BPA-5CC-7 1.99–2.5 GHz 5W Power Amplifier Installation and Operation Manual Doc #6051407907 Rev - Broadcast Microwave Services, Inc. 12367 Crosthwaite Circle Poway, CA 92064 Tel: +1 (858) 391-3050 | Toll-free (US): 800-669-9667 Fax: +1 (858) 391-3049 [email protected] bms-inc.com © 2008 All rights reserved. Broadcast Microwave Services, Inc. Specifications are subject to change without prior notice. This document contains confidential information and is intended for customer use only. It cannot be duplicated without prior authorization from BMS. BPA-5CC-7 1.99–2.5GHz 5W Power Amplifier Manual | Doc #6051407907 Rev - Broadcast Microwave Services, Inc. i WARNING! RF RADIATION EXPOSURE HAZARD • This warning is provided by Broadcast Microwave Services (BMS) Inc. for safety purpose. • The following information help to reduce the risk of RF exposure hazard. FCC Limit of RF Exposure According to the Federal Communication Commission (FCC), the Maximum Permissible Exposure (MPE) for RF radiation has been set to 1.0 mW/cm2 for the 1.99–2.5GHz linear power amplifier with maximum of 5 watts output power (OET Bulletin 65) for operation under part 90 of FCC regulations (47CFR90). The 1.99–2.5GHz power amplifier (PA) may be a part of a non-broadcast transmitter, and without an antenna it will not create RF exposure (power density) exceeding the 1.0 mW/cm2 FCC limit. However, a high-gain antenna such as a parabolic dish will greatly enhance the PA output power density beyond the MPE limit of 1.0 mW/cm2. In this situation a minimum distance from the antenna must be calculated in order to keep the MPE always below the safety limit. The calculation has been done for the PA based on the formula mentioned in OET Bulletin 56. The calculations have been done for different commonly used antenna in the BAS and Public Safety/Law enforcement applications. Figure 1 shows the plot of the minimum exposure distance for 5dBi, 16dBi, and 30dBi antennas, assuming the PA transmits the maximum power of 5 W. The minimum exposure distances are found from the cross points of the exposure graphs (for various antennas) with the line of maximum permissible exposure (i.e. 1mW/cm2). Notice that the numbers in Figure 1 predict the worse case scenario, which is straight in front of the antenna (exposing the antenna’s main lobe). Obviously the side-lobe exposures are well below these numbers as the radiation intensity drops dramatically on the side lobes. The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The user and installer must provide suitable operating procedures and warnings to meet MPE requirements when operating the PA into an antenna. Operational Limits and User Access CAUTION! • Do not 5A peak load in optional accessory equipment! • Do not exceed -12dBm average input power! NOTE There are NO user adjustable components in the amplifier! BPA-5CC-7 1.99–2.5GHz 5W Power Amplifier Manual | Doc #6051407907 Rev - Broadcast Microwave Services, Inc. ii Contents 1 Product Description ...........................................................................................................................1 1.1 RF Exposure ............................................................................................................................1 1.2 Linear Power Amplifier (BPA-5CC-7) Description.....................................................................2 1.3 Specifications ...........................................................................................................................3 1.4 Applications ..............................................................................................................................3 2 Installation ..........................................................................................................................................5 2.1 Installation Notes and Wiring Diagram.....................................................................................5 3 Warranty..............................................................................................................................................8 3.1 Customer Service and Contact Information..............................................................................8 4 Appendix .............................................................................................................................................9 4.1 Labels .......................................................................................................................................9 List of Figures Figure 1. Estimated RF exposure ................................................................................................................1 Figure 2. Parts locations ..............................................................................................................................2 Figure 3. External view ................................................................................................................................2 Figure 4. Typical application block diagram.................................................................................................4 Figure 5. Typical application ........................................................................................................................4 Figure 6. Pin-out for PTO connector, MS3112E14-5P.................................................................................5 Figure 7. PA wiring diagram ........................................................................................................................6 Figure 8. PA chassis footprint......................................................................................................................6 Figure 9. PA chassis dimensions.................................................................................................................7 Figure 10. BMS product label ................…

Text truncated - open the document above for the full version.

