EHA-1007CP02Mobile Computer

CK 3R | CK 3X Mobile Computer CK3X-NI User’s Manual iiCK3R and CK3X Mobile Computer User’s Manual Intermec Technologies Corporation Worldwide Headquarters 6001 36th Ave.W. Everett, WA 98203 U.S.A. www.intermec.com The information contained herein is provided solely for the purpose of allowing customers to operate and service Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2012 by Intermec Technologies Corporation. All rights reserved. The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar, dcBrowser, Duratherm, EasyADC, EasyCoder, EasySet, Fingerprint, i-gistics, INCA (under license), Intellitag, Intellitag Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan, Smart Mobile Computing, SmartSystems, TE 2000, Trakker Antares, and Vista Powered are either trademarks or registered trademarks of Intermec Technologies Corporation. There are U.S. and foreign patents as well as U.S. and foreign patents pending. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and/or other countries. Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A. This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (www.openssl.org). This product includes cryptographic software written by Eric Young ([email protected]). This product uses Regex++, Index software during its operational phases. The owner of Regex++ has granted use of the software to anyone provided such use is accompanied by the following copyright and permission notice: Regex++, Index. (Version 3.31, 16th Dec 2001) Copyright © 1998-2001 Dr John Maddock Permission to use, copy, modify, distribute and sell this software and its documentation for any purpose is hereby granted without fee, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice appear in supporting documentation. Dr John Maddock makes no representations about the suitability of this software for any purpose. It is provided “as is” without express or implied warranty. iTalkie is a trademark of TABLETmedia, Inc. CK3R and CK3X Mobile Computer User’s Manualiii Before You Begin This section provides you with safety information, technical support information, and sources for additional product information. Safety Information Your safety is extremely important. Read and follow all warnings and cautions in this document before handling and operating Intermec equipment. You can be seriously injured, and equipment and data can be damaged if you do not follow the safety warnings and cautions. This section explains how to identify and understand warnings, cautions, and notes that are in this document. Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at www.intermec.com and click Support > Returns and Repairs > Warranty. A warning alerts you of an operating procedure, practice, condition, or statement that must be strictly observed to avoid death or serious injury to the persons working on the equipment. A caution alerts you to an operating procedure, practice, condition, or statement that must be strictly observed to prevent equipment damage or destruction, or corruption or loss of data. Note: Notes either provide extra information about a topic or contain special instructions for handling a particular condition or set of circumstances. ivCK3R and CK3X Mobile Computer User’s Manual Disclaimer of warranties: The sample code included in this document is presented for reference only. The code does not necessarily represent complete, tested programs. The code is provided “as is with all faults.” All warranties are expressly disclaimed, including the implied warranties of merchantability and fitness for a particular purpose. Web Support Visit the Intermec web site at www.intermec.com to download our current manuals (in PDF). Visit the Intermec technical knowledge base (Knowledge Central) at www.intermec.com and click Support > Knowledge Central to review technical information or to request technical support for your Intermec product. Telephone Support In the U.S.A. and Canada, call 1-800-755-5505. Outside the U.S.A. and Canada, contact your local Intermec representative. To search for your local representative, from the Intermec web site, click About Us > Contact Us. Who Should Read This Manual This manual is for the person who is responsible for installing, configuring, and maintaining the CK3 Mobile Computer. In this manual, CK3 refers to models CK3R, CK3X, and CK3X-NI, unless specifically stated otherwise. This manual provides you with information about the features of the CK3, including how to install, configure, operate, maintain, and troubleshoot it. Before you work with the CK3, you should be familiar with your network and general networking terms, such as IP address. Related Documents The Intermec web site at www.intermec.com contains our documents (as PDF files) that you can download for free. CK3R and CK3X Mobile Computer User’s Manualv To d o w n l o a d d o c u m e n t s 1Visit the Intermec web site at www.intermec.com. 2Click the Products tab. 3Using the Products menu, navigate to your product page. For example, to find the CK3 computer product page, click Computers > Handheld Computers > CK3. 4Click the Manuals tab. If your product does not have its own product page, click Support > Manuals. Use the Product Category field, the Product Family field, and the Product field to help you locate the documentation for…

Text truncated - open the document above for the full version.

