CN3 Mobile Computer User's Manual iiPRELIMINARY - CN3 Mobile Computer User’s Manual Intermec Technologies Corporation Worldwide HeadquartersCedar Rapids Technical Communications 6001 36th Ave.W. 550 Second Street SE Everett, WA 98203Cedar Rapids, IA 52401 U.S.A.U.S.A. www.intermec.com The information contained herein is provided solely for the purpose of allowing customers to operate and ser- vice Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2006 by Intermec Technologies Corporation. All rights reserved. The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar, dcBrowser, Durath- erm, EasyADC, EasyCoder, EasySet, Fingerprint, i-gistics, INCA (under license), Intellitag, Intellitag Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan, Smart Mobile Computing, TE 2000, Trakker Antares, and Vista Powered are either trademarks or registered trade- marks of Intermec Technologies Corporation. There are U.S. and foreign patents as well as U.S. and foreign patent applications pending. Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and/or other countries. Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A. Contents CN3 Mobile Computer User’s Manual - PRELIMINARYiii Contents Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Global Services and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Who Should Read this Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x Patent Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi 1 Using the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Introducing the CN3 Mobile Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Learning Software Build Versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Resetting Your CN3 Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Scanning Bar Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Scanning with the 2D Area Imager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Reading Distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Using the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Charging and Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Maximizing Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Checking the Battery Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Adjusting the Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Enabling the Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Disabling the Beeper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Intermec Settings Applet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Using the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Using the Color-Coded Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Capitalizing All Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Using the Power (I/O) Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Using the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Software Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 SmartSystems Foundation Console (www.intermec.com/SmartSystems) . . . . . . . 13 Intermec Resource Kits (www.intermec.com/IDL) . . . . . . . . . . . . . . . . . . . . . . . . 13 Using the Speakers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Using the Status LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Using the Storage Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Setting the Vibrator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Wireless Network Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Contents ivPRELIMINARY - CN3 Mobile Computer User’s Manual Accessories for the CN3 Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Physical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

