E675JS0118Nexus Dual Band Repeater

044-05207 Rev A April 2008 RACK MOUNT REPEATER INSTALLA TION AND SERVICE MANUAL RM NEXUS FT RACK MOUNT RADIO © 2008 Powerwave Technologies Incorporated. All rights reserved. Powerwave Technologies and the Powerwave logo are registered trademarks. Powerwave Technologies Inc. reserves the right to make changes to documentation and equipment, including but not limited to com- ponent substitution and circuitry changes. Changes that impact this document may be subsequently incorporated in a later revision of this document. This Powerwave product is designed to operate within the Normal Operating (typical operating) ranges or conditions specified in this document. Operation of this equipment beyond the specified ranges in this document may cause (1) spurious emissions that violate regulatory requirements; (2) the equipment to be automatically removed from service when maximum thresholds are exceeded; or (3) the equipment to not perform in accordance with its specifications. It is the Operator's responsibility to ensure this equipment is properly installed and operated within Powerwave operating specifications to obtain proper performance from the equipment and to comply with regulatory requirements. The rated output power of a Nexus FT is for multiple carriers. As long as the composite power does not exceed the rated power (20W for North America), derating is not required for multiple carriers. For situations where regulatory requirements require reduced interference to adjacent band users, the rating would have to be reduced by 3 dB. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. Input power is rated at 115/230VAC, 50/60Hz, and should be protected based on the power and fuse specifications in Chapter 5 of this manual. Power strips should, at a minimum, conform to this requirement to prevent equipment damage and possible overload. Federal Communications Commission (FCC) This device complies with the technical standards governing mobile radio devices in accordance with FCC Rules. This device is intended to facilitate the reception and transmission of mobile radio devices in the cellular, PCS or other mobile services, and its operation by end users or others requires carrier consent under FCC rules. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CRF47 part 15 of the FCC rules. This equipment is also certified to CRF47 part 22 (cellular), part 24 (PCS) and part 90 (iDEN800 and iDEN900) of the FCC Rules depending on the band of operation. Changes or modifications not expressly approved by Powerwave Technologies, Inc. for compliance could void the user’s authority to operate this equipment. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Industry Canadian Requirements All Powerwave apparatus introduced in the Canadian market meet all requirements of the Canadian Interference-Causing Equip- ment Regulations. The -20dB bandwidth at 1900 MHz band is 80 MHz. The -20dB bandwidth at the 850 MHz is 34 MHz. The output impedance of the unit referenced in this document is 50 Ohms. The -20dB bandwidth at IDEN 800MHz band is 26 MHz. The Manu- facturer's rated output power of this equipment is for multi carrier operation. For situations when multiple carrier signals are present, the power rating per carrier would have to be reduced. For example, the power rating per carrier should be reduced by 3dB if two carriers are present. A special situation can exist where the power rating per carrier will need to be reduced further due to high crest factor (peak power) waveforms. Consult your Powerwave representative for these situations. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. The input signal is optical so input impedance requirements are not applicable. The term “IC:” before the radio certification number onl y signifies that Industry of Can- ada technical specifications were met. Operation is subject to the following two conditions: (1) this device may not cause interfer- ence, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. European Requirements The Powerwave Nexus FT apparatus introduced in EU markets are certified to ESTI EN 300 609-4 (GSM900 and DCS1800) and ESTI EN 301 908-11 (WCDMA). Powerwave Technlogies Inc., 1801 East St. Andrew Place, CA 92705 Santa Ana, USA. Phone +1 714 466 1000 – Fax +1 714 466 5800 – Internet www.powerwave.com 044-05207 Rev Ai Warnings, Cautions, and Notes Warnings, Cautions, and Notes are found throughout this manual where applicable. The associated icons in warnings and cautions are used to quickly identify a potential condition that could result in the consequences described below if precautions are not taken. Notes clarify and provide additional information to assist the user. WARNING: The warning symbol means danger. You are in a situation that could cause bodily injury or death. Before you work on any equipment, be aware of the hazards involved with electrical and RF circuitry and be familiar with standard practices for preventing accidents. CAUTION: The caution symbol means the potential exists for equipment damage or loss of data. NOTE Notes contain helpful suggestions or references to material not covered in the document. Revision RecordNexus FT RMR ii044-05207 Rev A Revision Record Revision Letter Date of Chang…

Text truncated - open the document above for the full version.

