EHA700C-SMC45-1Notepad Computer with 3 Radio Lans

User’s Manual 700 Series Color Mobile Computer 700 Series Color Mobile Computer User’s Manual ii SNOTICEThe information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec. DisclaimerofWarranties.Thesamplesourcecodeincludedinthisdocumentispresentedfor reference only. The code does not necessarily represent complete, tested programs. The code is provided“ASISWITHALLFAULTS.”ALLWARRANTIESAREEXPRESSLY DISCLAIMED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. We welcome your comments concerning this publication. Although every effort has been made to keep it free of errors, some may occur. When reporting a specific problem, please describe it briefly and include the book title and part number, as well as the paragraph or figure number and thepagenumber. Send your comments to: Intermec Technologies Corporation Publications Department 550 Second Street SE Cedar Rapids, IA 52401 ANTARES, INTERMEC, NORAND, NOR*WARE, PEN*KEY, ROUTEPOWER, TRAKKER, and TRAKKER ANTARES are registered trademarks and ArciTech, ENTERPRISE WIRELESS LAN, i-gistics, INCA, Mobile Framework, MobileLAN, TE 2000, UAP, and UNIVERSAL ACCESS POINT are trademarks of Intermec Technologies Corporation. 2002 Intermec Technologies Corporation. All rights reserved. Acknowledgments ActiveSync,ActiveX,Microsoft,MS,MS-DOS,Outlook,Pocket Outlook,Pocket PC,Windows, Windows NT,andtheWindows logoare registered trademarks andMSDN,SQL Server,Visual Basic,Visual C++,andWindows for Penare trademarks of Microsoft Corporation in the United States and/or other countries. Microsoft products are licensed to OEMs by Microsoft Licensing, Inc., a wholly owned subsidiary of Microsoft Corporation. Bluetoothis a trademark of Bluetooth SIG, Inc., U.S.A. CDMA2000is a trademark of the Telecommunications Industry Association (TIA). GSMis a registered trademark of the GSM Association. Microclean IIis a registered trademark of Foresight International. MultiMediaCardis a trademark of Infineon Technologies AG, Germany, and is licensed to MMCA (MultiMediaCard Association). SanDiskis a trademark of SanDisk Corporation. Siemensis a registered trademark of Siemens AG. Siemens product names are either trademarks or registered trademarks of Siemens or Siemens AG. Sprintis a registered trademark of Sprint Communications Company L.P. This product includes software developedby the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/) This product includes cryptographic software written by Eric Young ([email protected]) Contents iii700 Series Color Mobile Computer User’s Manual Contents Before You Beginxv.................................................................... Warranty Informationxv................................................... Safety Summaryxv........................................................ Warnings, Cautions, and Notesxvi........................................... About This Manualxvi.................................................... Format Conventions for Input From a Keyboard or Keypadxvii...................... Related Publicationsxviii................................................... Global Services and Supportxviii............................................. Web Supportxviii........................................................ Introduction About the 700 Series Color Mobile Computer2............................................... Audio System2........................................................... Speaker2................................................... Internal Microphone2........................................ External Headset Jack2........................................ Battery2................................................................ Low Battery Shutdown3....................................... System Status Maintained4.................................... CAB Files Within 700C Software Tools CD4................................... Modem Support4......................................................... Network Support4........................................................ Removeable Card Support5................................................. CompactFlash Cards5........................................ SecureDigital Cards5......................................... MultiMediaCards5........................................... Software Build Version5.................................................... What’ s New6......................................................................... 1 Contents iv700 Series Color Mobile Computer User’s Manual Pocket PC 2002 Introduction8......................................................................... Premium versus Professional Editions8...................................................... Where to Find Information10............................................................ Basic Skills11......................................................................... Buttons and Stylus11...................................................... Today Screen11.......................................................... Programs13............................................................. Navigation Bar and Command Bar14......................................... Pop-up Menus15......................................................... Notifications15.......................................................... Enter Information on Your 700 Series Computer16............................... Typing With the Soft Keyboard17............................... Using Block Recognizer17..................................... Using Letter Recognizer18..................................... Using Transcriber18.......................................... Selecting Typed Text18........................................ Writing on the Screen19.............…

Text truncated - open the document above for the full version.