CK3R/CK3X Mobile Computer Compliance Insert Model s 1007CP01, 1007CP02, 1007CP02L, 1007CP02-NI ME04 Complies with IDA Standards DA 102905 For Users in English-Speaking Regions (en) Intermec Mode l 1007CP02 is available certified for use in typical commercial environments as well as an optional version, Model 1007CP02- NI, certified for use in Divisio n 2 hazardous locations in the United States and Canada. This document addresses both use environments. The additional precautions for safe use of the Division 2 rated version are at the end of this document. Caution: This marking indicates that the user should read all included documentation before use. Retain this supplement for future reference. Users of this product are cautioned to use accessories and pe ripherals approved by Intermec Technologies Corporation. The use of accessories other than those recommended, or changes to this product that are not approved by Intermec Technologies Corporation, may vo id the compliance of thi s product and may result in the loss of the user’s authority to operate the equipment. Battery, Charger, and Power Supply Information Caution: For use with Intermec ba ttery pack Models AB17, AB18, 1001AB01, or 1001AB02 onl y. See battery instructions. For power supply, use Phi Hong model PSA10F-050Q-R (Intermec P/N 851-099-001). No us er-servi ceable parts. Charge only in or with Intermec model AC20, AD20, AD21, AD22, or AA23 with AE23 charger; or with Intermec base 1002UU01, 1002UU04 or 1002UU05 using Intermec adapter 1002UD02 or 1002UD05. Use of incorrect charger may pr esent a risk of fire or explosion. Promptly dispose of us ed battery pack according to the instructions. Caution: The battery pack used with this product may igni te, create a chemical burn hazard, explode, or release toxic materials if mistreated. Do not incinerate, disassemble, or heat above 100 °C (212 °F). Do not short circuit; may cause burns. Keep away from children. Battery Recycling Information Li-ion Li-ion This product contains or uses a lithium-ion (Li-ion) main batter y. When the battery reaches the end of its useful lif e, the spent battery should be disposed of by a qualified recycler or hazardous materials handler. Do not mix this battery wit h the solid waste stream. Contact your Intermec Technologies Service Center for recycling or disposal information. 802.11 Radio Precaution Statement Caution: Users are responsible for conf iguring the channels of operation that comply with their country regulatory standards. A Wireless Network Administrator should review the operating restrict ions detailed within the Access Point installation manual. Radiation Exposure Statement Warning: This equipment complie s with International Commission on Non-Ionizing Radiation Protection (ICNIRP), IEEE C95.1, Fede ral Communications Commissio n Office of Engineering and Technology (OET) Bulletin 65, Canada RSS-102, and European Committee for Electrotechnical Standardization (CENELEC) limits for exposure to radio freque ncy (RF) radiation. For CK3R (Model 1007CP01): If a body worn accessory is not purchased from Intermec, the accessor y must contain no metal and provide a 1.0 cm (0.39 in) spa ce between the de vi ce and the body. For CK3X (Model 1007CP02 & 1007CP02L): If a body worn accessory is not purchased from Intermec, the accessory must contain no metal and provide a 1.0 cm (0.39 in) spa ce between the de vi ce and the body. Use of antennas and accessories not authorized may void the compliance of this product and may result in RF exposures beyond the limits established for this equipment. To find RF exposure information, go to www.intermec.com > Products > Computers > Handheld Computers > CK3 > Manuals tab, and then scroll down to Regulator y Information. U.S.A. and Canada Laser Compliance and Precaution The 1007CP01, 1007CP02, 1007CP02L, and 1007CP02-NI are registered with the CDRH as a Class II LASER Product (21 CFR Subchapter J, Part 1040). This product has a maximum output of 1 mW at 630-680 nm. Caution: There are no user serviceable parts inside the 1007CP01 , 1007CP02, 1007CP02L, or 1007CP02-NI. Use of controls or adjustments, or performance of procedures other than those specified herein, may result in hazardous laser light exposure of up to 1 mW at 630-680 nm. Note: There are no controls or adjustments provided for routine operation or maintenance of the 1007CP01, 1007CP02, 1007CP02L, or 1007CP02-NI. 1 U.S. Dig ital Emissions Compliance This de vice complie s with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This de vice must accept any interference received, including interference that can cause undesired operation. This equipment has been tested and found to comply wit h the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause ha rmful interference to radio or television reception, which can be determine d by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the radio or tel evi sio n receiving antenna. • Increase the separation be tween the computer equip ment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the radio or tel evi sio n receiver is connected. • Consult the de aler or an experienced radio television techni cian for help. Canadian Digital Apparatus Compliance This device complies with Industry Canada licence-exempt RSS standar…