Broadcast Microwave Services, Inc. 12367 Crosthwaite Circle ⋅ Poway, CA 92064-6817 Phone: 858-391-3050 ⋅ Toll-free: 800-669-9667 ⋅ Fax: 858-391-3049 ⋅ Web: www.bms-inc.com May 12, 2008 Mr. Alan Laudani Certification Agent Nemko USA 11696 Sorrento Valley Road San Diego, CA 92121 Subject: Application and intended use of the BPA-5CC-7 5W Power Amplifier, FCC ID CNVHCII-5-7 References: (1) FCC email concerning type certification of CNVHCII-5-7 (2) FCC web site for Nextel reallocation (3) BMS BPA-5CC-7 Installation and Operation Manual (4) BMS web site marketing information, BPA 5/10W amplifiers Dear Sir/Madam: In regards to the additional material required to address “...filing should include attestation from applicant concerning application purpose and intended device marketing and use related to FCC WTB 2 GHz Relocation...”, BMS includes the following description and references to address this matter. BMS produces power booster amplifiers suitable for OFDM transmission. The BPA-5CC-7 may be used as part of a transmission system for electronic news gathering (ENG) broadcast television signals. When operated with a BMS exciter, the system meets FCC requirements under part 74 Broadcast Auxiliary Services for mobile relay stations for both the existing and reallocation channel plans. No adjustments are necessary. The operator may change channel plans at any time. The BMS system may be licensed for dual use, both in the existing BAS 2 GHz channel plan (1990-2025 MHz) and Nextel reallocation channel plan (2025-2110 MHz). The BPA-5CC-7 may also be used in the same application by public safety agencies in an inter-service sharing, Part 74 BAS and Part 90 Private Land Mobile Radio Service. Please note, the BPA-5CC-7 (FCC ID CNVHCII-5-7) is a 5 Watt amplifier and was certified under Parts 74 and 90. Regards, Graham Bunney, President/General Manager Broadcast Microwave Services, Inc. Reference 1 Re: FCC ID: CNVHCII-5-7 Applicant: Broadcast Microwave Services Inc Correspondence Reference Number: 50883 Form 731 Confirmation Number: TC436086 Date of Original E-mail: 04/17/2008 ...filing should include attestation from applicant concerning application purpose and intended device marketing and use related to FCC WTB 2 GHz Relocation (http://wireless.fcc.gov/services/index.htm?job=service_home&id=broadcast_auxiliary#2 GHz Relocation) - see also FCC documents FCC-03-280, DA-05-2223 - 18 MHz channel bandwidth is allowed for part 74 grants (at least until transition accomplished), but new grant devices should also have 12 MHz mode Reference 2 http://wireless.fcc.gov/services/index.htm?job=service_home&id=broadcast_auxiliary#2%20GHz%20Rel ocation Broadcast Auxiliary stations are used for relaying broadcast aural and television signals. ... The Broadcast Auxiliary services also include mobile TV pickups and remote pickup stations which relay signals from a remote location, back to the studio. 2 GHz Relocation BAS licensees in the 1990-2025 MHz band ("2 GHz band") are subject to relocation (for emerging technologies such as PCS, MSS) to a new BAS channel plan in the 2025-2110 MHz band. Reference 3 BPA-5CC-5-7 1.99–2.5 GHz 5W Power Amplifier Installation and Operation Manual (BMS Doc #6051407907 Rev -) 1.4 Applications Portable digital video COFDM transmitters, such as the BMS 2GHz CarryCoder II, are used behind the camera in electronic news gathering (ENG) for mobile broadcast auxiliary stations (BAS). These transmitters can only provide a medium RF power (e.g. < 1W), limiting the distance between the event site and relay station. To extend the transmission range, an external amplifier is needed to boost the transmitter power in order to compensate the path loss and ensure the acceptable Received Signal Level (RSL) at the destination. The BPA-5CC-7 will increase the RF power to the maximum 10W without adding spurious signals and distortions to the transmitter output. The power amplifier output is directly connected to the 2GHz transmitting antenna. Reference 4 http://www.broadcast-microwave-services.com/index.php?id=185 Linear Power Amplifier: The BPA-(x)-CC is a 5 or 10 W linear power amplifier that increases the transmission range of several BMS transmit systems.

