EHA-IM10IM10, IM10G

IF2 Network Reader and IM10 radio, 900 MHz Compliance Insert Model 1009FF01 Retain This Supplement / General Warning Caution: This marking indicates that the user should read all included documentation before use. Retain this supplement for future reference. Caution: Users of this product are cautioned to use accessories and peripherals approved by Intermec Technologies Corporation. The use of accessories other than those recommended, or changes to the product that is not approved by Intermec Technologies Corporation, may void the compliance of this product and may result in the loss of the user’s authority to operate the equipment.. Power Supply Information Caution: For Power Supply use Intermec Model AE15 (P/N 851-061-408). Alternatively this product may be powered by a Power-Over-Ethernet network compliant with IEEE 802.3at. If using POE users are cautioned to select a POE power source which complies with all of the safety and EMC regulations in the country of use. No user-serviceable parts. For Users Within North and South America This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that can cause undesired operation. Caution: FCC Compliance Intermec RFID systems require professional installation. Antennas: The users of this product are cautioned to use antennas and accessories approved by Intermec Technologies Corporation. The use of antennas and accessories other than those recommended, or changes to this product that are not approved by Intermec Technologies Corporation, may void the compliance of this product and may result in the loss of the user’s authority to operate the equipment. FCC Digital Emissions Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the radio or television receiving antenna. • Increase the separation between the computer equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the radio or television receiver is connected. • Consult the dealer or an experienced radio television technician for help. Canadian Digital Apparatus Compliance This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Radiation Exposure Statement Warning: This equipment complies with International Commission on Non-Ionizing Radiation Protection (ICNIRP), IEEE C95.1, Federal Communications Commission Office of Engineering and Technology (OET) Bulletin 65, Canada RSS-102, and CENELEC limits for exposure to radio frequency (RF) radiation. Use of antennas and accessories not authorized may void the compliance of this product and may result in RF exposures beyond the limits established for this equipment. When installing and using this product, a 25.4 cm (10 in.) passing distance must be maintained from the body or head of the user or nearby persons and the antenna. The antenna must not be touched during transmitter operation. This product is intended for business and industrial environments and should not be used by children. Conservez ce supplément / Mise en garde générale Attention: Ce marquage indique que l’usager doit, avant l’utilisation, lire toute la documentation incluse. Conservez ce supplement pour référence future. Attention: Utilisateurs de ce produit sont avisés d’utiliser des accessoires et des périphériques approuvés par Intermec Technologies Corporation. L’utilisation d’accessoires autres que ceux recommandés ou des changements à ce produit qui ne sont pas approuvés par Intermec Technologies Corporation peuvent annuler la conformité de ce produit et mettre fin au droit qu’a l’usager d’utiliser l’équipement. Information sur l'Alimentation Attention: Pour l’alimentation, utiliser le modèle Intermec AE15 (P/N 851-061-408). Alternativement, ce produit peut être alimenté par un réseau Power-Over-Ethernet conforme à la norme IEEE 802.3. Si vous utilisez POE les utilisateurs sont informés de choisir une source d'alimentation POE, qui est conforme à toutes les réglementations de sécurité et EMC dans le pays d'utilisation. Il ne contient aucune pièce réparable par l’utilisateur. À l’attention des utilisateurs en Amérique du Nord et du Sud Ce dispositif est conforme à la partie 15 des règlements du FCC et à la norme RSS-210 d’Industrie Canada. L’utilisation est assujettie aux deux conditions suivantes : (1) Ce dispositif ne doit pas causer d’interférence dommageable et (2) Ce dispositif doit tolérer toute interférence, incluant l’interférence pouvant causer un fonctionnement indésirable. Conformité aux normes canadiennes sur les appareils numériques Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouilleur du Canada. Énoncé sur l'exposition aux radiations Avertissement : Ce matériel est conforme à la Commission internationale de protection contre les rayonnements non ionisants (ICNIRP), IEEE C95.1, Federal Communications Commission Bureau d'ingénierie et de technologie (OET) Bulletin 65, Canada RSS-102 et CENELEC les limites d'exposition aux rayonnements d…

Text truncated - open the document above for the full version.

