E675JS0119Nexus Dual Band Repeater

COVERAGE SOLUTIONS INSTALLATION AND SERVICE MANUAL 044-05326 REV. B JULY 2010 NEXUS FT RACK MOUNT RADIO DRAFT © 2010 Powerwave Technologies Incorporated. All rights reserved. Powerwave Technologies and the Powerwave logo are registered trademarks. Powerwave Technologies Inc. reserves the right to make changes to documentation and equipment, including but not limited to com- ponent substitution and circuitry changes. Changes that impact this document may be subsequently incorporated in a later revision of this document. This Powerwave product is designed to operate within the Normal Operating (typical operating) ranges or conditions specified in this document. Operation of this equipment beyond the specified ranges in this document may cause (1) spurious emissions that violate regulatory requirements; (2) the equipment to be automatically removed from service when maximum thresholds are exceeded; or (3) the equipment to not perform in accordance with its specifications. It is the Operator's responsibility to ensure this equipment is properly installed and operated within Powerwave operating specifications to obtain proper performance from the equipment and to comply with regulatory requirements. The rated output power of a Nexus FT is for multiple carriers. As long as the composite power does not exceed the rated power (20W for North America), derating is not required for multiple carriers. For situations where regulatory requirements require reduced interference to adjacent band users, the rating would have to be reduced by 3 dB. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. Input power is rated at 115/230VAC, 50/60Hz, and should be protected based on the power and fuse specifications in Chapter 5 of this manual. Power strips should, at a minimum, conform to this requirement to prevent equipment damage and possible overload. Federal Communications Commission (FCC) This device complies with the technical standards governing mobile radio devices in accordance with FCC Rules. This device is intended to facilitate the reception and transmission of mobile radio devices in the cellular, PCS or other mobile services, and its operation by end users or others requires carrier consent under FCC rules. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CRF47 part 15 of the FCC rules. This equipment is also certified to CRF47 part 22 (cellular), part 24 (PCS) and part 90 (iDEN800 and iDEN900) of the FCC Rules depending on the band of operation. Changes or modifications not expressly approved by Powerwave Technologies, Inc. for compliance could void the user’s authority to operate this equipment. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Industry Canada The measured Canadian RF output power for the RH905022/13B is 46.3dBm. European Requirements The Powerwave Nexus FT apparatus introduced in EU markets are certified to ESTI EN 300 609-4 (GSM900 and DCS1800) and ESTI EN 301 908-11 (WCDMA). Powerwave Technologies Inc., 1801 East St. Andrew Place, CA 92705 Santa Ana, USA. Phone +1 714 466 1000 – Fax +1 714 466 5800 – Internet www.powerwave.com DRAFT 044-05326 Rev Biii Revision Record Revision Letter Date of Change Reason for Change Rev ASeptember 2008 Initial release Rev BJuly 2010Updated manual to show new FT RMR product DRAFT Nexus FT RM RMR iv 044-05326 Rev B This page intentionally left blank DRAFT Nexus FT RM RMRTable of Contents 044-05326 Rev Bv TABLE OF CONTENTS Warning, Cautions, and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Human Exposure to RF Radiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Repeater Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Installation and Maintenance of Antenna Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Radiation Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii Electrostatic Discharge (ESD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii Chapter 1 - Product Description Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 Scope of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 Cabinet Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 Rack Mount Radio module (RMR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 Chapter 2 - Indicators Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

1801 E. St. Andrew Place, Santa Ana, CA 92705 USA www.powerwave.com +1.714.466.1000 Fax. +1.714.466.5800 Tuesday, July 27, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for product family approval - FCC ID# E675JS0119 The Dual Band Repeater listed below were submitted to CKC labs for FCC testing. Product #1: RH304022/13B - FCC ID# E675JS0118 FCC Part 24 Part 22 UL Frequency 1850-1910 MHz 824-849 MHz DL Frequency 1930-1990 MHz 869-894 MHz Product #2: RH305022/13B - FCC ID# E675JS0119 FCC Part 24 Part 90 UL Frequency 1850-1910 MHz 806-824 MHz DL Frequency 1930-1990 MHz 851-869 MHz The family product of Powerwave WRH includes dual band Amplifiers with independent RF Input and Output port. The 1930-1990MHz band components used in the products is electrically and mechanically identical. These two units have different lower band frequencies therefore product #1 which is RH304022/13B - FCC ID# E675JS0118 was subjected to FCC part 22 and RH305022/13B - FCC ID# E675JS0119 was subjected to FCC part 90. Since both product employs identical RF component in the high frequency band, compliance testing to meet FCC part 24 rules was only performed on Product #1. The test data for Part 24 of product #1, Model: RH304022/13B - FCC ID# E675JS0118 is to be used to qualify product #2 , model: RH305022/13B - FCC ID# E675JS0119 Enclosed: System Block Diagrams (Confidential) and Schematics Diagrams (Confidential) Sincerely, Sean Doan Sr. Reliability Engineer Powerwave Technologies, Inc. 1801 E. St. Andrew Pl. Santa Ana, CA 92705 714-466-1216 Direct 714-466-5807 Fax [email protected]

