSIONING AND TOLERANCING TO BE INTERPRETED PER ASME Y 14.5-2009 DOCUMENT MAY NOT REPRESENT COMPLETE REQUIREMENTS. REFER TO PRODUCT STRUCTURE ACMAYINITIAL REVISION A B C D E F G REVRESPONSIBLEREVISION RECORD 12345678910 12345678910 A B C D E F G 100mm 3.5 6.1 NOT TO SCALE DESCRIPTION PART NUMBER ARTWORK CERT WIRELESS BLIP 23MAR20

NVLAP LAB CODE 200065-0 TEST REPORT Report Number. : 13487070-E3V2 Applicant : SRAM LLC 1000 W Fulton Market 4 th Floor Chicago, IL 60607, United States Model : 09601 FCC ID : C9O-BLPB2 EUT Description : Wireless Blip with BLE and AIREA Radios Test Standard(s) : FCC Part 1 Subpart I FCC Part 2 Subpart J Date Of Issue: May 13, 2021 Prepared by: UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538 U.S.A. TEL: (510) 319-4000 FAX: (510) 661-0888 REPORT NO: 13487070-E3V2 DATE: 5/13/2021 FCC ID: C9O-BLPB2 Page 2 of 6 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By V1 4/9/2021 Initial Issue -- V2 5/13/2021 Updated Section 8.1 Kiya Kedida REPORT NO: 13487070-E3V2 DATE: 5/13/2021 FCC ID: C9O-BLPB2 Page 3 of 6 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. REFERENCES ................................................................................................................... 5 4. FACILITIES AND ACCREDITATION ................................................................................. 5 5. DEVICE UNDER TEST ....................................................................................................... 5 6. MAXIMUM OUTPUT POWER ............................................................................................ 5 7. RF EXPOSURE RESULTS ................................................................................................. 5 8. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS .......................................... 6 8.1. FCC ............................................................................................................................. 6 REPORT NO: 13487070-E3V2 DATE: 5/13/2021 FCC ID: C9O-BLPB2 Page 4 of 6 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SRAM LLC 1000 W Fulton Market 4 th Floor Chicago, IL 60607, United States EUT DESCRIPTION: Wireless Blip with BLE and AIREA Radios MODEL: 09601 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J Complies UL Verification Services Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. All samples tested were in good operating condition throughout the entire test program. Measurement Uncertainties are published for informational purposes only and were not taken into account unless noted otherwise. This document may not be altered or revised in any way unless done so by UL Verification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL Verification Services Inc. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of the U.S. government. Approved & Released For UL Verification Services Inc. By: Reviewed By: Dan Coronia Kiya Kedida Operations Leader Senior Project Engineer Consumer Technology Division Consumer Technology Division UL Verification Services Inc. UL Verification Services Inc. REPORT NO: 13487070-E3V2 DATE: 5/13/2021 FCC ID: C9O-BLPB2 Page 5 of 6 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. 2. TEST METHODOLOGY All calculations were made in accordance with FCC KDB 447498. 3. REFERENCES All measurements were made as documented in test report UL Verification Services Inc. Document 13487070-E1 & 13487070-E2 for operation in the 2.4 GHz band and UL Verification Services Inc. Output power, Duty cycle and Antenna gain data is excerpted from the applicable test reports or client declarations. 4. FACILITIES AND ACCREDITATION The test sites and measurement facilities used to collect data are located at 47173 and 47266 Benicia Street, Fremont, California, USA. UL Verification Services Inc. is accredited by NVLAP, Laboratory Code 200065-0. The full scope of accreditation can be viewed at http://nist.gov/standards/scopes/2000650.htm. 5. DEVICE UNDER TEST The EUT is an Wireless Blip with BLE and AIREA Radios, powered by CR2032 battery, BLE operating in the frequency range of 2402 to 2480MHz and AIREA operating in the frequency range of 2405 to 2475MHz . 6. MAXIMUM OUTPUT POWER The maximum output power of the device is declared as the following: BLE = Power: 6dBm; Antenna Gain: -6.2 dBi AIREA = Power: 6dBm; Antenna Gain: -6.2 dBi The antenna(s) gain and type, as provided by the manufacturer…