Worldwide Headquarters6001 36th Avenue WestEverett, Washington 98203U.S.A.tel 425.348.2600fax 425.355.9551www.intermec.com© 2010 Intermec Technologies Corporation. All rights reserved. Petunjuk Referensi Cepat Pembaca Jaringan IF2 ,)㔥㒰䯙䇏఼ᖿ䗳খ㗗ᣛफ ̃ ̇˅ʳጻሁᔹᦰᕴݶຒ೶ەਐত Guide de référence rapide du lecteur réseau IF2 Kurzanleitung für IF2-Netzwerk-Lesegerät khTB∑䎥㞹䅙B⪙⑁B歹⩥B㴥㥝B㘵↡(ᄎ) Guia de referência rápida do leitor de rede IF2 Guía de referencia rápida del lector de red IF2 IF 2 Network ReaderModel 1009FF01 Quick Reference Guide IF2 Network Reader Quick Reference Guide*930-205-001*P/N 930-295-001 Where to Find More InformationTempat Mencari Informasi Lebih Lanjutᙃֵ䆺㒚᳝݇ڶᣂᇡาॾஒOù trouver d’autres détails Verweise zu weiteren Informationen㤂ⷡ⩩B⑁Bⴉᶙ䙅ἝB㟱䙅㛙B㚡☁㚽Onde obter mais informaçõesDónde encontrar más información www.intermec.comIn the U.S.A and Canada, call 1.800.755.5505 Caution: See Compliance Insert for use restrictions associated with this product. Hati-hati: Bacalah Sisipan Kepatuhan tentang pembatasan pemakaian yang terkait dengan produk ini.䄺ਞ˖᳝݇ᴀѻકⳌ݇ⱘՓ⫼䰤ࠊˈ䇋খ䯙Āヺড়ᗻᦦ义āDŽ૿ऱᎅࣔΖֱࠫૻشࠌข঴ءᣂڶ๵ᒤ༺଄խߠΚᓮ೶ܫᤞAttention: Consultez la Déclaration de conformité pour les restrictions d’usage associées à ce produit. Vorsicht: Das Konformitätsblatt führt etwaige Verwendungseinschrän kungen für dieses Produkt an. 㥝気\BⷥB㤉䕵ᷩBᷭ⤕┉B㆙㞖B㤉䙉㚽B⏭䙉B㡽(六)䙉B↡㞖㠭B㧭㌅Bỉ㤂㠱B㴥㥝䙅㏚㏉㜑PBCuidado: Consulte as informações sobre as restrições de uso associad as a este produto no encarte sobre conformidade. Precaución: Consulte el Inserto de cumplimiento para ver las restriccio nes de uso asociadas con este producto. This product is protected by one or more patents. Produk ini dilindungi oleh satu atau lebih paten. ᴀѻકফࠄϔ乍៪໮乍ϧֱ߽ᡸDŽ অᥨΖܓႈറڍࢨԫႈࠩ࠹ข঴ء Ce produit est protege par un brevet ou plus. Dieses Produkt ist durch ein oder mehre re Patente geschutzt. ⷥB㤉䕵㠭B 䙅ↅB㡡ㆮ㡅B䎦䚵Bṹ㚽B㡅䙡Bⷡ䜥⩩Bⴈ㎢⎵⏑PB Este produto está protegido por uma ou mais patentes. Este producto esta protegido por una o varias patentes. Electrical rating. Peringkat kelistrikan. 乱ᅮ⬉य़ঞ⬉⌕ ሽ՗๵ࡳଖΖ Cote électrique. Stromversorgung. 㣱ἝB◞ỶP Especifi cações eléctricas. Califi cacón eléctrica: x 55 V, 30 W POE: x 44 V, 350 mA Maximum ambient temperature (Tma). Temperatur kamar maksi mum (Tma). ᳔໻⦃๗ ⏽ᑺ 7PD DŽ ່Օᛩቼᄵ৫ʳʻ˧̀˴ʼΖ Température ambiante maximale (Tma). Maximale Umgebungslufttemperatur (Tul). 㹉᷍B㧩ⶭB㜕(v)BJvƒKPB Temperatura ambiente máxima (Tma). Temperatura máxima do ambiente (Tma): 122 ° F (50 ° C) To use the IF2, you need an Intermec Model AE15 (P/N 851-061-408) power supply with AC cord or a connection to an IEEE 802.3at compliant high p ower POE network. The power supply and power adaptor are sold and ordered separately. For help, contact your Intermec sales representative.Untuk menggunakan IF2, Anda memerlukan sumber tenaga Inter mec Model AE15 (P/N 851-061-408) dengan kabel AC atau koneksi ke POE tenaga ti nggi IEEE 802.3at. Sumber tenaga dan tenaga adaptor dijual dan dapat disorder s ecara terpisah. Untuk bantuan, hubungi perwakilan penjualan Intermec. Unt uk bantuan, hubungi perwakilan penjualan Intermec.