FCC Report Hierarchy For FCC ID EHA700C-SMC45-1 FCC ID EHA700C-SMC45 (Intermec) FCC ID HN22011B (Intermec) FCC ID HN2ABTM3-2 (Intermec) FCC ID PD9WCF2011BE (Intel) FCC ID EHAABTM3 (Intermec) FCC ID QIPMC45 (Siemens AG) FCC ID EHA700C-SMC45-1 (Intermec)

Exhibit 3 – External photographs Intermec 700C FCC ID: EHA700C-SMC45 Please see TÜV Product Service Report No. RO610071 for external photographs.

760 WITH: 1900MHZ GPRS, FCC (704) 802.11b RADIO, AND BLUETOOTH RADIO CONFIGURATION 760XXXG4XXXX4704 IC: ICES-003 Class B Tested To Comply With FCC Standards FOR HOME OR OFFICE USE Model: 700C MFD: XXXXXXXXX 2002 SN: xxxxxxxxxxx XXXXXXXX4323232XXX CN: 760XXXG4XXXX4704 12V 1,5A Made in Singapore I.T .E. 729T N309 FCC ID: EHA700C-SMC45-1 IC: ICES-003 Class B Tested To Comply With FCC Standards FOR HOME OR OFFICE USE Model: 700C MFD: XXXXXXXXX 2002 SN: xxxxxxxxxxx XXXXXXXX4323232XXX CN: 760XXXG4XXXX4704 12V 1,5A Made in Singapore I.T .E. 729T N309 FCC ID: EHA700C-SMC45-1 ARTMASTER REV D SCALE 1/1: ARTMASTER REV D SCALE 2/1:

