DGZH0001RF Controlled Duplex Receptacle

Intermatic Inc
RF Controlled Duplex Receptacle - FCC ID DGZH0001 - Intermatic Inc
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Mar 04, 2007
Application Purpose
Original Equipment
Date of Application
Mar 04, 2007
Equipment Note
RF Controlled Duplex Receptacle
Frequency Range
908.42000000 - 908.42000000
Company
Intermatic Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Request for Confidentiality Date: February 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: DGZH0001 Pursuant to 47 CFR Section 0.459 Intermatic, Inc understands that requests for non disclosure and confidential treatment is being made for the following information as stated under the Code of Federal Regulations Chapter 47, Part 0.459 and behalf of APPLICANT NAME: • Block Diagram • Schematics • Technical Product Description The above materials contain trade secrets, proprietary and technical information that would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Intermatic, Inc understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

Cover Letter(s)

Letter of Agency Date: February 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that Intermatic, Inc authorizes D.L.S. Electronic Systems, Inc. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signatory, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. FCC Labeling Requirements and Information Date: February 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: DGZH0001 The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Sincerely, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Modification Letter Date: February 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: DGZH0001 Please be advised that the following information is a list of modifications that will be included in the production process for the above-referenced equipment. Change 1: There were no modifications made during testing. Change 2: Change 3: Change 4: Change 5: Change 6: Change 7: Change 8: Change 9 Change 10: Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Manufacturer’s Letter Date: February 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: DGZH0001 To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

Cover Letter(s)

FCC ID: DGZH0001 D.L.S. ELECTRONIC SYSTEMS, INC. 1250 Peterson Drive Wheeling, Illinois 60090 FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21045-0429 Gentlemen: We are submitting for Intermatic, Inc, Inc., a In-Wall Duplex Receptacle Transmitter, Model Number: HA01, with a FCC ID: DGZH0001 for Certification. This unit has been tested and complies to Part 15, Subpart C. If there are any questions in regards to this application, please call D.L.S. Electronic Systems, Inc. at (847) 537 6400. Enclosed you will find a copy of our test report with the information and results of tests that is required under Part 15, Section 15.249. Thank you for your assistance in this matter. Sincerely, Arnom C. Rowe EMC-001375-NE DLS/sr

External Photos

FRONT BACK

ID Label/Location Info

INTERMATIC PLAZA y SPRING GROVE y ILLINOIS 60081-9698 y 815/675-7765 y FAX 815/675-7785 Unit Label – English Version: Unit Label – Canadian French Version: Approx Size 1.25”x1.50” 1 2

Internal Photos

INSIDE FRONT INSIDE REAR INSIDE FRONT INSIDE REAR KEYPCB KEYPCB BACK TOP SIDE Z-WAVE MODULE WITHOUT SHIELD BOTTOM SIDE Z-WAVE MODULE WITHOUT SHIELD MOUNTED Z-WAVE MODULE / SHIELD REMOVED

