EHA2126PCMCIA Wireless Network Interface

578-100-019 Revision BPage 1 of 4 Compliance Statement Insert Device Name: Wireless LAN Access PointModel Number: 6710 The responsible party for the compliance of this device is:Intermec Technologies Corporation 550 Second Street SE Cedar Rapids, Iowa 52401 USA (319) 369-3100 CAUTION: See users guide instructions for handling, charging, and replacing batteries. Failure to follow those instructions can result in personal injury, fire, or battery explosion. This product conforms to the following approvals. The user(s) of this product are cautioned to use accessories and peripherals approved by Norand Corporation. The use of accessories other than those recommended or changes to this product that are not approved by Norand Corporation may void the compliance of this product and may result in the loss of the users authority to operate the equipment. FCC Digital Emissions Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • • Reorient or relocate the radio of television receiving antenna. • • Increase the separation between the computer equipment and receiver. • • Connect the equipment into an outlet on a circuit different from that to which the radio or television receiver is connected. • • Consult the dealer or an experienced radio television technician for help. Canadian Digital Apparatus Compliance This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. FCC Spread Spectrum Transmitter Compliance This device is also certified to operate under Part 15, Subpart C, Section 15.247 of the FCC rules for Intentional Radiation Products. This certification includes Docket 87-389 covering rules effective June 1994. It may not cause interference to authorized radio communication devices, and must accept any interference caused by those devices. Canadian RSS-210 Spread Spectrum Transmitter Compliance Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Canadian 2.4 GHz Spread Spectrum Radio Certification This device requires a radio license, unless it is installed totally inside a building. (User’s must obtain this license.) Une license radio est requise oour ces dispositifs, sauf ouor ceux installés tout á fait á l’intérieur d’un bâtiment. (Il faut que l’utilisateur obtienne cette license.) Antenna Requirements FCC rules section 15.203 and Canada RSS-210 require that this device be operated using an antenna furnished by Norand Corporation. The antenna coupling on this product has been designed to accept only antennas manufactured Norand. Use of an antenna other than that furnished with the equipment is prohibited by FCC and Industry Canada rules. European Notice The 902-928 MHz Spread Spectrum Transmission (SST) radio referred to within the manual is not available for sale in Europe (including, but not limited to, Great Britain, Italy, Germany, France, Spain, Norway, Denmark, Sweden, Finland, Portugal, and the Benelux countries). Any references in the manual to 902- 928 MHz SST, or modules containing 902-928 MHz SST radios, should be disregarded by the users of this product in Europe. 578-100-019 Revision BPage 2 of 4 DECLARATION OF CONFORMITY (According to ISO/IEC Guide 22 and EN 45014) PAGE ONE OF TWO THE PRODUCT HEREWITH COMPLIES WITH THE REQUIREMENTS OF : THE LOW-VOLTAGE DIRECTIVE 72/32/EEC. THE EMC DIRECTIVE 89/336/EEC. Manufacturer’s Name:European Representative: Intermec Technologies CorporationIntermec International Incorporated 550 2nd Street SESovereign House, Vastern Road Cedar Rapids, Iowa 52401Reading, Berkshire RG1 8BT England Declares that the product listed below: Product Type:ITE/Residential, Commercial, and Light Industrial Product Name: Wireless LAN Access PointModel Number: 6710 Product Options:AllBeginning Serial Number: All Date Issued: May 30, 1996 Conforms to the following product specifications: Safety:IEC 950 / EN 60950 EMC:EN 55022 : 1995 / CISPR Publications 22 : 1993, Class B Limits and Methods EN 50082-1 : 1992 Generic Immunity Standard ETS 300 339 : Jun. 1993 Draft RES Generic EMC for radio equipments IEC 801-2 per Draft prETS 300 339, Clause 9.2 + 8 kV Air / + 4 kV Contact IEC 801-3 per Draft prETS 300 339, Clause 9.1 3 V/M, 80-1000 MHz, 80% @ 400 Hz IEC 801-4 per Draft prETS 300 339, Clause 9.3 AC Power Leads + 2 kV; Signal and Control Leads + 1.0 kV IEC 801-5 (Draft) Tested per Draft prETS 300 339, Clause 9.8 IEC 801-6 Tested per Draft prETS 300-339, Clause 9.4 AC Power Leads and Signal and Control Leads 3 Vrms, 150 kHz - 80 MHz, 80% @ 400 Hz Draft prETS 300 339, Clause 9.6, Tested per IEC 1000-4-11 30% (10 ms), 60% (100 ms), and 95% (5000ms) of 220 VAC nominal. prETS 300 683 : EMC Standard for short range devices IEC1000-4-2 Tested per Draft prETS 300 683, Clause 9.3 + 8 KV Air / + 4 KV Contact ENV 50140 Tested per Draft prETS 300 683, Clause 9.2 3 V/M, 80-1000 MHz, 80% @ 400 Hz IEC1000-4-4 Tested per Draft prETS 300 683, Clause 9.4 AC Power Leads + 2 kV; Signal And Control Leads + 1.0 kV ENV 50…

Text truncated - open the document above for the full version.

