EHA-INRD01HHF RFID board

1. Introduction This document introduces how to setup applications and use it. Below picture shows the directory hierarchy of SDK. In this SDK, we provide demo applications, drivers, and sample source code for Windows (BCB6, C#, Java, VC++2008), WinCE 5.0 and Linux. Figure 1 Directory hierarchy 2. Install Below sections introduces the steps to setup demo applications and drivers. 2.1 Windows Please follow below steps to install demo application. □ Unplug RFID HF device from USB port. □ Double-Click “RFID_NFC_Install.exe” under “.\Demonstration\Windows\BCB” path. And follow the steps to complete the installation. □ If you ever installed RFID HF Demo Application, the uninstall process will be launched first. □ Now, the installation process is launched. □ Plug-in RFID HF device into USB port. Follow the steps to install USB driver. □ Open device manager for double checking. In RFID category, RFID NFC Device was installed. □ Launch demo application by double click “RFID NFC Demo” shortcut on desktop. In the main screen, the “Status” area informs you the physical link status between PC and MSR310X. The default interface is USB. If no MSR310X been found on USB port, the “interface” area will be unlocked for manual selection. 2.2 WinCE □ Using ActiveSync to transfer “RFID_Cab.CAB” file from “.\Demonstration\WinCE” path to WinCE 5.0 based handheld device. □ Operate handheld device to find the installed file. And then, double click on it for starting installation. 2.3 Linux We only provide a command line application, TEST_ap, for demonstration. □ Copy “antusb.ko” and “TEST_ap” files from “.\ Demonstration\Linux” path to Linux PC. □ Open a new terminal on Linux PC. □ Install USB driver by typing “insmod antusb.ko” □ Add “alias rausb0 antusb” into “/etc/ modules.conf” □ Activate USB device by typing “ifconfig rausb0 up” □ Run “TEST_ap” 3. Operation 3.1 Read Tags □ Launch reader mode demo form by clicking “Mode”->”Reader”. Then the reader mode demo form will be shown as below. The RFID protocol can be selected from “Protocol” area. □ Choose “Inventory” page and put tags near MSR310X. Click “Start” button to finding tags continuously. □ Click “Stop” button to stop. □ Click “Clear” button to clear tag information. 3.2 Upgrade firmware by ISP tool □ Execute “ISP_Tool.exe” under “. \Tool” path. Click “Read” as shown below. □ Click “Read” button to select MSR310X firmware under “. \Firmware” path. Select file with 128 kB file size. □ Click “Auto” after selected file. As below. □ Click “Connect” to link with MSR310X. If success, flash type will be displayed. □ Click “Run” button to start downloading. You will see PASS if succeeded. 3.3 Upgrade firmware by DemoAP □ Launch reader mode demo form by clicking “Upgrade” □ Select 64kB firmware file and click “Start” button to upgrade. 3.4 Secure Demo □ Launch secure demo form by clicking “Mode”->”Secure Demo”. Then the secure demo form will be shown as below. The secure demo needs a pair of private key (for writing data) and public key (for verifying/reading data). The key pair can be generated by clicking “generate key pair” button. □ Select key pair by clicking “Select private key” and “Select public key” buttons. □ Enter “Old User Password” (If the tag was never set password before, let this filed empty.) , “New User Password”, “Data1”, “Data2” and then click “Write” button. A green text box “Write OK” means data is successfully written to MSR3200 tag. The MSR3200 tag will be locked if the “Lock Data” check box is checked. It is noted that the tag will no longer support write operation. PS: The maximum length of password is eight characters (64 bits). □ In order to compare the data written to tag and the data read from tag, keep “New User Password”, “Data1” and “Data2” the same as in previous step. Trigger data reading and verification by clicking “Verify” button. A green text box “Verify OK” means data is successfully read from MSR3200 tag and the data is the same as written before. □ Read data operation also enables data reading from MSR3200 tag but the data is manually verified by user. The “User Password” should be entered by user before clicking “Read” button. A green text box “Read OK” means data is successfully read from MSR3200 tag. The “Clear” button will clear “User Password”. Compliance Federal Communication Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device is intended only for OEM integrators under the following conditions: The antenna must be installed such th…

Text truncated - open the document above for the full version.

Date: 2011/10/21 FCC ID: EHA EHAEHA EHA- -- - INRD01H INRD01HINRD01H INRD01H Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Kian Meng Lim / Engineer Intermec Technologies Corporation 550 Second Street SE Cedar Rapids Iowa 52401-2029 USA

Intermec Technologies Corporation 550 Second Street SE Cedar Rapids Iowa 52401-2029 USA Date: 25 Oct 2011 Federal Communications Commission Authorization and Evaluation Division Subject: Short-term confidentiality request regarding application for certification of FCC ID: EHA- INRD01H Pursuant to DA 04-1705 of the Commission’s public notice, we request short-term confidential treatment for the following information until April 25, 2012 in order to ensure sensitive business information remains confidential until the actual marketing of the device. External Photos Test setup photos User’s Manual Internal Photos Sincerely yours, _____________________________ Kian Meng Lim / Engineer

FCC ID: EHA-INRD01H Report No. : RF980108A01 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch November 16, 2011 Dear Application Examiner, Intermec Technologies Corporation, It’s HF RFID board, FCC ID: EHA-INRD01H would like to have your authorization as a modular approval specific to the mobile device. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip MSR3100. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is XC6401EE20MRN. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a TEST BOARD extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. FCC ID: EHA-INRD01H Report No. : RF980108A01 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Ken Liu Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch

Date: December 9, 2010 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 To whom it may concern, Agent’s Authorization Letter I, named contact of grantee for Intermec Technologies Corporation, do hereby authorize, until further notice, Kain Meng Lim of Intermec Technologies, to act on my behalf in dealings before the Federal Communications Commission with respect to all matters relating to equipment authorizations under 47 CFR. This authorization maintains that Intermec Technologies Corporation remains responsible for all statements and exhibits in this application. I certify that no party (as defined in 47 CFR 1.2002) to this application, including myself, is subject to a denial of federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 853A. Certified By: Dave Fry Sr. EMC Engineer Intermec Technologies Corporation Dave Fry MS GR05 550 Second Street Cedar Rapids, IA 52401 Desk tel 319.369.3353 Lab tel 319.846.2415 Fax tel 319.846.2475 [email protected] 6001 36 th Avenue West Everett, Washington 98203 United States tel 425.348.2600 fax 425.355.9551 www.intermec.com

Intermec Technologies Corporation 550 Second Street SE Cedar Rapids Iowa 52401-2029 USA Agency Authorization Letter Date: October 7, 2011 FCC ID: EHA-INRD01H To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV CPS Taoyuan within the scope of this authorization shall have the same effects as our own. This authorization shall expire six months from the original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, _____________________________ Kian Meng Lim / Engineer

Page 1 CONSTRUCTION PHOTOS OF EUT

LABEL LOCATION Label Location

Page 2 Page 3

FCC ID: EHA-INRD01H Report No.: RF110908D07 Operational Description The transmitter of the EUT (HF RFID board) is powered by 5Vdc from host equipment. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF110908D07 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110908D07 MODEL NO.: INRD01h FCC ID: EHA-INRD01H RECEIVED: Sep. 8, 2011 TESTED: Sep. 8 ~ 21, 2011 ISSUED: Nov. 14, 2011 APPLICANT: Intermec Technologies Corporation ADDRESS: 550 Second street SE Cedar Rapids Iowa 52401-2029 USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) This test report consists of 30 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110908D07 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD ....................................................................................3 1 CERTIFICATION ................................................................................................4 2 SUMMARY OF TEST RESULTS ........................................................................5 2.1 MEASUREMENT UNCERTAINTY ......................................................................5 3 GENERAL INFORMATION .................................................................................6 3.1 GENERAL DESCRIPTION OF EUT ...................................................................6 3.1 DESCRIPTION OF TEST MODES .....................................................................7 3.1.1 CONFIGURATION OF SYSTEM UNDER TEST ................................................7 3.1.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL: ....................8 3.2 GENERAL DESCRIPTION OF APPLIED STANDARDS ..................................10 3.3 DESCRIPTION OF SUPPORT UNITS .............................................................10 4 TEST PROCEDURE AND RESULT .................................................................11 4.1 CONDUCTED EMISSION MEASUREMENT ...................................................11 4.1. LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................11 4.1.2 TEST INSTRUMENTS .....................................................................................11 4.1.3 TEST PROCEDURES ......................................................................................12 4.1.4 DEVIATION FROM TEST STANDARD ............................................................12 4.1.5 TEST SETUP ...................................................................................................13 4.1.6 EUT OPERATING CONDITIONS .....................................................................13 4.1.7 TEST RESULTS ...............................................................................................14 4.2 RADIATED EMISSION MEASUREMENT ........................................................16 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ......................................16 4.2.2 TEST INSTRUMENT ........................................................................................17 4.2.3 TEST PROCEDURE ........................................................................................18 4.2.4 DEVIATION FROM TEST STANDARD ............................................................18 4.2.5 TEST SETUP ...................................................................................................19 4.2.6 EUT OPERATING CONDITION .......................................................................19 4.2.7 TEST RESULT .................................................................................................20 4.3 FREQUENCY STABILITY ................................................................................25 4.3.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT .................................25 4.3.2 TEST INSTRUMENTS .....................................................................................25 4.3.3 TEST PROCEDURE ........................................................................................25 4.3.4 DEVIATION FROM TEST STANDARD ............................................................25 4.3.5 TEST SETUP ...................................................................................................26 4.3.6 EUT OPERATING CONDITION .......................................................................26 4.3.7 TEST RESULTS ...............................................................................................27 5 PHOTOGRAPHS OF THE TEST CONFIGURATION .......................................28 6 INFORMATION ON THE TESTING LABORATORIES .....................................29 7 APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB ............................................................30 Report No.: RF110908D07 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF110908D07 Original release Nov. 14, 2011 Report No.: RF110908D07 4 Report Format Version 4.0.0 1 CERTIFICATION PRODUCT: HF RFID board BRAND NAME: Intermec MODEL NO: INRD01h APPLICANT: Intermec Technologies Corporation TESTED: Sep. 8 ~ 21, 2011 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.225) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF110908D07 5 Report Format Version 4.0.0 2 SUMMA…

Text truncated - open the document above for the full version.

Report No.: RF110908D07 1 Report Format Version 4.0.0 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: RF110908D07 2 Report Format Version 4.0.0 Report No.: RF110908D07 3 Report Format Version 4.0.0 RADIATED EMISSION TEST Report No.: RF110908D07 4 Report Format Version 4.0.0