1801 E. St. Andrew Place, Santa Ana, CA 92705 USA www.powerwave.com +1.714.466.1000 Fax. +1.714.466.5800 Tuesday, July 27, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for product family approval - FCC ID# E675JS0119 The Dual Band Repeater listed below were submitted to CKC labs for FCC testing. Product #1: RH905022/13B - FCC ID# E675JS0120 FCC Part 27 Part 90 UL Frequency 1710-1755 MHz 806-824 MHz DL Frequency 2110-2155 MHz 851-869 MHz Product #2: RH305022/13B - FCC ID# E675JS0119 FCC Part 24 Part 90 UL Frequency 1850-1910 MHz 806-824 MHz DL Frequency 1930-1990 MHz 851-869 MHz The family product of Powerwave WRH includes dual band Amplifiers with independent RF Input and Output port. The 851-869MHz band components used in the products is electrically and mechanically identical. These two units have different higher band frequencies therefore product #1 which is RH905022/13B - FCC ID# E675JS0120 was subjected to FCC part 27 and RH305022/13B - FCC ID# E675JS0119 was subjected to FCC part 24. Since both product employs identical RF component in the low frequency band, compliance testing to meet FCC part 90 rules was only performed on Product #1. The test data for Part 90 of product #1, Model: RH905022/13B - FCC ID# E675JS0120 is to be used to qualify product #2 , model: RH305022/13B - FCC ID# E675JS0119 Enclosed: System Block Diagrams (Confidential) and Schematics Diagrams (Confidential) Sincerely, Sean Doan Sr. Reliability Engineer Powerwave Technologies, Inc. 1801 E. St. Andrew Pl. Santa Ana, CA 92705 714-466-1216 Direct 714-466-5807 Fax [email protected]

1801 E. St. Andrew Place, Santa Ana, CA 92705 USA www.powerwave.com +1.714.466.1000 Fax. +1.714.466.5800 Friday, July 30, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457 and Section 0.459 pertaining to confidential material. Powerwave Technologies, Inc. would like the following documents regarding this submission for FCC ID: E675JS0119 to be kept confidential. 1. All Schematics 2. All Block Diagrams 3. All Operational Descriptions 4. All Parts Lists 5. All Tune-up Procedure Documents The above materials contain trade secrets and proprietary information not customarily released to the public. The internal circuitry design uses proprietary techniques that are not known by the general public / industry. Powerwave Technologies customers have signed non-disclosure agreements. This product is only serviceable by Powerwave Technologies or a licensee. It is definitely not accessible by the general public in its deployment location(s). The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Sean Doan Reliability Engineer (714) 466-1216 (714) 466-5807 FAX [email protected]

1801 E. St. Andrew Place, Santa Ana, CA 92705 USA www.powerwave.com +1.714.466.1000 Fax. +1.714.466.5800 7/30/2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Short-term confidentiality request regarding application for certification of FCC ID: E675JS0119 Gentlemen: Pursuant to DA 04-1705 of the Commission’s public notice, we request short-term confidential treatment for the following information until January 16 th 2011 in order to ensure sensitive business information remains confidential until the actual marketing of the device: 1. Internal Photos 2. External Photos 3. Users Manuals 4. Test Setup Photos The above material contains trade secrets or technical data that if other companies with in the same industry were able to view, it would remove the edge on the market that this product provides our company. We acknowledge that any items where permanent confidentiality has been requested, the permanent request shall supersede this request. We understand that this request can be extended up to a maximum of 180 days. Should marketing for this product begin prior to the timeline indicated above, we will notify CKC Certification Services, LLC to remove the temporary confidentiality for the exhibits listed herein. Sincerely, Sean Doan Reliability Engineer (714) 466-1216 (714) 466-5807 FAX [email protected]

This report contains a total of 43 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Powerwave Technologies, Inc. ADDENDUM TO TEST REPORT 87766‐22 Nexus Dual Band Repeater, RH304022/13B Tested To The Following Standards: FCC Part 24 Subpart E Report No.: 87766‐22A Date of issue: July 29, 2010 TESTING CERT #803.01, 803.02, 803.05, 803.06 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long‐term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2of 43 Report No.: 87766‐22A TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 24 E .................................................................................................................................................................. 7 2.1033(c)(14)/2.1046/24.232(a) ‐ RF Power Output ................................................................................................. 7 2.1033(c)(14)/2.1049(i) ‐ Occupied Bandwidth ....................................................................................................... 13 2.1033(c)(14)/2.1051/24.238(a) ‐ Spurious Emissions at Antenna Terminal .......................................................... 22 2.1033(c)(14)/2.1053/24.238(a) ‐ Field Strength of Spurious Radiation ................................................................. 25 24.238(a) – Block Edge ............................................................................................................................................ 32 2‐11‐01/EAB/RF – Out of Band Rejection ................................................................................................................ 38 Supplemental Information .......................................................................................................................................... 42 Measurement Uncertainty ...................................................................................................................................... 42 Emissions Test Details .............................................................................................................................................. 42 Page 3of 43 Report No.: 87766‐22A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Powerwave Technologies, Inc. 1801 E. St. Andrew Place Santa Ana, CA 92705 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Sean Doan Project Number: 87766 Customer Reference Number: 137069 137069 DATE OF EQUIPMENT RECEIPT: July13, 2010 DATE(S) OF TESTING: July13 ‐15, 2010 Revision History Original: To perform the testing of the Nexus Dual Band Repeater, RH30422/13B with the requirements for FCC Part 24 Subpart E devices. Addendum A: To add Customer Declared Multiple Model Statement to include additional model numbers equivalent to the Nexus Dual Band Repeater, RH30422/13B. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4of 43 Report No.: 87766‐22A Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Site Registration & Accreditation Information Location Japan Canada FCC B…