Text truncated - open the document above for the full version.

CK3X and CK3R Mobile Computer RF Exposure Information Models: 1007CP01, 1007CP02, 1007CP02L, 1007CP02-NI Radio Frequency (RF) Radiation Exposure - Specific Absorption Rate (SAR) Information Warning: This equipment complies with International Commission on Non-Ionizing Radiation Protection (ICNIRP), IEEE C95.1, Federal Communications Commission Office of Engineering and Technology (OET) Bulletin 65, Canada RSS-102, and CENELEC limits for exposure to radio frequency (RF) radiation. Use of antennas and accessories not authorized may void the compliance of this product and may result in RF exposure beyond the limits established for this equipment. For Users Within North and South America The maximum IEEE C95.1 allowed SAR value is 1.6 W/kg over 1 g of tissue. Radio Frequency (RF) Exposure - Specific Absorption Rate (SAR) Test Results for Model 1007CP02, 1007CP02L and 1007CP02-NI Radio Technology W/kg Comment 802.11abgn 0.113 0.518 Held to face For body-worn operation Bluetooth N/A Negligible due to very low output power Radio Frequency (RF) Exposure - Specific Absorption Rate (SAR) Test Results for Model 1007CP01 Radio Technology W/kg Comment 802.11bgn 0.201 0.522 Held to face For body-worn operation For body-worn operation Bluetooth N/A Negligible due to very low output power Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2011 Intermec Technologies Corporation. All rights reserved. CK70 Mobile Computer RF Exposure Information *933-257-001* P/N 933-257-001, Revision A

June 28, 2012 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: EHA-1007CP02 To Whom It May Concern: This letter is to ascertain that Intermec Technologies Corporation Product 1007CP02 has been the units used for conducting FCC compliance testing, the DoC part will be tested by an FCC recognized test lab. If you have any question or concerns, please contact me at 319-369-3338 Sincerely, Sherie L Mathis Sr. Engineer, Safety & Compliance Intermec Technologies Corp. 6001 36 th Avenue West Everett, Washington 98203 United States tel 425.348.2600 fax 425.355.9551 www.intermec.com

Date: June 30, 2010 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 To whom it may concern, Agent’s Authorization Letter I, named contact of grantee for Intermec Technologies Corporation, do hereby authorize, until further notice, Sherie Mathis of Intermec Technologies, to act on my behalf in dealings before the Federal Communications Commission with respect to all matters relating to equipment authorizations under 47 CFR. This authorization maintains that Intermec Technologies Corporation remains responsible for all statements and exhibits in this application. I certify that no party (as defined in 47 CFR 1.2002) to this application, including myself, is subject to a denial of federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 853A. Certified By: Dave Fry Sr. EMC Engineer 550 Second Street Cedar Rapids, IA 52401 Dave Fry MS GR05 Sr. EMC Engineer tel 319.846.2415 fax 319.846.2475 [email protected] www.intermec.com