Test Report

1250 Peterson Dr., Wheeling, IL 60090 Company: Intermatic Incorporated Model Tested: HA01 Report Number: 12960 FCC Rules and Regulations / Intentional Radiators Operational in the 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHz, and 24.0-24.25 GHz Bands Part 15, Subpart C, Section 15.249 THE FOLLOWING ''MEETS'' THE ABOVE TEST SPECIFICATION Formal Name: In-Wall Duplex Receptacle Kind of Equipment: RF Controlled Duplex Receptacle Test Configuration: Direct wired to 125VAC main Hot & Neutral wires. (Tested at 120 vac, 60 Hz) Model Number(s): HA01 Model(s) Tested: HA01 Serial Number(s): NA Date of Tests: February 16 & 19, 2007 Test Conducted For: Intermatic Incorporated 7777 Winn Road Spring Grove, Illinois 60081 NOTICE: “This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government”. Please see the "Additional Description of Equipment Under Test" page listed inside of this report. © Copyright 1983- 2006 D.L.S. Electronic Systems, Inc COPYRIGHT NOTICE This report or any portion their of, may not be reproduced or modified in any form without the expressed written consent of D.L.S. Electronic Systems, Inc. Page -1 of 51- 1250 Peterson Dr., Wheeling, IL 60090 Company: Intermatic Incorporated Model Tested: HA01 Report Number: 12960 SIGNATURE PAGE Report By: Arnom C. Rowe Test Engineer EMC-001375-NE Reviewed By: William Stumpf OATS Manager Approved By: Brian Mattson General Manager Company Official: Intermatic Incorporated Page -2 of 51- 1250 Peterson Dr., Wheeling, IL 60090 Company: Intermatic Incorporated Model Tested: HA01 Report Number: 12960 TABLE OF CONTENTS i. Cover Page .......................................................................................................................................... 1 ii. Signature Page .................................................................................................................................... 2 iii. Table of Contents ............................................................................................................................ 3 iv. NVLAP Certificate of Accreditation .............................................................................................. 4 1.0 Summary of Test Report ................................................................................................................. 5 2.0 Introduction..................................................................................................................................... 5 3.0 Object .............................................................................................................................................. 5 4.0 Test Set-Up ..................................................................................................................................... 6 5.0 Test Equipment ............................................................................................................................... 7 6.0 Ambient Measurements .................................................................................................................. 8 7.0 Description of Test Sample............................................................................................................. 9 8.0 Additional Description of Test Sample......................................................................................... 10 9.0 Photo Information and Test Set-Up .............................................................................................. 11 10.0 Radiated Photos Taken During Testing ........................................................................................ 12 10.0 Conducted Photos Taken During Testing .....................................................................................16 11.0 Results of Tests ............................................................................................................................. 17 12.0 Conclusion .................................................................................................................................... 17 TABLE 1 – EQUIPMENT LIST .............................................................................................................. 18 Appendix A – Electric Field Radiated Emissions Test............................................................................. 20 1.0 Conducted Emission Measurements ............................................................................................. 21 1.0 Conducted Data and Graph(s) taken during testing ...................................................................... 22 2.0 Band Edge and Restrict Band Compliance ................................................................................... 27 2.0 Data and Graph(s) taken showing the Band Edge Compliance .................................................... 28 2.0 20 dB Bandwidth Data and Graph(s)............................................................................................ 33 2.0 Data and Graph(s) taken showing the Restricted Band Compliance ............................................ 35 3.0 Field Strength of Spurious Emission Measurements .................................................................... 48 3.0 Fundamental, Harmonic and Spurious Data and Graph(s) ........................................................... 50 Page -3 of 51- 1250 Peterson Dr., Wheeling, IL 60090 Company: Intermatic Incorporated Model Tested: HA01 Report Number: 12960 Page -4 of 51- 1250 Peterson Dr., Wheeling, IL 60090 Company: Intermatic Incorporated Model Tested: HA01 Report Number: 12960 1.0 SUMMARY OF TEST REPORT It was found that the In-Wall Duplex Receptacle, Model Number(s) HA01, ''meets'' the radio interference conducted and radiated emission requirements of the FCC ''Rules and Regulations'', Part 15, Subpart C, Section 15.249 for operational in the 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHz, and 24.0-24.25 GHz Bands. 2.0 INTRODUCTION On February 16…

Text truncated - open the document above for the full version.

Test Setup Photos

RADIATED UPSIDE DOWN RADIATED “X’ RADIATED “Y’ RADIATED “Z’

Contact Information

Applicant

Kimberly Boland(Director of Engineering)
[email protected]815-675-7730Fax: 815-675-7785

Technical Contact

DLS ElectronicsArnom Rowe
[email protected]847-537-6400

1250 Peterson Drive · Wheeling, Illinois · United States

Test Firm

DLS Electronic Systems, Inc.William Stumpf
[email protected]847-537-6400Fax: 847-537-6488

Technical Specifications

#Rule PartsFrequency RangePower Output
115C908.42 MHz - 908.42 MHz-