Broadcast Microwave Services, Inc. 12367 Crosthwaite Circle ⋅ Poway, CA 92064-6817 Phone: 858-391-3050 ⋅ Toll-free: 800-669-9667 ⋅ Fax: 858-391-3049 ⋅ Web: www.bms-inc.com January 30, 2008 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification FCC ID: CNVHCII-5-7 Authority to Act as Agent On our behalf, I appoint Alan Laudani of Nemko USA, 11696 Sorrento Valley Road, San Diego, CA to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc. still resides with Broadcast Microwave Services, Inc. 12367 Crosthwaite Circle, Poway, CA 92064. Dated this 30 th day of January 2008 Agency agreement expiration date: February 2008 By: Graham Bunney Signature Printed Title: President On behalf of: Broadcast Microwave Services, Inc. Telephone: 858-391-3050 x105

Broadcast Microwave Services, Inc. 12367 Crosthwaite Circle ⋅ Poway, CA 92064-6817 Phone: 858-391-3050 ⋅ Toll-free: 800-669-9667 ⋅ Fax: 858-391-3049 ⋅ Web: www.bms-inc.com January 30, 2008 Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA RE: FCC ID: CNVHCII-5-7, Request of Confidentiality for FCC ID: CNVHCII-5-7 Pursuant to Sections 0.457(d)(I)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics, Parts List, Operating Description, Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(I)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Graham Bunney President, Broadcast Microwave Services, Inc.

FCC LABEL

CNVHCII-5-7 Interior Product Photos Final Board DC Routing Board w/ Power Supply Driver Board Pre-driver Board RF Output Power In RF Input CNVHCII-5-7 Interior Product Photos Final Board (top/bottom) CNVHCII-5-7 Interior Product Photos DC Routing w/ Power Supply (top/bottom) CNVHCII-5-7 Interior Product Photos Driver Board (top/bottom) CNVHCII-5-7 Interior Product Photos Pre-driver Board (top/bottom)

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power --Conducted36.989dBm 4.999(W) Antenna gain(typical):30.00(dBi) Maximum antenna gain:1000.00(numeric) Prediction distance:625.00(cm) Prediction frequency:2483.50(MHz) Limit from table below:1(mW/cm^2) Power density at prediction frequency:1.0(mW/cm^2) EUT complies FCC/LSGAC Local Official’s Guide to RF A LOCAL GOVERNMENT OFFICIAL'S GUIDE TO TRANSMITTING ANTENNA RF EMISSION SAFETY: RULES, PROCEDURES, AND PRACTICAL GUIDANCE 2 4R PG S π =