བ䳔Փ⫼,)ˈᙼ䳔㽕䜡໛,QWHUPHFൟ$( 31 $& ⬉⑤㒓៪ ヺড়(((,DWᷛޚⱘ໻ࡳ⥛32(㔥㒰䖲᥹㒓DŽ⬉⑤㒓Ϣ⬉⑤䗖䜡఼ഛऩ⣀ߎଂ੠ᅮ䌁DŽབ䳔ᐂࡽˈ䇋㘨㋏ᔧഄⱘ,QWHUPHF䫔ଂҷ㸼DŽڕᏁشࠌʳ ̃ ̇˅Δ൞Ꮑ૞಻ໂʳ ̃́̇˸̅̀˸˶ʳীʳ˔ ̆˄ˈʳʻˣ˂ˡʳˋˈ˄ˀ˃ˉ˄ˀˇ˃ˋʼʳ˔˖ʳሽᄭ ʳٽฤࢨᒵ ̃ ̆ ̆ ̆ʳˋ˃˅ˁˆ˴̇ʳᑑᄷऱՕפ෷ʳˣˢ ̆ʳጻሁຑ൷ᒵΖሽᄭᒵፖሽᄭ಻൷ᕴ݁Ꮑ׼᝜ࡳࡉ᝜ΖڕᏁᚥܗΔᓮᜤ࿮ᅝچऱʳ ̃́̇˸̅̀˸˶ʳᔭഇז।ΖPour utiliser le IF2, vous avez besoin d’un cordon d’alimentation secteur modèle Intermec AE15 (P/ N 851-061-408) ou d’une connexion à un rése au POE haute puissance conforme à la norme IEEE 802.3 . L’alimentation et l’adaptateur secteur sont vendus et commandés séparément. Pour de l’assistance, contacter votre représentant commercial Intermec.Zum Gebrauch des IF2 wird ein Netzteil Intermec-Modell AE15 (Bestellnr. 851-061-408) mit einem Wechselstromnetzkabel oder ein Anschluss an ein I EEE 802.3at-konformes POE-Versorgungsnetzwerk benötigt. Das Netzteil und der We chselstromadapter sind separat zu bestellen und zu kaufen. Hilfestellungen erhalten Sie von Ihrem Intermec-Vertreter.khTB⩩B㆙㞖䙅⤑⭡NBceB䁁◉᳭B㡵⎁Bk–‡”‡…⮕⑥BcgSWBJrQpBZWSORXSOVR ZKB 㣱㞽BᷢỶἝↅBỉᶖ㚽B⹭䙖䙅⎁B᷍B㺉⤒BrqgB∑䎥㞹䅙㚽(ᄎ)BkgggBZRTPUB㛝ᶝ㡡B䘱㞁䙖⎵⏑PB㣱㞽BᷢỶἝB⳼B㣱㞽B㚡⏾䈝⎁Bⶱ(v)⥉B䏽⫑┅᷍B㧩ⰥBⴈ㎢⎵⏑PB(v)㞭㡡B䘱㞁䙉Bᶪ㞝NB䙡⏦B㪭㛚㡅Bk–‡”‡…B䏽⫑B⏭⪙㣽㚽BⰥ㡅䙅㏚㏉㜑PPara usar o IF2, você precisa de um no-break Intermec Modelo A E15 (P/N 851- 061-408) com cabo AC ou uma conexão com uma rede POE de alta alimentação compatível com IEEE 802.3. Um no-break e um adaptador de alim entação são vendidos e encomendados separadamente. Para obter ajuda, en tre em contato com o representante de vendas da Intermec.Para usar el IF2, se necesita una fuente de alimentación Inte rmec Modelo AE15 (P/N 851-061-408) con cable de corriente alterna (CA) o una conexión a una red POE de alta potencia que cumpla con la norma IEEE 802.3at. La fuente d e alimentación y el adaptador de energía se venden y piden por separado. Para reci bir asistencia, contacte a su representante de ventas de Intermec. IF 2 GPIO IOIOI IOIOI PoE PoE PoE Intermec Ready-to-Work Indicator Indikator Siap-Kerja Intermec,QWHUPHF5HDG\WR:RUNᣛ冫♃,QWHUPHF5HDG\WR:RUNᣛ冫఼Indicateur Intermec Ready-to-Work ™Kurzanleitung für IF2-Netzwerk-Lesegerätk–‡”‡…Bt‡ƒ†›O–‘Oy‘”B䕉㏉ἝIndicador Ready-to-Work da IntermecIndicador Intermec Ready-to-WorkPower Over EthernetTenaga lewat Ethernetҹ໾㔥կ⬉ҹ໾㎆䏃կ䳏Alimentation sur EthernetPower over Ethernet㡡⑁∤B㣱㞽B㢒㽅Alimentação sobre EthernetEnergía por EthernetPower LEDLED Tenaga⬉⑤/('䳏⑤/('Voyant DEL d’alimentationNetz-LED㣱㞽BngfLED de alimentaçãoLED de encendido Wired LAN LEDLAN LED yang terhubung ᳝㒓/$1/('᳝㎮/$1/('Voyant DEL de réseau local câbléFestnetz LAN-LED㠍(ᄒ)BncpBngfLED de LAN com fi oLED de LAN alámbrica Tag ID LEDID LED Tag ᷛᅤ,'/('῭(労),'/('Voyant ID étiquetteTag ID-LED㠍(ᄒ)BncpBngfLED de ID da etiquetaLED de identifi cación de rótulo RFID status LED (4 places)LED status RFID (4 tempat)5),'⢊ᗕ/('˄໘ 5),'⢔ᜟ/('˄㰩 DEL d’état du RFIDRFID Status-LED (4)thkfBㆮ䇉BngfBJVBṝ⑝KLED de status do RFID (4 locais)LED de…

