CWU-WAP250GWIRELESS ACCESS POINT

WA6102-ZZ SAP2315A 802.11b/g Access Point Management Guide Management Guide Guide 802.11b/g Access Point IEEE 802.11b/g Wireless Access Point SAP2315A E062006-EK-R01 FEGFT2315000E v Table of Contents Chapter 1: Initial Configuration 1-1 Logging into the Web Interface 1-1 Using the Setup Wizard 1-2 Chapter 2: System Configuration 2-1 Information 2-3 System 2-3 Client 2-4 Network 2-5 Event Log 2-6 System Settings 2-7 Administration 2-7 Operation Mode 2-8 Reboot System 2-8 Wireless VAP Settings 2-10 Basic 2-10 Channel Setting 2-11 WEP Security 2-11 WPA-PSK Security 2-12 Network Settings 2-14 DHCP Client 2-14 DHCP Server/NAT 2-15 PPPoE 2-17 Time and Log 2-18 Updating Firmware 2-20 Upgrade via the Web Page 2-20 Upgrade via a Remote Server 2-20 Appendix A: Troubleshooting A-1 Glossary Index vi Contents 1-1 Chapter 1: Initial Configuration The Access Point offers a user-friendly web-based management interface for the configuration of all the unitís features. Any PC directly attached to the unit can access the management interface using a web browser, such as Internet Explorer (version 5.0 or above). The initial configuration steps can be made through the web browser interface using the Setup Wizard. It is recommended to make the initial changes by connecting a PC directly to the access point before installing it in its intended location. The access point has a default IP address of 192.168.1.20 and a subnet mask of 255.255.255.0. If your PC has an IP address on the same subnet (that is, the PC and access point addresses both start 192.168.1.x), you can connect immediately to the web interface. Otherwise, you must first change your PCís IP address to be on the same subnet as the access point. Logging into the Web Interface In the web browserís address bar, type the default IP address: http://192.168.1.20. The web browser displays the access pointís login page. The User ID is fixed as ìadmin.î There is no default password, so just leave the Password box blank and click LOGIN. Note:It is strongly recommended that you configure a password. If a password is not configured, the management interface is not protected and anyone that can connect to the access point may be able to compromise your network security. For information on configuring a password, see ìAdministrationî on page 2-7. Figure 1-1. Login Page Initial Configuration 1-2 1 The home page displays the Main Menu. There are two options available, you can configure the basic features of the access point using the Setup Wizardís simple steps, or you can configure all features in detail using the Advanced Setup menu. Figure 1-2. Home Page Using the Setup Wizard There are only a few basic steps you need to set up the access point and provide a connection for your Wi-Fi phone and network access for other wireless stations. The Setup Wizard takes you through configuration procedures for the general network settings, such as IP configuration, wireless network name (Service Set Identifier), and wireless security. Follow these steps: 1.Launch the Setup Wizard ñ Click ìStart with Setup Wizardî on the home page. Using the Setup Wizard 1-3 1 2.Operation Mode Setting ñ Select an operation mode according to how your divice will function. Figure 1-3. Setup Wizard - Network Setting (AP) There are three operation modes: ïAP ó Set the device as an Access Point. ïRepeater ó Set the device as a Wireless Repeater to relay messages between subnetworks that use different protocols or cable types. The Root AP MAC Address can be assigned manually or selected after click ìScanî. Figure 1-4. Setup Wizard - Network Setting (Repeater) Initial Configuration 1-4 1 ïBridge ó Set the device as a Wireless Bridge to connect two local-area networks (LANs), or two segments of the same LAN that use the same protocol. The Bridge Nodes need to be assigned manually by the user. Figure 1-5. Wizard - Network Setting (Repeater) Using the Setup Wizard 1-5 1 3.Network Setting ñ Sets the access pointís IP address assignment method and configures the local Dynamic Host Configuration Prototcol (DHCP) server and Network Address Translation (NAT) settings. Figure 1-6. Setup Wizard - Network Setting There are three basic methods for configuring the access pointís IP address: ïDynamic IP ó The IP address is assigned automatically from a home gateway router or other device that has a DHCP server feature. ïPPPoE ó The IP address is assigned automatically from an Internet service provider (ISP) through an ADSL modem using Point-to-Point Protocol over Ethernet (PPPoE). If your ISP has provided you with a user name and password, enter these in the corresponding text boxes under PPPoE Setting. ïStatic IP ó The IP address is assigned manually by the user. This may be required if your access point is connected to a home gateway router or other device that does not support a DHCP server. If you select Static IP, enter an appropriate IP address and subnet mask that are compatible with your existing network. If a management station exists on another network segment, then you must enter the IP address for a Default Gateway that can route traffic between these segments. Also enter the IP address for the Domain Name Server (DNS) to be used for host-name to IP address resolution. Initial Configuration 1-6 1 Figure 1-7. Setup Wizard - DHCP Server and NAT Settings DHCP Server/NAT Setting ó This access point includes a DHCP server that can assign IP addresses to any wireless station or Wi-Fi phone requesting the service. Addresses are assigned from a common address pool configured on the access point. You can configure the address pool by specifying start and end IP addresses. NAT is a standard method of mapping multiple ìinternalî IP addresses to one ìexternalî IP address on devices at the edge of a network. For the access point, the internal (local) IP addresses are the IP addresses assigned to wireless clients by the DHCP server, and the external IP address is the IP address assigned to the access point itse…