578-100-008 Revision BPage 1 of 3 Compliance Statement Insert Device Name: Hand-held ComputerModel Number: 6400 The responsible party for the compliance of this device is:Intermec Technologies Corporation Norand Mobile System Division 550 Second Street SE Cedar Rapids, Iowa 52401 USA (319) 369-3100 CAUTION: See users guide instructions for handling, charging, and replacing batteries. Failure to follow those instructions can result in personal injury, fire, or battery explosion. This product complies to the following approvals. The user(s) of this product are cautioned to use accessories and peripherals approved by Norand Corporation. The use of accessories other than those recommended or changes to this product that are not approved by Norand Corporation may void the compliance of this product and may result in the loss of the users authority to operate the equipment. FCC Digital Emissions Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the radio of television receiving antenna. • Increase the separation between the computer equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the radio or television receiver is connected. • Consult the dealer or an experienced radio television technician for help. Canadian Digital Apparatus Compliance This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. FCC Spread Spectrum Transmitter Compliance This device is also certified to operate under Part 15, Subpart C, Section 15.247 of the FCC rules for Intentional Radiation Products. This certification includes Docket 87-389 covering rules effective June 1994. It may not cause interference to authorized radio communication devices, and must accept any interference caused by those devices. Canadian RSS-210 Spread Spectrum Transmitter Compliance Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Canadian 2.4 GHz Spread Spectrum Radio Certification This device requires a radio license, unless it is installed totally inside a building. (User’s must obtain this license.) Une license radio est requise oour ces dispositifs, sauf ouor ceux installés tout á fait á l’intérieur d’un bâtiment. (Il faut que l’utilisateur obtienne cette license.) Antenna Requirements FCC rules section 15.203 and Canada RSS-210 require that this device be operated using an antenna furnished by Norand Corporation. The antenna coupling on this product has been designed to accept only antennas manufactured Norand. Use of an antenna other than that furnished with the equipment is prohibited by FCC and Industry Canada rules. European Notice The 902-928 MHz Spread Spectrum Transmission (SST) radio referred to within this manual is not available for sale in Europe (including, but not limited to, Great Britain, Italy, Germany, France, Spain, Norway, Denmark, Sweden, Finland, Portugal, and the Benelux countries). Any references in this manual to 902-928 MHz SST, or modules containing 902-928 MHz SST radios, should be disregarded by the users of this product in Europe. 578-100-008 Revision BPage 2 of 3 DECLARATION OF CONFORMITY (According to ISO/IEC Guide 22 and EN 45014) PAGE ONE OF TWO THE PRODUCT HEREWITH COMPLIES WITH THE REQUIREMENTS OF : THE LOW-VOLTAGE DIRECTIVE 72/32/EEC. THE EMC DIRECTIVE 89/336/EEC. Manufacturer’s Name:European Representative: Intermec Technologies CorporationIntermec International Incorporated 550 2nd Street SESovereign House, Vastern Road Cedar Rapids, Iowa 52401Reading, Berkshire RG1 8BT England Declares that the product listed below: Product Type:ITE/Residential, Commercial, and Light Industrial Product Name: 6400 Hand-held Computer with all docking options Model Number:6400Product Options: All Beginning Serial Number:All Date Issued: April. 