Text truncated - open the document above for the full version.

Date: December 22, 2010 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 To whom it may concern, I, named contact of grantee for Intermec Technologies Corporation, do hereby attest that a Declaration of Conformity, based on testing from a FCC recognized accredited testing laboratory, will be made prior to marketing of the device. Certified By: Dave Fry Sr. EMC Engineer Intermec Technologies Corporation Dave Fry MS GR05 550 Second Street Cedar Rapids, IA 52401 Desk tel 319.369.3353 Lab tel 319.846.2415 Fax tel 319.846.2475 [email protected] 6001 36 th Avenue West Everett, Washington 98203 United States tel 425.348.2600 fax 425.355.9551 www.intermec.com

Date: December 17, 2010 Telecommunication Certification Body (and/or) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Long Term Confidentiality FCC ID: EHA-IM10 To whom it may concern, We hereby respectfully request that under the provisions of 47 CFR 0.457 and 0.459, the documents listed below and attached with this application for certification be provided with permanent confidential status. • Schematics • Theory of Operation • Frequency Block Diagrams Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents above contain trade secrets and proprietary information that are treated as confidential and not released to the public. Substantial competitive harm to Intermec or our suppliers could result should they be made available to the public. Please contact me if there are questions or additional information needed concerning this request. Sincerely, Dave Fry Sr. EMC Engineer, iNARTE ATL-0095-E Intermec Technologies Corporation Dave Fry MS GR05 550 Second Street Cedar Rapids, IA 52401 Desk tel 319.369.3353 Lab tel 319.846.2415 Fax tel 319.846.2475 [email protected] 6001 36 th Avenue West Everett, Washington 98203 United States tel 425.348.2600 fax 425.355.9551 www.intermec.com

Date: December 17, 2010 Telecommunication Certification Body (and/or) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Application for Grant of Original Certification Dear Application Examiner, Intermec Technologies Corporation is submitting this application for Original Certification for their RFID radio, FCC ID: EHA-IM10, model numbers IM10 and IM10G. The IM10 and IM10G are electrically and mechanically identical except that the IM10G contains software switched filter circuits utilized only for Japan compliance. The IM10/IM10G RFID radio operates at 1.0 Watt as frequency hopping spread spectrum transmitter operating within the 902.75 – 927.25 MHz band under Section 15.247. The radio is designed to read and write information to passive RFID tags. This application requests the IM10/IM10G be granted “Limited Modular Approval” to accommodate “Professional Installation”. RFID technology is used in specific locations and is limited in marketing to industrial and commercial users. Intermec RFID products are never sold to the general public. The installations are always overseen by Intermec systems engineers or RFID certified partners. A letter confirming the modular approval requirements is contained within this application. This radio is used within several Intermec products, integration testing will include verification the transmitter characteristics remain as documented in this application and the end product complies with all FCC regulations. Integration testing will be reported under Certification, Declaration of Conformity or Verification rules defined by 47 CFR Parts 2 and 15. Your efforts in reviewing this application are greatly appreciated. Please contact me if there are questions or additional information needed concerning this request. Sincerely, Dave Fry Sr. EMC Engineer, iNARTE ATL-0095-E Intermec Technologies Corporation Dave Fry MS GR05 550 Second Street SE Cedar Rapids, IA 52401 Desk tel 319.369.3353 Lab tel 319.846.2415 Fax tel 319.846.2475 [email protected] 6001 36 th Avenue West Everett, Washington 98203 United States tel 425.348.2600 fax 425.355.9551 www.intermec.com