Belt Clip Type 1 Belt Clip Type 2

Label Location

INTERMEC TECHNOLOGIES CORP. PORTABLE COMPUTER WITH 802.11A/B/G/N AND BT Model: 1007CP02 July 6th, 2012 Report No.: SL12011201-ICT-001_1007CP02(FCC_SAR) Rev1.0 (This report supersedes: SL12011201-ICT-001_1007CP02(FCC_SAR)) This Test Report is Issued Under the Authority of: David Zhang Compliance Engineer Leslie Bai Director of Certification Modifications made to the product : None This test report may be reproduced in full only. All Test Data Presented in this report is only applicable to presented Test sample. Title: RF Test Report of Intermec Technologies Corp Model : 1007CP02 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS+102 Issue 4 and Safety Code 6,EN 62209+2:2010 Serial# SL12011201+ICT+001_1007CP02(FCC_SAR) Rev1.0 Issue Date July 6th, 2012 Page 2 of 99 www.siemic.com REDIT SIEMIC SIEM Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom , SAR Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom , SAR Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety , SAR Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety, SAR Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom HongKong OFTA (US002) RF , Telecom Title: RF Test Report of Intermec Technologies Corp Model : 1007CP02 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS+102 Issue 4 and Safety Code 6,EN 62209+2:2010 Serial# SL12011201+ICT+001_1007CP02(FCC_SAR) Rev1.0 Issue Date July 6th, 2012 Page 3 of 99 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Intermec Technologies Corp Model : 1007CP02 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS+102 Issue 4 and Safety Code 6,EN 62209+2:2010 Serial# SL12011201+ICT+001_1007CP02(FCC_SAR) Rev1.0 Issue Date July 6th, 2012 Page 4 of 99 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ............................................................................................................. 6 2 TECHNICAL DETAILS .................................................................................................................................................. 7 3 INTRODUCTION ........................................................................................................................................................... 8 4 SAR MEASUREMENT SETUP ....................................................................................................................................... 9 5 ANSI/IEEE C95.1 – 1999 RF EXPOSURE LIMIT ............................................................................................................ 19 6 SYSTEM AND LIQUID VALIDATION ............................................................................................................................ 20 7 TYPE A MEASUREMENT UNCERTAINTY ................................................................................................................... 30 8 OUTPUT POWER VERIFICATION................................................................................................................................ 32 9 SAR TEST RESULTS .................................................................................................................................................. 36 ANNEX A. TEST INSTRUMENT & METHOD......................................................................................................................... 70 ANNEX B EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................................... 71 ANNEX C CALIBRATION REPORTS .................................................................................................................................. 72 Title: RF Test Report of Intermec Technologies Corp Model : 1007CP02 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS+102 Issue 4 and Safety Code 6,EN 62209+2:2010 Serial# SL12011201+ICT+001_1007CP02(FCC_SAR) Rev1.0 Issue Date July 6th, 2012 Page 5 of 99 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Intermec Technologies Corp Model : 1007CP02 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS+102 Issue 4 and Safety Code 6,EN 62209+2:2010 Serial# SL12011201+ICT+001_1007CP02(FCC_SAR) Rev1.0 Issue Date July 6th, 2012 Page 6 of 99 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programmed was to demonstrate compliance of the Intermec Technologies Corp Model: 1007CP02 against the current Stipulated Standards. The Portable Computer with 802.11a/b/g/n and BT have demonstrated compliance with the C95.1, IEEE 1528, OET Bulletin 65 Supplement C , RSS+102 Issue 4, Safety Code 6 and EN 62209+2:2010. The test has demonstrated that this unit complies with stipulated standards. EUT Information EUT Description : Mobile Computer Model No : 1007CP02 Serial No : 146X1200036 HW version : N/A IMEI : N/A…

Text truncated - open the document above for the full version.