8, 1996 Conforms to the following product specifications: Safety:IEC 950 / EN 60950 EMC:EN 55022 : 1995 / CISPR Publications 22 : 1993, Class B Limits and Methods EN 50082-1 : 1992 Generic Immunity Standard IEC 801-2 Tested per IEC 1000-4-2 : 1995-01 8 kV Air / 4 kV Direct, Criteria B IEC 801-3 Tested per IEC 1000-4-3 : 1995-02 3 V/M, 27-1000 MHz, 80% @ 1kHz, Criteria A IEC 801-4 Tested per IEC 1000-4-4 : 1995-01 Power leads 2 kV, Signal leads 1 kV, Criteria B ETS 300 339 : Jun. 1993 Draft RES Generic EMC for radio equipments IEC 801-2 per Draft prETS 300 339, Clause 9.2 + 8 kV Air / + 4 kV Contact IEC 801-3 per Draft prETS 300 339, Clause 9.1 3 V/M, 80-1000 MHz, 80% @ 400 Hz Type Approval Certification(s): see second page of Declaration of Conformity I, the undersigned, hereby declare that the equipment specified above conforms the above Directive(s) and Standard(s). Company Official: Arvin DanielsonPosition: Vice President Signature: Signed Copy on File Date: August 4, 1998 European Contact: Scott Mercer, Intermec International Incorporated, Sovereign House, Vastern Road, Reading, Berkshire, RG1 8BT England; Phone INT+44 118 987…

Text truncated - open the document above for the full version.

A Company Company Intermec Technologies Corporation Norand Mobile Systems Division 550 Second Street S.E. Cedar Rapids, IA 52401 December 21, 1998 Federal Communication Commission Equipment Approval Services PO Box 358315 Pittsburgh, PA 15251-5315 Dear Sirs: SUBJECT: FCC Certification Application, FCC ID: EHA2126 Please review the following new application for certification approval. Included is a Electronic Certification on form 731 for Intermec Technologies Corporation. This application is for the 2126 radio module which operates in the 2.4-2.4835 GHz band as a direct sequence spread spectrum transmitter under Section 15.247. The files are all in .pdf format for easy viewing. The report contains the important information concerning labeling, test data and set ups, as well as RF Exposure statements. Appendix files contain spectrum analyzer plots as well as spreadsheet detailing the characteristics of the transmitter. The radio is provided to Intermec Technologies Corporation by Lucent Technologies. Lucent Technologies has been contacted to provide to you copies of the Theory of Operation as well as Schmetics. Hopefully they will arrive in a timely manner, if not please contact me so I may expidite their transfer to you. In accordance with Part 0.459 of the Rules, we are requesting that the technical information provided within the application be treated as confidential and not be disclosed to third parties. Specifically this request applies to section 4.0 Theories of Operation and section 5.0 Schematics. These sections contain valuable trade secrets pertaining to the design and operation of the product. This material has been requested to be sent to you from Lucent Technologies and is intended to be physically separated from the remainder of the application. Please contact me at (319) 846-2415 should you have any question regarding this filing. Sincerely, Dave Fry, Regulatory Engineer

Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 1 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) Technologies Corporation Norand Mobile Systems Division EMC Test Laboratory MEASUREMENT/TECHNICAL REPORT Intermec Technologies Corporation 2126 2.4 GHz Spread Spectrum Transmitter REPORT NO: 981030-1 DATE: October 30 , 1998 APPENDIX B EQUIPMENT PHOTGRAPHS 1. Front of Radio Module 2. Back of Radio Module 3. Top of Radio Module 4. Front of PCB with shields 5. Front of PCB no shields 6. Back of PCB with shield 7. Bach of PCB no shield ANTENNA PHOTOGRAPHS Photo #DiscManufacturerPart NumberGainVSWR 8. Patch IntegralRadiallR380.500.0054.5 dBi2.1 9. Omni High GainMobile MarkOD9-24009 dBi2:1 10. PanelLarsen06336614 dBi1.5:1 11. YagiCushcraft06336515 dBi1.5:1 12. OmniCenturion0661471 dBi 13. OmniCushcraftS2403BP3 dBi1.5:1 14. OmniMobile MarkOD6-24006 dBi2:1 15. Omni High GainTecom5050408 dBi2:1 16. PatchTecom5050225 dBi2:1 17. PatchCushcraftS2406PL6 dBi1.5:1 18. Patch BidirectionalXertex245BD5W6 dBi1.5:1 19. PatchHuber & Suhner1324.19.00028.5 dBi1.5:1 20. PatchXertex245LD9W9 dBi1.5:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 2 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 1.Front of Radio Module Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 3 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 2. Back of Radio Module Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 4 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 3. Top of Radio Module Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 5 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 4. Front of PCB with shields Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 6 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 5. Front of PCB no shields Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 7 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 6. Back of PCB with shield Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 8 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 7. Bach of PCB no shield Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 9 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 8.Patch IntegralRadiallR380.500.0054.5 dBi2.1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 10 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 9. Omni High GainMobile MarkOD9-24009 dBi2:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 11 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 10. PanelLarsen06336614 dBi1.5:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 12 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 11. YagiCushcraft06336515 dBi1.5:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 13 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 12. OmniCenturion0661471 dBi Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 14 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 13. OmniCushcraftS2403BP3 dBi1.5:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 15 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 14. OmniMobile MarkOD6-24006 dBi2:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 16 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 15. Omni High GainTecom5050408 