SUPPLEMENTARY TEST REPORT In support of the Application for Grant of Equipment Authorisation of the Intermec Handheld Computer Terminal, 700C-SMC45 FCC ID: EHA700C-SMC45 - 1July 2003 TUV Product Service Ltd. Segensworth Road, Titchfield Fareham, Hampshire, United Kingdom, PO15 5RH Tel: +44(0)1329 443300, Fax: +44(0)1329 443331 www.tuvps.co.uk Report Number WS610071 – 02s1Page 1 of 19 REPORT ON:Specific Absorption Rate testing of the Intermec 700C-SMC45 Dual Mode (DCS1900 (GPRS) / 802.11b RLAN) Handheld Computer Terminal. Report No: WS610071 – 02s1 FCC ID:EHA700C-SMC45 - 1 PREPARED FOR:Intermec Mobile Systems Division 550 Second Street S.E Cedar Rapids IA 52401 ATTESTATION:The wireless portable devices described within this report have been shown to be capable of compliance for localised specific absorption rate (SAR) for General Population/Uncontrolled Exposure Limits as defined in Both, RSS-102 Issue 1 (Provisional) September 25, 1999: and FCC standard Supplement C (Edition 01-01) to OET Bulletin 65 (Edition 97-01) of 1.6 W/kg The devices were tested in accordance with the measurement procedures specified in Supplement C (Edition 01-01) to OET Bulletin 65 (Edition 97-01) and IEEE1528-200x (Draft December 2002). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements. A. Miller Senior SAR Test Engineer APPROVED BY: M Jenkins Wireless Group Leader DATED:17 th July 2003 DISTRIBUTION:Intermec Technologies CorporationCopy No: 1 Intermec Technologies Corporation (CD ROM).Copy No(s): 2 BABT Copy No.: 3 Copy No.: 1 Note: The test results reported herein relate only to the item tested as identified above and on the Status Page. FCC ID: EHA700C-SMC45 - 1 Report Number WS610071 – 02s1Page 2 of 19 CONTENTS EXECUTIVE SUMMARY3 1.1Status4 1.2Summary5 1.3Test Result Summary6 TEST DETAILS7 2.1Test Equipment8 2.2Test Software8 2.3Dielectric Properties of Simulant Liquids9 2.4Test Conditions10 2.5Measurement Uncertainty10 2.6SAR Measuring System10 Probe and Amplifier Specification Probe Calibration SAR Measurement Procedure 2.7Draft IEEE std 1528 Test Positions10 OET65(c) Flat Phantom Test Position – Graphical Representation 2.8SAR Distributions (Area Scans – 2D)11 2.9Test Positional Photographs13 2.10Record Photographs14 For copyright details see page 19 of 19 FCC ID: EHA700C-SMC45 - 1 Report Number WS610071 – 02s1Page 3 of 19 EXECUTIVE SUMMARY Specific Absorption Rate testing of the Intermec 700C-SMC45 Dual Mode (DCS1900 (GPRS) / 802.11b RLAN) Handheld Computer Terminal. PROJECT MANAGER: M. J. HARDY FCC ID: EHA700C-SMC45 - 1 Report Number WS610071 – 02s1Page 4 of 19 1.1STATUS MANUFACTURING DESCRIPTIONHandheld Computer Terminal STATUS OF TESTSpecific Absorption Rate Testing APPLICANTIntermec Technologies Corporation MANUFACTURERIntermec Technologies Corporation TYPE OR MODEL NUMBER700C Production Device HARDWARE VERSION245-227-207 (Drawing Number) MULTISLOT CLASSClass 10 GSM/GPRS 1900MHz BANDClass 1 (PCS1900) IMEI NUMBER350450410043999 RADIO LAN2.4GHz Direct Spread Spectrum SOFTWARE VERSIONF310-03 BLUETOOTH MODULEAlps/Socket BC01, part No. 805-608-002 SOFTWARE VERSIONHCI V11.3 BATTERY MANUFACTURERMicropower Electronics TYPE OR MODEL NUMBER318-013-002 TEST SPECIFICATIONS: Federal Communications Commission, Code of Federal Regulations, Title 47 (CFR47), Vol. 1, Chapter 1, Part 2 (§2.1091 and §2.1093). Federal Communications Commission (FCC) OET Bulletin 65c, Edition 01-01, Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields – Additional Information for Evaluating Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emissions RSS-102 Issue 1 (Provisional) September 25, 1999: Evaluation Procedure for Mobile and Portable Radio Transmitters with respect to Health Canada’s Safety Code 6 for Exposure of Humans to radio Frequency Fields REFERENCES: IEEE 1528 –200X: DRAFT Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques BABT REGISTRATION NUMBER:WS610071 - 02. RECEIPT OF TEST SAMPLES:4 th March 2003. START OF TEST:24 th June 2003. FINISH OF TEST:24 th June 2003. FCC ID: EHA700C-SMC45 - 1 Report Number WS610071 – 02s1Page 5 of 19 1.2SUMMARY This report must be read in conjunction with BABT report number WS610071 – 02, issued 28 th April 2003 This supplementary report covers additional test requirements for co-located SAR measurements caused by simultaneous transmission by two or more transmitters. For test configuration; See System & Device Settings below. The 700C-SMC45 is a Handheld Computer Terminal, which offers DCS1900/GPRS and 2.4GHz Wireless LAN (11Mbps DSSS) connectivity The data terminal utilises the Siemens GSM/GPRS module (Hardware Version S30880-S8300- A100-1) to offer GSM voice communication and GPRS functions. Testing for GSM and GPRS was carried out using antenna supplied by the client, Single band ‘White spot’ 805-606-104. Also installed is the approved Intel WCF2011BEWW Compact Flash Wireless LAN radio card and the approved Bluetooth module Alps/Socket BC01, part number 805-608-002. These radios do transmit simultaneously, for co-located Specific Absorption Rate (SAR), consideration was given to the GSM/GPRS module co-located with the Compact Flash Wireless LAN radio card. See below. SYSTEM & DEVICE SETTINGS i. The DCP settings for IXP-039 Amplifier were set to 20;20;20 (CW calibration settings) ii. The device was placed in a Multi-slot Class 10 application, GPRS transmit on two timeslots (Dominant Transmitter ON) and with Compact Flash Wireless LAN radio card (Co-locatedTransmitter OFF) and a SAR evaluation was performed.. iii. Then the device was placed in a Multi-slot Class 10 application, GP…

Text truncated - open the document above for the full version.