CN3 Mobile Computer User’s Manual - PRELIMINARY69 3 Configuring the Computer There are multiple ways to get an application to your CN3 Mobile Com- puter; like there are multiple ways to package the application for delivery. Note: Desktop icons and settings applet icons are shown to the left. Any place that Start is mentioned, tap the following Windows icon in the top, left corner of your CN3 desktop. Chapter 3 — Configuring the Computer 70PRELIMINARY - CN3 Mobile Computer User’s Manual Developing Applications for the Computer CN3Computers run applications programmed in Microsoft Visual Studios 2005. Use this chapter to understand what you need to develop a new application for the CN3 Computer. To develop applications for your CN3 Computer, use the Resource Kits in the Intermec Developer Library (IDL). Download the IDL from the Inter- mec web site at www.intermec.com/idl. Contact your Intermec representa- tive for more information. You need the following hardware and software components to use the resource kits: • Pentium desktop, 400 MHz or higher • Windows 2000 (Service Pack 2 or later) or Windows XP (Home, Profes- sional, or Server) • For native and managed development, Microsoft Visual Studio 2005 • 128 MB RAM (196 MB recommended) • 360 MB hard drive space for minimum installation (720 MB for com- plete) • CD-ROM drive compatible with multimedia desktop specification • VGA or higher-resolution monitor (Super VGA recommended) • Microsoft Mouse or compatible pointing device Packaging Applications for the CN3 Computer Use any of these methods to package applications for installation: • You could package an application as a cabinet (CAB) file. Recommended • For simple applications, the application itself may be the file to deliver. • It could be a directory structure that contains the application, supporting files like ActiveX controls, DLLs, images, sound files, and data files. Consider any of these when choosing a storage location for applications: • In the basic CN3 Computer, there are two built-in storage options: the Object Store and the Flash File Store. The Object Store is a Disk on Chip (DOC) Flash that looks like a disk. The Flash File Store is an area of storage which is embedded in a section of the system’s FLASH mem- ory. This storage area is not erased during a clean-boot. • If the optional Secure Digital storage card is in the system, then consider this card the primary location for placing an applications install files. This storage card creates the “\Storage Card” folder. Note: Microsoft eMbedded Visual C++ 4.0 may be used, but some features are not available. Chapter 3 — Configuring the Computer CN3 Mobile Computer User’s Manual - PRELIMINARY71 • Use the small nonvolatile Flash File Store region to hold CAB files that rebuild the system at clean-boot or install applications from a CAB file into the Flash File Store so they are “ready-to-run” when a clean-boot is performed. Since the FLASH in the system has a limited number of write cycles, do not use the Flash File Store for excessive writing pur- poses; however, reading is okay. Installing Applications on the Computer Any of these options can move items to locations on your CN3 Computer: Microsoft ActiveSync (page 71), Secure Digital storage cards (page 72), Wavelink Avalanche (page 72), or SmartSystems™ Console (page 73). Using Microsoft ActiveSync You can use Microsoft ActiveSync to establish a connection between your desktop and the CN3 Computer. Microsoft ActiveSync transfers files, syn- chronizes files, remote debugging, and other device management activities. See Chapter 2, “Windows Mobile” for information about the Microsoft ActiveSync application as provided by Microsoft Corporation. This can be a USB Microsoft ActiveSync connection. Files can be copied using Windows Explorer on a desktop or a laptop computer. This is usually good when updating few CN3 Computers. These instructions assume that Microsoft ActiveSync was installed onto your desktop and is up and running. If not, go to Chapter 2, “Windows Mobile” for an URL from which to download the latest application. 1Connect your CN3 Computer to your desktop using a USB cable. You may have to detach, then reattach the cable to “wake” the connection. 2Wait for a “Connected” message to appear in the Microsoft ActiveSync application to signal a connection to the CN3 Computer. If necessary, select File > Get Connected to initiate a connection or detach, then reat- tach the USB cable. 3Click Explore to access the “\Mobile Device” folder on your unit. Chapter 3 — Configuring the Computer 72PRELIMINARY - CN3 Mobile Computer User’s Manual 4From your desktop, select Start > Windows Explorer, then browse the “C:\Intermec\CN3 Mgmt Tools\CabFiles” path for any CAB files needed for your CN3 Computer. Select the appropriate file, right-click the file for a pop-up menu, then select Copy. 5Within the “\My Windows Mobile-Based Device” directory, go to the directory where you want the files located on the CN3 Computer, do a right-click for a pop-up menu, then select Paste. 6When all of the files are pasted, perform a clean-boot on the CN3 Com- puter. When the computer reboots, wait for the LED on the top left of your keypad to stop blinking. Tap Start > Programs > Windows Explorer to locate the newly copied executable files, then tap these files to activate their utilities. Using a Storage Card If you have a mini-Secure Digital (SD) storage card for your CN3 Com- puter, this is the best place for you to installation applications. 1If you are using a Secure Digital card reader, suspend the CN3 Com- puter, remove its mini-SD storage card, insert it in a mini-SD adapter card, then place it in the reader. For help, see “Using the Storage Card” on page 16. 2Copy your application file to the mini-SD card. If you are using Microsoft ActiveSync to copy the files to the mini-SD card, place the application in the “\Storage Card” folder on the CN3 Computer. 3If using a Secure Digital card re…

Text truncated - open the document above for the full version.

August 24, 2006 To Who It May Concern: Intermec Technologies Corporation, the undersigned, hereby authorizes Northwest EMC, Inc., to act on our behalf, as our agent, in the following matters related to the FCC and Industry Canada approval of our products: report submittal, related correspondence, the signing of all documents related to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Northwest EMC, Inc. within the scope of this authorization shall have the same affect as our own. This authorization shall expire 12 months from original date. If you have any questions regarding this application, please feel free to contact me via phone at 425- 267-2928, via fax at 425-348-2633 or via email at [email protected]. Sincerely, Cheryl D. White Compliance Engineer Intermec Technologies Corporation Safety & Compliance 6001 36 th Avenue West Everett, Washington 98203 United States tel 425 267 2928 fax 425 348 2633

NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 October 2, 2006 Dear Application Examiner: On behalf of Intermec Technologies, Inc., Northwest EMC, Inc. is submitting this application for the certification of Intermec’s CN3 handheld computer, FCC ID: EHA- 03CN3. It is a composite device that contains a GSM/GPRS/EDGE radio (Model MC75) and an 802.11b/g – Bluetooth combo radio (Model DHIB). Each radio uses it’s own RF path and antenna. Although the GSM/GPRS/EDGE radio can transmit simultaneously with the other radios, the 802.11b/g and Bluetooth radios cannot transmit simultaneously with each other. The receiver portion of the GSM/GPRS/EDGE radio transceiver has been verified to FCC 15B. The digital portion of the CN3 has been authorized through the DoC process. The technical reports and exhibits demonstrate compliance with FCC rules 47 CFR 15.247 as a DTS device, and Part 22H and 24E as a PCE device. Your efforts in reviewing this application are greatly appreciated. Best regards, Northwest EMC, Inc.

6001 36 th Avenue West Everett, Washington 98203 United States tel 425.348.2600 fax 425.355.9551 www.intermec.com 2-OCT-2006 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Hand Held Computer with Transceiver Certification To whom it may concern, Application: Intermec Technologies Corporation, 550 Second Street SE, Cedar Rapids, Iowa 52401-2029 herein submits for Certification of a Hand Held Computer with transceiver FCC ID: EHA-03CN3. Intermec is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Intermec requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Intermec trade secrets and confidential information that Intermec does not customarily release to the public and which is otherwise not generally available to the pubic. Confidentiality is requested for the following exhibits: • Theory of Operation • Schematics • Frequency Block Diagram • Tune up Procedure • Parts List Description: This equipment contains an GSM/GPRS cell phone radio module, which operates in the 850 and 1900 MHz GSM bands. This equipment also contains a combination 802.11g and Bluetooth module, which operates in the 2.400 – 2.4835 GHz frequency band. Contact Information: Please contact me by telephone at (319) 369-3865 or by e-mail ([email protected]) if there are questions or additional information needed concerning this filing. Yours truly, Scott J. Holub RF and EMC Compliance Supervisor Intermec Technologies Corporation 550 Second Street S.E. Cedar Rapids, IA 52401 USA

Greg Kiemel <[email protected]> Bluetooth certifications under 15.247 Joe Dichoso <[email protected]>Tue, Oct 3, 2006 at 7:21 AM To: Greg Kiemel <[email protected]> Cc: Chris Harvey <[email protected]>, Dave Tolman <[email protected]>, Dean Ghizzone <[email protected]>, Rashmi Doshi <[email protected]>, Andrew Leimer <[email protected]>, Steven Dayhoff <[email protected]>, George Tannahill <[email protected]>, Joe Dichoso <[email protected]> Greg, That is correct. A hybrid device does not need to meet the minimum 500 kHz BW. Chris, can you make sure that the following message gets in the TCB minutes? Bluetooth Certifications under Section 15.247. Bluetooth devices may file under the DTS, DSS, or Hybrid rules in Section 15.247 as long as all requirements for each are met. Do not mix requirements for one with requirements with another. When filing as a Hybrid device under Section 15.247, the note code DTS must be used. Do not use the DSS note code. The test report for a hybrid device must only show compliance with the hybrid requirements. When filing as a DTS, submit only a DTS test report. Use the DTS note code. When filing as a DSS, submit only a DSS test report. A DSS note code must be used. Thanks, Joe -----Original Message----- From: [email protected] [mailto:[email protected]] On Behalf Of Greg Kiemel Sent: Monday, October 02, 2006 2:15 PM To: Joe Dichoso Cc: Chris Harvey; Dave Tolman; Dean Ghizzone Subject: Bluetooth certifications under 15.247 Joe, Per the conversation we had today regarding Bluetooth, please see "Third Example" in KDB 453039. I believe this allows Bluetooth devices to be certified as DTS without meeting the minimum 500 kHz occupied bandwidth requirement (provided the other tests mentioned in the third example are performed): "There is no requirement for this type of hybrid system to comply with the 500 kHz minimum bandwidth normally associated with a DTS transmission..." Best regards, -- Greg Kiemel, Director of Engineering Northwest EMC, Inc. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 Main: 888-364-2378 Fax: 503-844-3826 www.nwemc.com Direct: 503-943-3126 Email: [email protected]