1801 E. St. Andrew Place, Santa Ana, CA 92705 USA www.powerwave.com +1.714.466.1000 Fax. +1.714.466.5800 7/27/2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457 and Section 0.459 pertaining to confidential material. Powerwave Technologies, Inc. would like the following documents regarding this submission for FCC ID: E675JS0118 to be kept confidential. 1. All Schematics 2. All Operational Descriptions 3. All Parts Lists 4. All Tune-up Procedure Documents The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Sean Doan Reliability Engineer (714) 466-1216 (714) 466-5807 FAX [email protected]

1801 E. St. Andrew Place, Santa Ana, CA 92705 USA www.powerwave.com +1.714.466.1000 Fax. +1.714.466.5800 7/27/2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Short-term confidentiality request regarding application for certification of FCC ID: E675JS0118 Gentlemen: Pursuant to DA 04-1705 of the Commission’s public notice, we request short-term confidential treatment for the following information for 180 days after completion in order to ensure sensitive business information remains confidential until the actual marketing of the device: 1. Internal Photos The above material contains trade secrets or technical data that if other companies with in the same industry were able to view, it would remove the edge on the market that this product provides our company. We acknowledge that any items where permanent confidentiality has been requested, the permanent request shall supersede this request. We understand that this request can be extended up to a maximum of 180 days. Should marketing for this product begin prior to the timeline indicated above, we will notify CKC Certification Services, LLC to remove the temporary confidentiality for the exhibits listed herein. Sincerely, Sean Doan Reliability Engineer (714) 466-1216 (714) 466-5807 FAX [email protected]

Non-Conformities FCC ID: E675JS0118 (CKC CS Ref # E10-000060-FCC-01) The items listed below represent requests for information following review of this application for certification under United S tates (FCC) regulations. Further question may arise pending review of responses to these items. OK ID # Non-Conformity or Comment Subm itted Response Respondent / Date of Response X C 1 The ID label we have on file is for the wrong FCC ID number. Please send us an updated one. Updated ID Labels provided Sean Doan 7/26/10 X C 2 We have no operational description for this product on file Operational Description provided Sean Doan 7/23/10 X C 3 We have no tune up procedure on file. Tune up info provided. Sean Doan 7/23/10 X C 4 We need the DC Voltages and Currents IAW 2.1033(c)(8): “The dc voltages applied to and dc currents into the several elements of the final radio frequency amplifying device for normal operation over the power range.” DC Voltages provided. Sean Doan 7/23/10 X TL 5 The test reports indicate FCC rule parts, but no specific test procedure as therein required, such as TIA/ EIA 603. Please clarify the test procedures used. Yes, TIA/EIA 603 was used as the test procedure. Eddie Wong 7/26/2010 6 The items indicated above must be submitted before processing can continue on the referenced application. Failure to provide t he requested information within 60 days may result in application dismissal pursuant to Section 2.917(c) and forfeiture of the filing fee pursuant to Se ction 1.1106. How to read the table: OK column indicates closure by CKC CS. ID column is for use with Agents to assist in identifying the probable source for closure. A – Application issue TL – Test lab issue C – Client issue R – Retesting may be necessary # column indicates unique or separate non-conformity items (note some items may be related). Non-Conformity or Comment column indicates the evaluators specific question or comment. Submitted response column indicates the response or a summary of the response provided. Respondent / Date of Response column indicates the responding party or agent and the date of the response was either received or logged.