Page 1 of 3 Date: December 17, 2010 Telecommunication Certification Body (and/or) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 ATTESTATION FOR MODULAR APPROVAL Ref FCC ID: EHA-IM10 Gentlemen; In order to obtain a modular transmitter approval, a cover letter requesting modular approval must be submitted and the 8 numbered requirements identified below must be addressed in the application for equipment authorization. This application requests the IM10 be granted “Limited Modular Approval” to accommodate “Professional Installation”. RFID technology is used in specific locations and is limited in marketing to industrial and commercial users. Intermec RFID products are never sold to the general public. The installations are always overseen by Intermec systems engineers or RFID certified partners. 1. The modular transmitter must have its own RF shielding. This is intended to ensure that the module does not have to rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with Part 15 limits. It is also intended to prevent coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed. Such coupling may result in non-compliant operation. Intermec Technologies is provided the radio as a shielded assembly. The radio is shown in this report reveals the transmitter emissions comply with the limits defined by the regulatory agencies. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The communication to the radio operates digital technology. The communication buffering eliminates the ability to over-modulate the radio under all conditions. 3. The modular transmitter must have its own power supply regulation. This is intended to 6001 36 th Avenue West Everett, Washington 98203 United States tel 425.348.2600 fax 425.355.9551 www.intermec.com Page 2 of 3 ensure that the module will comply with Part 15 requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. The IM10 radio board uses an onboard voltage regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Any antenna used with the module must be approved with the module, either at the time of initial authorization or through a Class II permissive change. The “professional installation” provision of Section 15.203 may not be applied to modules. The IM10 radio module utilizes unique connectors, RF cables for the system must be supplied by Intermec so antenna / cable system gain remains below the +6 dBi linear gain limit. Some RFID antennas are sourced with standard connectors; the approved antenna list is published in the user documentation provided with products that utilize this radio module. The professional installation provisions under Section 15.203 are addressed in the second paragraph of this letter. Limited Modular Approval is requested. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified or commercially available (see Section 15.31(i)). Testing herein shows the radio tested as a module. The setup photographs show no ferrites or decoupling devices to reduce emissions of the module. AC power line conducted emissions is shown within for the final product. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Page 3 of 3 Enclosed within this report are label diagrams with similar verbiage shown above. The module will show the FCC ID. If when integrated the radio module identifier is not visible, the exterior will show the “Contains TX FCC ID:” text. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For ex…

Text truncated - open the document above for the full version.

Northwest EMC TCB Compliance Opinion Rev. 12/08/09 ITRM0211 Information about the Applicant Grantee (Company Name) Intermec Technologies Corporation FCC Contact Person Dave Fry Address 550 Second St. SE City, State, Zip Cedar Rapids, IA 52401-2023 Job Number ITRM0211 Model IM10, IM10G FCC ID EHA-IM10 Agent NA Approval Type Original Equipment Class DSS Part 15, Spread Spectrum Transmitter Rule Part 15.247 (15C) Overview This application is for an original approval of Intermec Corporation's RFID radio models IM10, IM10G, FCC ID: EHA-IM10. The radio is a Frequency Hopping Spread Spectrum transmitter, operating under FCC 47 Cfr 15.247. Applicant is requesting limited modular approval, requiring professional installation. Exhibits have been submitted supporting the compliance of this device to the necessary requirements. Confidentiality requested for allowed files. Request is properly addressed and referenced. A letter listing the applicable modular requirements was submitted. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 12/29/2010

IM10 radio module within IF2 FCC and Canada ID silk screened on to printed circuit board FCC ID: EHA-IM10 IC: 1223A-IM10 Note: Model: IM10 with printed circuit load part number in lower left.