Radio and Antenna Location in the Intermec CN3 Hand Held Computer Scott Holub 20-SEP-06 CN3 Case Back with MC75 (antenna removed from case) CN3 Case Back with MC75 Antenna Installed CN3 Unit with Siemens MC75 GSM Module CN3 Unit with MC75 Module and support board removed to see DHIB module CN3 Unit with MC75 and DHIB modules removed CN3 Unit with MC75, DHIB, and main PCB removed from front housing

LAIRD PROPRIETARY, CONFIDENTIAL, OR SECRET Issued on April 6, 2006 Page 1 of 6 EN019.20B Willis Hardy 08/23/2006 Laird Product Engineering Place dates per Record Retention Policy AUTHOR DATE CONCUR REPORT NUMBER: XXXXXX TO: Requester: Intermec Manager: COPY: EXECUTIVE SUMMARY: Performance of Intermec CN3 GPRS US version were measured, provide for Intermec FCC filings. SCOPE: Performance of US version of the GPRS antenna DESIGN OF EXPERIMENT: Return Loss, Efficiency and Gain Patterns were measured on a CN3 GPRS fixture. CONCLUSIONS: The Return Loss, Efficiency, Peak Gain, Average Gain and Gain Patterns are provided. RECOMMENDATIONS: None ACTIONS: None APPENDIX: None KEY WORDS: Words that the report can be found under; Program, Part(s), Subject of work, Method(s) of solution, Software(s) used (list in alphabetical order) LAIRD PROPRIETARY, OR LAIRD CONFIDENTIAL, OR LAIRD SECRET Report Number: xxxxxxxxxxxx Page 2 of 6 Date: 08/23/2006 Efficiency in Free Space Intermec CN3 GPRS US Antenna Configuration: Free Space 0.0% 10.0% 20.0% 30.0% 40.0% 50.0% 60.0% 824 8 36 8 49 86 9 88 1 894 185 0 188 0 1 91 0 1 93 0 19 6 0 19 9 0 Freq. (MHz) E f f i ci e n cy ( % ) GPRS US Antenna Efficiency Freq. (MHz)Eff. (%)Eff. (dB) 82447.0%-3.28 83653.0%-2.76 84953.5%-2.72 86937.4%-4.27 88128.3%-5.47 89421.2%-6.74 185043.6%-3.60 188034.6%-4.61 191031.7%-4.98 193033.5%-4.75 196035.7%-4.47 199039.0%-4.09 Intermec CN3 GPRS US Antenna Configuration: Free Space -8.00 -7.00 -6.00 -5.00 -4.00 -3.00 -2.00 -1.00 0.00 824 836 849 86 9 8 81 894 18 5 0 1 88 0 191 0 193 0 196 0 19 9 0 Freq. (MHz) E f f i ci en c y ( d B ) GPRS US Antenna LAIRD PROPRIETARY, OR LAIRD CONFIDENTIAL, OR LAIRD SECRET Report Number: xxxxxxxxxxxx Page 3 of 6 Date: 08/23/2006 Return Loss, Free Space LAIRD PROPRIETARY, OR LAIRD CONFIDENTIAL, OR LAIRD SECRET Report Number: xxxxxxxxxxxx Page 4 of 6 Date: 08/23/2006 Gain Patterns, Phi=0, Free Space Phi=0 Freq. (MHz)Peak Gain Average Gain 8240.33-3.54 8360.91-2.91 8490.99-2.76 869-0.48-4.14 881-1.68-5.37 894-2.90-6.68 1850-1.67-3.27 1880-2.27-4.18 1910-2.67-4.81 1930-2.11-4.83 1960-0.84-4.65 1990-0.02-4.23 LAIRD PROPRIETARY, OR LAIRD CONFIDENTIAL, OR LAIRD SECRET Report Number: xxxxxxxxxxxx Page 5 of 6 Date: 08/23/2006 Gain Patterns, Phi=90, Free Space Phi=90 Freq. (MHz)Peak Gain Average Gain 824-1.00-3.91 836-0.38-3.36 849-0.27-3.28 869-1.78-4.84 881-2.87-6.01 894-4.15-7.35 1850-0.78-3.30 1880-1.69-4.40 1910-2.28-4.86 1930-2.27-4.67 1960-2.16-4.56 1990-1.61-4.43 LAIRD PROPRIETARY, OR LAIRD CONFIDENTIAL, OR LAIRD SECRET Report Number: xxxxxxxxxxxx Page 6 of 6 Date: 08/23/2006 Gain Patterns, Theta, Free Space Theta=90 Freq. (MHz)Peak Gain Average Gain 8240.16-2.33 8360.71-1.82 8490.74-1.79 869-0.62-3.33 881-1.72-4.46 894-2.70-5.58 1850-1.10-3.82 1880-1.78-4.69 1910-2.32-4.95 1930-2.14-4.62 1960-1.87-4.28 1990-0.70-3.92