dBi2:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 17 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 16. PatchTecom5050225 dBi2:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 18 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 17. PatchCushcraftS2406PL6 dBi1.5:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 19 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND ANTENNAS) 18. Patch BidirectionalXertex245BD5W6 dBi1.5:1 Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 20 of 21 APPENDIX B, PHOTOGRAPHS OF EQUIPMENT (RADIO AND A…

Text truncated - open the document above for the full version.

CHANGES:NEXT ASSY (A): New NOTE : Strike-through designators are not placed components 2345678910 11 12 13 14 15 A 4 A 4 A 4 A 3A3 REV.AAAAA ADR03412JVW09/98 REV DR-NUMBER INIT.DATE THE CONTENTS OF THIS DOCUMENT IS "LUCENT INTELLECTUAL PROPERTY" AND IS LUCENT TECHNOLOGIES NEDERLAND B. V./WCND THE PROPERTY OF THE LUCENT COMPANY. IT IS TO BE TREATED AS STRICTLY UNIT: WaveLAN/IEEE PC Card type 2 CONFIDENTIAL AND IS NOT TO BE DISCLOSED, REPRODUCED OR USED NAME : BOARD ASSY EXCEPT AS AUTHORISED IN WRITING BY LUCENT IN CONNECTION WITH THE DESIGNER: Lucent Technologies WCND DATE: sept 4, 1998 MANUFACTURE, MAINTENANCE AND USE SUPSD.BY:SUPSDS: OF THE LUCENT EQUIPMENT TO WHICH IT PERTAINS. COPYRIGHT  1998 LUCENT TECHNOLOGIES SHEET: 1 OF 6 SCALE: CODE: DOCUMENT NO. 010936 ITEMPART NUMBERREQ'DDESCRIPTIONDESIGNATOR LUCENT TECHNOLOG NEDERLAND B. V. /WCND 010936 UNIT: WaveLAN/IEEE PC Card type 2 SCALE:REV. A NAME : BOARD ASSY CODE:SHEET 2 OF 6 1 0000042 RFCON_PCCARD, CONNJ4 J5 2 0000081 THESEUS3, DIC, LUCENT, THESEUS3U200 3 0000352 B3629, AIC, SIEMENS, B39351B3629Z10U13 U14 4 0000361 AT29C010, DIC, ATMEL, AT29C010U11 5 0000381 MIC2920A-3.3BS, AIC, MICREL, MIC2920A-3.3BSU205 6 0000394 IND, IND, BLM21B222, MURATA, BLM21B222L2 L3 L7 L9 7 0017482 CAP, CAP, 1uF, MURATA, GRM40X5R105K10C3 C37 8 0017491 CAP, CAP, 2.2uF, MURATA, GRM40Y5V225Z10C10 9 0019064 IND, IND, 10uH, MURATA, LQG21C100N00L200 L201 L202 L203 L204 L205 10 0022361 RES, RES, 82.5, KOA, RK73H1JT82R5FR225 11 0027372 CAP, CAP, 22nF, MURATA, GRM39X7R223K25C5 C250 12 0028512 IND, IND, 1.8nH, COILCRAFT, 0603CS-1N8XKBCL209 L210 13 0028611 IND, IND, 39nH, COILCRAFT, 0603CS-39NXJBCL15 14 0028824 IND, IND, 12nH, TOKO, LL1608-FH12NJL5 L6 L8 L14 15 0028853 IND, IND, 22nH, TOKO, LL1608-FH22NJL4 L10 L11 16 0028861 IND, IND, 27nH, TOKO, LL1608-FH27NJL18 17 0028872 IND, IND, 33nH, TOKO, LL1608-FH33NJL206 L207 18 0028891 IND, IND, 47nH, TOKO, LL1608-FH47NJL17 19 0028911 IND, IND, 68nH, TOKO, LL1608-FH68NJL208 20 0028931 IND, IND, 100nH, TOKO, LL1608-FHR10JL1 21 0032442 RES, RES, 100, KOA, RK73H1ETP1000FR234 R240 22 0032902 RES, RES, 301, KOA, RK73H1ETP3010FR29 R31 23 0033024 RES, RES, 402, KOA, RK73H1ETP4020FR212 R213 R220 R221 24 0033112 RES, RES, 499, KOA, RK73H1ETP4990FR210 R238 25 0033342 RES, RES, 866, KOA, RK73H1ETP8660FR211 R214 26 0033408 RES, RES, 1.00k, KOA, RK73H1ETP1001FR19 R22 R23 R30 R32 R37 R40 R235 27 0033461 RES, RES, 1.15k, KOA, RK73H1ETP1151FR231 28 0033574 RES, RES, 1.50k, KOA, RK73H1ETP1501FR13 R25 R239 R242 29 0033698 RES, RES, 2.00k, KOA, RK73H1ETP2001FR18 R26 R27 R28 R206 R208 R237 R245 30 0033961 RES, RES, 3.83k, KOA, RK73H1ETP3831FR249 31 0034021 RES, RES, 4.42k, KOA, RK73H1ETP4421FR1 32 0034052 RES, RES, 