Test Status Intermec P/N N/P Intermec Intermec M/N, Supplier P/N Intermec N/M, Fournisseur N/P Description Description Gain (dBi)* Gain (dBi)* Cable Loss Perte du Câble (dB) Antenna/cable system gain (dBi) ABCDEFG E - F = G 805-609-001IA33A, Cushcraft SP9028PC156RSMPatch CP - Plaque PC4.004.0 805-622-002IA39A, Kathrein 25-178Patch CP - Plaque PC6.52.44.1 805-623-002IA39D, Kathrein 25-278Patch CP - Plaque PC5.02.42.6 805-626-001IA36B, Kathrein 25-578Patch LP - Plaque PL6.02.43.6 805-629-001IA33C, Mobile Mark PN10-915RCPIPatch CP - Plaque PC7.02.44.6 805-654-001IA33G, Huber Suhner 84024995Panel RCP - Panneau PCD5.52.43.1 805-654-002IA34A, Huber Suhner 84024996Panel LCP - Panneau PCG5.52.43.1 805-655-001IA33H, Huber Suhner 84024999Panel RCP - Panneau PCD7.02.44.6 805-655-002IA34B, Huber Suhner 84025000Panel LCP - Panneau PCG7.02.44.6 805-816-002IA33E, Cushcraft S9026XR1RRNPatch CP - Plaque PC3.02.40.6 -- , Huber Suhner 1309-57-0087-XPanel RCP - Panneau PC7.02.44.6 -- , Huber Suhner 1309-56-0001-XPanel RCP - Panneau PC8.03.4 4.6 -- , Mobile Mark PN7-915I-FLPanel RCP - Panneau PC4.02.41.6 -- , Mobile Mark EDN 191-1550Panel RCP - Panneau PC4.02.41.6 Testing-- , Kathrein 520 10087Panel RCP - Panneau PC7.52.45.1 -- , Kathrein 520 10073Panel RCP - Panneau PC5.22.42.8 Testing-- , Kathrein 520 10092Patch CP - Plaque PC-30.02.4-32.4 -- , Huber Suhner 1309.17.0089-xPanel RCP - Panneau PC4.52.42.1 Testing-- , Huber Suhner 1309.17.0085-xPatch LP - Plaque PL 8.02.45.6 Testing-- , NeWave Wave-N77ft. Multi-Axis Dipole5.52.43.1 -- , NeWave Wave-N55ft. Multi-Axis Dipole4.52.42.1 -- , NeWave Wave-N33ft. Multi-Axis Dipole3.02.40.6 -- , Mobile Mark BP6-915RCPIPanel RCP - Panneau PCD2.52.40.1 -- , Laird S9025PPanel RCP - Panneau PC2.52.40.1 * CP gain dBiC = dBi + 3 -X = blank or A, B, C.... pricing code * PC gain dBiC = dBi + 3-X = blanc ou A, B, C....code d'évaluation FCC Antennas IM10 RFID Module Intermec Part Number 805-609-001 Pro posed Intermec M/N IA33A Descri ption IA33A: 915, 7dBi, RHC Pol, SMA (RP) Fre quency Range 902 - 928 MHz Gain 4 dBi linear Im pedance 50 Ohms VSWR 1.5:1 Axial Ratio 2 dB Polarization Circular, RH Front-to-Back Ratio 18 dB Maximum In put Power 1 Watt H-Plane Beamwidth 65 degrees at 3 dB E-Plane Beamwidth 65 degrees at 3 dB Connecto r SMA Reverse Polarity Cable Len gth 156 Inches Wei ght 1.25 lbs Dimensions Shock RoHS, WEEE Status Mounting Hardware N/A Manufacturer Cushcraft-Laird Manufacturer M/N Manufacturer P/N SP9028PC156RSM Product ID FCC Antennas IM10 RFID Module Intermec Part Number Proposed Intermec M/N Descri ption Fre quency Range Gain Im pedance VSWR Axial Ratio Polarization Front-to-Back Ratio Maximum In put Power H-Plane Beamwidth E-Plane Beamwidth Connecto r Cable Length Wei ght Dimensions Shock RoHS, WEEE Status Mounting Hardware Manufacturer Manufacturer M/N Manufacturer P/N Product ID 805-622-002 IA39A IA39A: 915, 9.5 dBic, Cir Pol, N (RP) 902 - 928 MHz 6.5 dBi linear 50 Ohms <1.3:1 < 3 dB over entire half power beam Circular, LH > 15 dB 100 Watts (at 50oC) 80 degrees (half power) 30 degrees (half power) N Reverse Polarity N/A 5.2 lbs (2.4 kg) 19.3 x 6.1 x 1.9 inches (490 x 155 x 49 mm) 