Based upon the CN3 units tested for SAR and EMC measurements, the peak antenna gain when installed in the CN3: 802.11 b/g PIFA antenna: 1.34 dBi The following is supplemental antenna performance information. CN3 802.11b/g antenna performance summary. 7/18/06 P. Hulett File Name: 2006.06.08_CN3 Proto B_antenna gain_2400-2500MHz_Theta-Phi.pat Test Method: Two-Axis Dual-Polarization Pattern Measurement Test Start Time: 06/08/2006 17:59:33 Test End Time: 06/08/2006 18:38:20 Comments: CN3 Proto B 802.11b/g antenna gain Total Frequency (MHz) 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 Point Values Average Efficiency (dB) -2.762 -2.730 -3.505 -3.830 -3.622 -3.456 -3.781 -3.555 -3.783 -3.959 -4.028 -3.546 Gain (dBi) 1.807 2.189 1.764 1.747 2.075 2.175 1.946 2.201 1.867 1.704 1.478 1.905 Average Gain (dB) -2.762 -2.730 -3.505 -3.830 -3.622 -3.456 -3.781 -3.555 -3.783 -3.959 -4.028 -3.546

Based upon the CN3 units tested for SAR and EMC measurements, the peak antenna gain when installed in the CN3: Bluetooth Chip Antenna: -3.33 dBi The following is supplemental antenna performance information. Intermec CN3 2200 Brian Klinkner Bluetooth antenna gain test Summary: Screen View Right Side View Back Side View Left Side View Top View Bottom View CN3 Unit with MC75 Module and support board removed to see DHIB module

REPORT ON Specific Absorption Rate Testing of the Intermec Technologies Corporation CN3 Mobile Computer Report No WS615435/01 Issue 2 September 2006 Competence. Certainty. Quality. TUV Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk ; www.babt.com Report Number WS615435/01 Issue 2 Page 1 of 68 REPORT ON Specific Absorption Rate Testing of the Intermec Technologies Corporation CN3 Mobile Computer Report No: WS615435/01 Issue 2 PREPARED FOR Intermec Technologies Corporation 550 Second Street. SE CEDAR RAPIDS IA 52401-2023 USA ATTESTATION The wireless portable device described within this report has been shown to be capable of compliance for localised specific absorption rate (SAR) for General Population/Uncontrolled Exposure Limits as defined in the Following standards; FCC standard Supplement C (Edition 01-01) to OET Bulletin 65 (Edition 97-01) and RSS-102 Issue 2 (Provisional) September 25, 1999 of 1.6 W/kg. The measurements shown in this report were made in accordance with the procedures specified in Supplement C (Edition 01-01) to OET Bulletin 65 (Edition 97-01), RSS-102 Issue 2 (Provisional) September 25, 1999. All reported testing was carried out on a sample of equipment to demonstrate compliance with the above standar…