4.75k, KOA, RK73H1ETP4751FR228 R257 33 0034121 RES, RES, 5.62k, KOA, RK73H1ETP5621FR250 34 0034368 RES, RES, 10.0k, KOA, RK73H1ETP1002FR24 R216 R224 R227 R230 R232 R236 R241 R247 R248 R251 R254 R256 35 0034441RES, RES, 12.1k, KOA, RK73H1ETP1212FR204 36 0034532 RES, RES, 15.0k, KOA, RK73H1ETP1502FR36 R244 37 0034655 RES, RES, 20.0k, KOA, RK73H1ETP2002FR2 R3 R33 R34 R39 R200 R202 R215 R255 38 0034856 RES, RES, 32.4k, KOA, RK73H1ETP3242FR4 R5 R6 R205 R207 R218 R226 R252 39 0034931 RES, RES, 39.2k, KOA, RK73H1ETP3922FR233 40 0035011RES, RES, 47.5k, KOA, RK73H1ETP4752FR201 41 0036535 CAP, CAP, 1.0pF, MURATA, GRM36COG1R0C50C9 C12 C23 C27 C31 ITEMPART NUMBERREQ'DDESCRIPTIONDESIGNATOR LUCENT TECHNOLOG NEDERLAND B. V. /WCND 010936 UNIT: WaveLAN/IEEE PC Card type 2 SCALE:REV. A NAME : BOARD ASSY CODE:SHEET 3 OF 6 C33 C57 C271 42 0036551CAP, CAP, 1.5pF, MURATA, GRM36COG1R5C50C243 43 0036585 CAP, CAP, 2.2pF, MURATA, GRM36COG2R2C50C43 C44 C49 C64 C270 44 0036592 CAP, CAP, 2.7pF, MURATA, GRM36COG2R7C50C233 C235 45 0036623 CAP, CAP, 3.9pF, MURATA, GRM36COG3R9C50C26 C61 C263 46 0036713 CAP, CAP, 8.2pF, MURATA, GRM36COG8R2C50C17 C35 C245 47 0036733 CAP, CAP, 10pF, MURATA, GRM36COG100C50C48 C66 C269 48 00367518 CAP, CAP, 12pF, MURATA, GRM36COG120J50C16 C21 C22 C24 C28 C29 C32 C45 C50 C51 C59 C215 C216 C238 C241 C242 C246 C256 49 00368117 CAP, CAP, 22pF, MURATA, GRM36COG220J50C41 C42 C46 C47 C52 C58 C247 C248 C249 C251 C252 C259 C261 C262 C264 C265 C266 50 0036832 CAP, CAP, 27pF, MURATA, GRM36COG270J50C204 C208 51 0036892 CAP, CAP, 47pF, MURATA, GRM36COG470J50C30 C34 52 0036999 CAP, CAP, 120pF, MURATA, GRM36COG121J50C56 C207 C232 C234 C237 C253 C254 C257 C268 53 0037102CAP, CAP, 470pF, MURATA, GRM36X7R471K50C8 C6 54 00371413 CAP, CAP, 1nF, MURATA, GRM36X7R102K50C18 C20 C65 C200 C202 C205 C206 C210 C212 C217 C219 C228 C229 C260 55 0037151 CAP, CAP, 1.2nF, MURATA, GRM36X7R122K50C255 56 0037191 CAP, CAP, 2.7nF, MURATA, GRM36X7R272K50C53 57 0037211 CAP, CAP, 3.9nF, MURATA, GRM36X7R392K50C2 58 0037274 CAP, CAP, 15nF, MURATA, GRM36Y5V153Z50C38 C201 C213 C221 C222 C224 C225 59 00373125 CAP, CAP, 100nF, MURATA, GRM36Y5V104Z16C4 C19 C25 C36 C54 C55 C60 C62 C203 C209 C211 C214 C218 C220 C223 C226 C227 C230 C231 C236 C239 C240 C244 C258 C267 60 0038561 IND, IND, 2.7nH, TOKO, LL1005-FH2N7SL13 61 0038662 IND, IND, 18nH, TOKO, LL1005-FH18NKL12 L16 62 0050518 RES, RES, 0, KOA, RM73Z1ETDR8 R12 R14 R20 R21 R38 R99 R229 R246 R253 R258 R259 R260 63 0050763 RES, RES, 10, KOA, RM73B1ETP10RJR7 R9 R35 R219 64 0050832 RES, RES, 20, KOA, RM73B1ETP20RJR222 R223 65 0050931 RES, RES, 51, KOA, RM73B1ETP51RJR243 66 0051004 RES, RES, 100k, KOA, RM73B1ETP1003JR15 R17 R203 R209 R217 67 0051071 RES, RES, 200k, KOA, RM73B1ETP2003JR16 ITEMPART NUMBERREQ'DDESCRIPTIONDESIGNATOR LUCENT TECHNOLOG NEDERLAND B. V. /WCND 010936 UNIT: WaveLAN/IEEE PC Card type 2 SCALE:REV. A NAME : BOARD ASSY CODE:SHEET 4 OF 6 68 0051251 RES, RES, 1.0, KOA, RK73H2A1R0FR11 69 0051391 RES, RES, 3.9, KOA, RK73H2A3R9FR10 70 0080003 CAP, CAP, 10uF, MURATA, GRM235Y5V106Z16C7 C11 C13 71 0100011 SA2420, AIC, PHILIPS, SA2420U204 72 0100021 SA1630B, AIC, PHILIPS, SA1630BU201 73 0100032 BFP420, TRANSISTOR, SIEMENS, Q62702-F1591Q3 Q207 74 0100041 CDFDCJ22.0MHz, AIC, AT&TU8 75 0100051SI2301DS, TRANSISTOR, SILICONIX, (TEMIC)Q…

Text truncated - open the document above for the full version.

Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 1 of 44 Technologies Corporation Norand Mobile Systems Division EMC Test Laboratory MEASUREMENT/TECHNICAL REPORT Intermec Technologies Corporation 2126 2.4 GHz Spread Spectrum Transmitter REPORT NO: 981030-1 DATE: October 30 , 1998 This report concerns:Original Grant X Class II change Equipment Type: 2400- 2483.5 MHz Direct Sequence Spread Spectrum Transceiver, FCC 15.247 and Industry Canada GL-36 Issue 4, RSS-210 Issue 2 Request issue of the grant immediately upon completion of review. Measurement procedure used: ANSI C63.4-1992 and as described within this test report. Report Prepared by: Dave Fry Intermec Technologies Corporation Norand Mobile System Division EMC Test Lab 550 Second Street SE Cedar Rapids, Iowa 52401 Phone: (319) 846-2415 FAX: (319) 846-2475 Report Prepared For: Scott Holub Intermec Technologies Corporation Norand Mobile System Division 550 Second Street SE Cedar Rapids, Iowa 52401 Phone: (319) 369-3100 FAX: (319) 369-3453 This report contains data that is outside the NVLAP scope of accreditation. This report shall not be reproduced, except in full, without the permission of the EMC Lab, Intermec Technologies Corporation, Norand Mobile System Division. Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 2 of 44 TABLE OF CONTENTS SECTION NUMBER 1.0Compliance Certification 1.1 Measurement Uncertainties 2.0General Information 2.1Product Description 2.2Related Submittal(s)/Grant(s) 2.3Tested System Details 2.4Test Methodology 2.5Test Facility 3.0Product Labeling and Information to the User 3.1 Product Labeling and Placement 3.2 Information to the User 4.0Theories of Operation 5.0Schematics 6.0Conducted and Radiated Emission Test Data 7.0Equipment List APPENDIXES (may be file attachments for electronic applications of approval) A. 981030A1.pdfConducted and Radiated Measurement Photos B. 981030B1.pdf Photographs of Equipment (Radio and Antennas) C. 981030C1.pdf Transmitter conducted plots, 6 dB BW, PSD, Out of Band Emissions D. 981030D1.pdf Receiver conducted emissions plots E. 981030E1.pdf AC power line conducted emissions plots, TX and RX F. 981030F1.pdf TX, RX radiated emissions data module horz, 4.5 dBi internal patch ant. G. 981030G1.pdf TX, RX radiated emissions data module vert, 4.5 dBi internal patch ant. H. 981030H1.pdf TX, RX radiated emissions data module horz, 9 dBi dipole antenna. I. 981030I1.pdf TX, RX radiated emissions data module horz, 14 dBi panel antenna. J. 981030J1.pdf TX, RX radiated emissions data module horz, 15 dBi yagi antenna. K. 981030K1.pdf Lucent Technologies Corporation, Guidance document to FCC test reports L. 981030L1.pdf Lucent Technologies Corporation, Process Gain M. 981030M1.pdf6710 Users Manual and DoC insert N. 981030N1.pdf6400 Users Manual and DoC insert Norand Mobile System Division, EMC Test LabFCC ID: EHA2126 DOC. NO.: 577-500-829REPORT NO: 981030-1 2126 Radio Module FCC 15.247, Canada GL-36/RSS-210Page 3 of 44 1.0COMPLIANCE CERTIFICATION The electromagnetic compatibility test and data evaluations findings of this report have been prepared by the Norand EMC Test Lab of Norand Corporation in accordance with applicable specifications instructions required per- FCC SECTIONCANADA RSS-210/GL-36 TEST NAME 15.33, 15.354.0/ __Range of Meas., Meas. Detectors 15.15, 15.315.3, 5.8, 9.0, 11.0/ __General Requirements, Meas. Stds, 15.203, 15.2045.5/1.1Antenna Description(s) 2.925, 15.195.9, 8.9/__Labeling 15.215.10/4.0Information to the User 15.247 (a, b, c, d, e), 15.209__/B1.2(a,b,c,d)Transmitter Characteristics 15.2156.4/ __Freq. & Power Stability, Volts & Temp. 15.1097.3/3.3Receiver Radiated Emissions 15.207, 15.1076.6, 7.4/3.2AC Line Conducted Emissions, TX, RX 1.1307 (b)(1)_ / _RF Safety, Exposure Limits The data, data evaluation and equipment configuration represented herein are a true and accurate repres…