TEST REPORT In support of the Application for Grant of Equipment Authorisation of the Intermec Technologies Corporation Series 700C-SMC45 Handheld Computer Terminal FCC ID: EHA700C-SMC45November 2002 BABT. Segensworth Road, Titchfield Fareham, Hampshire, United Kingdom, PO15 5RH Tel: +44(0)1329 443300, Fax: +44(0)1329 443331 www.tuvps.co.uk REPORT NUMBER RO610071PAGE 1 OF 30 Equipment:700C-SMC45 FCC ID:EHA700C-SMC45 Specification:47 CFR 2 & 47 CFR 24 Applicant:Intermec Technologies Corporation Norand Mobile Systems Division 550 Second Street S.E. Cedar Rapids IOWA 52401 USA Manufacturer:As above Manufacturer’s Representative:Mr Scott Holub Approved by: M JENKINS Wireless Group Leader Dated:18 th November 2002 Start of Test:11 th October 2002 Completion of Test:22 nd October 2002 Report Distribution:Intermec Technologies CorporationMr S HolubCopy No. 1 BABTCopy No’s. 2 & 3 Copy No: 2 ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the applicable limits. I assume full responsibility for the accuracy and completeness of these measurements. On the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 2, and Part 24 of the FCC Rules under normal use and maintenance. Simon Bennett Test Manager FCC ID: EHA700C-SMC45 REPORT NUMBER RO610071PAGE 2 OF 30 CONTENTS:- Page No. Introduction3 Location of Testing3 Test Equipment and Ancillaries Used For Test3 Description of Equipment Under Test Configuration5 List of Performed Measurements5 The list of measured parameters covering SubclauseParameter to be measured 47 CFR2.1053Radiated Emissions6 47 CFR2.1046, 24.232Power Output10 Photographs of test sample(s)11 For copyright details see Page 30 of 30 FCC ID: EHA700C-SMC45 REPORT NUMBER RO610071PAGE 3 OF 30 Introduction The information contained within this report is intended to show verification of compliance of the Intermec Technologies Corporation 700C-SMC45 to the requirements of 47 CFR 2 and 47 CFR 24. Limited testing has been performed as the 700C-SMC45 contains a Transmitter Module which has previously gained approval to FCC Part 24. The FCC Identifier of this module was QIPMC45, the date of the FCC Grant was 13 th September 2002. Location Of Testing All testing was conducted at the premises of BABT, Segensworth Road, Fareham, Hampshire, PO15 5RH, by BABT Personnel, Simon Bennett , Phil Harrison and Steve Hartley . Radiated Emissions measurements were performed in a 3 metre Anechoic Chamber (OATS). A complete site description is on file with the FCC Laboratory Division, Registration Number: 90987. See Annex A. Test Equipment and Ancillaries Used For Test NoInstrument/AncillaryTypeManufacturerEMC No.Cal Due 1 Screened Enclosure----Siemens/Matsushita2533-- 2 BilogAntennaCBL6143Chase286011Apr 04 3 Turntable & ControllerHD050Emco2528-- 4 Antenna Mast2070Emco---- 5 Antenna Controller2090Emco---- 6 EMI Receiver8542EHewlett Packard228611 Dec 02 7 Low Noise Amplifier (8- 18GHz) AMF-4E-080180- 15-10P Miteq2430-- 8 Spectrum Analyser8562AHewlett Packard14277 Jan 03 9 Horn3115EMCO229729 Jun 03 10 Signal Generator8672AHewlett Packard41122 Dec 02 11 3GHz High Pass FilterF-100-3000-5-RRLC ElectronicsINV4467-- 12 Signal Generator2031Marconi198020 Aug 03 13Spectrum AnalyserFSEMRohde & SchwarzINV403428 Dec 02 14Digital Radio Test Set6103ERacalINV45062 Aug 03 15AttenuatorHFP-50NTrilithic160030 May 03 16Combiner1506AWeinschel Eng.INV449415 Jan 03 17Cable1 metre N-TypeReynoldsCS0561T/U 18ThermohygrographA1RotronicINV32272 Oct 03 19Cable1 metre SMA Type ReynoldsCS0569T/U 20AttenuatorHFP-50NTrilithic160230 May 03 Table 1 FCC ID: EHA700C-SMC45 REPORT NUMBER RO610071PAGE 4 OF 30 Test Equipment and Ancillaries Used For Test (continued) Note(s) 1)All items are calibrated annually except where labelled T/U (Tracebility Unscheduled). These items are calibrated within the test configurations using calibrated equipment. 2) Throughout the test report the test equipment used for each test is referenced using the number indicated in the table above. INSTRUMENTATION USED FOR EXERCISING THE EUT InstrumentManufacturerType NoINV No GSM Test SetHewlett Packard8922M3803 DCS Test SetHewlett Packard83220E3804 Table 2 FCC ID: EHA700C-SMC45 REPORT NUMBER RO610071PAGE 5 OF 30 Description of Equipment Under Test The 700C-SMC45 is a handheld computer terminal with a tri band GSM/GPRS radio module used for inventory control purposes. The equipment under test is made up of the following component parts. Module Vendor Kit Number Serial Number Handheld Computer TerminalIntermec Technologies Corporation700C-SMC45350450410044088 Table 3 List of Performed Measurements using the configuration in Table 3 i)Power Output Module Vendor Kit Number Serial Number Handheld Computer TerminalIntermec Technologies Corporation700C-SMC4519927020017 Table 4 List of Performed Measurements using the configuration in Table 4 i)Radiated Emissions FCC ID: EHA700C-SMC45 REPORT NUMBER RO610071PAGE 6 OF 30 Test CaseRadiated Emissions Test Date10 tth October 2002 Rule Parts24.238 System Configuration During EMC Testing The Intermec 700C with GSM/GPRS Radio Module was powered by its own internal battery. A communication link was established between the EUT and a Digital Radiocommunications Test Set. Test Procedure Testing to the requirements of FCC Part 24, Section 24.238, Emission Limits, was carried out on the Measurement Test Facility detailed in Annex A. In order to determine the Radiated Emission Limits, measurements of transmitter power (P) were first carried out on top, middle and bottom channels using a peak detector and the results are shown in Table 5 below. A preliminary profile of the Radiated Electric Field Emissions was obtained by operating the Equipment Under Test (EUT) on a remotely controlled turntable within a semi-anechoic chamber; measurements were…