203-734-001 kit included 203-733-001 kit order seperately 203-735-001 order seperately 203-737-001 order seperately Kathrein 25-178 FCC Antennas IM10 RFID Module Intermec Part Number Proposed Intermec M/N Descri ption Fre quency Range Gain Im pedance VSWR Axial Ratio Polarization Front-to-Back Ratio Maximum In put Power H-Plane Beamwidth E-Plane Beamwidth Connecto r Cable Length Wei ght Dimensions Shock RoHS, WEEE Status Mounting Hardware Manufacturer Manufacturer M/N Manufacturer P/N Product ID 805-623-002 IA39D IA39D: 915, 8 dBic, Cir Pol, N (RP) 865-928 MHz 5 dBi linear 50 Ohms <1.3:1 3 dB Circular, LH > 20 dB 100 Watts (at 50oC) 60 degrees (half power) 55 degrees (half power) N Reverse Polarity N/A 3.8 lb (1.7 kg) 12.2 x 10.3 x 2.4 inches (310 x 262 x 59 mm) 203-734-001 kit included 203-733-001 kit order seperately 203-735-001 order seperately 203-737-001 order seperately Kathrein 25-278 FCC Antennas IM10 RFID Module Intermec Part Number Proposed Intermec M/N Descri ption Fre quency Range Gain Im pedance VSWR Axial Ratio Polarization Front-to-Back Ratio Maximum In put Power H-Plane Beamwidth E-Plane Beamwidth Connecto r Cable Length Wei ght Dimensions Shock RoHS, WEEE Status Mounting Hardware Manufacturer Manufacturer M/N Manufacturer P/N Product ID 805-626-001 IA36B IA36B: 915, 6dBi, Vert Pol, N (RP) 865-928 MHz 6 dBi linear 50 Ohms <1.5:1 N/A Patch >20 dB 100 Watts (at 50oC) 90 degrees (half power) 70 degrees (half power) N Reverse Polarity N/A 3.3 lb (1.5 kg) 10.3 x 6.1 x 1.9 inches (262 x 155 x 49 mm) 203-734-001 kit included 203-733-001 kit order seperately 203-735-001 order seperately 203-737-001 order seperately Kathrein 25-578 FCC Antennas IM10 RFID Module Intermec Part Number Proposed Intermec M/N Descri ption Fre quency Range Gain Im pedance VSWR Axial Ratio Polarization Front-to-Back Ratio Maximum In put Power H-Plane Beamwidth E-Plane Beamwidth Connecto r Cable Length Wei ght Dimensions Shock RoHS, WEEE Status Mounting Hardware Manufacturer Manufacturer M/N Manufacturer P/N Product ID 805-629-001 IA33C IA33C: 915, 10 dBic, CP, N (RP) 902 - 928 MHz 7 dBi linear 50 Ohms 1.5:1 Circular, RH 20 dB 20 Watts 56 degrees 56 degrees N Reverse Polarity 1 Foot 3.0 lbs 12.5" x 12.5" x 3.5" Tilt bracket hardware included Mobile Mark PN10-915RCPI FCC Antennas IM10 RFID Module Intermec Part Number Proposed Intermec M/N Descri ption Fre quency Range Gain Im pedance VSWR Axial Ratio Polarization Front-to-Back Ratio Maximum In put Power H-Plane Beamwidth E-Plane Beamwidth Connecto r Cable Length Wei ght Dimensions Shock RoHS, WEEE Status Mounting Hardware Manufacturer Manufacturer M/N Manufacturer P/N Product ID 805-654-001 IA33G IA33G, 915, 8.5 dBic, RHCP, N (RP) 902-928 MHz 5.5 dBi linear 50 Ohms max. 1.5 4 dB Circular, RH > 20 dB 100 Watts (at 50 ̊C) 63 degrees (At 3dB) 63 degrees (A…

Text truncated - open the document above for the full version.

RF Exposure - MPE Estimates, RFID frequency of operation 902.75 - 927.25 MHz IM10 RFID Radio Module FCC regulations compliance 47 CFR 15.247(i) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energ…

Text truncated - open the document above for the full version.
