MIKES BABT PRODUCT SERVICE GmbHDUTY CYCLE Description Ohmstrasse 2-4 D-94342 Strasskirchen / GermanyPage 1 of 1 FCC ID: E9MHT40 DUTY CYCLE Description Due to the fact that this is a wireless microphone with analog frequency modulation and transmission of speech, the duty cycle is 100 % if the unit is operating. MIKES BABT PRODUCT SERVICE _____________________ Thomas Weise Wireless Communication Head of Department

FCC ID: E9MHT40 TTI - P-G 009 / 98-00 TTI - P-G 089 / 94-50 File No. T17590-1-01 KJ , Page 1 of 19 MIKES BABT PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 7.2 E M I S S I O N -- T E S T R E P O R T Testreport file no. : T17590-1-01 KJ ______________ Date : March 08, 2000 of issue _________________ Model : Handheld microphone transmitter ______________________________________________ Type : HT 40 ______________________________________________ Applicant : AKG Acoustics GmbH ______________________________________________ Manufacturer : WAGOL Industrial Co. LTD ______________________________________________ Licence holder : AKG Acoustics U.S. ______________________________________________ Address : 1449 Donelsen Pike, Nashville TN 37217 ______________________________________________ United States of America ______________________________________________ Test result accrdg. to the regulation(s) at page 3 : POSITIV This testreport with appendix consists of 46 pages. The testresult only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the testlaboratory. FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page 2 of 19 MIKES BABT PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 8.0 D I R E C T O R Y Page A) Documentation Directory2 ________ Testregulations3 ________ General information4-5 ________ Discovery of worst case condition 6 ________ Equipment under Test18 ________ Summary19 ________ B) Testdata Conducted emissions10/150 kHz - 30 MHz 7 ________ Spurious emissions (magnetic field) 10 kHz - 30 MHz 8-9 ________ Spurious emissions (electric field) 30 MHz - 1000 MHz 9-10 ________ Spurious emissions (electric field) 1 GHz - 18 GHz 10-11 ________ Conducted power of the fundamental wave measured on 12 the antenna terminals ________ Modulation limiting data 13-14 ________ Frequency error15 ________ Keeping the requirements of the emission mask 16-17 ________ Attachment A) Technical description of the test sample A1-A3 (e.g.CDF, Declaraton) ________ B) TestdataB1-B14 ________ C) Photodocumentation CI) Photos of the test setup CI 1-4 ________ CII) Photos of the EuT CII 1-5 ________ D) List of Test Equipment D1-D1 ________ FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page 3 of 19 MIKES BABT PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 8.0 T E S T R E G U L A T I O N S The tests were performed according to following regulations : o - EN 50081-1 / 2.1991 o - EN 50081-2 / 7.1993 -------------------------------------------------------------------------------- o - EN 55011 / 3.1991 o - Group 1 o - Group 2 o - class A o - class B o - EN 55014 / 4.1993 o - Household appliances and similar o - tools o - Semiconductor devices o - EN 55014 / A2:1990 o - EN 55104 / 5.1995 Category: o - EN 55015 / A1:1990 o - EN 55015 / 12.1993 o - EN 55022 / 5.1995 o - class A o - class B o - prEN 55103-1/ 3.1995 o - prEN 50121-3-2 / 3.1995 o - EN 60601-1-2 / 4.1994 o - VCCI o - class 1 o - class 2 ! - 47 CFR Part 74 Subpart H (74.861) FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page 4 of 19 MIKES BABT PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 8.0 A D D R E S S O F T H E T E S T L A B O R A T O R Y ! - MIKES BABT PRODUCT SERVICE GmbH Ohmstrasse 2-4 D - 94342 Strasskirchen o - ______________________________________ ______________________________________ ______________________________________ E N V I R O N M E N T A L C O N D I T I O N S Temperature: 15-35 ° C ______ Humidity 45-60 % ______ Atmospheric pressure 860-1060 mbar _________ POWER SUPPLY SYSTEM UTILIZED Power supply system : Internal batteries DC 3V STATEMENT OF MEASUREMENT UNCERTAINTY The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error of ± 4dB. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of the device. SHORT DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) The handheld transmitter HT 40 is used for e.g. in concerts, theaters and tv or radio studios to transmit audio signals to a receiver who gets back the audio signal from the high frequency signal via a demodulation circuit. The transmitter is processing the input signal which is given by a connectable wired microphone, modulating it on a carrier (frequency modulation) and amplifying it. This signal will be feeded through filters to the antenna and then radiated. The microphones exist in 3 different version: US54 / US58 / EU62. Additional to the base version HT 40, this transmitter will transmit additional the battery status of the integral battery. For detailed difference please see technical data. Number of received/tested samples: 3 / 1 DEFINITIONS FOR SYMBOLS USED IN THIS TEST REPORT ! - Black box indicates that the listed condition, standard or equipment is applicable for this Report. o - Blank box indicates that the listed condition, standard or equipment was not applicable for this Report. FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page 5 of 19 MIKES BABT PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 8.0 M E A S U R E M E N T P R O T O C O L F O R F C C , V C C I A N D A U S T E L Test Methodology Conducted and radiated emission testing is performed according to the procedures in International Special Committee on Radio Interference (CISPR) Publication 22 (1993), European Standard EN 55022 and Australian Standard AS 3548 (which are based on CISPR 22). The Japanese standard, "Voluntary Control Council for Interference (VCCI) by Data Processing Equipment and Electronic Office Machines, Technical…

Text truncated - open the document above for the full version.

FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page CI 1 of CI 4 MIKES PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 7.2 Test-Setup: Radiated emission 30 MHz - 1000 MHz (front view) FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page CI 2 of CI 4 MIKES PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 7.2 Test-Setup: Radiated emission 30 MHz - 1000 MHz (back view) FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page CI 3 of CI 4 MIKES PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 7.2 Test-Setup: Radiated emission 1000 MHz - 10th harmonic of the fundamental wave (front view) FCC ID: E9MHT40 File No. T17590-1-01 KJ , Page CI 4 of CI 4 MIKES PRODUCT SERVICE GmbH Ohmstrasse 2-4 94342 Strasskirchen Tel:+9424-9407-0 Fax:+9424-9407-60 Rev.No. 7.2 Test-Setup: Radiated emission 1000 MHz - 10th harmonic of the fundamental wave (back view)