Text truncated - open the document above for the full version.

Note: The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory Applicant:Siemens AG CETECOM - Certification and Testing in Communications GmbH Im Teelbruch 122 D-45219 Essen Germany Telephone: + 49 (0) 20 54 / 95 19 0 Fax: + 49 (0) 2054 / 95 19 20 T E S T R E P O R T No.: 2-20542043b/02 for GPRS/GSM 900/1800/1900 Module MC 45 + DSB 45 + Votronic Handset FCC ID: QIPMC45 TTI-P-G081/94 FCC Registration No. 99538 Test Report 2-20542043b/02, Page 2 of 65 20542043b_02.doc Table of contents 1. SUMMARY OF TEST RESULTS3 2. ADMINISTRATIVE DATA4 2.1. I DENTIFICATION OF THE TESTING LABORATORY 4 2.2. T EST LOCATION 4 2.3. O RGANIZATIONAL ITEMS 4 2.4. A PPLICANT ́ S DETAILS 4 2.5. M ANUFACTURER ́ S DETAILS 4 3. EQUIPMENT UNDER TEST (EUT)5 3.1. EUT: T YPE , S/N ETC . AND SHORT DESCRIPTIONS USED IN THIS TEST REPORT 5 3.2. A UXILIARY E QUIPMENT (AE): T YPE , S/N ETC . AND SHORT DESCRIPTIONS 5 3.3. EUT SET - UPS 6 3.4. EUT OPERATING MODES 6 4. TEST SET-UPS7 4.1. T EST S ET - UP 1 FOR C ONDUCTED MEASUREMENTS 7 4.2. T EST S ET - UP 2 FOR R ADIATED MEASUREMENTS 8 4.3. P ARAMETER SETTINGS ON MOBILE PHONE AND CMU9 5. MEASUREMENTS10 5.1. C ALIBRATION OF ANECHOIC CHAMBER 10 5.2. RF POWER OUTPUT § 2.1046 CONDUCTED 11 5.3. RF POWER OUTPUT § 2.1046 RADIATED 12 5.4. O CCUPIED BANDWIDTH § 2.104913 5.5. S PURIOUS EMISSIONS AT ANTENNA TERMINALS § 2.105117 5.6. F IELD STRENGTH OF SPURIOUS RADIATION § 2.105326 5.7. F REQUENCY STABILITY / TEMPERATURE VARIATION § 2.105550 6. INSTRUMENTS AND ANCILLARY EQUIPMENT „CTC“53 6.1. S INGLE INSTRUMENTS 53 6.2. T EST SYSTEMS 55 7. PHOTOGRAPHS56 7.1. E XTERNAL PHOTOS OF EUT56 7.2. I NTERNAL PHOTOS OF EUT57 7.3. P HOTOS OF TEST SET - UP 59 Test Report 2-20542043b/02, Page 4 of 65 20542043b_02.doc 2. Administrative Data 2.1. Identification of the testing laboratory Company name:CETECOM Certification and Testing in Communications GmbH Address:Im Teelbruch 122 D-45219 Essen - Kettwig Germany Laboratory accreditation:DAR-Registration No.: TTI-P-G081/94 FCC- Registration No.: 99538 Responsible for testing laboratory:Dipl.-Ing. W. Richter Deputies:Dieter Franke Dipl.-Ing. Karin Silberhorn Dipl.-Ing. Heiko Strehlow 2.2. Test location 2.2.1. Test laboratory “CTC” Company name:see chapter 2.1. Identification of the testing laboratory 2.3. Organizational items Reference No.:20542043 Order No.:-- Responsible for test report and project leader:Dipl.-Ing. V. Krueger Receipt of EUT:2002-07-17 Date(s) of test:2002-07-17 – 2002-08-01 Date of report:2002-08-19 Number of report pages:65 Number of diagram pages (annex):no diagrams --------------------------------------------------------------------------------------------------------------------------------------- Version of template: 4.05 2.4. Applicant ́s details Applicant ́s name:Siemens AG Address:Siemensdamm 50 13629 Berlin Germany Contact person:Mr. Hussein Halawi; Tel. +49 30 38630211 2.5. Manufacturer ́s details Manufacturer ́s name:please see