Nemko USA, Inc. Phone (858) 755-5525 Fax (858) 452-1810 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 Test Report: 2007 129154 FCC Applicant: Broadcast Microwave Services 12367 Crosthwaite Circle Dock 10 Poway, CA 92064 (858) 391-3050 x107 (858) 391-3049 - fax Equipment Under Test: 5W Linear Power Amplifier Model: BPA-5CC-7 FCC ID: CNVHCII-5-7 In Accordance With: FCC PART 2, FCC PART 74 Subpart F and FCC PART 90 Subpart I Tested By: Nemko USA Inc. 11696 Sorrento Valley Road San Diego, CA 92121-1024 Date: December 11, 2007 Total Number of Pages: 36 Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 - Fax (858) 452-1810 DATE DOCUMENT NAME DOCUMENT # PAGE December 11, 2007 5W Linear Power Amplifier BPA-5CC-7 - FCC Test Report FCC ID: CNVHCII-5-7 2007 129154 FCC 2 of 37 Page 2 of 37 DOCUMENT HISTORY REVISION DATE COMMENTS - December 11, 2007 Prepared By: F.S.Custodio - December 11, 2007 Initial Release: Alan Laudani NOTE: Nemko USA, Inc. hereby makes the following statements so as to conform to Chapter 10 (Test Reports) Requirements of ANSI C63.4: 2003 “Methods and Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz”: o The unit described in this report was received at Nemko USA, Inc.'s facilities on November 21, 2007. Testing was performed on the unit described in this report on November 21, 2007 to December 10, 2007. o The Test Results reported herein apply only to the Unit actually tested, and to substantially identical Units. o This report does not imply the endorsement of the Federal Communications Commission (FCC), NVLAP or any other government agency. This Report is the property of Nemko USA, Inc., and shall not be reproduced, except in full, without prior written approval of Nemko USA, Inc. However, all ownership rights are hereby returned unconditionally to Broadcast Microwave Services, and approval is hereby granted to Broadcast Microwave Services and its employees and agents to reproduce all or part of this report for any legitimate business purpose without further reference to Nemko USA, Inc. Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 - Fax (858) 452-1810 DATE DOCUMENT NAME DOCUMENT # PAGE December 11, 2007 5W Linear Power Amplifier BPA-5CC-7 - FCC Test Report FCC ID: CNVHCII-5-7 2007 129154 FCC 3 of 37 Page 3 of 37 Table of Contents Section 1. Summary of Test Results...............................................................................5 Section 2. General Equipment Specification.................................................................6 Section 3. RF Power Output..............................................................................................7 Section 4. Modulation Characteristics..........................................................................11 Section 5. Occupied Bandwidth.....................................................................................15 Section 6. Spurious Emissions At Antenna Terminals.............................................20 Section 7. Field Strength of Spurious...........................................................................28 Section 8. Frequency Stability........................................................................................30 Section 9. Test Equipment List.......................................................................................31 APPENDICES Section 6. Spurious Emissions At Antenna Terminals.............................................32 Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 - Fax (858) 452-1810 DATE DOCUMENT NAME DOCUMENT # PAGE December 11, 2007 5W Linear Power Amplifier BPA-5CC-7 - FCC Test Report FCC ID: CNVHCII-5-7 2007 129154 FCC 4 of 37 Page 4 of 37 CERTIFICATION Nemko USA, Inc., an independent Electromagnetic Compatibility (EMC) Test Laboratory, produced this Test Report and performed the Radio Frequency Interference (RFI) testing and data evaluation contained herein. Nemko USA, Inc.’s measurement facility is currently registered with the United States Federal Communications Commission (FCC) in accordance with the provisions of 47 United States Code (CFR) Part 2, Subpart I, Section 2.948(a). A current description of Nemko USA, Inc.’s measurement facility is on file with the FCC. Nemko USA Inc. has additionally satisfied the FCC that it complies with the requirements set forth in 47 CFR Part 2, Subpart I, Section 2.948(d) regarding the accreditation of EMC laboratories. As a result, the FCC has placed Nemko USA Inc. on its list of EMC laboratories approved to perform Declaration of Conformity (DOC) procedure testing. The RFI testing, test data collection and test data evaluation were accomplished in accordance with the ANSI C63.4: 2003 Standard, and in accordance with the applicable sections of the FCC rules (47 CFR Parts 2 and 18)." digital devices. The testing was also accomplished in accordance with Industry Canada's ICES-003 standard for unintentional radiating device per EMCAB-3, Issue 3 (May 1998). The administrative summary of this test report provides a description of the test sample I hereby certify that the test data, test data evaluation, and equipment configurations used to compile this test report are a true and accurate representation of the test sample’s radio frequency interference characteristics as of the test date(s), and, for the design of the test sample. Alan Laudani, RF/EMC Test Specialist Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 - Fax (858) 452-1810 DATE DOCUMENT NAME DOCUMENT # PAGE December 11, 2007 5W Linear Power Amplifier BPA-5CC-7 - FCC Test Report FCC ID: CNVHCII-5-7 2007 129154 FCC 5 of 37 Page 5 of 37 Section 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equ…