INTERMEC TECHNOLOGIES CORPORATION PORTABLE COMPUTER WITH 802.11A/B/G/N AND BT Model : 1007CP02 July 2,2012 Report No.: SL12011201-ICT-001 (WLAN_15.407) Rev1.0 (This report supersedes: SL12011201-ICT-001 (WLAN_15.407)) Modifications made to the product : None This Test Report is Issued Under the Authority of: Choon Sian Ooi Test Engineer Leslie Bai Engineering Reviewer This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report of Intermec Technologies Corporation, Model : 1007CP02 To FCC 15.407:2011 , RSS210 Issue 8 Serial# SL12011201'ICT'001 (WLAN_15.407) Rev1.0 Issue Date July 2,2012 Page 2 of 60 www.siemic.com Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one'stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China , Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC (RCB 208) RF , Telecom HongKong OFTA (US002) RF , Telecom Title: RF Test Report of Intermec Technologies Corporation, Model : 1007CP02 To FCC 15.407:2011 , RSS210 Issue 8 Serial# SL12011201'ICT'001 (WLAN_15.407) Rev1.0 Issue Date July 2,2012 Page 3 of 60 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Intermec Technologies Corporation, Model : 1007CP02 To FCC 15.407:2011 , RSS210 Issue 8 Serial# SL12011201'ICT'001 (WLAN_15.407) Rev1.0 Issue Date July 2,2012 Page 4 of 60 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION......................................................................................................................... 6 2 TECHNICAL DETAILS ................................................................................................................................................................. 7 3 TEST SUMMARY .......................................................................................................................................................................... 9 4 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ............................................................................................... 10 ANNEX A. TEST INSTRUMENT & METHOD ..................................................................................................................................... 27 ANNEX B EUT AND TEST SETUP PHOTOGRAPHS ....................................................................................................................... 28 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT .............................................................................................................. 29 ANNEX D USER MANUAL, BLOCK & CIRCUIT DIAGRAM ............................................................................................................. 31 ANNEX E USER MANUAL, BLOCK & CIRCUIT DIAGRAM.............................................................................................................. 32 ANNEX F SIEMIC ACCREDITATION ................................................................................................................................................. 33 Title: RF Test Report of Intermec Technologies Corporation, Model : 1007CP02 To FCC 15.407:2011 , RSS210 Issue 8 Serial# SL12011201'ICT'001 (WLAN_15.407) Rev1.0 Issue Date July 2,2012 Page 5 of 60 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Intermec Technologies Corporation, Model : 1007CP02 To FCC 15.407:2011 , RSS210 Issue 8 Serial# SL12011201'ICT'001 (WLAN_15.407) Rev1.0 Issue Date July 2,2012 Page 6 of 60 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programme was to demonstrate compliance of the Intermec Technologies Corporation, Portable Computer with 802.11a/b/g/n and BT, against the current Stipulated Standards. The Portable Computer with 802.11a/b/g/n and BT have demonstrated compliance with the FCC 15.407:2011 & RSS210 Issue 8 DFS . Applicant & EUT Information Applicant Information Applicant / Client Intermec Technologies Corporation 6001 36th Ave. West Everett, WA 98203, USA Manufacturer1 Intermec Technologies Corporation 6001 36th Ave. West Everett, WA 98203, USA EUT Information EUT Description : Mobile Computer Model Name : 1007CP02 Serial No : N/A Input Power : 4.4/4.7VDC 2/1.5A Frequency : WLAN (5180'5240MHz) (5260 ' 5320MHz) (5500'5700MHz) Modulation : DSSS/OFDM Classification Per Stipulated Test Standard : UNII Device Title: RF Test Report of Intermec Technologies Corporation, Model : 1007CP02 To FCC 15.407:2011 , RSS210 Issue 8 Serial# SL12011201'ICT'001 (WLAN_15.407) Rev1.0 Issue Date July 2,2012 Page 7 of 60 www.siemic.com 2 TECHNICAL DETAILS Laboratory performing the tests SIEMIC Laboratories 2206 Ringwood Ave, San Jose, CA 95131 Date of EUT received Jun…

Text truncated - open the document above for the full version.

Top Position (LCD Up) Note: Separation distance 1 cm Bottom Position (LCD Down) Note: Separation distance 1 cm Left Side Position Note: Separation distance 1 cm Right Side Position Note: Separation distance 1 cm Position (Bottom) with belt clip type 1 Note: Separation distance 0 cm Position (Left) with belt clip type 2 Note: Separation distance 0 cm Position with bar code scanner handle – 1 Note: Separation distance 0 cm Position with bar code scanner handle – 2 Note: Separation distance 0 cm

Radiated Emission Radiated Emission Test Setup (30MHz – 1GHz) - Front View Radiated Emission Test Setup (30MHz – 1GHz) – Rear View Radiated Emission Test Setup (Above 1GHz) - Front View Radiated Emission Test Setup (above 1GHz) – Rear View Conducted Emission Conducted Emission Test Setup – Front View Conducted Emission Test Setup – Rear View