Applicant ́s details Address:please see Applicant ́s details Test Report 2-20542043b/02, Page 5 of 65 20542043b_02.doc 3. Equipment under test (EUT) 3.1. EUT: Type, S/N etc. and short descriptions used in this test report short descrip- tion*) EUTType S/N serial number HW hardware status SW software status EUT A GPRS / GSM ModuleMC 4500499941137807 7 B 2.5SW: 34 EUT B Development support box DSB 45# 200B 1.1V 1.0 EUT C Handset VotronicHH-SI-30.3Sample 2V 1.1-- EUT D EUT E EUT F *) EUT short description is used to simplify the identification of the EUT in this test report. Additional Information for EUT A Frequency range:1850.2 – 1909.8 MHz Number of channels:300 Nominal power supply voltage:4,5 V (of module) Power supply range:3,3 – 4,5 V Temperature range:-30°C - +60°C Emission designator:300KGXW Antenna:… integral antenna: antenna connector: external antenna Max. stated nominal output power: conducted 30,0 ±2 dBm, radiated 30,0 ±2 dBm EIRP Max. measured output power:conducted 29,7 dBm, radiated 30,6 dBm EIRP 3.2. Auxiliary Equipment (AE): Type, S/N etc. and short descriptions AE short descrip- tion*) Auxiliary EquipmentType S/N serial number HW Hardware status SW software status AE 1 RS 232 cable 1for Com1 - Port--Length=1.81 meter-- AE 2 RS 232 cable 2for Com2 - Port--Length=1.81 meter-- AE 3 AC/DC AdapterMW 1000 GSSample 2Input: 230 V AC, 50 Hz, 28 W Output: 3-6V 9-12 V DC, 1000 mA, 12 VA -- AE 4 GSM Antenna900/ 1800 MHz# 10 dB Gain length=1 meter -- *) AE short description is used to simplify the identification of the auxiliary equipment in this test report. Test Report 2-20542043b/02, Page 6 of 65 20542043b_02.doc 3.3. EUT set-ups EUT set-up no.*) Combination of EUT and AERemarks set. 1EUT A + EUT B + EUT C + AE 1 + AE 2 + AE 3 Set-up for conducted measurements: MC 45 situated outside the DSB45 support-box com-1 cable and com-2 cable connected to DSB-Box but not terminated on the other side (open) set. 2EUT A + EUT B + EUT C + AE 1 + AE 2 + AE 3 + AE 4 Set-up for radiated measurements: MC 45 situated outside the DSB45 support-box com-1 cable and com-2 cable connected to DSB-Box but not terminated on the other side (open) set. 3---- *) EUT set-up no. is used to simplify the identification of the EUT set-up in this test report. 3.4. EUT operating modes EUT operating mode no.*) Description of operating modes Additional information op. 1 IDLE The mobile station is synchronized at the Broadcast Control Channel (BCCH) and listening to the Common Control Channel (CCCH), for details please see chapter: 4.3. Parameter settings on mobile phone and CMU. op. 2 TCH A communication link is established between the mobile station and the test simulator. The transmitter is operated at its maximum rated output power, for details please see chapter: 4.3. Parameter settings on mobile phone and CMU. *) EUT operating mode no. is used to simplify the test report. Test Report 2-20542043b/02, Page 7 of 65 20…

Text truncated - open the document above for the full version.
